13. ABOUT US
Driven by the passion for innovation, we at Dr Trust endeavour to provide
our customers with the latest medical inventions with an objective to
promote good health and wellness all around the world. All the medical
devices and health monitors provided by Dr Trust are supported by
accurate, latest and ground breaking technologies, innovated at our
headquarters in NY, USA. All our products adhere to the most stringent CE
and FDA guidelines and are strongly recommended by doctors and health
practitioners. Our products are designed in the utmost exemplary ways to
ensure that their accuracy and convenience are unrivalled. The ease of their
use and operation makes them even more suitable for users of all age
groups.
Dr Trust strives to enhance the quality of lifestyle by providing with the most
trusted and innovative health care and wellness products. Being a
renowned global leader in health care products, Dr Trust ensures that our
technically efficient team works dynamically and tirelessly to provide the
best of the medical devices to our clients. The products that we have to offer
are suitably designed for use at homes, laboratories and hospitals.
WALKER
The Premium Quality Power of Mobility
Our ground breaking solutions allow you to monitor your health in the
easiest ways possible. In today's era when all of our lives are too hassled to
handle, it becomes a bit difficult to pay attention to our health. But it has
now become easier with the coming of the monitoring devices which can
be conveniently used at homes and even on the go.
We bring to you a variety of best self medical devices, trusted and used
by Doctors, medical professionals and home users all over the world.
12
Page 2
TABLE OF CONTENTS
1. INTRODUCTION
1. INTRODUCTION
2. ASSEMBLY INSTRUCTIONS
3. WALKER KEY FEATURES
4. WALKER USAGE BASICS
5. FOLDING AND UNFOLDING THE WALKER
6. WALKER HEIGHT ADJUSTMENT
7. HOW TO USE THE WALKER
l Three-point Gait
l Wheelchair To Walker Transfer
l Wheelchair to Walker Transfer
(with lower extremity injury to right leg or foot)
l Adjustments
8. PRODUCT SPECIFICATIONS
3
Dr Trust Walker is ergonomically designed to provide a large base of support
3
4
and balance to a person who is unable to walk or who needs mobility
assistance because of age or other medical conditions like nervous disorder,
fracture, surgery, stroke etc. It is made up of anodized aluminum frames
5
5
6
which are durable and lightweight. The rubber bottoms allow the users to
walk comfortably and safely on a variety of surfaces. Its feet also facilitate a
strong grip on the oor and aids in maintaining a balance while walking.
Additionally, with easy to open and fold design it offers more relaxed and
6
stable walk for users every time.
Weight Capacity: 100 kg
2. ASSEMBLY INSTRUCTIONS
1. Open the package and remove all contents from it.
2. Carefully open walker and engage its rear push locks and it is ready to use.
8
9. MAINTENANCE AND CARE
10. SAFETY CAUTIONS
11. Q&A
12. WARRANTY
13. ABOUT US
9
9
10
11
12
CAUTIONS
l This is a walking aid only. It is not to be used as a transportation device.
l Do not attempt to operate walker without reading and understanding
the instructions contained in this manual.
l Make sure that this walker has been fully opened and adjusted to your
height. The handles should be at the level of your hips. Your elbows
should be slightly bent when you hold the handles.
Page 3
l Must test it for stability before applying full weight to hand grips.
lUnique U-shaped frame design creates greater clearance.
If you fail to understand the instructions given in the manual, serious bodily
injury and damage may occur. To understand the cautions and instructions
correctly contact a professional or technical personnel before use.
3. WALKER KEY FEATURES
lA lightweight aluminum u-shape frame that combines strength 7
durability for the user to maneuver.
lComfortable with contoured hand grips
lCan be adjusted to accommodate all users
lEasy folding and push mechanism with safety lock eases transportation
and storage.
lMade up of stable and sturdy anodized aluminum frames.
lPromotes natural walking.
lComfortable use with pleasing looks.
lThe patient is able to bring the walker closer to assist in standing because
of the improved cross-frame.
lHave a rubber tip on the bottom of each of the four legs.
lFrame folds easily using the push button mechanism.
lMaximum stability when standing.
4. WALKER USAGE BASICS
l It does not have wheels, so you will need to lift it and place it in front of
you to move forward.
l All its 4 tips need to be on the ground before you put your weight on it.
l Look forward when you are walking, not down at your feet.
lVery reliable in working with reverse-roll locks.
lEasy to carry & fold.
lDesigned to provide full weight bearing.
lSmooth functioning ensured.
lEach side operates independently to allow easy movement through
narrow spaces and greater stability while standing.
l Use a chair with armrests to make sitting and standing easier.
5. FOLDING AND UNFOLDING THE WALKER
l To unfold the walker, pull the handgrip and rearlegs away from each
other, and the walker should begin to unfold. Continue to unfold the
frame until the latchsnap buttons extend and lock.
l To fold the walker, face it from the open end, press the latch snap
buttons, tilt the walker so that it rests on its rear legs only, and push the
front legs towards the rear legs.
Page 4
6. WALKER HEIGHT ADJUSTMENT
Step 2
l Adjust the height of the walker in a way so that the top, rear bar is
aligned with the middle of the user's buttocks. To do this, press the snap
buttons on each leg and slide the leg up or down as needed.
l After installing or adjusting the legs, one must check if all four leg
extensions are adjusted to the same height, using the same snap
button hole.
l The snap buttons protrude fully from the adjustment holes.
Height Measurement: Measured from the oor to top of the grip. This
7. HOW TO USE THE WALKER
It is a walker without wheels. It has a rubber tip on the bottom of each of
the four legs.
Three-point Gait
Lift the walker up and place it in front of you
making sure all four legs end up on the oor.
(pic 2)
(pic 2)
Step 3
Carefully walk forward, one step at a time. (pic
3)
(pic 3)
To walk safely, you need to stand inside the frame, grasp the handles on each
side, lift the walker, place it down a few inches in front of you, and then you
step forward.
Step 1
Align the middle of your feet with the
back legs of the walker. (pic 1)
(pic 1)
WHEELCHAIR TO WALKER TRANSFER
Make certain that the wheels of the wheelchair are locked. Lift your body by
pushing down on the arm-rest and carefully transfer, one hand at a time, to
the walker (You can also ask for assistance if you feel uncertain).
Page 5
WHEELCHAIR TO WALKER TRANSFER
(WITH LOWER EXTREMITY INJURY TO RIGHT LEG OR FOOT)
Make certain the wheels of the wheelchair are locked. Lift your body by
pushing down on the arm-rests and carefully transfer the left hand rst,
followed by the right hand (if the injury is on the left leg or foot, transfer the
right hand rst, followed by the left).
ADJUSTMENTS
Walker is ergonomically shaped which provides a larger base of support
and aids in maintaining a balance while walking. The released handles make
it easy to open and close for enhanced stability and comfort.
l Adjust the walker so that when your arm is extended, the walker
handle is at wrist height.
l Elbows should be exed at 20°to 30 .
9. MAINTENANCE AND CARE
l Inspect the walker regularly. Tighten the nut sand bolts as necessary.
l If a problem is discovered that may impact the product's function,
immediately eradicate it.
l Use water and, if needed, soap to clean the walker.
l Avoid any undue stress to the walker while using, storing, or
transporting it.
l Each time you unfold or adjust the walker, ensure that snap buttons
fully extend from their corresponding holes.
10. SAFETY CAUTIONS
l Do not use this product without reading and understanding the
instructions explained in this manual.
l Do not use with broken or missing body parts.
CAUTIONS
Be aware of;
ü Throw rugs ü Toys ü Cracks in the oor
ü Drapes ü Animals ü Liquids or puddles
8. SPECIFICATIONS
Weight 2.76kg
Height Range 76-84 cm
Frontal Width 55 cm
Lateral Width 48 cm
Weight Capacity 100 kg
l Do not use the product in any way other than described herein.
l Do not exceed the maximum weight capacity as this could result in a
serious injury. Its maximum weight capacity: 100kg
l Do not use the walker to walk backwards, down gradients or to climb
stairs, curbs, or to go over obstacles or serious injury may occur.
l Do not perform any adjustments to the walker while it is in use.
l Do not use the walker to provide assistance while rising from a lower
position. If you use it to pull yourself up to a standing position this could
result in a fall.
Page 6
l Do not hang anything from the frame of the walker.
Serious injury may result from improper use of this walker. If you are unable
to understand the warnings, cautions, or instructions, contact a health care
professional, dealer, or technical personnel before use. Even you can ask your
doctor, physical, or occupational therapist or other qualied professional to
assure the proper height adjustment.
11. Q & A
Who Would Need a Walker?
A walker is a good option for those who are in need of mobility assistance.
Also, those with poor upper arm strength, or who are unable to balance
may prefer the security offered by a walker. It allows individuals to walk
independently and aid in accommodating a more active lifestyle.
What are the benets of using a walker?
Walkers are good choices for individuals with limited mobility and special
functionality needs. They offer these people the best and safest choice to
regain their freedom and independence of motion. They increase
condence and make them more independent. Additionally, there is less
danger of falling. Posture, strength and endurance may improve.
How to Use a Walker Properly?
Individuals should hold both handles rmly, but without causing tension
in the hands. Walk slowly, at a steady pace, and stay alert for obstacles that
could cause a fall. While the other way is by following the general
guidelines explained in the manual, one can use the walker properly.
www.drtrustusa.com
@drtrust
@drtrustisin
COPYRIGHT 2018 DR TRUST. ALL RIGHTS RESERVED
