ENGLISH
Declaration of Conformity
Manufacturer: TEC SA DreamVision, 7 Rue La Caille, 75017 Paris, France
Local distributor: Contact details available on www.dreamvision.net
We declare under our sole responsibility that the DreamWeaver projector conforms to
the following directives and norms:
EMC Directive 89/336/EEC, Amended by 93/68/EEC
EMC: EN 55022
EN 55024
EN 61000-3-2
EN 61000-3-3
Low Voltage Directive 73/23/EEC, Amended by 93/68/EEC
Safety: EN 60950: 2000
October, 2002
Trademarks
Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple
Computer, Inc. IBM is a trademark or registered trademark of International Business
Machines, Inc. Microsoft, PowerPoint, and Windows are trademarks or registered
trademarks of Microsoft Corporation. Digital Light Processing is a trademark or reg-
istered trademark of Texas Instruments. Faroudja, DCDi, and TrueLife are trade-
marks or registered trademarks of Faroudja. DreamVision and DreamWeaver are
trademarks or registered trademarks of TEC SA.
FCC Warning
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by DreamVision can void the user's
authority to operate the equipment.
Safety Certifications
UL, CE
Important Note:
Be aware that:
The lamp of a projector is never covered by the warranty, except as listed in the War-
ranty conditions (page 43)
The DreamWeaver uses a DMD
TM
chip from TI
TM
. This micromirror device is the
main component of the DLP
TM
system. Although DreamVision produces the Dream-
Weaver with the maximum percentage of active micro-mirrors, there may be some
micro mirrors that do not produce light. To know more about that, you can contact
DreamVision at info@dreamvision.net
2
Ta b le of Contents
Introduction 3
Positioning the projector 5
Video connections 6
Connecting a video device 7
Displaying a video image 8
Connecting a computer 10
Shutting down the projector 11
Troubleshooting your setup 11
Using the keypad buttons 18
Using the remote control 19
Optimizing video images 20
Customizing the projector 20
Using the menus 21
Picture menu 22
Settings menu 28
Maintenance 30
Cleaning the lens 30
Replacing the projection lamp 31
Appendix 33
Specifications 33
Accessories 33
Red LED behavior and projector errors 34
Projected image size 34
Source compatibility 35
Projector dimensions for ceiling mount installations 36
RS-232 terminal specifications 37
For complete details on connecting and operating the projector, refer to this
User’s Guide.
Important Operating Considerations
Do not place the projector on a tablecloth or other soft covering that may
block the vents. Vents are placed along the left and right sides of the projec-
tor, as well close to the projector front Lens.
Do not use a non-approved ceil-
ing mount. In the unlikely event of the lamp rupturing, discard any edible
items placed in the surrounding area and thoroughly clean the area along
the sides and in the front of the projector.
2 ft (.6m)
2 ft (.6m)
2 ft (.6m)
Do not place objects in the areas along the side and in the front of the projector
3
Introduction
First of all, we would like to thank you for chosing a DreamVision
®
Home
Cinema Projector. Your new DreamWeaver projector from DreamVision
®
is
specifically designed for home cinema applications. The DreamWeaver sets
the standard for high-definition digital perfection, featuring true High Defi-
nition 1280x720 resolution using the latest DLP™ technology and new
DCDi video processing from Faroudja™. Calibrated to D65 color mastering
standards, the DreamWeaver reproduces colors and details the way the
director intended. Whether you are watching movies or High Definition
broadcasts, you will enjoy breathtaking image quality.
Included items
Projector components and features
user’s guide
programable remote
projector
lens cap
power
cable
and baterries
keypad
zoom
focus
elevator foot release
remote
control
receiver (IR)
air intake
IR
(under the top
cabinet)
vent
I/O panel
leveling
foot
exhaust
heat vent
Remote Receiver
IR
under the top cabinet
Under the top cabinet
4
Connector Panel
The projector provides eight discreet video connectors, located under the
top cover of the top cabinet:
• two component RCA
• two S-video
• one composite RCA
• one M1-DA (HD, DVI, and computer)
• one VESA (HD, HD component, and computer)
• one component D5
It also has a mini-jack input for a Niles or Xantech-compatible IR repeater
and an RS-232 connector for serial control. The Command Line Interface
(CLI) specifications and commands are listed in the Appendix starting on
page 37.
Two 3.5 mm mini-jack triggers provide 12 volt current. Trigger 1 provides a
constant output while the projector is on. If you connect your projection
screen to Trigger 1, when you turn on the projector the screen will move
down; when you turn the projector off, the screen will return to the storage
position. Trigger 2 provides a 4:3 aspect trigger. When you select 4:3 in the
Aspect Ratio menu or from the
Resize
button on the remote, a 12v signal
will be sent after a five second delay. Use this trigger for screens with 4:3
aspect curtains. When you switch back to 16:9 format, the curtains open to
reveal the entire screen.
For details on each connector type and their inputs, see page 35.
IRin
1
2
YY
Pr Pr
Pb Pb
serialcontrol
M1-DA
vesa
trigger1
8
2
1
3
4
6
5
7
trigger2
component
s-video
video
D5
component
lock
remote control
receiver (IR)
power
connector
s-video
video
component
video
video/computer
1 & 2
serial
connector
D5
video
IR input
12v triggers
screen trigger connection
3.5mm mono plug
+12v
ground
to screen relay (see screen manufacturer
for details)
5
Positioning the projector
There are a number a factors to consider when determining where to set up
the projector, including the size and shape of your screen, the location of
your power outlets, and the distance between the projector and the rest of
your equipment. Here are some general guidelines.
1
Position the projector on a flat surface at a right angle to the screen.
The projector must be within 10 feet (3 m) of your power source. To
ensure adequate cable access, place the projector at least 6 inches
(0.15m) from a wall or other objects. Place the projector at least 5.6 feet
(1.7 m) from the projection screen.
If you install the projector on the ceiling, refer to the installation guide
that comes with the Ceiling Mount Kit for more information. To turn
the image upside down, see page 28. DreamVision recommends use of
an authorized DreamVision ceiling mount. The Ceiling Mount Kit is
sold separately, see page 33.
2
Position the projector the desired distance from the screen.
The distance from the lens of the projector to the screen, the zoom set-
ting, and the video format determine the size of the projected image.
For more information about projected image sizes, see page 34.
The image exits the projector at a given angle. This image offset is 116%.
This means that if you have an image 10’ high, the bottom of the image will
be 1.6’ above the center of the lens.
Check Page 34 for further help.
lens center
bottom of image
1.6’ above lens
10’ high
6
Video connections
You can connect VCRs, DVD players, camcorders, digital cameras, video
games, HDTV receivers, and TV tuners to the projector. (You cannot directly
connect the coaxial cable that enters your house from a cable or satellite
company; the signal must pass through a tuner first. Examples of tuners are
digital cable boxes, VCRs, digital video recorders, and satellite TV boxes.
Basically, any device that can change channels is considered a tuner.) Audio
must be provided by your own speakers, as the projector has no separate
audio controls. If there is more than one output, select the highest quality
one. DVI, Component video and RGB (M1, HD15) have the best quality, fol-
lowed by S-video, and then composite video
.
For a complete list of compatible sources, see page 35 of the Appendix.
Ta b le 1: Video connections
Input signal
Connector
Connector label
on projector
Standard Broadcast TV (not
HDTV), via cable, digital
cable, satellite TV, DirectTV
Component video
S-video
Composite video
Component 3, 6
S-video 4, 5
Video 7
HDTV Component video
VESA
DVI
Component 3, 6
VESA 2
M1-DA 1
DVD Component video
S-video
Composite video
Component 3, 6
S-video 4, 5
Video 7
VCR Composite video
S-video
Component video
Video 7
S-video 4, 5
Component 3, 6
Video Camera Composite video
S-video
Video 7
S-video 4, 5
Video Game VESA
Composite video
S-video
Component video
VESA 2
Video 7
S-video 4, 5
Component 3, 6
IRin
1
2
YY
Pr Pr
Pb Pb
serialcontrol
M1-DA
vesa
trigger1
8
2
1
3
4
6
5
7
trigger2
component
s-video
video
D5
component
s-video
video
component
video
M1-DA VESA
7
Connecting a video device
If your video device has more than one output, select the highest quality
one. DVI video has the best quality, followed by Component video, S-video,
and then composite video.
If the video device uses component cable connectors, plug the cable’s green
connectors into the green component-out connector on the video device and
into the green component connector (labeled “
Y
”) on the projector. Plug the
component cable’s blue connectors into the blue component-out connector
on the video device and into the blue component connector (labeled “
Pb
”)
on the projector. Plug the component cable’s red connectors into the red
component-out connector on the video device and into the red component
connector (labeled “
Pr
”) on the projector.
If the video device uses a round, four-prong S-video connector, plug an
S-video cable into the S-video connector on the video device and into the
S-
video
connector on the projector.
If the video device uses a yellow composite video connector, plug a com-
posite video cable’s yellow connector into the video-out connector on the
video device. Plug the other yellow connector into the yellow
Video
con-
nector
on the projector.
If the video device uses a DVI connector, plug an M1-D cable into the video-
out connector on the video device. Plug the other connector into the
M1-DA
connector
on the projector.
If the video device uses a VESA connector, plug a VESA cable into the
video-out connector on the video device. Plug the other connector into the
VESA
connector
on the projector.
Connecting the power cable
Connect the power cable to the connector on the back of the projector and to
your electrical outlet. The Power LED on the keypad turns solid green.
NOTE
: Always use the power cable that shipped with the projector.
IRin
1
2
YY
Pr Pr
Pb Pb
serialcontrol
M1-DA
vesa
trigger1
8
2
1
3
4
6
5
7
trigger2
component
s-video
video
D5
component
connect composite video cable
IRin
1
2
YY
Pr Pr
Pb Pb
serialcontrol
M1-DA
vesa
trigger1
8
2
1
3
4
6
5
7
trigger2
component
s-video
video
D5
component
c
onnect power cable
connect VESA cable
connect M1-D cable
connect S-video cable
connect component cable
M1-DA
1
IRin
serialcontrol
vesa
2
component
3
Pb Pb
Pr Pr
YY
s-video
5
4
1
2
component
6
video
7
D5
8
trigger1
trigger2
M1-DA
1
IRin
serialcontrol
vesa
2
component
3
Pb Pb
Pr Pr
YY
s-video
5
4
1
2
component
6
video
7
D5
8
trigger1
trigger2
M1-DA
1
IRin
serialcontrol
vesa
2
component
3
Pb Pb
Pr Pr
YY
s-video
5
4
1
2
component
6
video
7
D5
8
trigger2
trigger1
M1-DA
1
IRin
serialcontrol
vesa
2
component
3
Pb Pb
Pr Pr
YY
s-video
5
4
1
2
component
6
video
7
D5
8
trigger1
trigger2
8
Displaying a video image
Remove the lens cap.
Press the
Power
button on the top of the projector.
The LED flashes green and the fans start to run. When the lamp comes on,
the startup screen displays and the LED is steady green. It can take a minute
for the image to achieve full brightness.
? No startup screen?
Get help on page 11.
Plug in and turn on the video device.
An image from the video device should appear on the projection screen. If it
doesn’t, press the
Source
button on the keypad.
Adjust the height of the projector by pressing the release button to extend
the elevator foot. Rotate the leveling foot, if necessary.
Position the projector the desired distance from the screen at a 90 degree
angle to the screen. See page 34 for a table listing screen projected image
sizes and distances to the screen.
turn on video device
adjust distance
adjust height
press Power
elevator
foot
leveling
foot
rotate
9
Adjust the zoom or focus rings by rotating them until the desired image size
and sharpness are produced.
If the image is not square, adjust the keystone using the buttons on the key-
pad. Press the upper
Keystone
button to reduce the width of the upper por-
tion of the image, and press the lower
Keystone
button to reduce the width
of the lower portion.
The
Contrast
,
Brightness
,
Color
, and
Tint
are factory calibrated to D65 col-
ors, but you can adjust these settings in the Picture menu if necessary.
See page 21 for help with the menus.
adjust Picture menu
adjust keystone
adjust zoom and focus
zoom
focus
10
Connecting a computer
Connect either a VESA cable or M1 cable into the appropriate connector on
the projector. Connect the other end to the video port on your computer. If
you are using a desktop computer, you first need to disconnect the monitor
cable from the computer’s video port.
Connect the power cable to the connector on the back of the projector and to
your electrical outlet.
The Power LED on the projector’s keypad turns solid green.
NOTE
: Always use the power cable that shipped with the projector.
Turn on the projector, then your computer.
You can control the projector from an LCD control panel or computer by
connecting an RS-232 cable to the projector’s
Serial
connector. Specific
RS-232 commands can be found in the Appendix starting on page 38
IR
in
Pr
connect power cable
IRin
1
2
YY
Pr Pr
Pb Pb
serialcontrol
M1-DA
vesa
trigger1
8
2
1
3
4
6
5
7
trigger2
component
s-video
video
D5
component
YY
connect RS-232 cable
connect computer cable
M1-DA
M1-DA
1
IRin
serialcontrol
vesa
2
component
3
Pb Pb
Pr Pr
YY
s-video
5
4
1
2
component
6
video
7
D5
8
trigger2
trigger1
1
IRin
serialcontrol
vesa
2
component
3
Pb Pb
Pr Pr
YY
s-video
5
4
1
2
component
6
video
7
D5
8
trigger2
trigger1
M1-DA
1
IR
in
serialcontrol
vesa
2
component
3
Pb Pb
Pr
YY
s-video
5
4
1
2
component
6
Pr
video
7
D5
8
trigger2
trigger1
11
Shutting down the projector
Power Save
The projector has a Power Save feature in the System menu that automati-
cally turns the lamp off after no signals are detected for 20 minutes. After 10
additional minutes with no signal, the projector powers down. If an active
signal is received before the projector powers down, the image is displayed.
You must press the
Power
button to display an image after 30 minutes have
passed.
Turning off the projector
To turn off the projector, press the
Power
button. The lamp turns off and the
LED blinks green for about one minute while the fans continue to run to
cool the lamp. When the lamp has cooled, the LED lights green and the fans
stop. Unplug the power cable to completely power off the projector.
Troubleshooting your setup
If your image appears correctly on the screen, skip to the next section
(page 19). If it does not, troubleshoot the setup.
The LED on top of the projector’s keypad indicates the state of the projector
and can help you troubleshoot.
The following table shows some potential problems. In some cases, more
than one possible solution is provided. Try the solutions in the order they
are presented. When the problem is solved, you can skip the additional
solutions.
Ta b le 2: LED behavior and meaning
LED color/behavior
Meaning
solid green The projector is plugged in, or the projec-
tor has been turned on and the software
has initialized. The projector has been
turned off and the fans have stopped.
blinking green The
Power
button has been pressed and
the software is initializing, or the projec-
tor is powering down and the fans are
running to cool the lamp.
blinking red
The projector will not start up if the LED
is blinking red. You must correct the prob-
lem, disconnect and reconnect the power
cable, then power on the projector.
See page 34 for more information on
blinking red LEDs.
A fan (blinks 4 times) or lamp (blinks 3
times) failure has occurred. Turn off the
projector and wait one minute, then turn
the projector on again. Also check for a
blocked vent or a stopped fan (blinks 5
times).
solid red An unidentifiable error: please contact
Technical Support.
12
Problem Solution Result
No startup screen
Plug power cable in and remove lens cap
press Power button
Correct image
Image not centered on screen
Move projector, adjust zoom, adjust height
Correct image
Adjust horizontal or vertical position in
Picture>Advanced menu
zoom
13
Image not square
Adjust keystone on keypad
Square image
Image does not fit 16:9 screen
Change aspect ratio to 16:9 in
Picture>Aspect ratio menu
Correct image
Edges of image distorted
Turn Overscan on in the Picture>Advanced
menu
Correct image
AB
AB
14
1. Projected colors don’t match source
2. Colors are washed out or too deep
3. Image from component source appears greenish
1. Adjust color, tint, color temperature,
brightness, or contrast in the menus.
2. Pick another gamma setting
3. Pick another color space
Correct image
Image upside down
Turn off Ceiling in Settings>System menu
Correct image
Image reversed left to right
Turn off Rear in Settings>System menu
Correct image
A
B
AB
A
AB
COLOR
COLOR
15
Video image “torn” and fragmented
Change Video Standard in
Picture>Advanced menu
Correct image
Lamp won’t turn on, LED blinking red (page 11)
Make sure vents aren’t blocked; allow
projector to cool for one minute
Unplug projector; wait one minute; plug in
projector and turn it on: lamp lights
blinks
red
A
A
B
B
AB
16
Computer-specific troubleshooting
Only startup screen appears
Press the Source button
Activate laptop’s external port
Computer image projected
No computer image, just the words “Signal out of
range”
Adjust computer refresh rate in Control
Panel>Display>Settings>Advanced>
Adapter (location varies by operating
system)
Computer image projected
A
or restart
laptop
A
A
A
A
A
Signal out of range
17
Still having problems?
If you need assistance, call directly you DreamVision retailer or contact our
local importer (www.dreamvision.net)
Or, send us an e-mail at
:
service@dreamvision.net
When sending your DreamWeaver to one of our DreamVision Service Cen-
ters for repair, we recommend shipping the unit in its original packing
material, or having a professional packaging company pack the unit with
all accessories for shipping. Never forget to insure your shipment for its full
value.
Image fuzzy or cropped
Set your computer’s display resolution to
the native resolution of the projector
(Start>Settings>Control
Panel>Display>Settings tab, select
1280x720)
Image clear and not cropped
For a laptop,
disable laptop
monitor
or turn-on dual-
display mode
A
A
A
18
Using the keypad buttons
Most buttons are described in detail in other sections, but here is an over-
view of their functions:
Power
–turns the DreamWeaver on (page 8) and off (page 8).
Menu
–opens the on-screen menus (page 21).
Select
–confirms choices made in the menus (page 21).
Up/down arrows
–navigates to and adjusts settings in the menus (page 21).
Auto image
–resets the projector to the source.
Presets
–cycles through the 3 available user preset settings (page 24).
Keystone
–adjusts squareness of the image (page 11).
Brightness
–adjusts intensity of the image (page 22).
Resize
–changes the aspect ratio (page 22).
Source
–changes the active source (page 28).
menu navigation buttons
19
Using the remote control
Use the provided four batteries in install them in the Remote. To operate,
point the remote at the screen or at the projector. The range of optimum
operation is 0 to 9,14 m. (30 feet).
Press the remote’s
DREAM
button to have access to the DreamWeaver func-
tions. Press then the
MENU
button (11) to enter the DreamWeavers’ menu.
Use the arrow buttons (12) to navigate, and the
Select
button (13 or 8)to
select features and adjust values in the menus. See page 21 for more info on
the menus.
The remote also has:
•
Power
button (1) to turn the projector on and
OFF
button (2) to tun it
off (see page 11 for shutdown info)
• backlight button (3) to light the remote’s buttons in the dark
On
Page 1
of the LCD screen you have also direct access to
•
Brightness +/-
and
Contrast +/-
(4)
buttons to adjust the image
•
4 pre-set video inputs
(5) buttons to select the source
•
Resize
(6) button to change the Aspect Ratio (see page 22)
Then, press the Page (7) button to have access to the
Page 2
of the menu:
•
Blank
(9) button to display a blank screen instead of the current image
(to change the color of the screen, see page 29)
•
Auto
(10) button to resynch the projector to the source
Tr oubleshooting the remote
• Make sure the batteries are installed in the proper orientation and are
not dead.
• Make sure you’re pointing the remote at the projector or the screen, not
at the video device or the computer, and are within the remote range of
30 feet (9.14m).
•
SYSTEM
PAGE 1
DREAM
MENU RESIZE
DVI 1 BRIGHT+
RGB 2 BRIGHT-
YUV 3 CONT+
SVHS4 CONT-
2
1
3
4
5
6
7
11
12
12
13
8
9
9
8
ENTER AUTO
BLANK
PAGE 1
DREAM
10
20
Optimizing video images
After the video device is connected properly and the image is on the screen,
you can optimize the image using the onscreen menus. For general informa-
tion on using the menus, see page 21.
• Change the Aspect ratio. Aspect ratio is the ratio of the image width to
image height. TV screens are usually 1.33:1, also known as 4:3. HDTV
and most DVDs are 1.78:1, or 16:9. Choose the option that best fits your
input source in the menus, or press the
Resize
button on the remote to
cycle through the options. See page 22.
• Adjust the Keystone, Contrast, Brightness, Color, or Tint in the Picture
menu. See page 22.
• Select a different Color Temperature or use the Color Control to adjust
the gain and offset of the red, green, and blue color. See page 26.
• Select a specific Color Space or Gamma. See page 26.
• Select a different Video Standard. Auto tries to determine the standard
of the incoming video. Select a different standard if necessary. See
page 26.
•Turn overscan on to remove noise around the video image. See page 27.
• Fine tune component inputs using the TrueLife™ adjustments. See
page 25.
• Choose High Power to maximize the light output. Remember that the
High Power choice is not necessary, and may even bring over saturated
white, when your room is dark enough. See page 28.
• Make sure your DVD player is set for a 16:9 television. See your DVD
player’s user ’s guide for instructions.
Customizing the projector
You can customize the projector for your specific setup and needs. See
page 28 to page 30 for details on these features.
• For rear projection, turn Rear mode on in the
Settings>System
menu.
• For ceiling mounted projection, turn Ceiling mode on in the
Set-
tings>System
menu.
•Turn the projector’s display messages and power-on chime on and off.
•Turn on power saving features.
• Specify blank screen colors and startup logos. Make the menus translu-
cent.
• Specify the menu language.
21
Using the menus
To open the menus, press the menu button on the keypad or remote. (The
menus automatically close after 60 seconds if no buttons are pressed.) The
Main menu appears. Use the arrow buttons to move up and down to high-
light the desired submenu, then press the
Select
button.
To change a menu setting, highlight it, press
Select
, then use the up and
down arrow buttons to adjust the value, select an option using radio but-
tons, or turn the feature on or off using check boxes. Press
Select
to confirm
your changes. Use the arrows to navigate to another setting. When your
adjustments are complete, navigate to Exit, then press
Select
to go to the
previous menu; press the
Menu
button at any time to close the menus.
The menus are grouped by usage:
• The Picture menu provides image adjustments.
• The Settings menu provides set-up type adjustments that are not
changed often.
• The About menu provides a read-only display of information about the
projector and source.
Certain menu items may be hidden until a particular source is connected.
For example, Tint is only available for NTSC video sources and will be hid-
den when other sources are active. Other menu items may be grayed out
when they are not available. For example, Brightness is grayed out until an
image is active.
Picture menu
Settings menu
Main menu
About menu
Menu
button
Keypad navigation
buttons
22
Picture menu
To adjust the following five settings, highlight the setting, press
Select
, use
the up and down arrows to adjust the values, then press select to confirm
the changes. All menu defaults are listed in a table starting on page 38.
Keystone
: adjusts the image vertically and makes a squarer image. You can
also adjust keystone from the keypad.
Contrast
: controls the degree of difference between the lightest and darkest
parts of the picture and changes the amount of black and white in the
image.
Brightness
: changes the intensity of the image. You can also adjust bright-
ness from the keypad.
Color
: (video sources only) adjusts a video image from black and white to
fully saturated color.
Tint
: (NTSC video sources only) adjusts the red-green color balance in the
image.
Aspect Ratio
: Aspect ratio is the ratio of the image width to image height.
TV screens are usually 1.33:1, also known as 4:3. HDTV and most DVDs are
1.78:1, or 16:9. You can choose Native, 4:3, 16:9, Letterbox, or Natural Wide.
The default is 16:9. The goal is to show the most detail on the screen while
preserving the ratio of width to height. The native resolution of the projec-
tor is 1280x720. Use Native, 4:3 or Naural Wide for 4:3 input sources; use
Native, 16:9 or Letterbox for 16:9 input. Pressing the
Resize
button on the
remote cycles through these options.
Native
: this mode bypasses the internal scaler, displaying the image
with no resizing.
Since the native resolution is 1280x720 and 4x3 video images are
approximately 640x480, 4x3 images will always be smaller than the dis-
play and will be centered in the display. Computer images 1024x768 or
smaller will also be centered in the display. If a 16x9 video source or a
1280x1024 or larger computer source is viewed, it will display up to
1280 pixels and 720 lines from the center of the input.
Aspect ratio
increasing keystone
decreasing keystone
23
16:9:
the default is
16:9
,
which
preserves the 16:9 aspect ratio and is
designed to be used with content that is Enhanced for Widescreen TVs.
4:3
: resizes the image from its original version to fit a standard 4:3
aspect ratio screen. If you have a 4:3 source on a 16:9 screen, the image
is placed in a 16:9 space, so black bars appear at the sides of the image.
Letterbox:
preserves the 16:9 aspect ratio. If you have a 16:9 source
and screen, the image fills the screen. If your source is letterboxed, the
image expanded to fill the screen.
Natural Wide
: this mode stretches a 4:3 image to fill the entire 16:9
screen. The center two-thirds of the image is unchanged; the edges of
the image are stretched.
letterbox
natural wide
aspect ratio
aspect ratio
4:3 aspect ratio
16:9
aspect ratio
9
16:9 image input
16
9
16:9 image
16
9
black bars
black bars
3
4:3 image input
4:3 image on 16:9 screen
3
3
4:3 image input
black bars
4
9
16
4
4:3 image fills 16:9 screen
16
9
letterbox image input
black bars
16:9 image fills 16:9 screen
4
16
24
Presets
: This allows you to customize settings and save the settings to be
restored later. To restore the factory default settings, choose Factory Reset in
the
Settings>Service
menu.
To set a preset for the current source, adjust the image, select
Save Settings
in the Presets menu, then choose Save User 1, 2, or 3. You can recall these
settings in the future by selecting the appropriate user presets.
Presets
Save User Presets
25
Advanced settings
TrueLife
: This option refers to Faroudja’s TrueLife processing of the image.
All standard definition interlaced video signals (composite, S-video and
component) are routed through this processor. Extended and High Defini-
tion progressive component sources are not routed though this processor by
default. You can turn TrueLife on to route these signals through the proces-
sor and then adjust the following 2 options:
Chroma Detail
: This adjusts the color sharpness.
Luma Detail
: This adjusts the sharpness.
Noise Reduction
: adjusts signal noise reduction. Choose Off to have no
noise reduction, choose Auto to have the software determine the amount of
noise reduction, or choose Manual and adjust the Level.
Skintone Bypass
prevents the noise reduction processing from being
applied to skin tones. Images of people often look better with less process-
ing. Available when Auto or Manual are selected.
CCS
: (Cross Color Suppression) processes the signal to remove any color
information from the luma portion of the signal. It is On for all composite
signals, Off for all component signals, and can be turned on or off for all
S-video signals.
NTSC 2:2 Pulldown
: Turn this feature on to correctly display NTSC signals
created from 30 frames/second source material (instead of the film standard
24 frames/second).
2:2/3:2 Off
: Turn this feature on to turn off film mode detection. Some video
material (especially film animation) is difficult to distinguish from film.
Advanced
Noise reduction
26
Color Space
: This option applies to computer and HDTV sources (it won’t
appear in the menu for video sources). It allows you to select a color space
that has been specifically tuned for the video input. When Auto is selected,
the projector automatically determines the standard. To choose a different
setting, turn off Auto, then choose RGB for computer sources, choose
REC709 for component 1080i or 720p sources, or choose REC601 for compo-
nent 480p or 576p sources.
Color Temperature
: changes the intensity of the colors. Select a listed
value.
Color Control
: allows you to individually adjust the gain (relative warmth
of the color) and the offset (the amount of black in the color) of the red,
green, and blue colors.
Gamma
: Gamma tables contain preset intensity configurations optimized
for the input source. You can select a gamma table that has been specifically
tuned for either film, video, Bright Room, or PC input. (Film input is mate-
rial originally captured on a film camera, like a movie; video input is mate-
rial originally captured on a video camera, like a TV show or sporting
event.)
NOTE
: Your viewing preferences may vary. Cycle through the gamma
options and pick the one you like the best.
Video Standard
: When it is set to Auto, the projector attempts to pick the
video standard automatically based on the input signal it receives. (The
video standard options may vary depending on your region of the world.)
If the projector is unable to detect the correct standard, the colors may not
look right or the image may appear “torn.” If this happens, manually select
a video standard by selecting NTSC, PAL, or SECAM from the Video Stan-
dard menu.
Video Standard
Gamma
Color Control
Color Temperature
Color Space
27
Overscan: (video sources only) removes noise around the video image.
The following 4 options are for computer or HDTV sources only.
Phase: adjusts the phase of the video signal’s digital conversion.
Tracking: adjusts the frequency of the video signal’s digital conversion.
Horizontal/Vertical Position: adjusts the position of the source.
28
Settings menu
Sources: allows you to assign a particular input to a specific source key on
the remote and enables or disables Autosource. When Autosource is not
checked, the projector defaults to the last-used source. If no source is found,
a blank screen displays. When Autosource is checked, the projector checks
the last-used source first at power up. If no signal is present, the projector
checks the sources in order until a source is found or until power down.
You can use the Source Enable feature to eliminate certain sources from this
search, which will speed the search. By default, the check boxes for all
sources are checked. Uncheck a source’s box to eliminate it from the search.
System
All options in this menu toggle between on and off.
Rear: reverses the image so you can project from behind a translucent
screen.
Ceiling: turns the image upside down for ceiling-mounted projection.
NOTE: It is recommended that all final image adjustments in Ceiling mode
are made once the unit has fully warmed up (approximately 20 minutes).
Auto Power: When Auto Power is checked, the projector automatically
goes into the startup state after the projector receives power. This allows
control of ceiling mounted projectors with a wall power switch.
Display Messages: displays status messages (such as “Searching”) in the
lower-left corner of the screen.
High Power: Turn this on to increase the light output of the lamp. This also
shortens lamp life and increases fan noise.
Source 1
Settings menu
System menu
Source Enable
Sources
29
Power Save: when On, the lamp is automatically turned off after no signals
are detected for 20 minutes. After 10 additional minutes with no signal, the
projector powers down. If an active signal is received before the projector
powers down, the image will be displayed.
Startup Logo: allows you to display a blank Black, White, or Blue screen
instead of the default screen at startup and when no source is detected.
Blank Screen: determines what color displays when you press the Blank
button on the remote or when no source is active.
Language: allows you to select a language for the onscreen display of
menus and messages.
Startup logo
Blank Screen
Language
System menu
30
Service: to use these features, highlight them and press Select.
Factory Reset: restores all settings (except Lamp Hours, Ceiling, and Rear)
to their default after displaying a confirmation dialog box.
Test Pattern: displays a test pattern when the Blank button on the remote
is pressed. To select the patterns, use the up/down arrows on the remote or
keypad.
Service Code: only used by authorized service personnel.
Maintenance
Cleaning the lens
1 Apply a non-abrasive camera lens cleaner to a soft, dry cloth.
Avoid using an excessive amount of cleaner, and don’t apply the
cleaner directly to the lens. Abrasive cleaners, solvents or other harsh
chemicals might scratch the lens.
2 Lightly wipe the cleaning cloth over the lens in a circular motion. If you
don’t intend to use the projector immediately, replace the lens cap.
clean the lens
with a soft dry cloth
and non-abrasive
cleaner
Service menu
31
Replacing the projection lamp
The lamp hour timer in the About menu counts the number of hours the
lamp has been in use. After 1980 hours, the message “Change lamp” briefly
appears on the screen at each startup. To maintain optimal video perfor-
mance, we recommend changing the lamp after 2000 hours, depending on
usage.
1 Turn off the projector and unplug the power cable.
2 Wait 60 minutes to allow the projector to cool thoroughly.
3 Turn the projector upside down and remove the lamp door by removing
the two screws and sliding the lamp door tabs out of the three tab bays.
CAUTION: Never operate the projector with the lamp door removed.
This disrupts the air flow and causes the projector to overheat.
4 Loosen the captive screw on the lamp module.
bail wire
loosen the screw on lamp module
the projector
wait 60 minutes
turn off and unplug
Lamp hours used
32
WARNINGS:
•To avoid burns, allow the projector to cool for at least 60 minutes before
you replace the lamp.
• Do not drop the lamp module. The glass may shatter and cause injury.
• Do not touch the glass lamp screen. Fingerprints can obscure projection
sharpness.
• Be extremely careful when removing the lamp module. In the unlikely
event that the lamp ruptures, small glass fragments may be generated.
The lamp module is designed to contain most of these fragments, but
use caution when removing it.
5 Carefully remove the lamp module by grasping and lifting the metal
bail wire. Dispose of the lamp in an environmentally proper manner.
6 Install the new lamp module, making sure that it is properly seated.
7 Tighten the single screw.
8 Replace the lamp door by sliding the tabs into the tab bays and tighten-
ing the two screws.
9 Plug in the power cable, then press the Power button to turn the projec-
tor back on.
10 Reset the lamp hour timer.
Resetting the lamp timer
To reset the lamp age, simultaneously holding down the two Brightness
buttons on the projector’s keypad for 10 seconds.
Using the security lock
The projector has a security lock for use with a PC Guardian Cable Lock
System. Refer to the information that came with the lock for instructions on
how to use it.
IRin
1
2
YY
Pr Pr
Pb Pb
serialcontrol
M1-DA
vesa
trigger1
8
2
1
3
4
6
5
7
trigger2
component
s-video
video
D5
component
security lock
33
Appendix
Specifications
Accessories
NOTE: Use only approved accessories.
Temperature Operating
50 to 95
° F (10 to 35° C) at 0 - 10,000 feet
Non-operating
-4 to 158
° F (-20 to 70° C) at 0 -20,000 feet
Altitude Operating 0 to 3,048 meters (10,000 feet)
Non-operating 0 to 6,096 meters (20,000 feet)
Humidity Operating 10% to 95% relative humidity, non-condensing
Non-operating 10% to 90% relative humidity, non-condensing
Dimensions
Diameter: 439 mm - Height: 127 mm
Weight
4. 4 kg unpacked
Optics Focus Range
1.5 - 10 meters (5 - 32.8 feet)
Lamp Type
UHP lamp (dual watt: 200 and 250 watt)
Input Power Requirements 100V-120V 4A, 50/60 Hz
200V-240V 2A 50 Hz
Standard Accessories
(ship with the projector)
Shipping Box (with packaging)
Power Cable (country-dependent)
Programmable Remote (and batteries)
Projection Lamp Module (included in projector)
Lens Cap
User’s Guide
Optional Accessories
Projector Mount
Replacement Lamp Module
34
Red LED behavior and projector errors
If the projector is not functioning properly and the red LED is blinking, con-
sult Ta b le 2 to determine a possible cause. There are two second pauses
between the blinking cycles.
Projected image size
Ta b le 3: Red LEDs
Red LED Behavior Explanation
One (1) blink The lamp won't strike after five (5)
attempts. Check the lamp and lamp door
installations for loose connections.
Three (3) blinks The projector has shut down the lamp.
Turn off the projector, wait one minute,
then turn it back on. Replace the lamp.
Contact Technical Support for repair if
replacing the lamp does not solve the
problem.
Four (4) blinks The fan has failed. Replace the lamp (the
lamp module contains a fan). Contact
Technical Support for repair if replacing
the fan does not solve the problem.
Five (5) blinks The projector is overheating. Check for a
blocked air vent. Contact Technical Sup-
port for repair if clearing the air vents
does not solve the problem.
Ta b le 4:
Range of projection distances for a given screen size
16:9 Screen
dimensions
(inches/m)
Projection Distance
Screen
diagonal
(inches/m)
Maximum
zoom
(feet/m)
Minimum
zoom
(feet/m)
27x48
.69x1.22
55.1/1.4 6.0/1.82 8.3/2.54
34x60
.9x1.5
68.8/1.75 7.5/2.3 10.4/3.2
40.5x72
1.0/1.8
82.6/2.1 9.0/2.7 12.5/3.8
45x80
1.1x2.0
91.8/2.3 10.0/3.0 13.9/4.2
49x87
1.2/2.2
99.8/2.5 10.8/3.3 15.1/4.6
52X92
1.3X2.3
105.6/2.7 11.4/3.5 16.0/4.9
54X96
1.4X2.4
110.1/2.8 11.9/3.6 16.7/5.1
58X104
1.5X2.6
119.3/3.0 12.9/3.9 18.1/5.5
65X116
1.7X3
133.1/3.4 14.4/4.4 20.1/6.1
35
Source compatibility
Ta b le 5:
Source Compability
Video Component and RGB HDTV (720p, 1035i, 1080p, 1080p-24Hz)
DVI/HDCP for digital video and encrypted digital video
Component EDTV (480p, 576p progressive scan),
SECAM: M, Component, Composite and S-Video standard
video (480i, 576i, 576i RGB SCART with adapter,
NTSC, NTSC M 4.43,
PAL: B, H, I, M, N)
Computer Digital and analog PC, Macintosh, 1280x1024 resolution
Communi-
cation
USB and RS-232
Ta b le 6:
Projector Inputs and Outputs
2-Component
(Gold RCA)
HDTV, EDTV, and Standard TV component
1-Component
(D5)
HDTV, EDTV, Standard TV, RGB SCART with adapter
2-S-Video Standard Video
1-Composite
(RCA)
Standard Video
1-M1-DA VESA HDTV RGB, HDTV component, DVI, computer, and USB
1-HD15 VESA HDTV RGB, HDTV component, computer
1-9-pin Dsub
male
RS-232
1-3.5 mm mini
jack
IR Repeater (Niles/Xantech compatible)
2-3.5 mm mini
jack
1-12v screen drop, 1-12v 4:3 aspect “curtains”
36
Projector dimensions for ceiling mount installations
320 mm
449 mm
8.7"
221.4 mm
4.3"
109.5 mm
0.14"
3.6 mm
8.5"
216 mm
110 mm
55 mm
75 mm
37
RS-232 terminal specifications
Communication configuration
To control the projector from an LCD control panel, connect an RS-232 cable
to the serial control connector on the projector and set your computer’s
serial port settings to match this communication configuration:
Command format
All commands consist of 3 alpha characters followed by a request, all
enclosed in parentheses. The request can be a read request (indicated by a
“?”) or a write request (indicated by 1 to 4 ASCII digits).
A read request format: (AAA?) where
( starts the command
AAA denotes the command
? denotes the read request
) ends the command
A read command returns the range and the current setting, for example
:
A write request example: (AAA####) where
( starts the command
AAA denotes the command
#### denotes the value to be written
(leading zeros not necessary)
) ends the command
Some commands have ranges, while others are absolute. If a number
greater than the maximum range is received, it is automatically set to the
maximum number for that function. If a command is received that is not
understood, a “?” is returned. With absolute settings, “0” is off, 1-9999 is on.
The one exception is the Power command, where 0 is off and 1 is on
.
Setting Value
Bits per second 19,200
Data bits 8
Parity None
Stop bits 1
Flow control None
Emulation VT100
Function Command Response
Brightness (BRT?) (0-22, 10)
Lamp hours (LMP?) (0-9999, 421)
Function Command Response
Brightness (BRT10) Sets the brightness to 10
Power (PWR0) Turns power off
Power (PWR1) Turns power on
Power (PWR9999) ?
38
Supported commands
Function Command Range Default
Aspect Ratio ARZ 0-4
0 = Native
1 = 16:9
2 = 4:3
3 = Letterbox
4 = Natural Wide
1
Auto Chime Enable ACE 0-1 1
Auto Power APO 0-1 0
Auto Source ASC 0-1 1
Blank BLK 0-1 0
Blank Screen BSC 0-2
0 = black
1 = blue
2 = white
0
Blue Color Offest BCO 1-63 32
Blue Gain BCG 1-63 32
Brightness BRT 8-252 128
Ceiling CEL 0-1 0
Chroma Detail CDE 8-248 128
Color CLR 8-252 128
Color Space CSM 0-7
0 = RGB
3 = REC601
2 = REC709
7 = Auto
7
Color Temp TMP 0-2
0 = 9300
1 = 8200
2 = 6500
2
Contrast CON 8-252 128
CCS CCS 0-1 0
Display Messages DMG 0-1 1
Factory Reset (Write only) RST 0-1 n/a
Gamma Table GTB 0-4
0 = PC
1 = Video
2 = Film
3 = Bright Room 1
4 = Bright Room 2
2
Green Color Offset GCO 1-63 32
Green Gain GCG 1-63 32
High Power Enable HPE 0-1 0
Horizontal Position HPS n/a n/a
Keystone DKC 2-254 128
Lamp Hours (Read only) LMP 0-32767 0
Lamp Reset LMR 0-32767 0
Luma Detail LDE 8-248 128
Menu MNU 0-1 0
Menu Navigation NAV 0-4
0 = up
1 = down
4 = select
n/a
39
Language LAN 0-11
0 = English
1 = French
2 = German
3 = Spanish
4 = Chinese Tradi-
tional
5 = Japanese
6 = Korean
7 = Portuguese
8 = Russian
9 = Norwegian
10 = Chinese Sim-
plified
11 = Italian
0
NTSC 2:2 Pulldown Enable NPE 0-1 0
Noise Reduction Enable NRE 0-2
0 = Off
1 = Auto
3 = Manual
8
Noise Reduction Level NRL 8-248 8
Overscan OVS 0-1 0
Phase MSS 0-31 n/a
Power PWR 0-1 0
Power Save PSV 0-1 0
Presets PST 0-2
0 = User 1
1 = User 2
2 = User 3
0
Rear Project REA 0-1 0
Red Color Offset RCO 1-63 32
Red Gain RCG 1-63 32
Skintone Bypass Enable SBE 0-1 1
Source SRC 0-7
0 = Video 1, M1
1 = Video 2, VESA
2 = Video 3, Com-
ponent 1
3 = Video 4,
S-Video 1
4 = Video 5,
S-Video 2
5 = Video 6,
Component 2
6 = Video 7,
Composite
7 = Video 8, D5
2
Startup Logo DSU 0-1 1
Tint TNT 8-252 128
Tracking MTS 2148-2248 n/a
Translucent OSD TOE 0-1 1
TrueLife Enable TLE 0-1 1
Ver tical Position VPS n/a n/a
Video Standard VSU 0-3
0 = Auto
1 = NTSC
2 = PAL
3 = SECAM
0
40
Numerics
12v triggers 4, 35
16x9 4, 13, 20, 22, 23
4x3 23
4x3 aspect trigger 4
A
Adjusting image 9, 22
Advanced menu 25
Altitude limits 33
Aspect Ratio 22
Auto Power 28
Autosource 28
B
Blank Screen 29
Blinking green 11
Blinking red 11
C
Cable box 6
CCS 25
Ceiling 28
Chroma Detail 25
Cleaning the lens 30
CLI commands 38
Color Space 26
Color suppression 25
Colors are incorrect 14
Command line interface commands 38
Component cable connector 7
Composite video connector 7
Computer, connecting 10
Connecting
computer 10
power cable 7
video device 7
Connector panel 4
Contacting DreamVision 17
Customer service contact information 17
D
D65 colors 9
Dimensions of projector 36
Display Messages 28
DreamVision website 2
DVI connector 7
E
Error codes 34
F
Factory Reset 30
Faroudja video proecessing 25
Focus 9
Fuzzy image 17
H
HDTV 6, 20, 22, 35
HDTV sources 26, 27
Height, adjusting 8
High Power 28
Horizontal Position 27
41
I
display video 8
focussing 9
size 5
zooming 9
Inputs 35
IR repeater 4
K
Keystone 9, 22
L
Lamp replacement 31
Lamp timer, resetting 32
Lamp won’t turn on 15
Language 29
LED
blinking green 11
blinking red 15
solid green 11
LED behavior 11, 34
Lens cleaning 30
Letterbox 23
Luma Detail 25
M
Main menu 21
Maintenance 30
Menus 21
changing the language 29
making translucent 29
N
Native 22
Natural Wide 23
No computer image 16
No startup screen 12
Noise Reduction 25
NTSC Pulldown 25
O
Offset 5
Only startup screen appears 16
Optional accessories 33
Overscan 27
P
Phase 27
Picture menu 22
Power button 8
power cable 7, 10
Power Save 11, 29
Presets 24
projection distance 5, 34
projector
adjusting height 8
cleaing the lens 30
compatible sources 35
connecting a video device 7
connector panel 4
controlling projection screen 4
customizing 20
dimensions 36
displaying a video image 8
image sizes 34
included items 3
inputs and outputs 35
LED behavior 11
maintaining 30
menus 21
42
optimizing images 20
optional accessories 33
overview 3
positioning 5, 8
remote control 19
replacing the lamp 31
resetting lamp timer 32
saving settings 24
security lock 32
setting up 5
shutting down 11
specifications 33
standard accessories 33
troubleshooting 11
R
Rear 28
Remote control 19
Replacing the lamp 31
Resetting the lamp timer 32
Resize button 22
Resolution 3
RS-232
connecting 4, 10
RS232
specifications 37
S
Security lock 32
Serial connection 10
Serial connection 4, 37
Service Code 30
Service menu 30
Settings menu 28
Shutting down the projector 11
Skintone Bypass 25
Solid green 11
Solid red 11
Source compatibility 35
Source troubleshooting 12, 16
Sources 28
Specifications 33
Standard accessories 33
Startup Logo 29
S-video connector 7
System menu 28
T
Temperature limits 33
Test Pattern 30
Tracking 27
Triggers 4
Troubleshooting 11, 12, 16
TrueLife settings 25
TV tuner 6
V
Vertical Position 27
VESA connector 7
Video connections 6
Video images, optimizing 20
Video processing 25
W
Warranty 17
Website 2
Z
zoom 9
43
Limited Warranty
Subject to the Limitations, Exclusions and Disclaimers hereof, TEC SA
DreamVision (DreamVision) warrants that the Projector, Lamps and Acces-
sories (hereinafter collectively or individually referred to as “Product” as
appropriate) purchased from DreamVision or ibe if tge DreamVision dis-
tributors will conform to DreamVisions’ specifications and be free from
defects in material or workmanship for the respective Limited Warranty
period. DreamVision does not warrant that the Product will meet the spe-
cific requirements of the end-user customer.
If the Product while subject to this Limited Warranty, is defective in material
or workmanship during the warranty period, then DreamVision, at its
option, will REPAIR or REPLACE the Product.
All exchanged parts and Products replaced under this Limited Warranty
will become property of DreamVision. Dr
eamVisions’ sole obligation is to
supply (or pay for) all labor necessary to repair the Product found to be
defective within the Limited Warranty period and to repair or replace defec-
tive parts with new parts or, at the option of Dr
eamVision, serviceable used
parts that are equivalent or superior to new parts performance. Limited
Warranty periods are as follows:
• Pr
ojector Product Limited Warranty Period (Excluding Lamps):
• See distributors’ specific conditions.
• Lamp Pr
oduct Limited Warranty Periods: From the date of Projector
Product purchase, the original installed lamp shall have a 90-day or
500 hours usage Limited Warranty Period, whichever comes first, and
replacement Lamps purchased at the time of Projector Product pur-
chase will have a 500 hours usage Limited Warranty period.
• Accessor
y Product Limited Warranty Period: one (1) year from date
of purchase.
WARRANTY LIMITATION AND EXCLUSION
THIS WARRANTY SETS FORTH DREAMVISIONS’ MAXIMUM LIABIL-
ITY FOR ITS PRODUCT. THIS WARRANTY EXTENDS ONLY TO PROD-
UCTS PURCHASED FROM DREAMVISION OR A DREAMVISION
AUTHORIZED RESELLER.
DreamVision shall have no further obligation under the foregoing Limited
Warranty if the Product has been damaged due to abuse, misuse, neglect,
smoke exposure (cigarette or otherwise), accident, unusual physical or elec-
trical stress, unauthorized modifications (including use of an unauthorized
mount), tampering, alterations, or service other than by DreamVision or its
authorized agents, causes other than from ordinary use or failure to prop-
erly use the Product in the application for which said Product was intended.
This Limited Warranty excludes Product cleaning, repair, or replacement of
plastics due to cosmetic damage and damage as a result of normal wear.
Product repair outside of the terms of the Limited Warranty will be on a
time and materials basis. Prolonged Product “demonstration” causes
unusual Product wear and is not considered normal use under the terms of
this Limited Warranty.
The Accessory Product Limited Warranty covers the accessory item only
and excludes normal wear. The Lamp Product Limited Warranty excludes
expected lamp degradation.
Remanufactured Products and Software Products are exempt from the fore-
going Limited Warranty. Please refer to the appropriate Remanufactured
Product Limited Warranty or Software Product Limited Warranty for appli-
cable Warranty information.
DISCLAIMER OF UNSTATED WARRANTIES
THE WARRANTY PRINTED ABOVE IS THE ONLY WARRANTY APPLI-
CABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR
PURPOSE ARE DISCLAIMED. THERE
ARE NO WARRANTIES THAT
EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF AND
THE FOREGOING WARRANTY SHALL NOT BE EXTENDED, ALTERED
OR VARIED EXCEPT BY WRITTEN INSTRUMENT SIGNED BY DREAM-
VISION. SOME JURISDICTIONS DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY MAY LAST, SO SUCH LIMITA-
TIONS MAY NOT APPLY TO YOU.
Loading...
