2 3
URL : http://www.iRiver.com
Provides information on our company, products, and email addresses for
support.
Unique feature of “Firmware (system software) Upgrade” is available for
download on our site. The Firmware provides new features as well as
enhancements to current features. New CODECS that will be introduced in
the future will be supported via Firmware Upgrade.
Provides FAQ as well as a User’s Forum.
Register your iRiver product online so that our Customer Service is able to
provide support as efficiently as possible.
iRiver Limited does not assume any responsibility for errors or omissions in
this document or make any commitment to update the information contained
herein.
iRiver is a registered trademark of iRiver Limited in the Republic of Korea and
/or other countries and is used under license. Microsoft Windows Media and the
Windows Logo are trademarks or registered trademarks of Microsoft
Corporation in the United States and /or other countries.
All other brand and product names are trademarks of their respective
companies or organization. All other product names may be trademarks of the
companies with which they are associated.
1999-2003 iRiver Limited. All right reserved.
Unique Design
Multi-Codec Player
: Supports MP3, WMA, ASF formats.
Firmware Upgrade
: Provides the latest updated features via firmware upgrade.
Player features such as add on, modification, and continuous improvement of
player are always provided.
Graphic LCD supporting Multiple Languages
: iFP-300 Series comes with graphic LCD which can support multiple languages
FM Function
You can easily listen to FM stations and set your favorite stations by using Auto
Preset and Frequency Memory functions.
6 Preset EQ :
Normal, Rock, Jazz, Classic, U Bass, Metal
5 Band User EQ
GUI(Graphic User Interface) MENU SUPPORTING
Easy Navigation
Support MP3 Direct Encoding:
8KHz ~ 44.1KHz, 8Kbps ~ 320Kbps
4
5
FRONT VIEW
SIDE VIEW 1
INTRODUCING TO THE IRIVER WEBSITES.....................................................................
UNIQUE FEATURE.............................................................................................................
CONTENTS.........................................................................................................................
1. LOCATING THE CONTROLS
FRONT VIEW, SIDE VIEW 1...............................................................................................
SIDE VIEW 2........................................................................................................................
LCD WINDOW.....................................................................................................................
2. BASIC OPERATION
BASIC OPERATION............................................................................................................
INSTALLING SOFTWARE ON THE PC..............................................................................
BASIC OPERATION EXPLANATION..................................................................................
PLAYER & FILE TRANSFERING........................................................................................
HANDLING FOLDERS & FILES..........................................................................................
ADDITIONAL FUNCTIONS..................................................................................................
LISTENING TO MUSIC.......................................................................................................
OPERATING THE FM TUNER............................................................................................
RECORDING FM.................................................................................................................
RECORDING VOICE...........................................................................................................
RECORDING EXTERNAL EQUIPMENT
3. USEFUL FEATURES
NAVIGATION(SEARCHING)...............................................................................................
MNAVIGATION(MODE).......................................................................................................
PROGRAM MODE...............................................................................................................
EQ MODE............................................................................................................................
MENU...................................................................................................................................
4. ADDITIONAL INFORMATION
POWER SUPPLY................................................................................................................
TROUBLE SHOOTING........................................................................................................
PRECAUTIONS...................................................................................................................
ACCESSORIES...................................................................................................................
SPECIFICATIONS...............................................................................................................
Neck Strap
MIC
LCD Window
Volume +
Volume -
STEREO
Power ON/OFF
/ (Play/Stop)
MEMORY/EQ
A-B
Mode/REC
6 7
SIDE VIEW 2
LCD Window
THE ORDER
OF SONGS
BIT RATE
PLAY
TIME
PLAYBACK MODE
BATTERY INDICATOR
VOLUME
EQUALIZER
WAVEFORM
FOLDER NAME
SAMPLING RATE
PROGRAM
FILE
FORMAT
ARTIST/TITLE NAME
HOLD
USB Connection Port
Hold
Earphone
Battery Compartment
8 9
When using Navigation
Click
1. LCD window.
2. To select the previous music for
MP3 or station for FM.
3. To increase volume
4. To select the next music for MP3 or
station for FM.
5. To decrease volume
6. To select NAVI/MENU function.
7. To start or stop playback for MP3,
to select mode for FM or turn off.
8. To select EQ mode, A-B repeat or
memory stations for FM
automatically.
EQ:NORMAL ROCK JAZZ
CLASSIC UBASS METAL
USER EQ
9. To select function, playback mode,
or record/stop recording.
When using Menu
Long Click
Press NAVI/MENU button and find the desired track by pressing the VOL + or VOL – button.
To select the track, press the NAVI/MENU button, or the PLAY/STOP button.
To move to the upper folder, push the switch.
If there is no upper folder, NAVIGATION stops.
Press + on volume button to increase volume
and press – on button to decrease volume.
Selecting FM Mode when listening FM :
(Refer to p. 34)
P
u
s
h
Click
BASIC OPERATION
NAVIGATION
Long Click
P
u
s
h
Click
MP3 FM VOICE LINE IN Changing :
10
A long press of
the
NAVI/MENU button will execute
the
menu function.
Scrolling between menus : Press and
Exit : Push the VOL - switch down or hold down the NAVI/MENU button.
Select Function: Press the NAVI/MENU Button to down.
While an MP3 file is playing, press MODE/REC to activate selected modes,
such as Repeat and Shuffle.
Press and hold the MODE/REC button:
You can select MP3 or FM or voice or Line-in recording functions (Play mode is
automatically activated when MP3 is selected).
MENU
MODE
11
Stop playback.
Click the
“NAVI/MENU”
button.
Select the files to delete by
using VOL
or VOL .
Click the “MODE” button.
“File delete are you sure?” is displayed on
the LCD.
Select “yes”by using
and
to
delete. Then click NAVI/MENU button.
FILE DELETE
Stop playback.
Select the folder to delete.
Click the “MODE” button.
“Folder delete are you sure?” is displayed on the
LCD.
Select “yes”by using
and
to delete.
Then click NAVI/MENU button.
You can only deletea blank folder. In order to delete a folder, you must first delete the files in the folder.
FOLDER DELETE
Click the
“NAVI/MENU” button.
DELETING FILES ON THE PLAYER
DELETING FOLDERS ON THE PLAYER
NOTE
Insert the Installation CD into the CD-ROM drive. The following
screen appears after inserting the CD.
You can save MP3 files or other types of files on the Player and other types of
files except music files(MP3, WMA, ASF) on the PC by using the Music Manager
Program.
You can update the features of the player by downloading from the internet.
(Log on to www.iriver.com)
The installation CD contains the
following contents :
- Device Driver
- Manager Program
System Requirements
Pentium 133MHz or faster CD-ROM drive
USB port 10MB free hard disk space
Window 98SE / ME / 2000 / XP
When installation is automatically not
started, execute the setup.exe of the
installation CD, and then the Manager
program is automatically setup.
When installing in O.S after Microsoft Windows 2000, install the software
after log-in on administrator
12
Connect the USB cable to the PC after playback stops. It may cause malfunction.
Connect the USB cable(provided) to the USB port of your computer.
Type “A”
Type “B”
USBportonthePC
USBportontheiFP-300Series
USB cable
Type “A”
Type “B”
Turn on the player, remove the
protective cover of USB port, and
connect the USB cable.
“USB CONNECTED” will appear on
the LCD of the player.
To install “New hardware”
13
NOTE
14
15
Click “Next” to Install iRiver Music
Manager.
Click “Next” after selecting the
language to install.
Select the folder to Install.
Click “Next”.
Installation is progressing.
Click “Install” to install.
Click “Finish”
Completed the installation of “New
hardware”.
16 17
Click „Continue Anyway“ inspite of following alert display when installing in
Window XP O.S.
When installing in Window XP O.S.
1. Basic operation
Manager version to be Installed is
displayed.
Initial activated manager window
Double click the iRiver Music Manager
icon on the PC to start the Manager
program.
19
1) Downloading from the PC
Select the folder and the file on the
PC to download to the player.
Select the folder to be saved in the
player.
2. PLAYER & FILE TRANSFERING
18
Click the “Download” icon or select
“Download” in the Transfer menu to
download.
Files which file name is over 127 chracters(Korean: 63characters) by English is not downloaded.
Files over 511 chracters by English including path name and file names is not downloaded.
In ROOT folder, the numbers of files can be recorded are totally limited to 1024, which includes
the file names is 8 and extended file name is 3. But it is unlimited in the lower folder.
Downloading is processing.
Downloading is completed.
CAUTION
20 21
1) Uploading to the PC
Select the folder to be saved on the
PC.
Click the “Upload” icon or select “Upload” in
the Transfer menu to upload.
Select files or folders in the player
to save.
- You cannot upload general music files(MP3, WMA, ASF) from the player to the PC
according to copyright laws.
- You can upload files made by the player or general data files besides music files.
Uploading is completed.
Uploading is processing.
CAUTION
22
3) Transfering of folders or files on the player
23
Drag and move folders or files to be moved to the wanted place.
4) Moving to upper folder(PC & Player)
Move to upper folder on the PC
Move to upper folder on
the player
Click the “Refresh” icon
to display the contents of the PC or player.
5) Refresh(PC & Player)
Move to upper folder on the PC
Move to upper folder
on the player
Click the “moving icon to upper folder” in the menu bar of the iRiver Music Manager.
