1
User Manual
&
2
Before using DreamScreen, review the “For Your Safety” section of this manual. Conrm
you have all the parts of the DreamScreen. Follow the instructions and diagrams for an easy
installation to enhance your TV.
DreamScreen Products
All available in &
Classic
Mega
Xtreme
DIY
FLEX
TV Sizes 35-45 inches TV Sizes 65-80 inchesTV Sizes 45-65 inches
Use your own LEDs
3
Video
Responsive LED backlighting responds to
the colors on your TV or computer screen.
Imagine all of your favorite TV, Movies & Video
Games bigger, brighter and easier on your
eyes. Smart TV lighting at 60 fps creates the
ultimate immersive home theater experience.
Music
Watch DreamScreen’s LED lights dance to
your favorite beats and create a visual musical
experience. Choose from 4 Audio Visualizers
and advanced music color settings. Connect
through HDMI or an Audio Jack to get the
party started.
Ambient
Choose a vibrant array of colors in Ambient
Mode or enjoy the dynamic Ambient Scenes
like tranquil “Ocean” or “Fireside”. Advanced
Settings to customize your DreamScreen
experience.
Smart TV Backlighting in 3 Modes!
Total Control via WiFi! Add Surround Lighting with DreamScreen SideKick
4
Table of Contents
Parts of DreamScreen (for HD, 4K and DIY)
Important Information
DreamScreen HUB (HD & 4K)
Installing Classic, Mega & Xtreme
Installing FLEX LEDs
Installing Your LEDs with DreamScreen DIY
DreamScreen Connections
Download the App and Connect to WiFi
Adding DreamScreen to WiFi network
Naming and Grouping DreamScreens
Using the DreamScreen App
Setting the size in DreamScreen App
Video Settings
Music Settings
Advanced Settings
Troubleshooting/Setup Help
For Your Safety
Regulatory Notices
5
6
7
8
10
12
14
15
16
18
19
20
21
22
23
24
25
26
5
Power Supply
For all models
LED Reel &
FLEX Connector
Only for FLEX
HDMI Cord
For all Models
Parts of a DreamScreen HD | 4K | DIY | LEDs
DreamScreen Hub
For all Models
LED Lights
Only for
Classic, Mega & Xtreme
DIY Connector
Only for DIY
Pg
12
Pg
8
Pg
10
*USA power supply pictured.
World wide power supplies oered.
FLEX only
DIY only
6
(Classic, Mega
and Xtreme option
shown here)
7
DreamScreen HUB (HD & 4K)
Power Supply LED Out 2
HDMI Out to TV
LED Out 1
3.5mm
Audio Jack
Mode
HDMI Source
Power Detect HDMI-In 1 HDMI-In 2 HDMI-In 3
Video
Music
Ambient
Sleep
Indicator LED
Connect all of your favorite devices
and label them in the DreamScreen App
8
Installing Classic, Mega & Xtreme
Classic
Mega
Xtreme
Mega
Xtreme
Total of 12 LED Strips
4 LED Strips
TV Sizes 32-45 inches
2 LED Strips
4
6
8
2
3
4
12
18
24
32"-45"
45"-65"
65"-80"
TV
Size
Horizontal
LED Strips
Vertical LED
Strips
Total
LED Strips
The Classic, Mega and Xtreme sizes are
designed for a range of TV sizes.
Use this page as a visual guide to check if
your DreamScreen size is correct.
8 LED Strips
TV Sizes 65-80 inches
4 LED Strips
Total of 24 LED Strips
6 LED Strips
TV Sizes 45-65 inches
Total of 18 LED Strips
3 LED Strips
For more assistance and instructional videos
visit www.dreamscreentv.com/setup
Classic
9
1 2
3
Peel adhesive cover from LED strip.
Start at the BOTTOM LEFT of the BACK of your TV.
Apply CLOCKWISE.
*Before install, wipe TV of dust and debris.
Adhere LEDs along the edge of your
TV. The adhesives are designed to be
forgiving during install, so adjust as
necessary.
*Mega size shown here.
Installing Classic, Mega & Xtreme
For more assistance and instructional videos
visit www.dreamscreentv.com/setup
10
Peel adhesive cover from LED strip.
Installing FLEX LEDs
Start adhering the LEDs at any corner.
Apply and press LEDs into position.
The adhesives are designed to be forgiving during
install. So adjust as necessary.
After selecting starting corner,
adhere in clockwise or anti-clockwise direction.
11
At the start of
the LED Strips.
Installing FLEX LEDs
When arriving at a corner,
fold the strip at a 90° angle as shown here.
Insert the cut end into the
Flex Connector.
Fold the wings of the Flex
Connector.
Press the wing until it snaps
shut
12
Peel adhesive cover from LED strip.
Installing Your LEDs with DreamScreen DIY
Start adhering the LEDs at any corner.
After selecting starting corner,
adhere in clockwise or anti-clockwise direction.
Apply and press LEDs into position.
The adhesives are designed to be forgiving during
install. So adjust as necessary.
13
When arriving at a corner,
fold the strip at a 90° angle as shown here.
Place each wire from the LED strip into the
corresponding slot in the DIY connector and use a
screwdriver to secure the wires in place.
The connections are 5V, DOUT (Signal) and GND.
Installing Your LEDs with DreamScreen DIY
14
DreamScreen Connections
LED 2 - Extra LED input
for FLEX or DIY
Power Supply
HDMI to TV LED 1 - Input
HDMI 3
HDMI 2
HDMI 1
15
Download the App and Connect to WiFi
Enjoy full control of your DreamScreen via
WiFi on the Android and iOS app.
Download now by searching
DreamScreen TV in the Apple or Google
Play Store.
16
Adding DreamScreen to WiFi network Android Users
Install and Plug in devices
then select Add New
Devices to Network.
Select Devices and Press
Continue
Select network in dropdown
Enter your
WiFi Password
The app will now connect to each device and add them to the network. This process can take a few
minutes depending on the number of devices. You may see the lights blink during this process.
17
Adding DreamScreen to WiFi Network iOS Users
Plug in all your devices
and press here to add to
network.
Select the devices that you
want added to network and
press continue.
Select network in
dropdown
Enter password and
press continue.
The app will now connect to each device and add them to the network. This process can take a
few minutes based on number of devices. You may see the lights blink during this process.
Connecting in
iOS settings
18
Naming and Grouping DreamScreens
Swipe to Right /
Press Menu
to view Groups &
Devices
User-dened
Groups
Add new Device
Unlock to edit
Naming and
Grouping
Group Title
Devices in Group
Edit Naming and Grouping
19
Using the DreamScreen App
Brightness Control
Select HDMI Source
Will change color when active.
Music from Audio Jack
Music from HDMI
Settings
Name of DreamScreen
Device selected
Select Video, Music or
Ambient Mode
20
Setting the Size in DreamScreen App
Select Size in Dropdown
FLEX and DIY only
Horizontal Count
Vertical Count
Unlock to Edit
Select allocation
of LED 1 and LED2
184 LEDs on single output
starting top left of screen
92 LEDs on each output
30 LEDs overlapping on top
Guides for Classic, Mega
& Xtreme/App Install
FLEX & DIY
Examples
Pick a Starting Point
Set Horizontal/Vertical
LED Count
21
Video Settings
Adjust the RGB Channels
when the wall behind the
TV is not white.
The fade rate setting
adjusts the reaction
speed of the LEDs.
Enhances RGB tones to make
lighter hues appear stronger.
Can either be disabled
or set to three levels:
Low, Medium or High.
Widescreen Detection can
either be Automatic, Manually
Enabled or Disabled.
Set a minimum background
light irrespective of content
on screen.
22
Music Settings
Audio Visualizers
Select from 4 Audio
Visualizers to enhance your
music experience
Adjust color of
Treble, Middle, Bass.
Adjust intensity of
Treble, Middle, Bass.
23
Advanced Settings
Control Zones of TV that are On.
Control Zone Intensity
Enable CEC communication between TV
and selected source.
Allow for CEC commands to switch to
active HDMI source.
Allow for DreamScreen to automatically switch
to sleep mode if the USB port on the TV turns
o.
Allow for TV to turn o DreamScreen lights via
CEC. This feature will require your TV to have
CEC capability and the option enabled in the
TV’s settings
If DreamScreen is changing LEDs faster than the TV,
this setting can be used to delay the LEDs up to
60 frames.
24
Troubleshooting/Setup Help
No Video/Audio Showing on TV:
First check that all cords are connected:
Check to make sure Video Sources (Cable, Chromecast, AppleTV, XBox,
Playstation, etc.) are connected to the DreamScreen hub’s INPUT and the TV is
connected to the OUTPUT.
Ensure that the correct HDMI input channel is selected on your TV.
Check to ensure that the video source is HDMI 1080p, 1080i, 4K or 720p.
The LEDs around my TV are not lighting up:
Verify the DreamScreen HDMI Hub is powered ON - Check the indicator light on
the DreamScreen HDMI Stick.
Check if LEDs are connected to the bottom of the DreamScreen Hub -
Toggle through dierent modes - Indicator lights will change.
Check the Advanced Settings of the App - Are all the Zones turned o?
Check the App - Is the Brightness turned down to zero?
Toggle DreamScreen Modes -
(Standby, Video, Music, Ambient).
Some LEDs around my TV are not lighting up:
Check to see if the correct size of DreamScreen is selected. Check Size in App:
Installation Settings Dropdown. Check size on black DreamScreen box.
Check the Advanced Settings of the App. Are any of the zones turned o?
For a list of FAQ please visit www.dreamscreentv.com/faq
For Installation Videos please see www.dreamscreentv.com/setup
In Video Mode, the LEDs are ickering:
Check to see if all the connections are correct.
Check to see if the video source is set to HDMI 1080p, 1080i, 4K or 720p.
Check out our FAQs at dreamscreentv.com/faq/
or contact us @ www.dreamscreentv.com/contact
25
For Your Safety
Important Safety Instructions - Your DreamScreen is designed and manufactured to
operate within dened design limits. Misuse may result in electric shock or re.
Read the following safety instructions before operating your DreamScreen.
To reduce the risk of electric shock or component damage, switch o the power
before adhering LED strips to TV and connecting LED Strips, HDMI components to
DreamScreen. Use DreamScreen with provided power supply.
Do not force the connectors into the plugs. The connectors are designed to be
easily inserted and removed.
Do not install any components near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that produce heat. Do not
install LED Strips on surfaces that have a temperature higher than 60C (140F).
Protect the cords from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the device. For wall
mounted TV ensure that the wire is not stretched or pinched in wiring conduits.
Do not dismantle DreamScreen Hub. Do not use the LED Strips with any other LED
Lighting controllers.
Do not attempt to splice wires to extend or reposition the LED Strips.
This product is not intended to be used outdoors. Do not use this product near
water or excessive moisture.
DreamScreen is not responsible for any seizures from over exposure to rapid
lighting. Use DreamScreen products at your own risk.
26
Regulatory Notices
FCC COMPLIANCE STATEMENT: This device complies with part 15 of
the FCC
Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
INFORMATION TO USER: This equipment has been tested and found
to comply with the limits for a Class B digital device, pursuant to Part
15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions,
it may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or TV reception, which can be determined by
tuning the equipment o and on, the user is encouraged to try and
correct the interference by one or more of the following measures:
* Reorient or relocate the receiving antenna * Increase the distance
between the equipment and the receiver. * Connect the equipment
to outlet on a circuit dierent from that to which the receiver
is connected. * Consult the dealer or an experienced radio/TV
technician for help.
FCC ID: Contains 2ADUIESP-12-F
27
Hereby, DreamScreen LLC, declares that DreamScreen is in
compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
The symbol on the product or its packaging signies that this
product has to be disposed separately from ordinary household
wastes at its end of life. Please kindly be aware that this is your
responsibility to dispose electronic equipment at recycling centers
so as to help conserve natural resources. Each country in the
European Union should have its collection centers for electrical
and electronic equipment recycling. For information about
your recycling drop o point, please contact your local related
electrical and electronic equipment waste management authority
or the retailer where you bought the product.
Regulatory Notices
28
Thank you for purchasing a DreamScreen!
Questions & Comments - info@dreamscreentv.com
Socialize With Us!
/DreamScreentv@DreamScreentv
Loading...
