Dream Vision Inti+, Intiplus 1 User Manual

2 R699810 - Inti+ Series User Manual

Changes

Dreamvision provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not
limited to the implied warranties or merchantability and fitness for a particular purpose. Dreamvision may make
improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time
without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the
information in this publication; these changes are incorporated in new editions of this publication.

Copyright

All right reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be
recorded, transmitted or stored in a retrieval system without the prior written consent of Dreamvision.

Guarantee

Dreamvision provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of
guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred during
transport, as well as for material and manufacturing faults. Dreamvision must be informed immediately in writing of
any complaints.
If the purchaser or third party caries out modifications or repairs on goods delivered by Dreamvision, or if the goods
are handle incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of
risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will
be rendered invalid. Not included in the guarantee coverage are system failures which are attributed to programs or
special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as normal maintenance
are not subject to the guarantee provided by Dreamvision either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual must
be complied with by the customer.

Trademarks

Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of
their respective holders. All brands and product names mentioned in this manual serve as comments or examples
and are not to be understood as advertising for the products of their manufactures.

R699810 - Inti+ Series User Manual 3

TABLE OF CONTENTS

1.0 SAFETY INSTRUCTIONS ............................................................................................. 5

1.1 Important Information........................................................................................................................ 5

1.2 Important Safeguards......................................................................................................................... 5

1.3 REGIONAL SPECIFIC INFORMATION......................................................................................... 7

2.0 INSTALLATION GUIDELINES .................................................................................... 8

2.1 About 3D Content and 3D Projection................................................................................................ 8

2.2 THX-3D Display Certification (Inti+2 & +3).................................................................................... 8

2.3 Comfort and Caution with 3D Content.............................................................................................. 9

2.4 3D-Synchro Emitter........................................................................................................................... 9

2.5 Environment of Use......................................................................................................................... 10

2.6 Air-Flow and Space Requirements.................................................................................................. 10

2.7 Ceiling Mounting the Unit............................................................................................................... 10

2.8 Projection Distance.......................................................................................................................... 11

2.9 Setting the Lens and using Lens Memories.....................................................................................12

3.0 REMOTE CONTROL UNIT (RCU) ............................................................................ 14

3.1 General View ................................................................................................................................... 14

3.2 Loading and replacing batteries....................................................................................................... 14

3.3 How to use the Remote Control Unit............................................................................................... 15

4.0 GETTING STARTED .................................................................................................... 16

4.1 General View ................................................................................................................................... 16

4.2 Connecting the Power Cord............................................................................................................. 17

4.3 Operating LEDs ............................................................................................................................... 17

4.4 Operating and Navigation Buttons .................................................................................................. 18

5.0 CONNECTIONS............................................................................................................. 19

5.1 Caution when connecting a device to HDMI input ......................................................................... 19

5.2 Connecting a Video Source to the Projector .................................................................................... 19

5.3 Connecting an Automation or Control device ................................................................................. 20

6.0 MENU AND PICTURE SETTING............................................................................... 21

6.1 Menu Structure ................................................................................................................................ 21

6.2 Picture Adjust menu......................................................................................................................... 25

Picture Mode and Color Profiles....................................................................................... 25

Color Profiles (Inti+2 & +3) ............................................................................................. 25

Color Temperature............................................................................................................. 25

Gamma .............................................................................................................................. 25

Dark / Bright Level ........................................................................................................... 26

Picture Tone (Inti+2 & +3 only)........................................................................................ 26

Contrast ............................................................................................................................. 26

Brightness.......................................................................................................................... 26

Color.................................................................................................................................. 26

Tint .................................................................................................................................... 26

Advanced........................................................................................................................... 26

Reset.................................................................................................................................. 28

6.3 Input Signal menu............................................................................................................................ 28

HDMI Inputs .....................................................................................................................28

Component ........................................................................................................................ 28

PC (Inti+2 & +3 only)....................................................................................................... 28

Picture Position ................................................................................................................. 29

Aspect Ratio ...................................................................................................................... 29

Mask.................................................................................................................................. 29

Progressive (only 480i, 576i, 1080i) ................................................................................. 29

3D Setting.......................................................................................................................... 29

6.4 Installation Menu ............................................................................................................................. 30

Lens Control...................................................................................................................... 30

Pixel Adjust (Inti+1 only) ................................................................................................. 30

4 R699810 - Inti+ Series User Manual

Pixel Adjust (Inti+2 & +3 only)........................................................................................ 30

Installation Style................................................................................................................ 31

Keystone............................................................................................................................ 31

Anamorphic....................................................................................................................... 31

Screen Adjust .................................................................................................................... 32

Black Level ....................................................................................................................... 32

6.5 Display Setup Menu......................................................................................................................... 32

Back Color ........................................................................................................................ 32

Menu Position ...................................................................................................................32

Menu Display ....................................................................................................................33

Line Display ...................................................................................................................... 33

Source Display ..................................................................................................................33

Logo .................................................................................................................................. 33

Language ........................................................................................................................... 33

6.6 Function Menu................................................................................................................................. 33

Off-Timer .......................................................................................................................... 33

High Altitude Mode........................................................................................................... 33

Communication Terminal (Inti+2 & +3)........................................................................... 33

Network (Inti+2 & +3)...................................................................................................... 33

Remote Code.....................................................................................................................33

Lamp Reset........................................................................................................................ 33

6.7 Information Menu............................................................................................................................ 33

Input Terminal................................................................................................................... 33

Input Source Format.......................................................................................................... 33

Deep Color Depth ............................................................................................................. 34

Resolution ......................................................................................................................... 34

H. Frequency ..................................................................................................................... 34

V. Frequency ..................................................................................................................... 34

Lamp Time ........................................................................................................................ 34

Calibrator........................................................................................................................... 34

6.8 Expert Calibration (Inti+2 & +3)..................................................................................................... 34

7.0 ANAMORPHIC SETUPS.............................................................................................. 35

7.1 Lens Zoom and Theatre System Kit ................................................................................................ 35

7.2 Using the Remote Control Unit. ...................................................................................................... 35

7.3 Installing a Motorized Anamorphic Lens ........................................................................................ 36

8.0 MAINTENANCE............................................................................................................ 37

8.1 Clean Dirt on the Cabinet ................................................................................................................ 37

8.2 Dirt on the Lens ............................................................................................................................... 37

8.3 Replacing the Lamp......................................................................................................................... 37

8.4 Cleaning and Replacing the Dust Filters ......................................................................................... 38

8.5 Troubleshooting............................................................................................................................... 39

9.0 MISCELLANEOUS ....................................................................................................... 40

9.1 RS-232C protocol ............................................................................................................................ 40

9.2 LAN protocol (Inti+2 & +3)............................................................................................................ 45

9.3 Infra Red, long hex-pronto compatible RCU................................................................................... 47

9.4 Compatible resolutions .................................................................................................................... 47

9.5 Specifications................................................................................................................................... 48

1.0 SAFETY INSTRUCTIONS

R699810 - Inti+ Series User Manual 5

1.0 SAFETY INSTRUCTIONS

1.1 Important Information

Lead-free regulation

This product has a High Intensity Discharge (HID) lamp that contains a small amount of mercury. It also contains
lead in some components.
Disposal of these materials may be regulated in your community due to environmental considerations. For disposal
or recycling information please contact your local authorities, or the Electronics Industries Alliance: http://
www.eiae.org.

Information for Users on Disposal of Old Equipment

This symbol indicates that the electrical and electronic equipment should not be disposed as general
household waste at its end of life. Instead, the product should be handed over to the applicable
collection point for the recycling of electrical and electronic equipment for proper treatment, recovery
and recycling in accordance with your national legislation.
By disposing of this product correctly, you will help to conserve natural resources and will help
prevent potential negative effects on the environment and human health which could otherwise be caused by
inappropriate waste handling of this product.
For more information about collection point and recycling of this product, please contact your local municipal office,
your household waste disposal service or the shop where you purchased the product. Penalties may be applicable
for incorrect disposal of this waste, in accordance with national legislation.

Other Countries outside the European Union:

If you wish to dispose of this product, please do so in accordance with applicable national legislation or other rules
in your country for the treatment of old electrical and electronic equipment.

About the installation place

Do not install the projector in a place that cannot support its weight securely.
If the installation place is not sturdy enough, the projector could fall or overturn, possibly causing personal injury.

1.2 Important Safeguards

Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure
your personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE
HAZARD. In order not to defeat the safeguards incorporated into this product, observe the following basic rules for

its installation, use and service.

Please read these Important Safeguards carefully before use.

• All the safety and operating instructions should be read before the product is operated.

• All warnings on the product and in the operating instructions should be adhered to.

• All operating instructions should be followed.

• Place the projector near a wall outlet where the plug can be easily unplugged.

• Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

• Do not use attachments not recommended by the product manufacturer as they may be hazardous.

• Do not use this product near water. Do not use immediately after moving from a low temperature to high
temperature, as this causes condensation, which may result in fire, electric shock, or other hazards.

CAUTION:

To reduce the risk of electric shock, do not remove cover. Refer servicing to qualified service personnel. This
projector is equipped with a 3-blade grounding type plug to satisfy FCC rule. If you are unable to insert the plug
into the outlet, contact your electrician.

WARNING:

To prevent fire or shock hazards, do not expose this appliance to rain or moisture. This apparatus must be
earthed.

The power input is auto-ranging from 100 to 240 VAC.

1.0 SAFETY INSTRUCTIONS

6 R699810 - Inti+ Series User Manual

• Do not place this product on an unstable cart,
stand, or table. The product may fall, causing
serious injury to a child or adult, and serious
damage to the product. The product should be
mounted according to the manufacturer’s
instructions, and should use a mount
recommended by the manufacturer.

• When the product is used on a cart, care should
be taken to avoid quick stops, excessive force,
and uneven surfaces which may cause the
product and cart to overturn, damaging
equipment or causing possible injury to the
operator.

• Slots and openings in the cabinet are provided
for ventilation. These ensure reliable operation of
the product and protect it from overheating.
These openings must not be blocked or covered.
(The openings should never be blocked by
placing the product on bed, sofa, rug, or similar
surface. It should not be placed in a built-in
installation such as a bookcase or rack unless
proper ventilation is provided and the
manufacturer’s instructions have been adhered
to). For proper ventilation, separate the product
from other equipment, which may prevent
ventilation and keep a distance of more than 5-9”
(150 mm).

• This product should be operated only with the
type of power source indicated on the label. If you
are not sure of the type of power supply to your
home, consult your product dealer or local power
company.

• This product is equipped with a three-wire plug.
This plug will fit only into a grounded power
outlet. If you are unable to insert the plug into the
outlet, contact your electrician to install the
proper outlet. Do not defeat the safety purpose of
the grounded plug.

•Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them. Pay particular
attention to cords at doors, plugs, receptacles,
and the point where they exit from the product.

•For added protection of this product during a
lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the
wall outlet and disconnect the cable system. This
will prevent damage to the product due to
lightning and power line surges.

• Do not overload wall outlets, extension cords, or
convenience receptacles on other equipment as
this can result in a risk of fire or electric shock.

•Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short out parts that could result
in a fire or electric shock. Never spill liquid of any
kind on the product.

• Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltages and other hazards. Refer all
service to qualified service personnel.

• Unplug this product from the wall outlet and refer
service to qualified service personnel under the
following conditions:

a) When the power supply cord or plug is
damaged.

b) If liquid has been spilled, or objects have fallen
on the product.

c) If the product has been exposed to rain or
water.

d) If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the Operation
Manual, as an improper adjustment of controls may
result in damage and will often require extensive
work by a qualified technician to restore the product
to normal operation.

e) If the product has been dropped or damaged in
any way.

f) When the product exhibits a distinct change in
performance - this indicates a need for service.

• When replacement parts are required, be sure
the service technician has used replacement
parts specified by the manufacturer or with same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or
other hazards.

• Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.

• The product should be placed more than one foot
away from heat sources such as radiators, heat
registers, stoves, and other products (including
amplifiers) that produce heat.

• When connecting other products such as VCR’s,
and personal computers, you should turn off the
power of this product for protection against
electric shock.

• Do not place combustible behind the cooling fan.
For example, cloth, paper, matches, aerosol cans
or gas lighters that present special hazards when
over heated.

• Do not look into the projection lens while the
illumination lamp is turned on. Exposure of your
eyes to the strong light can result in impaired
eyesight.

• Do not look into the inside of this unit through
vents (ventilation holes), etc. Do not look at the
illumination lamp directly by opening the cabinet
while the illumination lamp is turned on. The
illumination lamp also contains ultraviolet rays
and the light is so powerful that your eyesight can
be impaired.

• Do not drop, hit, or damage the light-source lamp
(lamp unit) in any way. It may cause the light­source lamp to break and lead to injuries. Do not
use a damaged light source lamp. If the light­source lamp is broken, ask your dealer to repair
it. Fragments from a broken light-source lamp
may cause injuries.

• The light-source lamp used in this projector is a

1.0 SAFETY INSTRUCTIONS

R699810 - Inti+ Series User Manual 7

high pressure mercury lamp. Be careful when disposing of the light source lamp. If anything is unclear, please
consult your dealer.

• Do not ceiling-mount the projector to a place which tends to vibrate; otherwise, the attaching fixture of the
projector could be broken by the vibration, possibly causing it to fall or overturn, which could lead to personal
injury.

• Use only the accessory cord designed for this product to prevent shock.

• The power supply voltage rating of this product is AC120 V, AC100 V – AC240 V, the power cord attached
conforms to the following power supply voltage. Use only the power cord designated by our dealer to ensure
Safety and EMC.

• When it is used by other power supply voltage, power cable must be changed.

• Ensure that the power cable used for the projector is the correct type for the AC outlet in your country. Consult
your product dealer.

• Caution: Do not allow any unqualified person to install the unit. Be sure to ask your dealer to install the unit (e.g.
attaching it to the ceiling) since special technical knowledge and skills are required for installation. If installation
is performed by an unqualified person, it may cause personal injury or electrical shock.

1.3 REGIONAL SPECIFIC INFORMATION

FCC INFORMATION (USA ONLY)

Changes or modification not approved by Dreamvision could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encourage to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC

The Federal Communications Commission (FCC) is an independent United States government agency, created,
directed, and empowered by Congressional statute.
The FCC was established by the Communications Act of 1934 as the successor to the Federal Radio Commission
and is charged with regulating all non-Federal Government use of the radio spectrum, including radio and television
broadcasting, and all interstate telecommunications like wire, satellite and cable as well as all international
communications that originate or terminate in the United States. The FCC's jurisdiction covers the 50 states, the
District of Columbia, and U.S. possessions.

2.0 INSTALLATION GUIDELINES

8 R699810 - Inti+ Series User Manual

2.0 INSTALLATION GUIDELINES

2.1 About 3D Content and 3D Projection

This unit is compatible with 3D playback. The source can be connected using one of the two available HDMI 1.4a
inputs. The 3D effect is based on the binocular parallax which is the difference of the view on a single object when
seen from the left and right eyes, respectively.

Binocular parallax

3D movies use two sets of images: one set for the left eye, the other set for the right eye. These images can be
stored into three compatible formats: Frame packing, Top-&-Bottom or Side-by-Side.

This unit is compatible with the following 3D formats:

• 1080p @ 23.98/24Hz - Frame Packing, Top & Bottom and Side-by-Side

• 720p @ 50 or 59.94/60Hz - Frame Packing, Top & Bottom and Side-by-Side

• 1080i @ 50/60Hz - Frame Packing and Side-by-Side

• 1080p @ 50/60Hz Side by Side

The left and right images are produced alternatively. Therefore, the shutter glasses are used to separate the left eye
images which will be only visible to the left eye, and the right eye images only visible to the right eye. The human
brain then perceives stereo objects based on the visual differences between two images of the same object but
taken from different angles.

The 3D-glasses are used to separate the left and right image, therefore producing a 3D effect.

2.2 THX-3D Display Certification (Inti+2 & +3)

The THX-3D Display certification aim to reproduce faithfully
images at home according to the intentions of the film director
during playback of 2D and 3D images, and they are the proof
of high definition and high quality, indicating that Inti+2 & +3
have cleared more than 400 rigorous image quality tests
including accuracy of color reproduction, cross-talk, viewing
angle and video processing performance.

L

R

L

R

L

R

L

R

2.0 INSTALLATION GUIDELINES

R699810 - Inti+ Series User Manual 9

The THX certification features by using THX picture mode:

• Correct Gamma and Color Temperature

• No Overscan or Scaling

• Correct High Definition color Gamut

The Best in Class Parameters also include ANSI and Sequential contrast, luminance and color Uniformity, color
tracking with gray scale, optimum brightness, deinterlacing performance, jaggie and countouring.

2.3 Comfort and Caution with 3D Content

The closer one looks at stereoscopic images, the greater the binocular disparity, which means greater perception of
outward projection. At the same time, the spectator must focus on these outward objects on the screen. The
projecting image and the real focus distance cause a great contradiction. This causes visual fatigue and discomfort.
That means that the more 3D effect, the more outward effects, and the more your eyes will try to focus nearer than
where the objects are actually -really- located.This strain contributes to fatigue and discomfort.

Prevent child under 5 years old to watch 3D

The comprehensive brain function to judge stereoscopic vision which includes the feeling for real distances,
develops while growing up by touching and seeing real objects, but in early childhood, it is still in an underdeveloped
state. Even though there are individual differences, children under 5 are still developing. Letting them frequently
watch virtual 3D video images can be an obstacle for the development of a comprehensive three-dimensional feel.
Additionally, younger children may suddenly become sick, because they continue watching without realizing
symptoms like 3D sickness or deterioration of health. Please accompany your child while it watches 3D programs.

2.4 3D-Synchro Emitter

In order to match the timing of the displayed video images with the timing of the opening/closing 3D glasses
shutters for each eye, the projector in 3D mode sends the correct synchro data to the 3D synchro emitter.

CAUTION ABOUT HEADACHES AND EYE STRAINS

Please stop watching if you do not feel well and consult a physician if necessary. People who already have a kind of
photosensitivity, sufferers from heart disease, and people in poor physical condition should not watch 3D
stereoscopic images. It is also recommended that you take a break periodically.

3D MOVIES AND PARALLAX

The parallax is an important parameter for 3D movies that directly affects comfort during 3D projection. It is admitted
that generally the maximum value of the parallax must not exceed 6,5 cm which is an average value of people’s
distance between their left and right eyes and because the parallax value changes with the screen size, it is
important to set this parameter to a value with which everyone feels that the 3D effect is comfortable.
In general, women and children have smaller faces and may feel better with a smaller parallax value. Do not hesitate
to alter this settings if you feel eye-strains or headaches.

3D GLASSES SYNCHRONIZATION

In regard to the Infrared 3D emitter model, if you experience synchro issues with Infra Red glasses in an installation
where the synchro signal is bouncing from the projection screen, please direct the 3D emitter in such a way towards
the seats that the infrared rays can directly reach the 3D glasses. In a few cases the synchronization may not work
correctly:

-If you are near infrared communication equipment or lighting equipment.

-If the 3D-glasses do not face directly to the 3D synchro emitter

2.0 INSTALLATION GUIDELINES

10 R699810 - Inti+ Series User Manual

2.5 Environment of Use

Do not use this unit in rooms with cigarette smoke or oily smoke. This may cause the unit to malfunction.

Mounting this unit to the ceiling

Check temperature during install. If there is a heater, the air may reach a higher temperature than expected.

Precautions of Usage

This unit makes use of a light source lamp that reaches a high temperature during projection. Do not allow
projection under the following conditions:

• Projection with the unit laid on sides.

• Projection with the unit installed in an unreasonable angle of more than 15° horizontally and 5° vertically. Doing
so will shorten the lamp life.

• Projection at a location that blocks the air inlets or exhaust vents.

• Projection at a place exposed to air blasts from an air conditioner.

2.6 Air-Flow and Space Requirements

This unit can be installed in table, ceiling, rear table or rear ceiling position. Make sure that the unit is installed within
the space requirements described below (A: air inlets, B: air outlets).

Air flow

Space requirements

2.7 Ceiling Mounting the Unit

When mounting of this unit is required, make use of the 4 screw holes (M5x20 screws) at the bottom of this
unit indicated by the letter A. Allow sufficient space around the air inlets to avoid blocking them

.

A

A

B

A

B

A

B

200 mm

200 mm

200 mm100 mm

2.0 INSTALLATION GUIDELINES

R699810 - Inti+ Series User Manual 11

Precautions for Ceiling-mount

•To ceiling-mount this unit, special expertise and techniques are
necessary. Be sure to ask your dealer or specialist to perform
mounting.

• Do not mount at places that may be subjected to vibration and
shock.

• Depth of the screw holes (A) is 23 mm. Use at least 13mm long
screws but not longer than 23mm as you may damage inside
the projector.

• Install at a safe place in case this unit or a part of it may drop. If
the light-source lamp is broken, small pieces of glass from the
mesh of the filter may appear outside the unit.

• Regardless whether the unit is still under guarantee,
Dreamvision is not liable for any product damage caused by
mounting the unit with third party ceiling mount or when the
environment is not suitable for ceiling-mount.

Dimensions

Distances between left and right feet holes is D = 337 mm.
Distances between front and back feet holes is d = 290 mm.

2.8 Projection Distance

Projection Distance Chart

• The projection screen sizes and projecting distances in the table above are provided only as a guide. Please use
them as reference during installation.

• The distances are calculated for a projection image of 16:9 aspect ratio

What is the best projection distance for 3D

A 3D projection that makes use of stereoscopic images is very similar to an illusionist show where the brain is
tricked to perceive two pictures as a real 3D scene. Anyway, the trick can be fairly easily revealed:

• If you move from one side to the other side of the screen, there will be a place where you will be off-axis enough
to let you perceive the flatness of the projected pictures instead of interpreting them as a 3D object.

• If the parallax is not appropriate to the screen size, the two pictures will be perceived distinctly and therefore the

Projection Screen Size

Diagonal size

(Aspect Ratio 16:9)

Projection Screen Size

Base size

(Aspect Ratio 16:9)

Projection Screen

Height

(Aspect Ratio 16:9)

Inti+ Series

Projecting Distance

minimum - maximum

50" (1270 mm) 43,6" (1107 mm) 24,5" (623 mm) 151 cm - 305 cm

60" (1524 mm) 52,3" (1328 mm) 29,4" (747 mm) 178 cm - 366 cm

70" (1778 mm) 61,0" (1550 mm) 34,3" (872 mm) 209 cm - 428 cm

83" (2108 mm) 72,3" (1837 mm) 40,7" (1034 mm) 251 cm - 507 cm

92" (2337 mm) 80,2" (2037 mm) 45,1" (1146 mm) 279 cm - 562 cm

100" (2540 mm) 87,2" (2214 mm) 49,0" (1245 mm) 301 cm - 613 cm

110" (2794 mm) 95,9" (2435 mm) 53,9" (1370 mm) 331 cm - 675 cm

138" (3505 mm) 120,3" (3055 mm) 67,7" (1718 mm) 418 cm - 843 cm

150" (3810 mm) 130,7" (3321 mm) 73,5" (1868 mm) 453 cm - 860 cm

180" (4572 mm) 156,9" (3985 mm) 88,2" (2241 mm) 545 cm - 1107 cm

200" (5080 mm) 174,3" (4428 mm) 98,1" (2491 mm) 6060 cm - 1230 cm

A

A

A

A

d

D

2.0 INSTALLATION GUIDELINES

12 R699810 - Inti+ Series User Manual

brain will interpret the 3D-projection as two superposed pictures.

In general the perception of the 3D effect will vary according to your seat position and to the screen size. When a
movie is produced for 3D projection, the director knows at witch distance the effect will be perceived and witch
depth he intends to gives to the objects. In general, the recommended distance is three times the height of the
screen to obtain the best results.

Recommended seat distance for 3D projection

2.9 Setting the Lens and using Lens Memories

Adjust the picture position

The optimum image can be obtained when the centre of this projector’s lens and the screen are placed
perpendicular to each other. Take note of the projection angle when placing them. You can also use up to +/- 15° up

and down position and configure trapezoidal correction.

This unit comes with a optical shift that features vertical and horizontal adjustment of the projection screen position.
Adjust the picture to your screen.

• The Vertical Shift level is between -80% and 80% of the Screen Height (0.80 x H).

• The Horizontal Shift level is between -34% and 34% of the Screen Base (0.34 x B).

• The shift level is set to 0% vertically and horizontally by default, that means that the optical lens is aligned with
the center of the screen.

• If the projector is not installed perpendicularly to the screen, use keystone correction to fulfill your screen. Note
that using keystone correction, may be disabled by 3D projection. If you want to watch 3D movies within the
conditions, it is not recommended to use trapezoidal correction.

This unit comes with a vertical and horizontal shift to suit most installations. Make sure that your installation
does not exceed 80% vertical offset and 34% horizontal offset to avoid trapezoidal correction.

H = Screen Height

Distance = 3 x H

Screen Height

(H)

Screen Base (B)

Horizontal Shift +/- 34%

Ver tical Shift

+/- 80%

2.0 INSTALLATION GUIDELINES

R699810 - Inti+ Series User Manual 13

•To avoid the use of keystone correction, and only use the vertical and horizontal shifts, make sure to not exceed
the values contained in the tab below:

2.9.0.1 Adjust the picture position

The Inti+ Series projector has motorized vertical and horizontal shifts. Browse into the Menu to the [Lens Control]
setting into the [Installation] menu, select the shift adjustment. Or use the direct access button on the Remote
Control Unit [Lens Control] to make the lens adjustment.
You can use self-generated test pattern of the projector or an external pattern, from a calibration DVD by example,
by setting the Adjust pattern option to Off.

2.9.0.2 Adjust the picture Zoom

Into the [Lens Control] menu, press the [Ok] button to access the [Zoom] adjustment. Use the up and down buttons
to adjust the picture size until the screen is completely filled.

2.9.0.3 Adjust the Picture Focus

From the [Lens Control] menu, press the [Ok] button to access the [Focus] adjustment. Use the up and down
buttons to adjust the picture focus

Using Lens Memories

You can save the current picture position, zoom and focus in up to 3 different Lens Memories. Each memory stores
the current position, zoom, focus of the lens and you can set a custom name up to 10 characters.

2.9.0.1 Saving current lens setup

Fist step is to set the lens to fill the desired screen. Then go into the Menu ⇒⇒

⇒⇒

Installation ⇒⇒⇒⇒ Lens Control, Select Lens Memory Save and choose one of the three
memory available. You can call back anytime later this current lens setup using the
Direct access button [Lens Memory] on the RCU.

2.9.0.2 Limitations of use

Each memory can store a different picture size and position, but there are limitations
on the possible pictures sizes and positions because of the projector being fixed. In
order to calculate the best position of the projector toward the screen, the installer
has to make sure that among the different desired pictures, the smaller one with the
smallest zoom, is within the offset limits (horizontal and vertical shifts) of the
projector. Once the position of the projector is determined by the smallest possible
picture, double check that the largest one does not exceed the zoom capacity.

Left - Right shift 0% 5% 10% 15% 20% 25% 30% 34%

max. Up - Down shift 80% 74% 66% 57% 47% 34% 18% 0%

3.0 REMOTE CONTROL UNIT (RCU)

14 R699810 - Inti+ Series User Manual

3.0 REMOTE CONTROL UNIT (RCU)

3.1 General View

3.2 Loading and replacing batteries

• Push the cover tab with the fingernail a little backwards and pull upwards the cover top. Slide the cover forward
to remove.

• Push the battery body towards the spring and lift up to remove. Insert two AAA size batteries, making sure the
polarities match the + and - marks inside the battery compartment.

• Insert the lower tab of the battery cover in the gap at the bottom of the remote control, and press the cover until
it is firmly closed.

BACK

HIDE

LIGHT

ANAMO.

HDMI 1

3D

FORMAT

HDMI 2

COMP.

STAND BY

MENU

GAMMA

COLOR

P.F I L E

PICTURE MODE

INPUT

FILM

ON

COLOR

TEMP

PIC.

ADJ.

CINEMA ANIME

3D

NATURAL

STAGE

THX

USER C.M.D.

3D

SETTING

LENS

CONTROL

LENS

MEMORY

[Power On] button

Select Active [Input]

Display [Menu]

[Stand By] button

Select [3D Format]

[Anamo]rphic mode

[Back] to previous menu

Navigation buttons

Backlight button

Color Profile

Confirm button

[Lens control]

Shift, Focus and Zoom

[Hide] Display

Gamma Adj.

Color temp. Adj.

Basic Picture Adj.

Select a Picture Mode

Select a [Lens Memory]

Display [3D Setting] menu

Crystal Motion Drive

3.0 REMOTE CONTROL UNIT (RCU)

R699810 - Inti+ Series User Manual 15

3.3 How to use the Remote Control Unit

The operable distance of the remote control unit is about 7m for direct reception and within 30 degree angle with
respect to the sensor.

CAUTION WHEN USING BATTERIES

Do not mix new and old batteries.Do not mix different type of batteries as they are different in characteristics. Insert
batteries according to the + and - marks on the battery case. Do not put batteries into fire or recharge them if they
are not design to. Remove the batteries if the remote control is not to be used for a prolonged period. Use
manganese batteries wherever possible, Do not use rechargeable batteries.

NOTICE

If the remote control has to be brought closer to the projector to operate, it means that the batteries are wearing out.
When this happens, replace the batteries. Insert the batteries according to the + and - marks.

The remote control unit can be used by having the transmission signal reflected off a screen, as the effect of
signals reflected from the RCU differ with the type of screen used, operable distance may decrease.

Front InfraRed sensor

Back InfraRed sensor

4.0 GETTING STARTED

16 R699810 - Inti+ Series User Manual

4.0 GETTING STARTED

4.1 General View

Front side

• Optical Lens & Lens cover. The lens cover is motorized on Inti+2 & +3.

• Operating LEDs: see section 4.3, page 17 for more details.

• Air Outlets: see “Air-Flow and Space Requirements”, page 10.

Rear side

• Input Panel: connect your video source to the correct input.

• Operating and Navigation buttons described in section 4.4, page 18.

• Main Power: connect the power cord as shown below.

• Lamp trap: see “Procedure for Lamp Replacement”, page 37 for more details about lamp replacement.

• Air Inlets: see “Air-Flow and Space Requirements”, page 10.

Air Outlet

Front IR sensor

Optical Lens & Lens cover

Operating LED

Air Inlet

Input Panel

Lamp trap

Operating buttons

Main Power
