Instruction Manual

1 What's Included

The following components are included with your purchased product:

- 10.1 inch Tablet PC

- Power Adapter

- USB Cable

- Instruction Manual

2 Getting Started

Before operating your Tablet PC for the first time, please read this manual
carefully and follow the instructions as below.

3 Battery charging

The tablet is equipped with a built-in rechargeable Lithium battery. It is
suggested to fully charge the battery before use.
We strongly recommend to use the power adapter included in the
packaging, using other adapter may damage the tablet and void the
warranty.
Charging Process

- Connect the power adapter to your tablet, and plug the power adapter
to the nearest electrical outlet.

- Users can still use the tablet while it is being charged.

3

ENGLISH

3 4 5 6 7 8

4 Appearance and buttons

1. Camera

2. ESC

Press on ESC button will return to the previous interface.

3. Headphone Socket

3.5 mm standard earphone socket

4. HDMI output interface

HDMI output interface

5. Power Socket

1

2

9 10

4

6. Mini USB Port

Mini USB port: you can use it to connect to PC for data transmission,
charging or connection with external USB devices.

7. TF Card Slot

Micro SD card slot

8. USB2.0 Port

Use it to read your U-Disk or other media devices with USB2.0
interface.

9. Menu & Home Button

Menu button and back to Home button. Both buttons can also have
the functions of Volume + and Volume - (press on either button and
hold it for 3 seconds to increase or decrease the sound volume.)

10. Power Switch

Turn on/off tablet

5 Turn ON/OFF Tablet

1. Turn On: after the battery has been fully charged, press & hold the

power switch for around 3 seconds to turn on the device. Screen lock
will be showed after starting up.

2. Turn Off:When the tablet is ON, press & hold the power switch for
around 3 seconds and the system will popup out power off option, tap
on it to turn the tablet off.

3. Lock screen: quickly press Power Switch and release to lock screen.

4. Unlock screen: slide the lock icon rightward onto the unlock icon to

unlock the screen and go to main interface; Slide the lock icon leftward
onto the camera icon to open camera.

5

ENGLISH

6

Remarks:

- When battery power has been used up, the tablet will shut down itself
automatically.

- If you illegally turn off the device, restart will scan and restore the disk,
it may take longer time to enter into system.

6 Connection with PC

1. Use the USB cable provided to connect the tablet with PC, device will

pop up the USB connection window, click “Turn on USB storage”
to connect to PC, in the connection mode, you can copy or delete the
file on the device or the file on the memory device.

7

ENGLISH

7 Tablet Operation Interface

1. After starting up, you will enter into below main screen interface

2. In the main interface, you can manage main interface software

icons: press the icon and hold it for 3 seconds, then you can drag
anywhere in the main interface.

3. Delete icons: press the icon and hold it for 3 seconds, and drag

the icon onto the “Remove” icon, then you can delete that icon
from desktop.

8

4. Touch the screen and hold for around 4 seconds, the dialog box

“Choose wallpaper from” will pop out as shown below:

You can choose the wallpaper from different sources and change
the wallpaper.

9

ENGLISH

5. Status Bar Descriptions

From left to right: Back to previous interface, Back to main interface,
Display the Apps performed previously, Menu key, USB connected, USB
connected, USB debugging connected,TF-card information, Current
time, battery charge icons, current time.

6. Quick Guide For Touch Operations

- No matter which interface you are on the screen, you can go back to
main screen by tapping the key located at the left bottom
corner of the main screen.
[Attention] The key functions as back to main screen
interface.

- During options, by tapping the back key at the left bottom
corner of the touch screen, you can return to previous screen
interface.

- During operations, by tapping the menu key on the left bottom
corner of touch screen, the screen will pop out the below interface:

- Click to see all history of Apps performed previously.

10
