Page 1
Odor Sensor
Negative Ions (NO OZONE)
Air Quality Sensor (PM2.5)
Remote Control
Ultra Quiet Sleep Mode
Multi Stage Filtration
User Manual
UV Light
Intelligent All In One
Page 2
Performance Indicators
Purifier Features
Illustration of the Product
Installation Instructions
Function Descriptions
Humidifier Functions
Cleaning the Filter s
Precautions
Intelligent AirQualitySystem
Troubleshooting
Warranty
1
1
3
4
6
8
9
10
11
12
13
CONTENTS
Page 3
www.DrevalAir.com
1
PERFORMANCE INDICATORS
PURIFIER FEATURES
Cold Catalyst Filter
Product Name Air Purifier Model D950
Purification
Method
1. Cold Catalyst Filter 2. Cellular Activated Carbon Filter
3. Anti-Bacterial Filter 4. High Eciency HEPA 5. UV Lamp,
6. Negative ion Generator 7. Ultrasonic Humidifier
Application Area 430 sq ft’
Net Weight 14.5 LBS
Air Purification
Capacity CADR
220m’/h (for PM 2.5)
Wind Speed
High Speed:
5.8m-6.8m/s
Medium Speed:
3.5m-4.5m/s
Low Speed:
1.5m-2.5m/s
Wind Velocity 3 Speeds select High, Medium, Low
Noise
High 55 dB Medium 30dB
Low 18 dB
Dimension L14x W 7.5 x 22 inch
Rated Voltage
AC 11 OV-120V or 220V-240V
Please refer to the nameplate on the back of machine.
Rated power
humidification
15 W
Added Features
Ultrasonic Humidifier , Intelligent Odor Sensor Control, Air Quality
Sensor Humidity Indicator
1. The cold catalyst will play a catalyst eect in normal living environment without
any external assistance like UV light, sunlight, high temperature or pressure.
2. lt catalyzes the formaldehyde, ammonia, benzene, TVOC, hydrogen sulfide and
other harmful gases to work with oxygen, and then decompose them into water
and carbon dioxide.
3. The cold catalyst itself does not change during the decomposition process, thus
the cold catalyst is long lasting and can be valid up to 5 years.
4. The main ingredients of the catalyst are food and medicine additives.
Therefore,the product is of non-toxic, non-corrosive and non-flammable. It
works under normal condition and produces only water and carbon dioxide.
5. The cold catalyst can be used to deal with formaldehyde, ammonia, benzene,
TVOC, hydrogen sulfide and other harmful gases released by plywood, furniture,
wallpapers, carpets, curtains and bedspreads.
Rated power
purification
Designed in USA Made in China
Power
frequency
45 W 60 HZ
Page 4
www.DrevalAir.com
2
Cellular-Activated Carbon Filter
Anti-bacterial Filte
High Eciency HEPA Filter
Anion Release
Ultraviolet Sterilize Light
Intelligent Air Quality System
Ultrasonic Humidifier
The cellular-activated carbon carries high ecient additives. It has excellent
absorption and dust collection abilities.
The 5-microns filter with antimicrobial agents can eciently kill bacteria in the air.
The precision of the HEPA filter is 0.01-0.03 micron. It is able to eliminate particles
larger than 0.03 micron with the filtration rate of 99.07% or more. Dust, bacteria,
fungi, viruses, allergens and other small and tiny particles are not able to get through
the HEPA filter.
The ionizer releases anions and makes the oxygen in the air electronegative thus
gathering the positively-charged particles like floating dust, bacteria, viruses and smoke.
The particles become denser and can be easily trapped by filters or sink to the ground.
The smaller the particle size, the higher the capture rate. Does not produce Ozone.
A variety of bacteria and airborne viruses can be killed by the 365nm ultraviolet light.
The UV germicidal lamp is used to purify the air and it is able to eliminate odor caused
by smoke and mold. Besides, it also produces a certain amount of negative ions, which
freshens the air in the room.
This unit comes with an intelligent Air Quality sensor , Humidity Sensor and display.
It can automatically adjust the fan speed according to the setting and displays Air
quality: Red (Poor), Orange (Ordinary), Green (Excellent).
The unit comes with humidification function. User may turn on the humidification
function ( especially in a dry weather or heated room) to:
1. Increase air humidity and improve the quality of respiration.
2. Moisturize the skin.
3. Improve human body’s metabolism, relieve tension and fatigue.
4. Eectively remove the musty odor caused by smoke and mold.
Page 5
www.DrevalAir.com
3
Control Panel Odor Sensor Outfalls
Front Plate Air Outlet Display Panel
Middle Case Rear Case
Remote Control
Receiver
Humiditity Sensor Water Tank Dumping Switch
Air Quality
Display Board
Handle Control Button
ILLUSTRATION OF THE PRODUCT
15
1 6 11
2 7 12
3 8 13
4 9 14
5 10 15
12 13
4
3
14
1
2
5
6
11
10
9
8
7
Page 6
www.DrevalAir.com
4
INSTALLATION INSTRUCTIONS
Filter Installation Instructions
With your thumb against the front panel,
and your right hand in the gap at the
front panel of the machine, gently pull on
the panel to open the front panel.
Make sure the filters are installed
in position. Turn the buckles to
secure the filters.
Remove all packaging bags of
filter 1 and filter 2.
1
23
Page 7
www.DrevalAir.com
5
Filter Replacement Diagram and Instructions
Place Filter 2 (Antimicrobial
Filter and HEPA Compound
Filters) back into the inner side
of the product. Note: Ensure the
tab side is facing you.
Make sure the filters are
installed in position. Turn the
buckles to secure the filters.
To install the front panel, place
the bottom part into the host
buckle and close the front
panel. The front panel will be
held by built-in magnets.
Place Filter 1 (Cold Catalyst and
Activated Carbon. Compound
Filters) back into the inner side
of the product. Note: Ensure the
tab side is facing you
1
3 4
2
Page 8
www.DrevalAir.com
6
FUNCTION DESCRIPTIONS
The product is equipped with a remote controller powered by
DC3V batteries. If no power please configure the battery by
yourself. Do not directly connect with the family power and use.
Please use the remote control product positive. (If you use a
dierent angle, will cause no conduction phenomenon, this is a
normal phenomenon, please adjust the use of perspective.)
Product powered, have a buzzer sounds. The digital screen
display the machine is in stand-by mode. “00”.
When pressing on the On/O button, the tree design will flash in
the digital screen.
When pressing on the timer button, the machine is turned on and
the intelligent odor sensor control is started, too. The machine
will adjust the speed automatically according to the air quality.
The timer starts from 1 -12 hours. The power will be turned o
when time expires.
The speed control button circulates from low, medium, high and
o. The speed is shown on the digital screen.
1
2
3
4
5
Page 9
www.DrevalAir.com
7
When pressing on the sleep button, the machine will be at low
speed and the intelligent odor sensor control is turned o. The
speed and sleep buttons are controlled in a mutually exclusive
manner. When one is turned on, the other is turned o.
Press the anion button to turn on the anion generator. When it
is turned on. The icon will be shown on the display screen. The
intelligent odor sensor control is turned on automatically at the
same time.
Press the sterilize button to turn on the UV germicidal light and
the icon will be shown on the display screen. When it is turned on.
The intelligent odor sensor control is turned on automatically at
the same time.
Press the Mist button to turn on the humidifier.
Press the AUTO button, the anion, Germicide and wind speed and
mist will turn on automatically. under Auto mode, Wind speed is
automatically adjusted according to the current air quality. Mist
is automatically adjusted according to the amount of current air
humidity.
6
7
8
9
10
Page 10
www.DrevalAir.com
8
FUNCTIONS OF HUMIDIFIER
Press and hold the water tank clasp at 45 ° and remove the water
tank.
Rotate the valve in an anti-clockwise manner. Remove the valve
and fill the tank with water. Once finished, turn and shut the valve
in a clockwise manner. (Please ensure that the rubber seal does
not fall o.)
Keep water tank inclined at 45 ° when installing it back into the
machine.)
After the installation of the water tank, please ensure that no
bubbles are generated before pressing the humidify button. You
can adjust the mist amount by pressing the mist button by low,
medium and high speed.
When the humidifier is not in use, discharge the water from the
water outlet and keep the water tank empty.
1
2
3
4
5
Page 11
www.DrevalAir.com
9
Filter maintenance and cleaning
Humidifier maintenance and cleaning
Ionizer maintenance and cleaning
Best Practices on Cleaning of Filter,
Humidifier and Anion Generator
In order to extend the filter life, the filters
should be exposed to sunlight periodically in
order to release the harmful gas and odor, at
the same time, to kill bacteria.
Use citric acid detergent and follow the
instructions to configure solution, pour into
the humidifier and soak for 10-20 minutes,
then use the toothbrush or cloth to clean
the humidifier, discharge the water through
the outlet, and then rinse one more time.
Use the Brush Pen as cleaning tool, brush tip enter from the airflow outlet on the top
of anion generator Emitter, clean the dust on the emitter from each point of view.
Page 12
www.DrevalAir.com
10
PRECAUTIONS
Do not use this machine in the following environments
Warning
1. When using the machine, there should be a gap of at least 8 inches at both
sides and back of the product, and 12 inches from the top surface for proper air
circulation. Hanging objects should not be placed above the machine, in order
to avoid falling into it. Do not place purifier on uneven ground. Please do not
put this machine next to curtains and furniture so as not to aect the machine
performance.
2. Do not use this machine in a humid or high temperature environment.
3. Do not use this product near gas appliances, heating devices or near stove.
4. This machine is suitable for temperature 41°F - 104°F this machine is only for
indoor use.
1. 1. Before you move the machine, please cut o the power supply.
2. For safety please do not allow children or the disabled to handle the equipment
unsupervised,
3. 3. Before using the machine need to first check the power cord and plug are
damaged, do not bend or pull the power cord, power cord, and power cable; do
not arbitrarily change so as not to loose contact or an electric shock hazard.
4. Do not use wet hand to plug power plug, make sure the local power supply
voltage is the same as indicated on the nameplate on the back of machine.
5. If the machine has trouble, In order to avoid danger, do not secretly open
inspection or maintenance, please discontinue the use of the product and contact
an authorized agent to fix it.
6. This machine shall not be used with a program controller, a timer or any other
automatic switching device used, so as to avoid damage to the machine
7. Never place fingers, hands, or other small objects into any openings, slots, or
holes of machine, such as vents, air outlets, etc. to avoid accidents.
8. 8. Do not block the inlet and outlet, for example, do not place objects in front of
the outlet or inlet.
Page 13
www.DrevalAir.com
11
Memory reset as follows:
Precautions
9. This product is not supposed to be used as daily ventilator, dust cleaner, or cooker
hood.
10. lf the water tank leaks, turn o the power and put the product in an upright
position for 30 minutes before use.
11. Note: Clean odor sensor area and humidity sensor area often to prevent collecting
dust and aecting the eciency.
12. Do not use this product near gas appliances, heating devices or near stove.
13. Please unplug purifier from the socket after use and before cleaning.
14. Please do not use this machine under temperature changes or in a larger
environment because it may create condensation water droplets within the
product.
15. Please use distilled, purified or tap water for humidifier.
16. Do not use any aroma or essential oils.
Intelligent Air Quality system memory reset instructions
If the air quality indicator displays a red light and the machine power is cut o
suddenly, you may have to reset the intelligent memory sensor. Otherwise, the red
light displayed will remain until reset.Long press the sleep button until you hear the
buzzer “drop by drop” sound when air quality indicator light starts blinking
1. When the machine is working on the memory reset function, please make sure
the environment is not heavily polluted
2. lf the memory reset function is used in a heavily polluted environment, the
display light could be wrong.
Page 14
www.DrevalAir.com
12
TROUBLESHOOTING
When the filter system must be cleaned or replaced
Problem Solution
No air comes out from
the outlet
Please check whether the product is turned
on and connected to the power supply.
Outlet airflow is
significantly weakened
than before
The filters are dirty and they need to be
cleanedW or replaced. You can gently shake
the filters to remove the dust and other
objects on it.
The filter packaging bag is not removed.
Please remove the filter packaging bag.
The air quality is not
significantly improved
after
long run of the machine
Check the filter layers installation sequence.
Filters are worn out, you need to replace all
the filters.
When should I replace the
filters
The first filter: The surface is dirty and fades
in color. The tiny hole of the cold catalyst
is blocked by dust or the color of the active
carbon has obviously changed. Life time:
8-14 months.
The second filter: The white HEPA changes to
yellow, black, or mildew. Life time: 8-14
months.
Remarks: The filter life span is determined by
the environment airquality andthe duration
used.
Alarm is Generated Check if the water tank is empty.
Powered Down
Check if the anti-fall o switch is properly
switched o.
Page 15
www.DrevalAir.com
13
DrevalAir warrants this product against defects in materials and workmanship for the 2 Year period
of time from the date of purchase. During this period, DrevalAir warrants that upon receipt of the
product from the owner found to be defective in material or workmanship, DrevalAir will repair
or replace, at its discretion, any defective item at no charge for that item. Replacement products
or repaired parts will be guaranteed for only the unexpired portion of the original warranty or six
months, whichever is greater. This limited warranty does not apply to any defect resulting from
accident, misuse, improper maintenance, or normal wear and tear. Your machine’s proper functioning
and lifetime are only guaranteed with the usage of DrevalAir filters. Any defect resulting from the
usage of non-genuine DrevalAir filters or parts will not be covered by this warranty. If you believe
your product is defective, contact DrevalAir (contact details are below) for instructions on where to
send it for repair. CONTACT DREVALAIR please email [email protected] or call the number 1-888200-3370 Monday through Friday 10AM – 5 PM EST or visit www.DrevalAir.com/contact and fill out
the form.
WARRANTY
Loading...
