DSP9100 IP Network Server
Zone adding: newly increased partitions can be added and display automatically
without settings or host restart; 200 partitions can be added in total.
Zones can be grouped to operate such as switching on/off and volume turning down
/up.
Display grouping information, partition status (on-off/volume/real-time program name),
program list and timing point information.
Support broadcasting program operation on single or multiple grouping (s) or zone (s).
It has two control modes including program control and manual control on all
partitions.
It can set limitless number of time point solutions, which supports backup saving. It can
add / modify / delete the timing points and send the points to assigned zone.
High-capacity program source space is built in and can be classified based on users’
needs.
It can synchronize common programs into network voice box.
Support system remote upgrading on loudspeaker box and intelligent paging centers.
10/100M adaptive, support DHCP/IP setting, LAN and WAN
Small in size, low-power dissipation and energy-saving without screen
Industrial design to ensure reliable operation
APP of network broadcast software supports mobile platform. You can use iPad to
control wirelessly the network terminal software
Features
Term
Specification
Processor
Intel Celeron
RAM
2G/DDR3
Hard disk
64G solid disk
Video interface
HDMI, VGA
Audio interface
One Headphone jack,one microphone
jack
USB
Front：USB * 2，back：USB * 4
Supporting agreement
TCP/IP、UDP、IGMP（Multicast）
Network
RJ45 （10/100M Ethernet）
Power input
~220V /50Hz
Product size（LxWxH）
44×430×214mm
Product weight
2.3kg
Specification
Network broadcasting server applies industrial control host. The system is stable and
reliable. It has built-in SSD solid-state flash drive and anodized aluminum alloy panel so
that it can work for 24hrs all around the clock as well as run normally under
low-temperature or high-temperature for long term. In addition, the complete system needs
no additional maintenance in virtue of mature Ethernet hardware. It has advantages of small
size, low-power dissipation and energy-saving operation. Disposed by professional central
control management software, it can conduct timing point management, built-in program
management and partition management.
