Drive 12036-ADJ User Manual

adjustable height bathtub
safety rail

altura adjustable barra de
seguridad para bañera

hauteur reglable barre de
sécurité pour baignoire

item 12036-ADJ

www.drivemedical.com

Item # 12036-ADJ

Shown

NOTE Safety Rail often requires retightening

from time to time. Check periodically before
use and retighten as needed.

installation instructions

1. Clean bathtub thoroughly and wipe dry
before applying rail. Contact surfaces must
be dry and free of soapy residue to assure
secure installation.

2. Loosen knob (A) until rail is wide enough to
slip on side of bathtub.

3. Place Safety Rail on bathtub with knob (A)
facing outside of tub and tighten until rail
feels tight and secure.

4. To test installation of rail, pull forward, back
and side to side. If rail slips or moves, make
sure surface is free of soapy film and is dry,
then replace at desired location
and retighten.

height adjustment

1. After the tub rail in installed on the tub,
remove the locking collars (figure 1). Once
removed, pull up or push down from the top
of the handle to the desired height. Once
the desired height is determined, making
sure both holes line up, replace the both
locking collars. Be sure the locking pins go
through the tubing and protrudes on the
opposite side.

CAUTION Please use extreme care when

installing on fiberglass tubs.
DO NOT OVERTIGHTEN as the clamp may
crack the fiberglass.

figure 1
