photo by courtesy of Sound of Music, India
SIGLOS Series
by
4K & 3D PROJECTORS FOR HOME CINEMA and SMALL VENUES
V1.2
www.dreamvision.net
When Fashion meets Performances
Since 1996, DreamVision, in the shadow of the world-famous Montmartre hill in Paris, has been developing
and rening the latest advancements in digital display technology in order to provide state-of-the-art video
products for Home Cinema. Today, DreamVision is a highly respected, global brand in high-performance
video.
What sets DreamVision apart is this unique blend of latest technologies with high quality materials,
attention to detail and striking European design. The Siglos Series is yet another illustration of this
philosophy.
The projector’s ultra-stylish chassis was created by the famed French designer, Antoine Beon, also known
by the DreamVision fans for his work with the DreamBee and DreamWeaver Series. A contemporary work
of art, Siglos comes standard in black or white. Siglos is available to order in a rainbow of high gloss colors
which can t into any ne interior, including some lifestyle limited editions, such as the beautiful sportscar
red one (called Rosso Special f.) on the picture below.
The small details that make a big difference
Each unit is double checked and calibrated by our 20-years experienced video engineer in order to obtain
a perfect picture quality and nish.
DreamVision also chose the most advanced manufacturing process and luxurious materials chosen for
their extreme rigidity and performance in heat and noise absorption (noise level below 19 dB).
With the Siglos Series, 3D projection at home now becomes a reality
For the DreamVision R&D team it is always very important to do 3D the right way, without sacricing
the performance with regular 2D content.
Therefore, DreamVision is the only brand to offer
the choice between two technologies: Active 3D and
Passive 3D. Active 3D is about pure performance,
whereas Passive 3D is more about comfort, brightness
and cost-effectiveness. Our new Passive 3D solution
is 2x brighter than any equivalent DLP solution on the
market.
Whichever your choice, the supplied 3D kit (either with the
new Active 3D dongle or the new Passive 3D polarizer) of the Siglos will allow an easy integration within
a few minutes time.
Raising the standards of picture quality
The new three-chip system used on the Siglos Series can accomodate high resolutions up to 3840x2160
pixels (also known as 4K). Using the latest technological innovations, DreamVision has achieved a
breathtaking contrast ratio through an improved light engine (60,000:1 for Siglos1, 120,000:1 for Siglos2
and a amazing 150,000:1 for Siglos3).
In addition to jaw-dropping clarity and detail, the Siglos Series also deliver more accurate color reproduction
within billion color graduations for lifelike realism.
®
The Crystal Motion
algorithm is a frame interpolation method which brings an immersive experience to
sport, concerts, TV shows. Picture becomes dramatically realistic and three-dimensional, without motion
blur or artifacts.
regular projector
Siglos Projector
Obviously the Siglos Series are not dedicated to watching singers or footballers only. Thanks to a new
very pure optical lens, the Siglos Series create a new standard in dark colors rendition. When watching a
movie, black is really black - thanks to the implementation of DreamVision’s new True Cinema Black III®
enhancement - and a lot more detailed thanks to the interpolated 4K resolution.
The Siglos have many preset Picture Modes (including THX on Siglos2 and Siglos3). An Expert Calibration
Menu (via RS232) and CMS functions (Color Management System for color calibration) are accessible for
the advanced installers of Siglos2 and 3.
Versatility and Ease of Installation
In addition to its impressive performance, the Siglos projectors are also a snap to install.
The input panel, concealed on the back of the projector,
offers quick access to a wide array of connections.
The 2x zoom, combined with a
variable electronic lens aperture,
allows for perfect adjustment in
virtually any residential installation.
With the new fully motorized
professional lens, the installation
becomes easier and faster.
The Siglos Series will accommodate
almost any kind of setup thanks to
the +/-80% vertical shift and the +/34% horizontal shift, seconded by the
crisp, high quality Keystone.
The optional Theatre System Kit includes
an optically rst-class anamorphic lens and
a motorized lens holder (picture on the right).
No more unpleasant black bars, no more loss
of brightness and no more waste of pixels. Just
sit comfortably, relax and enjoy the show in pure
TM
Cinemascope
format.
All in all, the DreamVision Siglos projectors and their dedicated accessories are
denitely the best compromise on the marketplace for picture quality, brightness/colours and comfort.
215 mm / 8.5’’
Weight
15.1 kg (33.3 lbs)
505 mm / 19.9’’ 505 mm / 19.9’’455 mm / 17.9’’
Model Version SIGLOS 1 SIGLOS 2 SIGLOS 3
P/n ir 3d Pack R9201500 (1x glasses) N/A N/A
P/n rF 3d Pack R9201501 (2x glasses) R9201502 (2x glasses) R9201503 (4x glasses)
P/n PassiVe 3d Pack R9201504 (4x glasses) R9201505 (4x glasses) R9201506 (4x glasses)
Panel Technology 3-chip LCOS 0.7 inch panel (1920x1080 x3)
disPlay resoluTion 3840 x 2160 (4K Resolution)
oPTic Full-glass Motorized Lens (zoom & focus) 1.4 -2.8:1 (2x zoom)
oPTic slide coVer No Yes
screen oFFseT Motorized Optical Shift +/- 80% vertically +/- 34% horizontally
screen size (16:9) 60” - 240” diagonal
laMP consuMPTion 230 W Bulb - up to 4 000 hours (with lamp used in standard mode)
BrighTness 1 300 ansi Lumens
naTiVe conTrasT raTio 60 000:1 120 000:1 150 000:1
dynaMic conTrasT raTio 600 000:1 1 200 000:1 1 500 000:1
noise leVel Less than 19 dB
inPuTs 2x HDMI
adjusTaBle lens aPerTure Auto 1, Auto 2, Manual 16 steps
slM™ sMarT laMPliFe ManageMenT Automatic (Congurable)
exPerT caliBraTion Menu YES (for calibration expert only)
PicTure Mode PreseTs 4 + 4 User Modes 6 Presets + THX + 4 User Modes + 4 for Expert only
color sPace ProFiles 10 Presets + 5 Users 20 Presets + 5 Users
hoMe-cineMa
Video Processing
screen adjusTMenT 106 Modes
3d coMPaTiBiliTy
3d FeaTures 2D to 3D Conversion, 3D V-Stretch (For Theatre System Kit)
cMs FuncTions YES (7-Axis)
Frame Packing, Side-by-Side, Top & Bottom (including 720p/1080p24 Side by Side)
400 Hz Crystal Motion
True Cinema Black III
4K Interpolation (3840 x 2160)
®
®
WeighT 14.3 kg (31.5 lbs) 15.1 kg (33.3 lbs)
diMensions (lxWxh) 505 x 455 x 215 mm (19.9 x 17.9 x 8.5 inches)
hoMe auToMaTion RS-232 (Dsub 9) / LAN RJ45
digiTal keysTone YES V+/- 16° (not in 3D Mode)
PoWer VolTage and consuMPTion AC 110~240V 50/60Hz 360 W / 4.8 W in stand-by / 0.4W in Eco-Mode stand-by
Box diMensions 61x58x41 cm 19.5 kg (67x66x52 cm - 21.5 kg when shipped individually)
oPTions 3D Glasses, Theater System Kit, Ceiling Mount kit, Motorized Lift, special colors and nishes, screens
