Dry & Store DryMax, DryMax UV Operating Instructions Manual

SAVE THESE INSTRUCTIONS

Introduction

This product has been designed for all types of hearing
instruments, including hearing aids, noise maskers, ear

monitors, ear buds, amplifi ers, and implant equipment.

Used daily, it can help most hearing instruments

sound better, last longer, and perform more reliably.

Technology exclusive to Dry & Store removes damaging
moisture, dries earwax, captures odours, and in high-

humidity conditions, can also extend zinc air battery life.

Additionally, the DryMax-UV model improves comfort by
killing the bacteria that are the most common cause of skin

irritation among hearing device users.

Before Your First Use (Important)

1. Activate the desiccant: A disposable “Dry-Brik® Mini”,

which should be replaced every month, is included. The

Dry-Brik performs three important functions: (1) to
permanently remove the moisture molecules that are
released from the devices during the drying cycle, (2) to
drive the relative humidity inside the box to a much lower
level than is possible with just a heater, thus maximizing

the drying capability, and (3) to capture odours.

To activate the Dry-Brik Mini,

remove the foil cover. Do not remove

the foil until you are ready to use the
Dry-Brik, because once it is removed
the Dry-Brik will begin adsorbing

moisture.

2. Record the activation date: To alert

you when it is time for replacement,

a card is attached to each Dry-Brik.

Write the date that the Dry-Brik was

placed in service on this card.

NOTE: To ensure maximum
performance, change the
Dry-Brik Mini every month.

3. Place the activated Dry-Brik Mini
in your unit, as shown in Figure 3.

4. Connect the AC adapter: The

micro-USB plug fits into the rear

of the unit. Do not force; it should
slide in easily. Finally, plug the AC adapter into an active
electrical outlet.

O

perating Instructions

READ ALL INSTRUCTIONS BEFORE USING

IMPORTANT SAFEGUARDS

This product is for household use. When using electrical

products, especially when children are present, basic safety
precautions should always be followed, including:

DANGE R – To reduce the risk of electrocution:

• Do not use while bathing.

• Do not place or store product where it can fall or be

pulled into a tub or sink.

• Do not place in or drop into water or other liquid.

• Do not reach for this device if it has fallen into water.
Unplug immediately.

WARNING – To reduce the risk of burns, electrocution, fi re,

or injury to persons:

• Closely supervise use of the product by, on or near
children or disabled individuals.

• Use this product only for its intended use as described

in this manual.

• Never operate this product if it has a damaged cord or
plug, if it is not working properly, if it has been dropped

or damaged, or dropped into water. Return it to the

place of purchase or service center for examination

and repair.

• Never place the product on a soft surface such as a bed.
Keep any air openings free of lint, hair, and the like.

• Do not use outdoors or operate where aerosol (spray)
products are being used or where oxygen is being

administered.

• The AC adapter included with your unit is made
specifi cally for this product. Do not use it with another

appliance, and do not use an adapter from any other

electrical device in its place.

• DryMax-UV only: The lamp illuminates only when the

lid is closed in order to prevent exposure to the UV-C
light. Do not modify any components to override this
safety feature. Do not look directly at the UV-C lamp
while illuminated. If the lamp shatters, unplug the
appliance immediately. Do not use until the appliance
has been repaired by an authorized service center.
Wear gloves when contacting any glass particles.
Dispose of properly.

NOTE: This product is not designed to diagnose,
prevent, monitor, treat, or alleviate disease.

OPERATING CONDITIONS

The operating temperature of this appliance is a range

of 95° to 104° F (35°- 40° C). This appliance will function
properly at indoor ambient temperatures from 65°- 86° F
(18°- 30° C).

Some models do not contain a germicidal lamp. If this applies to your appliance, disregard any instruction or comment that refers to “germicidal”, “blue light”,

“ultraviolet”, “UV”, “UV-C”, or “lamp”.

1

2

4

DM / DM-UV INSTR (ENG) 0718 Rev B

Instructions for Use

1. Wipe excess moisture and earwax from your hearing aids

before placing them in the drying chamber.

You may place as many components in the drying

compartment as will comfortably fit without crowding in

order to allow unimpeded air flow.

You can leave the batteries in, but open the battery cover

to allow for air circulation.

2. Close the lid and lightly touch the

start button, which is on the top of

the unit on the right side. (Figure 5).

A green dot will glow just above

the start button. DryMax turns off
automatically after 8 hours.

Best results come from a complete 8-hour cycle, but

periods as short as 30 minutes will be beneficial.

3. It is important that the Dry-Brik Mini be replaced one

month from the date of activation in order to ensure the

highest level of care for your hearing instruments. Discard
the depleted Dry-Brik Mini in household refuse.

About the UV-C Sanitizing Cycle*

(DryMax-UV model only)

If you r un i t ha s a UV- C sanitizing la mp (DryMa x-UV model),

a blue light will be visible for 1½ minutes after the unit is

started, indicating that the sanitizing cycle is operating.

Note: All operations cease when the lid is opened, which also

resets the timer.

The lamp in the DryMax-UV kills germs, bacteria, and mold

by emitting UV-C light at the peak germicidal wavelength
(254 nm). Many users will experience reduced itching and
irritation as a result. However, this appliance is not a sterilizer,

and the manufacturer makes no claims as to degree of

bacterial kill. It is not designed to diagnose, prevent, monitor,
treat, or alleviate disease. The UV-C lamp does not affect the
heating/drying cycle.

Use with Implant Equipment

Implant hardware must be kept dry to function properly,

and regular use of this appliance eliminates the moisture

that accumulates from the environment and/or perspiration.

Leave zinc-air batteries in the processor (where applicable)

but remove the battery cover. Place the processor, headpiece
and cable in the drying compartment.

For two sets of implant equipment, the DryBrik Mini can

be positioned between the two to separate the magnets from

each other.

General Product Care

For best results, do not operate this appliance in high­humidity locations such as a bathroom. Keep the lid closed at

all times, because the effectiveness of the Dry-Brik Mini will
be reduced due to moisture adsorption from the surrounding

air. Clean with a soft cloth. Never use strong cleaning agents
or abrasives. Do not spray any liquid into the tray or onto the
UV lamp.

Troubleshooting Tips

• If no lights illuminate after touching the start button:

Is the lid completely closed and has the start button been
touched? If yes, verify that the AC adapter is securely

connected to both the appliance and the electrical socket,
and that the electric socket is not controlled by a wall

switch which is in the off position. Next, try another
AC adapter (available from the place of purchase or at
www.dryandstore.com). Replace it only with an adapter
provided by the manufacturer. If the unit still will not

start, the internal electronics may be faulty, so return it

to the place of purchase or service center for evaluation.

• If unit is noisy: Noise problems are usually fan-related.

Sound resonates inside the unit, so some noise is to be

expected, even from the high-quality ball-bearing fan
used in this product. If the fan noise varies in intensity
or frequency, return the unit to the place of purchase or
service center for evaluation.

• If unit is not drying properly: Has the Dr y-Brik Mini been
replaced regularly? It is important that it be replaced every
month according to the instructions. Since the appliance

operates slightly above body temperature, when you place
the palm of your hand on top of the lid, it should feel

warm within 30 minutes of startup. Also check for fan

movement by listening closely or by pressing your hand

on the lid to feel a very slight vibration.

• If no blue light is visible (DryMax-UV model only):

Note: The UV-C lamp comes on 2 to 3 seconds after

touching the start button on the lid of the DryMax-UV,

and then stays on for only 90 seconds. The lid must be

completely closed for the lamp to operate, and it turns off

when the lid is opened. The lamp function does not affect
the temperature or the duration of the 8 hour drying cycle.
If no blue light is visible, then it will be necessary to have
the unit serviced.

Contact for service if these

troubleshooting tips do not solve the issue:

In North America, call Customer Service at

1-888-327-1299 or visit www.dryandstore.com/help

Outside North America, contact the place of purchase

or a service center for evaluation.

Some models do not contain a germicidal lamp. If this applies to your appliance, disregard any instruction or comment that refers to “germicidal”, “blue light”,

“ultraviolet”, “UV”, “UV-C”, or “lamp”.

5

DM / DM-UV INSTR (ENG) 0718 Rev B
