v 1.0
MaxCLL 500 NITS - 10 000 NITS
Auto Tone Mapping with HDR10
Hybrid Log
Gaming Mode
10 Installation Memories
by
4K native, 8K-Interpolation, HDR and 3D VIDEO-PROJECTORS
FOR HOME-CINEMA & SMALL VENUES
1
www.dreamvision.net
4K and beyond performances
Since 1996, DreamVision, in the shadow of the world-famous Montmartre hill in Paris, has been developing
and rening the latest advancements in digital display technology in order to provide state-of-the-art video
products for Home Cinema. This new projector’s chassis was created by the famed French designer, Antoine
Béon. These shapes are a contemporary work of art that could easily integrate a modern living room. The
Eos Series Series are true 4K performers, that means that they come equipped with a three-chips light
engine of 4096 x 2160 pixels and even the Eos Signature comes with an exclusive 8K up-scaling algorithm
that can display resolutions up to 8192 x 4320 pixels.
DreamVision also chose the most advanced manufacturing process and luxurious materials for their
performances in heat and noise absorption (noise level below 20 dB). The Eos Series can be ordered in
black or white as standard, but can also be ordered with any custom RAL paint.
The Eos Series can be ordered with any custom RAL paint to perfectly match the interior design.
Dedicated to sharp pictures and precision, the Eos Series come with an improved Low Latency mode that
drastically reduces the motion blur and enhances the thrill when playing video games or viewing virtual
reality show and simulations. The Low Latency mode is seconded by the Crystal Motion® algorithm which is
a frame interpolation method that brings an immersive experience to sport, concerts or TV shows.
Versatility and Ease of Installation
In addition to its impressive performance, the Eos Series projectors are also a easy to install. The
input panel, concealed on the back of the projector, oers quick access to a wide array of connections.
The 2 x zoom, combined with an electronic lens aperture, will allow for perfect adjustment in virtually any
residential installations. With the fully motorized and remote controlled lens, the installation becomes easier
and faster. The Eos Series Series will accommodate almost any kind of setups thanks to the ±80% vertical
shift and the ±34% horizontal shift. And if that is not enough, either you can opt for a Eos Signature model
that has a larger vertical shift up to ±100% and ±43% horizontal shift or you can use the crisp, high quality
Keystone correction.
The Eos Signature is the most versatile of the Eos Series thanks to its 43% vertical shift and 100% horizontal shift.
The Eos Signature, the sharpest home theater projector ever
Sharpness is not only a matter of pixels or resolution, but also it depends on other elements such as the lens
purity or the up-scaling quality. The Eos Signature comes with a large 100 mm diameter optic made with
numerous Low-Dispersion lenses that further enhances the picture sharpness and also the picture quality
thanks to the 1 000 000:1 contrast ratio. The Eos Signature also comes with an amazing 8K-Interpolation
algorithm that is capable to upscale perfectly any lower quality sources up to 8K resolution. No wonder why
the Eos Signature, with its world premiere 8192 x 4320 image display resolution, is claiming the title of the
most precise projector on the home theater market ever manufactured.
2
The sharpest model, the Eos Signature, is obtained by combining large, high quality
26 kg (57.3 lbs)
optical elements with the world rst 8K-interpolation and Low Latency computations.
Auto Tone Mapping for HDR content
The Eos Series Series come with a new Auto Tone Mapping feature will automatically detect and apply the
optimum settings for HDR10 content directly from the mastering information encoded into the HDR media
to obtain the best HDR eect. HDR contents will always be bright with the optimum contrast.
The Eos Series Series also come with other color space presets precisely calibrated to most current standards
such as BT.709 or DCI-P3. The Eos 2 and Eos Signature integrate special color lters making them even
capable of covering more than 80% of BT.2020 color gamut.
without HDR
When it comes to HDR contents, any lack of precision would be unforgiveable and would lead to disastrous
results on the screen. This is why the HDR support is continuously improved and the Eos Series has a new
dedicated interface with special color prole to nely tune the HDR parameters, optimizing the exceptional
contrast and brightness outputs to obtain even brighter HDR pictures with default settings.
The Cinemascope™ format optimized for the native 4096 x 2160 resolution
The optional Fixed Cinemascope™ Lens kit includes an optically rst-class anamorphic
lens and a exclusive lens holder. Once installed, no more unpleasant black bars, no more
loss of brightness and no more waste of pixels. The new scaling modes are optimized for
the true 4K resolution and make the best use of the native 17:9 aspect ratio of the
projector to obtain a Cinemascope picture.
All in all, the DreamVision Eos Series projectors and their dedicated accessories are
denitely the best projection system on the marketplace for picture quality, brightness/
colors and comfort.
26 cm / 10.1’’
Feet 2 cm
Width 50 cm / 19.7’’
52 cm / 20.4’’
Width 50 cm / 19.7’’
Weight
3
3
Model Eos 1 Eos 2 Eos Signature
Standard Pack R9201901 R9201902 R9201903
Native Resolution 4 096 x 2 160 (4K Resolution)
Display Resolution 4 096 x 2 160 (4K Resolution) 8 192 x 4 320 (8K Resolution)
Signal Compatibility HDR content auto-detect, 4K streaming services and UHD Blu-ray disks up to 4K60p
Panel Technology 3-chip LCOS 4K 0.69” panels
Optic Standard Full-glass 65 mm Lens (2x zoom)
Optic Motorizations Motorized Zoom, Focus, Shift
Throw Ratio 1.4:1 - 2.8:1
Screen Oset ±80% vertically / ±34% horizontally ±100% vertically / ±43% horizontally
Screen Size 60” - 200” diagonal (16:9) 60” - 280” diagonal (16:9)
Lamp Consumption 265 W NSH Bulb - up to 4 500 hours (with lamp used in low mode)
Brightness 1 800 Lumens 1 900 Lumens 2 200 Lumens
Native Contrast Ratio 40 000:1 80 000:1 100 000:1
Dynamic Contrast Ratio 400 000:1 800 000:1 1 000 000:1
High-Quality, 8K-optimized, 100 mm
diameter Lens with Low Dispersion
elements (2x Zoom)
CMS Functions YES (6-Axis)
Color Modes REC.709 (HDTV) REC.709, DCI-P3 and BT.2020
Expert Calibration NO YES
Picture Modes 4 Presets + 6 Users
Color Space Proles 7 Presets + 6 Customs 9 Presets + 6 Customs 10 Presets + 6 Customs
Noise Level Less than 20 dB (in low mode)
Inputs 2x HDMI 2.0b inputs (with HDCP 2.2 and 18 Gbps transmission band)
Home Automation RS-232 (Dsub 9) / LAN RJ45 / 12V Trigger (out)
Home-cinema
Video Processing
3D Compatibility Frame Packing, Side-by-Side, Top & Bottom
Pixel Alignment 1/16 pixel steps in 81 individual zones
Digital Keystone YES (Vertical only)
Weight 26 kg (57.3 lbs)
Dimensions (WxHxD) 50 x 26 x 49.5 cm (19.7” x 10.1” x 19.5”) 50 x 26 x 52 cm (19.7” x 10.1” x 20.4”)
HDR Picture modes with Perceptual Quantization (PQ) EOTF and Hybrid Log gamma
HDR colorimetry and MaxCLL / MaxFALL meta-data auto-detect
High quality Low Latency processing optimized for real time simulations and gaming
Advanced blur reduction and enhanced 400Hz Crystal Motion®
4 Presets + Film + 6 Users +
2 Expert only
4 Presets + Film + THX + 6 Users +
4 Expert only
Power and Consumption AC 110~240V 50/60Hz 400 W / 0.3W in Standby Eco-Mode
Box dimensions (LxWxH) 66 x 65 x 44 cm - 30 kg (66.1 lbs)
Optional 3D Kits
Other options Fixed Cinemascope Lens kit, Ceiling Mount kit, Motorized Lift, special colors and nishes
3D Passive glasses with B.E.S.T. 3D Passive polarizer
Very B.E.S.T. “horizontal” 3D Passive (Brighter with less ghosting)
3D Active glasses with RF dongle
Page 2, Deadpool 2©, page 3: Avengers: Innity War©
