Dukane 8782 User Manual

Model 8782

#080009

Projector

8755G-RJ/8782

User's Manual (detailed) Operating Guide

Thank you for purchasing this projector.

WARNING Before using this product, please read the “Safety Guide”

first. After reading, store in

About this manual

Various symbols are used in this manual. The meanings of these symbols are described below.

WARNING This symbol indicates information that, if ignored, could possibly

CAUTION This symbol indicates information that, if ignored, could possibly

result in personal injury or even death due to incorrect handling.

in personal injury or physical damage due to incorrect

result handling.

Please refer to the pages written following this symbol.

a safe place for future reference.

NOTE • The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in this manual.

• The reproduction, transfer or copy of all or any part of this document is not permitted without express written consent

Trademark acknowledgment

• Mac is registered trademarks of

• VES

A and SVGA are trademarks of the Video Electronics Standard Association.

• Windows is a registered trademark of Microsoft Corporation

All other trademarks are the properties of their respective owners

Apple Computer, Inc.

Contents

About this manual. . . . . . . . . . 1

Contents . . . . . . . . . . . . . . . . . 2

Projector features. . . . . . . . . . 3

Preparations . . . . . . . . . . . . . . 3

Contents of package . . . . . . . . . . . . .3

Fastening the lens cover . . . . . . . . . .3

Part names . . . . . . . . . . . . . . . 4

Projector . . . . . . . . . . . . . . . . . . . . . .4

Control panel . . . . . . . . . . . . . . . . . . .5

Rear panel . . . . . . . . . . . . . . . . . . . . .5

Remote control . . . . . . . . . . . . . . . . .6

Setting up . . . . . . . . . . . . . . . . 7

Arrangement . . . . . . . . . . . . . . . . . . .7

Connecting your devices . . . . . . . . .10

Connecting power supply . . . . . . . .12

Using the security bar and slot . . . .12

Remote control . . . . . . . . . . . 13

Putting batteries . . . . . . . . . . . . . . .13

About the remote control signal . . . .13

Changing the frequency of remote

control signal

. . . . . . . . . . . . . . . . .14

Using as a

simple PC mouse & keyboard . . .14

Power on/off . . . . . . . . . . . . . 15

Turning on the power . . . . . . . . . . . .15

Turning off the power . . . . . . . . . . . .15

Operating . . . . . . . . . . . . . . . 16

Adjusting the volume . . . . . . . . . . . .16

Temporarily muting the sound . . . . .16

Selecting an input signal . . . . . . . . .16

Searching an input signal . . . . . . . .17

Selecting an aspect ratio . . . . . . . . .17

Adjusting the projector's elevator . .18

Adjusting the zoom and focus . . . . .18

Using the automatic adjustment feature

. .19

Adjusting the position . . . . . . . . . . .19

Correcting the keystone distortions

. .20

Using the magnify feature . . . . . . . .20

Freezing the screen . . . . . . . . . . . . .21

Temporarily blanking the screen . . .21

Using the menu function . . . . . . . . .22

EASY MENU. . . . . . . . . . . . . . 24

ASPECT, AUTO KEYSTONE EXECUTE, KEYSTONE , PICTURE MODE, BRIGHTNESS, CONTRAST, COLOR, TINT, SHARPNESS, WHISPER, MIRROR, RESET, FILTER TIME, LANGUAGE, G

o to Advanced Menu...

PICTURE menu . . . . . . . . . . . 26

BRIGHTNESS, CONTRAST, GAMMA, COLOR TEMP, COLOR, TINT, SHARPNESS, MY MEMORY

IMAGE menu . . . . . . . . . . . . . 29

ASPECT, OVER SCAN, V POSITION, H POSITION, H PHASE, H SIZE, AUTO ADJUST EXECUTE

INPUT menu . . . . . . . . . . . . . 31

PROGRESSIVE, VIDEO NR, COLOR SPACE, COMPONENT, VIDEO FORMAT, FRAME LOCK, COMPUTER IN, RESOLUTION

SETUP menu . . . . . . . . . . . . . 34

AUTO KEYSTONE EXECUTE, KEYSTONE , WHISPER, MIRROR, VOLUME, SPEAKER

, AUDIO

SCREEN menu. . . . . . . . . . . . 36

LANGUAGE, MENU POSITION, BLANK, START UP, M

yScreen

, M

yScreen Lock

MESSAGE, SOURCE NAME

OPTION menu . . . . . . . . . . . . 40

AUTO SEARCH, AUTO KEYSTONE , AUTO ON, AUTO OFF, LAMP TIME, FILTER TIME, MY BUTTON, SERVICE, SECURITY

NETWORK menu . . . . . . . . . . 51

DHCP, IP ADDRESS, SUBNET MASK, DEFAULT GATEWAY, TIME DEFFERENCE, DATE AND TIME, e-SHOT, INFORMATION, SERVICE

Maintenance . . . . . . . . . . . . . 54

Lamp . . . . . . . . . . . . . . . . . . . . . . . .54

Air ﬁlter . . . . . . . . . . . . . . . . . . . . . .56

Internal clock battery . . . . . . . . . . . .57

Other care . . . . . . . . . . . . . . . . . . . .58

Troubleshooting . . . . . . . . . . 59

Related messages . . . . . . . . . . . . . .59

Regarding the indicator lamps . . . . .60

Shutting the projector down . . . . . . .61

Resetting all settings . . . . . . . . . . . .61

Phenomena that may be easy

to be mistaken for machine defects

Speciﬁc

ations . . . . . . . . . . . . 64

. .62

Network Guide . . . . . . . . . 1-35

Technical Guide . . . . . . .

Safety Guide . . . . . . . . . .

. 1-17

. 1-9

Projector features / Preparations

Projector features

This projector has a capability to project various picture signals onto a screen. This projector requires only a minimal amount of space for installation and can produce a large projected image from even a short distance. This projector boasts a variety of I/O port and low noise. These features provide you with the broad use of this projector.

Preparations

Contents of package

Please see the “Contents of package” section in the User’s Manual (concise) which is a book. Your projector should come with the items shown there. Contact immediately your dealer if anything is missing.

NOTE • Keep the original packing materials, for future reshipment. Be sure to use the original packing materials when moving the projector. Use special caution for the lens.

Fastening the lens cover

To avoid losing the lens cover, please fasten the lens cover to the projector using the enclosed strap.

Fix the strap to the strap hole of the lens cover.

Thread one end of the strap through the strap hole of the lens cover and make the loop at the end, and let the other end of the strap through the loop. Not have a knot in the strap at either end.

Fix the strap to the strap hole of the projector.

Thread the other end of the strap through the strap hole of the projector and make

the loop there. Let the lens cover with the one end of strap though the loop.

Part names

Projector

(1) Lamp cover (54)

The lamp unit is inside. (2) Focus ring (18) (3) Zoom ring (18) (4) Control panel (5) (5) Elevator buttons (x 2) (18) (6) Elevator feet (x 2) (18) (7) Remote sensor (13) (8) Lens (18, 58) (9) Lens cover (3) (10) Intake vents (11) Filter cover (

The air lter and intake vent are

inside. (12) Speaker (35) (13) Exhaust vent (14) AC inlet (12) (15) Power switch (15) (16) Rear panel (5) (17) Security bar (12) (18) Security slot (12) (19)

Slot cover (57) The internal clock battery is inside.



56)

(6)

(9)

HOT!

(19)

(18)

HOT!

(8)

(13)

(16)

(1) (2) (3) (4)

(7)

(6)

(4)

(17)

(13)

(6)

(1)

(5)

(12)

(11)

(10)

(6)

(10)

(11)

(14)

(15)

WARNING ►HOT! : Do not touch around the lamp cover and the exhaust

vents during use or just after use, since it is too hot. ►Do not look into the lens or vents while the lamp is on, since the strong light is not good for your eyes. ►Do not handle the elevator buttons without holding the projector, since the projector may drop down.

CAUTION ►

Maintain normal ventilation to prevent the projector from heating up. Do not cover, block or plug up the vents. Do not place anything that can stick or be sucked to the vents, around the intake vents. Clean the air lter periodically. ►Do not use the security bar and slot to prevent the projector from falling down, since it is not designed for it.

Part names

BATTERY

Control panel

(1) STANDBY/ON button (15) (2) INPUT button (16, 22) (3) MENU button (

It consists of four cursor buttons. (4) POWER indicator (15, 60) (5) TEMP indicator (60) (6) LAMP indicator (60)



22)

Rear panel

(1) AUDIO IN1 port (10) (2) AUDIO IN2 port (10) (3) AUDIO OUT port (10) (4) COMPUTER IN1 port (10) (5) COMPUTER IN2 port (10) (6) MONITOR OUT port (10) (7) Shutdown switch (61) (8) CONTROL port (10)

(9) USB port (10) (10) COMPONENT

(Y, Cb/Pb, Cr/Pr) port (10) (11) VIDEO port (10) (12) S-VIDEO port (10) (13) AUDIO IN3 (L,R) ports (10) (14) LAN port (10)

(1)

(3) (4) (7)

(14)

(6) (5) (4)

(1) (2)(3)

(6)(5)

(2)

(10)

(9)(8) (11)

(12)(13)

CAUTION ►Use the shutdown switch only when the projector is not turned off by normal procedure, since pushing this switch stops operation of the projector without cooling it down.

Part names

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

Remote control

(1) VIDEO button (17) (2) COMPUTER button (16) (3) SEARCH button (17) (4) STANDBY/ON button (15) (5) ASPECT button (17) (6) AUTO button (19) (7) BLANK button (21) (8) MAGNIFY - ON button (20) (9) MAGNIFY - OFF button (14, 20) (10) HOME button (14) (11) END button (14) (12) PAGE UP button (14) (13) PAGE DOWN button (14) (14) VOLUME button (16) (15) MUTE button (14, 16) (16) FREEZE button (21) (17) MY BUTTON - 1 button (42) (18) MY BUTTON - 2 button (42) (19) KEYSTONE button (20) (20) POSITION button (19, 22) (21) MENU button (22) (22) ▲/▼/◄/► cursor buttons (14, 22, 23) (23) ENTER button (14, 22, 23) (24) ESC button (14, 22) (25) RESET button (14, 22, 23) (26) Battery cover (13)

(2) (1) (5)

(10)

(8)

(9) (11) (16) (17) (20) (22)

(24)

the remote control

(3) (4) (6)

(7) (12) (14) (15) (13) (19) (18) (21) (23) (25)

Back of

(26)

Setting up

Install the projector according to the environment and manner the projector will be used in.

Arrangement

Refer to the illustrations and tables below to determine screen size and projection distance.

8755G-RJ

The values shown in the table are calculated for a full size screen: 1024×768

Screen size (diagonal)

Projection distance (±10%)

, c2 Screen height (±10%)

On a horizontal surface

Suspended from the ceiling

• Keep a space of 30 cm or more between the sides of the projector and other objects such as walls.

• Consult with your dealer before a special installation such as suspending from a ceiling.

Screen size

(diagonal)

inch m m inch m inch cm inch cm inch m inch m inch cm inch cm inch

30 0.8 0.9 34 1.1 41 41 16 5 2 1.0 38 1.1 45 39 15 -1 0 40 1.0 1.2 46 1.4 56 55 22 50 1.3 1.5 58 1.8 70 69 60 1.5 1.8 70 2.1 84 70 1.8 2.1 80 2.0 2.4 93 2.8 112 110 43 12 5 2.6 102 3.1 122 103 41 -3 -1

90 2.3 2.7 100 2.5 3.0 117 3.6 140 137 54 15 6 3.2 127 3.9 153 129 51 -4 -2 120 3.0 3.6 140 4.3 169 165 65 18 7 3.9 153 4.7 184 154 61 -5 -2 150 3.8 4.5 200 5.1 6.0 235 7.2 282 274 108 30 12 6.5 256 7.8 307 257 101 -8 -3 250 6.4 7.5 294 9.0 353 343 135 38 15 8.1 320 9.8 384 322 127 -10 -4 300 7.6 9.0 352 10.8 423 411 162 46 18 9.8 384 11.7 461 386 152 -12 -5

Projection distance

min. max. min. max.

81 2.5 98 96 38 11 4 2.3 89 2.7 107 90 35 -3 -1

105 3.2 126 123 49 14 5 2.9 115 3.5 138 116 46 -4 -1

176 5.4 211 206 81 23 9 4.9 192 5.8 230 193 76 -6 -2

4 : 3 screen 16 : 9 screen

c1 c2

Screen

height

82 32 9 4 1.9 76 2.3 91 77 30 -2 -1

Screen

height

6 2 1.3 50 1.5 61 51 20 -2 -1

27 8 3 1.6 63 1.9 76 64 25 -2 -1

Projection distance

Screen

height

Screen

height

Setting up

Arrangement (continued)

8782

The values shown in the table are calculated for a full size screen: 1024×768

Screen size (diagonal)

Projection distance (±10%)

, c2 Screen height (±10%)

On a horizontal surface

Suspended from the ceiling

• Keep a space of 30 cm or more between the sides of the projector and other objects such as walls.

• Consult with your dealer before a special installation such as suspending from a ceiling.

Screen size

(diagonal)

inch m m inch m inch cm inch cm inch m inch m inch cm inch cm inch

30 0.8 0.9 35 1.1 43 41 16 5 2 1.0 39 1.2 47 39 15 -1 0

40 1.0 1.2 47 1.4 57 55 22

50 1.3 1.5 59 1.8

60 1.5 1.8

70 1.8 2.1 83 2.5

80 2.0 2.4 95 2.9 115 110 43 12 5 2.6 104 3.2 125 103 41 -3 -1

90 2.3 2.7 100 2.5 3.0 12

0 3.0 3.6 150 3.8 4.6 179 5.5 216 206 81 23 9 4.9 195 6.0 235 193 76 -6 -2 200 5.1 6.1 250 6.4 7.6 300 7.6 9.1 359 11.0 432 411 162 46 18 9.9 391 12.0 471 386 152 -12 -5

Projection distance

min. max. min. max.

71 2.2 86 82 32 9 4 2.0 78 2.4 94 77 30 -2 -1

107 3.3 129 123 49 14 5 3.0 117 3.6 141 116 46 -4 -1 119 3.6 144 137 54 15 6 3.3 130 4.0 156 129 51 -4 -2 143 4.4 172 165 65 18 7 4.0 156 4.8 188 154 61 -5 -2

239 7.3 288 274 108 30 12 6.6 261 8.0 314 257 101 -8 -3 299 9.1 360 343 135 38 15 8.3 326 10.0 392 322 127 -10 -4

4 : 3 screen

71 69 27 8 3 1.6 65 2.0 78 64 25 -2 -1

100 96 38 11 4 2.3 91 2.8 109 90 35 -3 -1

c1 c2

Screen

height

Screen

height

6 2 1.3 52 1.6 62 51 20 -2 -1

Projection distance

16 : 9 screen

Screen

height

Screen

height

Setting up

WARNING ►Place the projector in a stable horizontal position. If the

projector falls or is knocked over it could cause injury and/or damage to the projector. Using a damaged projector could then result in re and/or electric shock.

• Do not place the projector on an unstable, slanted or vibrational surface such

as a wobbly or inclined stand.

• Do not place the projector on its side, front or rear position.

• Consult with your dealer before a special installation such as suspending

from a ceiling. ►Place the projector in a cool place, and ensure that there is sufcient ventilation. The high temperature of the projector could cause re, burns and/ or malfunction of the projector.

• Do not stop-up, block or otherwise cover the projector's vents.

• Keep a space of 30 cm or more between the sides of the projector and other

objects such as walls.

• Do not place the projector on metallic thing or anything weak in heat.

• Do not place the projector on carpet, cushions or bedding.

• Do not place the projector in direct sunlight or near hot objects such as

heaters.

• Do not anything near the projector lens or vents, or on top of the projector.

• Do not place anything that may be sucked into or stick to the vents on the

bottom of the projector. This projector has some intake vents also on the

bottom. ►Do not place the projector anyplace where it may get wet. Getting the projector wet or inserting liquid into the projector could cause re, electric shock and/or malfunction of the projector.

• Do not place the projector in a bathroom or the outdoors.

• Do not place anything containing liquid near the projector.

CAUTION ►Avoid placing the projector in smoky, humid or dusty place. Placing the projector in such places could cause re, electric shock and/or malfunction of the projector.

• Do not place the projector near humidiers, smoking spaces or a kitchen. ►Position the projector to prevent light from directly hitting the projector's remote sensor.

Setting up

RGB IN

AUDIO IN

Y CB/PB CR/PR

COMPONENT VIDEO OUT

L R

AUDIO OUT

VIDEO OUT

L R

AUDIO OUT

L R

AUDIO OUT

S-VIDEO OUT

AUDIO OUT

RGB OUT

AUDIO OUT

USB

RGB OUT

LAN

RS-232C

Connecting your devices

Be sure to read the manuals for devices before connecting them to the projector. Make sure that all the devices are suitable to be connected with this product, and prepare the cables required to connect. Please refer to the following illustrations to connect them.

Speakers

Monitor

VCR/DVD

player

WARNING ►Do not disassemble or modify the projector and accessories.

►Be careful not to damage the cables, and do not use damaged cables.

CAUTION ►Turn off all devices and unplug their power cords prior to connecting them to projector. Connecting a live device to the projector may generate extremely loud noises or other abnormalities that may result in malfunction or damage to the device and the projector. ►Use appropriate accessory or otherwise designed cables. Ask your dealer about non-accessory cables which may have to be of a specic length or equipped with a core. For cables with a core only at one end, connect the end with the core to the projector. ►Make sure that devices are connected to the correct ports. An incorrect connection may result in malfunction or damage to the device and the projector.

Setting up

Connecting your devices (continued)

NOTE • Be sure to read the manuals for devices before connecting them to the projector, and make sure that all the devices are suitable to be connected with this product. Before connecting to a PC, check the signal level, the signal timing, and the resolution.

- Some signal may need an adapter to input this projector.

- Some PCs have multiple screen display modes that may include some signals which

are not supported by this projector.

- Although the projector can display signals with resolution up to UXGA (1600X1200),

the signal will be converted to the projector’s panel resolution before being displayed. The best display performance will be achieved if the resolutions of the input signal and the projector panel are identical.

• While connecting, make sure that the shape of the cable's connector ts the port to connect with. And be sure to tighten the screws on connectors with screws.

• When connecting a laptop PC to the projector, be sure to activate the PC’s external RGB output. (Set the laptop PC to CRT display or to simultaneous LCD and CRT display.) For details on how this is done, please refer to the instruction manual of the corresponding laptop PC.

• When the picture resolution is changed on a pc depending on an input, automatic adjustment function may take some time and may not be completed. In this case, you may not be able to see a check box to select “Yes/No” for the new resolution on Windows. Then the resolution will go back to the original. It might be recommended to use other CRT or LCD monitors to change the resolution.

• In some cases, this projector may not display a proper picture or display any picture on screen. For example, automatic adjustment may not function correctly with some input signals. An input signal of composite sync or sync on G may confuse this projector, so the projector may not display a proper picture.

About Plug-and-Play capability

Plug-and-Play is a system composed of a PC, its operating system and peripheral equipment (i.e. display devices). This projector is VESA DDC 2B compatible. Plug-andPlay can be used by connecting this projector to a pc that is VESA DDC (display data channel) compatible.

• Take advantage of this feature by connecting an RGB cable to the COMPUTER IN1 port (DDC 2B compatible). Plug-and-Play may not work properly if any other type of connection is attempted.

• Please use the standard drivers in your pc as this projector is a Plug-and-Play monitor.

Setting up

Connecting power supply

At rst, make sure that the power switch of the projector is set to OFF position (marked "O").

Put the connector of the power cord into the

AC inlet of the projector. Firmly plug the power cord’s plug into the

outlet.

AC inlet

WARNING ►Please use extra caution when connecting the power cord, as

incorrect or faulty connections may result in re and/or electrical shock.

• Only use the power cord that came with the projector. If it is damaged, contact your dealer to newly get correct one.

• Only plug the power cord into an outlet rated for use with the power cord's specied voltage range. The power outlet should be close to the projector and easily accessible. Remove the power cord for complete separation.

• Never modify the power cord.

Using the security bar and slot

A commercial anti-theft chain or wire up to 10 mm in diameter can be attached to the security bar on the projector. Also this product has the security slot for the Kensington lock. For details, see the manual of the security tool.

Anti-theft chain or wire

WARNING ►Do not use the security bar and slot to prevent the projector

from falling down, since it is not designed for it.

CAUTION ►Do not place anti-theft chain or wire near the exhaust vents. It

may become too hot.

Security slot

Power cord

Security bar

NOTE • The security bar and slot is not comprehensive theft prevention

measures. It is intended to be used as supplemental theft prevention measure.

Remote control

Putting batteries

Please set the batteries to the remote control before using it. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place.

Holding the hook part of the battery

cover, remove it. Align and insert the two AA batteries

according to their plus and minus terminals

as indicated in the remote control.

Replace the battery cover in the direction of the arrow and snap it back into place.

WARNING ►Always handle the batteries with care and use them only as directed. Improper use may result in battery explosion, cracking or leakage, which could result in re, injury and/or pollution of the surrounding environment.

• Be sure to use only the batteries specied. Do not use batteries of different types at the same time. Do not mix a new battery with used one.

•

Make sure the plus and minus terminals are correctly aligned when loading a battery.

• Keep a battery away from children and pets.

• Do not recharge, short circuit, solder or disassemble a battery.

•

Do not allow a battery in a re or water. Keep batteries in a dark, cool and dry place.

•

If you observe battery leakage, wipe out the leakage and then replace a battery. If the

leakage adheres to your body or clothes, rinse well with water immediately.

• Obey the local laws on disposing the battery.

About the remote control signal

The remote control works with the projector’s remote sensor. This projector has a remote sensor on the front. The sensor senses the signal within the following range when the sensor is active: 60 degrees (30 degrees to the left and right of the sensor) within 3 meters about.

NOTE • The remote control signal reected in the screen or the like may be available. If it is difcult to send the signal to the sensor directly, attempt to make the signal reect.

• The remote control uses infrared light to send signals to the projector (Class 1 LED), so be sure to use the remote control in an area free from obstacles that could block the remote control’s signal to the projector.

•

The remote control may not work correctly if strong light (such as direct sun light) or light

from an extremely close range (such as from an inverter uorescent lamp) shines on the

remote sensor of the projector. Adjust the position of projector avoiding those lights.

Approx.

3 m

30º

Remote control

USB

USB STORAGE

AUDIO OUT

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

Changing the frequency of remote control signal

The accessory remote control has the two choices on signal frequency Mode 1:NORMAL and Mode 2:HIGH. If the remote control does not function properly, attempt to change the signal frequency. In order to set the Mode, please keep pressing the combination of two buttons listed below simultaneously for about 3 seconds. (1) Set to Mode 1:NORMAL... MUTE and RESET buttons (2) Set to Mode 2:HIGH... MAGNIFY OFF and ESC buttons Please remember that the REMOTE FREQ. in the SERVICE item of the OPTION menu (44) of the projector to be controlled should be set to the same mode as the remote control.

Using as a simple PC mouse & keyboard

The enclosed remote control works as a simple mouse and keyboard of the PC, when the projector's USB port (B type) connects with the PC's USB port (A type) port via a mouse cable.

(1) HOME key: Press HOME button. (2) END key: Press END button. (3) PAGE UP key: Press PAGE UP button. (4) PAGE DOWN key: Press PAGE DOWN button. (5) Mouse left button: Press ENTER button. (6) Move pointer: Use the cursor buttons ▲, ▼, ◄ and ►. (7) ESC key: Press ESC button. (8) Mouse right button: Press RESET button.

USB port

(2)

(1)(2)

(3)(1)

(4)

CAUTION ►Improper use of the simple mouse

& keyboard function could damage your equipment.

(5)

While using this function, please connect this product only to a PC. Be sure to check your PC’s manuals

(7)

before connecting this product to the PC.

NOTE •

When the simple mouse & keyboard function of this product does not work

correctly, please check the following.

- When the mouse cable connects this projector with a PC having a built-in pointing device (e.g. track ball) like a notebook PC, open BIOS setup menu, then select the external mouse and disable the built-in pointing device, because the built-in pointing device may have priority to this function.

- Windows 95 OSR 2.1 or higher is required for this function. And also this function may not work depending on the PC’s congurations and mouse drivers.

- You cannot do things like press two buttons at once (for instance, pressing two buttons at the same time to move the mouse pointer diagonally).

- This function is activated only when the projector is working properly. This function is not available while the lamp is warming up (the POWER indicator blinks green), and while adjusting the volume and display, correcting for keystone, zooming in on the

screen, using the BLANK function, or displaying the menu screen.

(6)

(8)

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

Power on/off

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

Power on/off

STANDBY/ON button POWER indicator

Turning on the power

Make sure that the power cord is rmly and correctly

connected to the projector and the outlet. Remove the lens cover, and set the power switch to

ON position (marked “ I “). The POWER indicator will light up in steady orange (60). Then wait several seconds because the buttons may not function for these several seconds.

Press STANDBY/ON button on the projector or the

remote control. The projection lamp will light up and POWER indicator will begin blinking in green. When the power is completely on, the indicator will stop blinking and light in steady green (60).

Power switch

To display the picture, select an input signal according to the section “Selecting an input signal” (16).

Turning off the power

Press the STANDBY/ON button on the projector or the remote control. The message

“Power off?” will appear on the screen for about 5 seconds.

Press the STANDBY/ON button again while the message appears.

The projector lamp will go off, and the POWER indicator will begin blinking in orange. Then POWER indicator will stop blinking and light in steady orange when the lamp cooling is complete(60).

Make sure that POWER indicator lights in steady orange, and set the

power switch to OFF position (marked “O“). POWER indicator will go off. Attach the lens cover.

Do not turn the projector on for about 10 minutes or more after turning it off. Turning the projector on again too soon could shorten the lifetime of some consumable parts of the projector.

Power switch

WARNING

►A strong light is emitted when the projector’s power is on. Do not look into the lens of the projector or look inside of the projector through any of the projector’s openings. ►Do not touch around the lamp cover and the exhaust vents during use or just after use, since it is too hot.

NOTE • Turn the power on/off in right order. Please power on the projector prior to the connected devices. Power off the projector after all of connected devices are powered off.

•

The projector has the AUTO ON function, which can make the projector automatically

turn on. For more information, please see AUTO ON item of OPTION menu

• Use the shutdown switch (61) only when the projector is not turned off by normal procedure.

(40).

Operating

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

Operating

VOLUME button

Adjusting the volume

Press VOLUME button on the remote control.

A dialog will appear on the screen to aid you in adjusting the

volume.

Use the ▲/▼ cursor buttons to adjust the volume.

To close the dialog and complete the operation, press the VOLUME button again. Even if you do not do anything, the dialog will automatically disappear after a few seconds.

● When is selected for current picture input port, the volume adjustment is disable. Please see AUDIO item of SETUP menu

(35)

▲/▼ button

Temporarily muting the sound

Press MUTE button on the remote control.

A dialog will appear on the screen indicating that you have muted the sound. To restore the sound, press the MUTE or VOLUME button. Even if you do not do anything, the dialog will automatically disappear after a few seconds.

● When is selected for current picture input port, the sound is always muted. Please see AUDIO item of SETUP menu

(35)

Selecting an input signal

Press INPUT button on the projector.

Each time you press the button, the projector switches

its input port from the current port as below. COMPUTER IN 1  COMPUTER IN 2

VIDEO  S-VIDEO 

COMPONENT (Y, Cb/Pb, Cr/Pr)

● While TURN ON is selected for AUTO SEARCH item in

OPTION menu (



), the projector will keep checking the

ports in above order repeatedly till an input signal is detected.

MUTE button

INPUT button

Press COMPUTER button on the remote control.

Each time you press the button, the projector switches

its input port from the current port as below. COMPUTER IN 1  COMPUTER IN 2

●

While TURN ON is selected for AUTO SEARCH item in OPTION menu, the projector will keep checking every port sequentially till an input signal is detected when VIDEO, S-VIDEO or COMPONENT port is selected, the projector will check COMPUTER IN1 port rst.

(continued on next page)



(

)

. If COMPUTER button is pushed

COMPUTER button

Operating

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

Selecting an input signal (continued)

Press VIDEO button on the remote control.

Each time you press the button, the projector switches its input

VIDEO button

port from the current port as below.

COMPONENT(Y, Cb/Pb, Cr/Pr)  S-VIDEO  VIDEO

● While TURN ON is selected for AUTO SEARCH item in OPTION menu, the projector will keep checking every port sequentially till an input signal is detected

(40)

. If COMPUTER button is pushed when VIDEO, S-VIDEO or COMPONENT port is selected, the projector will check COMPUTER IN1 port rst.

Searching an input signal

Press SEARCH button on the remote control.

The projector will start to check its input ports as below

SEARCH button

in order to nd any input signals. When an input is found, the projector will stop searching and display the image. If no signal is found, the projector will return to the state selected before the operation.

COMPUTER IN 1  COMPUTER IN 2 VIDEO  S-VIDEO 

COMPONENT (Y, Cb/Pb, Cr/Pr)

● While TURN ON is selected for AUTO SEARCH item in OPTION

menu (



), the projector will keep checking the ports in above order

repeatedly till an input signal is detected.

Selecting an aspect ratio

Press ASPECT button on the remote control.

Each time you press the button, the projector switches the

mode for aspect ratio in turn.

For a computer signal



NORMAL  4:3



16:9

SMALL



For a video signal, s-video signal or component video



signal

4:3



16:9  14:9

SMALL



For no signal



4:3 (xed)

● ASPECT button does not work when no proper signal is inputted.

● NORMAL mode keeps the original aspect ratio setting.

ASPECT button

Operating

Adjusting the projector's elevator

When the place to put the projector is slightly uneven to the left or right, use the elevator feet to place the projector horizontally. Using the feet can also tilt the projector in order to project at a suitable angle to the screen, elevating the front side of the projector within 10 degrees. This projector has 2 elevator feet and 2 elevator buttons. An elevator foot is adjustable while pushing the elevator button on the same side as it.

Holding the projector, push the elevator buttons to loose the elevator feet.

Position the front side of the projector to the desired height.

Release the elevator buttons in order to lock the elevator feet.

After making sure that the elevator feet are locked, put the projector gently.

If necessary, the elevator feet can be manually twisted to make more precise

adjustments. Hold the projector when twisting the feet.

To loose an elevator foot, push the elevator button on the same side as it.

CAUTION ►Do not handle the elevator buttons without holding the projector, since the projector may drop down. ►Do not tilt the projector other than it elevating its front within 10 degrees using the adjuster feet. A tilt of the projector exceeding the restriction could cause malfunction or shortening the lifetime of consumables, or the projector itself.

Adjusting the zoom and focus

Use the zoom ring to adjust the screen size.

Use the focus ring to focus the picture.

To nely adjust, twist the foot.

Focus ring

Zoom ring

Using the automatic adjustment feature

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

Press AUTO button on the remote control.

Pressing this button performs the following.

For a computer signal



The vertical position, the horizontal position and the horizontal phase will be automatically adjusted. And the horizontal size will be automatically set to the default. Make sure that the application window is set to its maximum size prior to attempting to use this feature. A dark picture may still be incorrectly adjusted. Use a bright picture when adjusting.

For a video signal, s-video signal or component video signal



The video format best suited for the respective input signal will be selected automatically. This function is available only when AUTO is selected for VIDEO FORMAT item in INPUT menu The vertical position and horizontal position will be automatically set to the default. For a component video signal, also the horizontal phase will be automatically set to the default.

● The automatic adjustment operation requires approx. 10 seconds. Also please note that it may not function correctly with some input. When this function is performed for a video signal, a certain extra such as a line may appear outside a picture.

●

The items adjusted by this function may vary when FINE or DISABLE is

selected for AUTO ADJUST item of SERVICE item in OPTION menu

(32)

Operating

AUTO button

(43)

Adjusting the position

Press POSITION button on the remote control when no menu

is indicated.

The “POSITION” indication will appear on the screen.

Use the ▲/▼/◄/► cursor buttons to adjust the picture position.

When you want to reset the operation, press RESET button on the remote control during the operation. To complete this operation, press POSITION button again. Even if you do not do anything, the dialog will automatically disappear after a few seconds.

● When this function is performed on a video signal, s-video signal or component video signal, some image such as an extra-line may appear at outside of the picture.

● When this function is performed on a video signal, s-video signal or component video signal, the range of this adjustment depends on OVER SCAN in IMAGE

(29)

● If POSITION button is pressed when a menu is indicated on screen, the displayed picture does not move its position but the menu does.

setting. It is not possible to adjust when OVER SCAN is set to 10.

POSITION button

Operating

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

Correcting the keystone distortions

Press KEYSTONE button on the remote control. A dialog will

appear on the screen to aid you in correcting the distortion. Use the ▲/▼ cursor buttons to select AUTO or MANUAL

operation, and press the ► button to perform the following.

KEYSTONE button

(1) AUTO executes automatic vertical keystone correction. (2) MANUAL displays a dialog for keystone correction.

Use the ▲/▼ buttons for adjustment.

To close the dialog and complete this operation, press KEYSTONE button again. Even if you do not do anything, the dialog will automatically disappear after a few seconds.

● The adjustable range of this correction will vary among inputs. For some input, this function may not work well.

●

When V:INVERT or H&V:INVERT is selected for MIRROR item in SETUP menu, if the

projector screen is inclined or angled downward, this function may not work correctly.

● When the zoom adjustment is set to TELE (telephoto focus), the automatic keystone distortion correction may be excessive. This function should be used when the zoom adjustment is set to the full WIDE (wide-angle focus) whenever possible.

● When the projector is placed on the level (about ±0°), the automatic keystone distortion correction may not work.

● When the projector is inclined to near ±30 degree or over, this function may not work well.

● This function will be unavailable when Transition Detector is on (49).

Using the magnify feature

Press the ON button of MAGNIFY on the remote control.

The “MAGNIFY” indication will appear on the screen and the projector will go into the MAGNIFY mode. When the ON button of MAGNIFY is pressed rst after the projector is started, the picture will be zoomed twice. The indication will disappear in several seconds with no operation.

Use the ▲/▼ cursor buttons to adjust the zoom level. The picture of

video, s-video or component video signal can be zoomed in up to 2 times, and the one of computer signal can be zoomed in up to 4 times. To move the zoom area, press POSITION button in the MAGNIFY mode, then use the ▲/▼/◄/► cursor buttons to move the area. And to nalize the zoom area, press POSITION button again.

To exit from the MAGNIFY mode and restore the screen to normal, press the OFF button of MAGNIFY on the remote control.

● The projector automatically exits from the MAGNIFY mode when the input signal is changed or when the display condition is changed.

● In the MAGNIFY mode, the keystone distortion condition may vary, it will be restored when the projector exits from the MAGNIFY mode.

NOTE • The zoom level can be nely adjusted. Closely watch the screen to

nd the level you want.

ON/OFF button

MAGNIFY

Operating

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

COMPUTER

Freezing the screen

Press FREEZE button on the remote control.

The “FREEZE” indication will appear on the screen (however, the indication will not appear when TURN OFF is selected for MESSAGE item in SCREEN menu

(39)

), and the projector will go into the FREEZE mode, which the picture is frozen. To exit the FREEZE mode and restore the screen to normal, press FREEZE button again.

● The projector automatically exits from the FREEZE mode when one of the projector’s buttons or remote control buttons of STANDBY/ON, SEARCH, COMPUTER, VIDEO, BLANK, AUTO, VOLUME, MUTE, KEYSTONE, MENU, MAGNIFY and MY BUTTON1/2(except MY MEMORY or PICTURE MODE is assigned to)

(42)

is pressed.

● If the projector continues projecting a still image for a long time, the LCD panel might possibly be burned in. Do not leave the projector in the FREEZE mode for too long.

FREEZE button

Temporarily blanking the screen

Press BLANK button on the remote control.

The BLANK screen will be displayed instead of the screen

of input signal. Please refer to BLANK item in SCREEN menu

(36).

To exit from the BLANK screen and return to the input signal screen, press BLANK button again.

● The projector automatically returns to the input signal screen when one of the projector’s buttons or the remote control buttons (except ASPECT, POSITION, MAGNIFY or FREEZE button, also except MY BUTTON1/2 if AUTO KEYSTONE EXECUTE or MY MEMORY or PICTURE MODE is assigned to

(42)

) is pressed.

BLANK button

NOTE • The sound is not connected with the BLANK screen function.

If necessary, set the volume or mute rst.

Operating

HOM

PAGE UP

PAGE DOWN

VIDE

FREEZ

MAGNIFY

ASPECT

AUT

BLANK

MUT

VOLUME

KEYS

MY BUTTO

POSITIO

1 2

ENTE

RESET

COMPUTER

HOME

PAGE UP

PAGE DOWN

END

VIDEO

FREEZE

OFF

MAGNIFY

ASPECT AUTO

BLANK

MUTE

VOLUME

KEYSTONE

MY BUTTON

POSITION

1 2

ESC

ENTER

RESET

COMPUTER

Using the menu function

This projector has the following menus: PICTURE, IMAGE, INPUT, SETUP, SCREEN, OPTION, NETWORK and EASY MENU. EASY MENU consists of functions often used, and the other menus are classied into each purpose and brought together as Advanced Menu. Each of these menus is operated using the same methods. The basic operations of these menus are as follows.

MENU button

ENTER button MENU button

Cursor buttons

ESC button

Press the MENU button on the remote control or the projector.

The Advanced Menu or EASY MENU, which has priority just after powered

RESET button

on will appear. If you want to move the menu position, use the cursor buttons after pressing the POSITION button. While the projector is displaying any menu, MENU button on the projector works as the cursor buttons.

In the EASY MENU

If you want to change it to the Advanced Menu,

select the Go to Advanced Menu... Use the ▲/▼ cursor buttons to select an item to

operate.

Use the ◄/► cursor buttons to operate the item.

(continued on next page)

EASY MENU

Operating

Using the menu function (continued)

In the Advanced Menu

Use the ▲/▼ cursor buttons to select a menu.

If you want to change it to the EASY MENU, select EASY MENU. Then press the ► cursor button, or ENTER button to select an item. The lower layer menu of the selected item will appear.

Use the ▲/▼ cursor buttons to select an item to

operate. Then press the ► cursor button, or ENTER button to progress. The operation menu of the selected item will appear.

Use the ▲/▼ cursor buttons to operate the item.

● Some functions cannot be performed when a certain input port is selected, or when a certain input signal is displayed.

● When you want to reset the operation, press RESET button on the remote control during the operation. Note that some items (ex. LANGUAGE, H PHASE, VOLUME) cannot be reset.

● In the Advanced Menu, when you want to return to the previous display, press the ◄ cursor button or ESC button on the remote control.

Press MENU button on the remote control again to close the menu and

complete this operation. Even if you do not do anything, the dialog will

automatically disappear after about 10 seconds.

Advanced Menu

EASY MENU

From the EASY MENU, items shown in the table below can be performed.

Select an item using the ▲/▼ cursor buttons. Then perform it according to the following table.

Item Description

ASPECT

AUTO

KEYSTONE

EXECUTE

KEYSTONE

Using the ◄/► buttons switches the mode for aspect ratio. See the ASPECT item in IMAGE menu (29).

Using the ► button executes the auto keystone function. See AUTO KEYSTONE EXECUTE item in SETUP menu (34).

Using the ◄/► buttons corrects the vertical keystone distortion. See KEYSTONE item in SETUP menu (34).

Using the ◄/► buttons switches the picture mode. The picture modes are combinations of GAMMA and COLOR

TEMP settings. Choose a suitable mode according to the projected source.

NORMAL ó CINEMA ó DYNAMIC ó BOARD(BLACK)

DAYTIME ó WHITEBOARD ó BOARD(GREEN)

NORMAL #2 MID DEFAULT #1 DEFAULT

PICTURE MODE

CINEMA #3 LOW DEFAULT #2 DEFAULT DYNAMIC #1 HIGH DEFAULT #3 DEFAULT BOARD(BLACK) #4 Hi-BRIGHT-1 DEFAULT #4 DEFAULT BOARD(GREEN) #5 Hi-BRIGHT-2 DEFAULT #4 DEFAULT WHITEBOARD #2 MID DEFAULT #5 DEFAULT DAYTIME #6 Hi-BRIGHT-3 DEFAULT #6 DEFAULT

• When the combination of GAMMA and COLOR TEMP differs from pre-assigned modes above, the display on the menu for the PICTURE MODE is “CUSTOM”. Please refer to GAMMA (26) and COLOR TEMP (26) items in PICTURE menu.

• When this function is performed, a certain extra such as a line may appear.

(continued on next page)

COLOR TEMP GAMMA

EASY MENU (continued)

Item Description

BRIGHTNESS

CONTRAST

COLOR

TINT

SHARPNESS

WHISPER

MIRROR

RESET

FILTER TIME

LANGUAGE

Go to

Advanced Menu...

Using the ◄/► buttons adjusts the brightness. See BRIGHTNESS item in PICTURE menu (26).

Using the ◄/► buttons adjusts the contrast. See CONTRAST item in PICTURE menu (26).

Using the ◄/► buttons adjusts the strength of whole color. See COLOR item in PICTURE menu (26).

Using the ◄/► buttons adjusts the tint. See TINT item in PICTURE menu (26).

Using the ◄/► buttons adjusts the sharpness. See SHARPNESS item in PICTURE menu (27).

Using the ◄/► buttons turns off/on the whisper mode. See WHISPER item in SETUP menu (35).

Using the ◄/► buttons switches the mode for mirror status. See MIRROR item in SETUP menu (35).

Performing this item resets all of EASY MENU items except FILTER TIME and LANGUAGE. A dialog is displayed for conrmation. Selecting RESET using the ▲ button performs resetting.

Performing this item resets the lter time which counts usage time of the air lter. A dialog is displayed for conrmation. Selecting RESET using the ▲ button performs resetting. See FILTER TIME item in OPTION menu (41).

Using the ◄/► buttons changes the display language. See LANGUAGE item in SCREEN menu (36).

Select Go to Advanced Menu… on the menu, and press the ► or ENTER button to use the menu of PICTURE, IMAGE, INPUT, SETUP, SCREEN, OPTION or NETWORK.

EASY MENU

PICTURE menu

#1 DEFAULT  #1 CUSTOM  #2 DEFAULT  #2 CUSTOM



#3 DEFAULT



CUSTOM



#5 CUSTOM

 #5

DEFAULT

 #4

CUSTOM

 #4

DEFAULT



CUSTOM



DEFAULT



#2 MID CUSTOM



#3 LOW DEFAULT



#3 LOW CUSTOM



#1 HIGH DEFAULT  #1 HIGH CUSTOM  #2 MID DEFAULT



#6 Hi-BRIGHT-3 CUSTOM



#6 Hi-BRIGHT-3 DEFAULT



#5 Hi-BRIGHT-2 CUSTOM



#5 Hi-BRIGHT-2 DEFAULT



#4 Hi-BRIGHT-1 CUSTOM



#4 Hi-BRIGHT-1 DEFAULT

PICTURE menu

From the PICTURE menu, items shown in the table below can be performed.

Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or ENTER button to execute the item. Then perform it according to the following table.

Item Description

BRIGHTNESS

CONTRAST

GAMMA

Using the ▲/▼ buttons adjusts the brightness.

Light ó Dark

Using the ▲/▼ buttons adjusts the contrast.

Strong ó Weak

Using the ▲/▼ buttons switches the gamma mode.

To adjust the "CUSTOM" modes, see "To adjust CUSTOM function in GAMMA and COLOR TEMP" (28).

Using the ▲/▼ buttons switches the color temperature mode.

COLOR TEMP

To adjust the "CUSTOM" modes, see "To adjust CUSTOM function in GAMMA and COLOR TEMP" (28).

Using the ▲/▼ buttons adjusts the strength of whole color.

COLOR

Strong ó Weak

• This item can be selected only for a video signal, s-video or component video signal.

Using the ▲/▼ buttons adjusts the tint.

TINT

Greenish ó Reddish

• This item can be selected only for a video signal, s-video or component video signal.

(continued on next page)

PICTURE menu (continued)

Item Description

Using the ▲/▼ buttons adjusts the sharpness.

SHARPNESS

MY MEMORY

Strong ó Weak

• There may be some noise and/or the screen may icker for a moment when an adjustment is made. This is not a malfunction.

This projector has 4 memories for adjustment data (for all the items of PICTURE menu). Selecting a function using the ▲/▼ buttons and pressing the ► or ENTER button performs each function.

LOAD-1, LOAD-2, LOAD-3, LOAD-4

Performing a LOAD function loads the data from the memory linked in the number included in the function’s name, and adjusts the picture automatically depending on the data.

• The LOAD functions whose linked memory has no data are skipped.

• Remember that the current adjusted condition will be lost by loading data. If you want to keep the current adjustment, please save it before performing a LOAD function.

• There may be some noise and the screen may icker for a moment when loading data. This is not malfunction.

• You can perform the LOAD function using MY BUTTONs. Please see MY BUTTON item in OPTION menu (42).

SAVE-1, SAVE-2, SAVE-3, SAVE-4

Performing a SAVE function saves the current adjustment data into the memory linked in the number included in the function’s name.

• Remember that the current data being stored of a memory will be lost by saving a new data into the memory.

PICTURE menu

LOAD-1 ó LOAD-2 ó LOAD-3 ó LOAD-4

SAVE-4 óSAVE-3 ó SAVE-2 ó SAVE-1

PICTURE menu

PICTURE menu (continued)

To adjust CUSTOM function in GAMMA and COLOR TEMP

Sele cting a mod e who s e na m e in c lude s CUSTOM in GAMMA or COLOR TEMP item and then pressing the ► button or ENTER button displays a dialog to aid you in adjusting the mode. Choose an item using the ◄/► buttons, and adjust the level using the ▲/▼ buttons.

• When this function is performed, lines or other

distortion may appear.

You can display a test pattern on the top of the screen for checking the effect of your adjustment by pressing the ENTER button. Each time you press the ENTER button, the pattern changes as below.

No pattern  Gray scale of 9 steps



Ramp  Gray scale of 15 steps

• You can also adjust each function without displaying test patterns.

for adjusting GAMMA

You can change the brightness of particular tones. The eight equalizing bars correspond to eight tone levels of the test pattern (Gray scale of 9 steps) except the darkest in the left end. If you want to adjust the 2nd tone from left end on the test pattern, use the equalizing adjustment bar “1”. The darkest tone at the left end of the test pattern cannot be controlled with any of equalizing adjustment bar.

for adjusting COLOR TEMP

You can change the intensity of each of 3 colors (Red, Green, Blue). OFFSET adjustments change the color intensity on the whole tones of the test pattern. GAIN adjustments mainly affect color intensity on the brighter tones of the test pattern.



GAMMA COLOR TEMP

test pattern

+ 100 hidden pages
