Dualit Percolator Instruction manual

t: [phone] f: [phone] e: [e-mail] www.dualit.com

Dualit Limited County Oak Way Crawley West Sussex RH11 7ST

IMPORTANT SAFETY PRECAUTIONS

TO REPLACE FUSE,
REMOVE SILVER LABEL

TROUBLESHOOTING GUIDE

POSSIBLE CAUSE(S) SOLUTION(S)

THE PERCOLATOR DOES NOT TURN ON

1. The percolator may not be properly connected to the power supply
or the fuse may have failed.

2. Boil dry feature may have been activated. If the percolator is accidentally
switched on with no water inside, the boil-dry device will switch off the
heating element to prevent damage to the percolator.

3. The percolator does boil but the power light does not illuminate. 3. The power neon may have blown. Call customer services

INDICATOR LIGHT HAS NOT TURNED GREEN

1. If the switch on the percolator is off, the green light will not turn on. 1. Ensure the percolator is plugged in, sat on the power base and

2. If the switch is on and there is no green light, then your percolator

may be faulty.

WATER IS SPURTING OUT OF THE SPOUT

1. You may have overlled the percolator. 1.1 Only ll to the 10 cup max marker.

2. The percolator may have descaling solutions remaining inside

the body.

MARKS HAVE APPEARED IN THE PERCOLATOR

1. Small brown spots can build up inside the percolator. This is not rust,

small deposits of limescale which contain iron can build up inside the percolator.

2. A build-up of coffee residue on the heating plate. 2. Descale regularly (see cleaning & care) as this may affect the

WATER DROPLETS COLLECTS ON TOP THE POWER BASE

1. This is condensation and perfectly normal. 1. Dry with non abrasive cloth.

COFFEE GROUNDS FOUND IN THE CUP

1. Excessive amounts of coffee grounds are present in the bottom of the

percolator or cup.

1. Check the plug is in the socket and the switch on the power base
is turned on. Replace the fuse if necessary.

2. Wait 10 minutes for the percolator to reset.
NOTE: if discolouration of the heating plates has occurred,

this can be easily removed by descaling your percolator.

on 01293 652500 for further information.

switched on.

2. Ensure the percolator is plugged in, sat on the power base and
switched on. If problems persist, call customer services on
01293 652500 for further information.

1.2 Wait 10 seconds to allow the boiling water to settle before
pouring.

2. Follow the instructions from the cleaning & care section
and rinse throughly.

1. Descale regularly (see cleaning & care).

performance of the percolator.

1. Try a courser grind of coffee to prevent grounds falling through

the basket.

TO ACCESS SCREW.

OR BY POST

DUALIT.COM/REGISTER

PERCOLATOR

REGISTER YOUR

DON’T FORGET TO

Instruction Manual

Percolator

GB-C

READ ALL INSTRUCTIONS

BEFORE USING THE PERCOLATOR KEEP
THESE INSTRUCTIONS FOR FUTURE
REFERENCE

• THIS IS AN ATTENDED APPLIANCE
D

o not leave appliance unattended during use, unplug

after each use (risk of re if an unattended appliance is left

operating or plugged in).

• This appliance can be used by children aged from 8 years and above if

they have been given supervision or instruction concerning use of the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance and its cord
out of reach of children aged less than 8 years

• Appliances can be used by persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in
a safe way and if they understand the hazards involved.

• Children shall not play with the appliance.

• This appliance is intended for household use only. If the appliance is

used improperly or for professional or semi-professional purposes or if
it is not used according to these instructions the Guarantee becomes
invalid and Dualit refuses any liability for damage caused.

Electrical safety

• Before plugging in, check that the voltage marked on the appliance

corresponds with the supply voltage.

• NOTE: any plug cut from the power supply cord should be disposed

of immediately. Inserting any cut off plug into a 13A socket-outlet is
hazardous.

• N

fuse is the same current value as the original. Replacement fuses are
available and should be ASTA approved to BS1362.

• A short power-supply cord is to be provided to reduce risks resulting

from becoming entangled in or tripping over a longer cord.

• Do not operate any appliance with a damaged lead or plug, or after the

appliance malfunctions or has been damaged, cracked or dropped in any
manner.

If the power cord is damaged it must, for safety reasons, be replaced by

Dualit or an authorised Dualit repairer.

• To disconnect, switch off, then remove plug from wall outlet.

• Unplug the power base from the wall socket when not in use, or before

moving and cleaning.

• Ensure that the percolator is correctly positioned on the power base

before switching on.

• To be protected against electrical hazards, re and injury to persons, do

not immerse the mains lead, plug, power base or percolator in water or
any other liquid.

• Use the percolator only with the power base supplied and vice versa.

• Do not move while the percolator is still switched on.

• Remove the percolator from its power base before lling or pouring.

• Ensure that the lid is fully closed before switching the kettle on,

otherwise it may not properly switch off, causing a scalding hazard.

• Avoid the spillage of any liquid on the connector.

General safety

• NOTE: when you lift the percolator from the base, you will see drops

of moisture on the surface of the power base. This is perfectly normal,
and should not be cause for alarm or returning the percolator.

• Do not place the percolator, power base or mains lead on or near any

hot surface, hot hob, gas burner or in a heated oven.

ever use the plug without the fuse cover tted. Ensure replacement

• Do not use the percolator for any purpose other than mentioned in this

instruction booklet. Otherwise, this may result in an injury caused by misuse.

• Do not operate the percolator on an inclined plane.

• Do not use in bathroom or outdoors.

• Do not store or use in an appliance garage or under cupboards.

• Do not operate the percolator unless the tube, basket and lid assembly is

correctly in position.

• Do not remove or open the lid while the water is boiling as scalding may

occur.

• Use handles or knobs – do not touch hot surfaces.

• If the percolator is overlled, boiling water may be ejected, causing a

scalding hazard.

• Water/Coffee will remain hot for a considerable time after boiling and can

present a scald hazard. Heating element surface is subject to residual heat

after use. Keep the percolator, power base and the mains lead away from
the edge of worktops and out of the reach of children.

• When boiling, hot steam will be emitted from the percolator.

Scalding may occur if you are within 400mm of the spout.

• Scalding may occur if the lid is opened during the brewing cycle and the

body of the percolator will get hot.

• This percolator features boil-dry protection. If the percolator is accidently

switched on without water, the boil-dry device will switch off the heating
element to prevent damage to the percolator. Wait approximately 10

minutes for the percolator to cool down, lift and rell as normal. The

percolator is now ready to use again. NOTE: if discolouration of the heating
plates has occurred, this can be easily removed by descaling your percolator.

• Take care when pouring – pour slowly and do not over-tilt the percolator.

• Allow the percolator to cool down completely before cleaning and storing.

• CAUTION: to prevent damage to the appliance, do not use alkaline

cleaning agents. When cleaning, use a soft cloth and a mild detergent.

• The use of accessory attachments not recommended by Dualit may result

in re, electric shock or injury to persons.

• Use handles or knobs do not touch hot surfaces.

• Water will remain hot for a considerable time after boiling and can present

a scald hazard.

• Keep the percolator, power base and the mains lead away from the edge

of worktops and out the reach of children.

• Do not allow the mains lead to hang over the edge of the worktop, or

anywhere it may accidentally be caught or tripped over.

• Do not switch on unless the percolator contains at least four

cupfuls of water.

• Do not operate unless oor of the percolator is covered.

• Do not ll above the 10 cup mark on the water level indicator.

• Ensure the clear knob on the lid is not damaged or cracked

before use.

• Do not operate the percolator if lled with descaling

solution.

SAVE THESE INSTRUCTIONS

Unpack the box with care, keeping all the packaging materials until you are satised
everything is present and in working order. Once satised remove any tags from the

appliance body and recycle the packaging appropriately. Do not remove tags from the
cord. You may wish to keep the box to store your appliance.

DON’T FORGET TO

REGISTER YOUR
PERCOLATOR

WWW. DUALIT.COM/REGISTER

OR BY POST

KNOW YOUR PERCOLATOR

P

L

U

G

I

N

B

E

F

O

R

E

U

S

E

USING THE PERCOLATOR

LID

MIN & MAX MARK

WATER INDICATOR

SPOUT

HANDLE

INDICATOR LIGHT

ON/OFF SWITCH

CORD TIDY

In the interest of improving products, Dualit Ltd. reserves the right to change the product specication without prior notice.

All illustrations are for representation only, your model may vary from illustrations shown.

SETTING UP

BASKET

ASSEMBLY

COVER

CUP
INDICATOR

BASKET

PERCOLATOR
TUBE

The cup markings are given purely as a guide. Adjust coffee/tea and water quanities to your taste.
The percolator can be used for either coffee or tea, if you switch between the two clean all parts thoroughly.

4

TEA

For tea, we recommend 4 tea bags for a

maximum capacity of 10 cups, adjust for

personal preference. Note, not suitable for
loose tea.

7

SWITCH ON

INSERT TUBE

5

Once lled, lightly tap the basket to release

any loose grounds of coffee from holes on
the underside of the basket. Then insert the
percolator tube through the basket until it
rests on the spring.

8

POUR

AUTO OFF

Lower the basket assembly into the
percolator, aligning the bottom of the
percolator tube on the centre element of the
percolator. Add the cover to the basket and

push the lid rmly onto the percolator.

LOWER BASKET ASSEMBLY

6

9

SWITCH OFF

AFTER 45

MINS

Before rst use or if the percolator has been out of use for a long time, ll to the 10 cup mark and use without coffee for one

operation, then discard the water and rinse the percolator out with fresh cold water.

1

POSITION

Place the percolator as close to the
wall socket as possible. When in use
ensure the percolator is not placed
under kitchen cabinets.

DO NOT STORE OR USE YOUR PERCOLATOR IN AN APPLIANCE GARAGE OR UNDER CUPBOARDS.

2

CORD TIDY

Use the shortest cord possible.
Wrap excess cord round the
cord tidy on the base of
the percolator.

3 4

INCLINED PLANE NOT IN A TRAY

Do not operate on an inclined
plane.

Do not operate in a tray.

USING THE PERCOLATOR

WARNING: IF THE PERCOLATOR HAS JUST BOILED, IT WILL BE FULL OF STEAM, WHICH WILL ESCAPE AS SOON
AS THE LID IS OPENED.

1

REMOVE LID
& ASSEMBLY

2

FILLING

3

COFFEE

Plug in and place the percolator onto the power
base and switch on. The indicator light will cycle
between orange and off when brewing, then
turn green when ready. This will take between
5-10 mins dependent on capacity and will keep
your tea/coffee warm for up to 30-40 mins.

CLEANING & CARE

1

DISCARD WASH

N

E

N

H

W

G

U

L

P

N

U

Unplug and let the percolator cool down
completely before cleaning. Remove the
percolator from the power base and discard
any remaining liquid. Remove the lid and
basket assembly. Dispose of the used coffee
grounds or tea bags.

O

T

Remove the percolator from the power
base before pouring. To avoid splashing, pour
slowly and do not over-tilt. For tea - serve
immediately. If the percolator is left idle for
45 minutes, it will switch off. We recommend
discarding any remaining content and for
further beverages return to point 1.

2

I

N

U

S

E

Wash with hot, soapy water, rinse in clean cold
water and dry thoroughly. Wipe the outside
and inside surfaces of the percolator with a
soft, damp cloth. Do not immerse the

body or power base in water. Please
note, this product is not dishwasher safe.

After use, always remove from the power
base, switch off and unplug.

Never leave unattended. Warning: if
the percolator has just been used the
contents will be hot.

DESCALE REGULARLY

3

Use descaling products suitable for kitchen
appliances, these are readily available online or
from most supermarkets or department stores.
Use as per instructions on the packet.

Follow these few simple steps to minimise
scale build up: Empty the percolator after
each use; do not allow water to stand in the
percolator overnight. Use ltered water instead
of tap water. Descale regularly, at least once a
month. If you live in a hard water area you may
need to descale more often. When descaling

has nished, empty the percolator and rinse

it out a minimum of 3 times with fresh water,

then rell with fresh water, boil, then discard

boiled water. FAILURE TO DO SO
CAN CAUSE INJURY.

DO NOT OPERATE PERCOLATOR

WITH DESCALING SOLUTION IN IT.

Remove the percolator from the power base
and lift the lid off. Then remove the basket
assembly.

Fill the percolator with the required amount
of water. The capacity, in cups, is marked on
the inside wall of the percolator, minimum
4 cupfuls of water and a maximum of 10.

Do not overll; boiling water may be

ejected, causing a scalding hazard.

For coffee, put the required amount of course,
ground coffee in the basket by referring to the
cup indicator marks which correspond with the
water indicator in the percolator.

Tip: When lling the basket, put a nger over

the centre tube to prevent coffee grounds
from falling through.

INSTRUCTIONS ON ENVIRONMENT PROTECTION

Do not dispose of this product in the usual household garbage at the end of its life cycle. Please hand
it over to a collection point for the recycling of electrical and electronic appliances. The symbol on the
product, the instruction of use or the packaging will inform you about the methods of disposal. The
materials are recyclable as mentioned on its marking. By recycling, material recycling or other forms of
re-utilization of old appliances you are making an important contribution to protect our environment.
Please inquire at the community administration for the authorised disposal location.
