1. We suggest you spend a short time reading through this leaflet and then
follow the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the assembly
should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they remain
fully tightened.
7. Keep glue and fittings out of children’s reach.
In the unlikely event that this product has missing or damaged parts, please
call 08442 920000 to obtain spares
Before you
start, here
is some
helpful advice
Minimum No. of people
recommended to assemble
This product.
Approx assembly time:
BRUGES SUPER KING B/S
Assembly Instructions
NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that
the bed will be used in.
1 of 7
Component parts and fittings contained in the box
PARTS
Fittings（A）
A
B
C
D
E
F
G
H
I
J
K
L
O
N
M
M6 JCN Nut 6pcs
Connector 4pcs
Connecting bolt 4pcs
Spanner 1pc
Ф8 Spring Washer 4pcs
M8 Nut 4pcs
M6x35mm Bolt 6pcs
Φ10 Dowel 4pcs
M6x60 Bolt 12pcs
4MM Allen key 1pc
Φ8 Dowel 16pcs
Locking Nut 16pcs
Locking Pin 16pcs
35mm Screw 28pcs
16mm Screw 6pcs
2 pieces
4 pieces
1 piece
4 pieces
4 pieces
4 pieces
4 pieces
1 piece
1 piece
1 piece
3 pieces
2 pieces
2 pieces
1 piece
2 pieces
2 of 7
ASSEMBLY
1) Attachment of center rails to side rails.
1) Attachment of short rails to center rails.
STEP 1
STEP 2
STEP 3
3 of 7
ASSEMBLY
1) Attachment of side rails to Head/footboard.
1) Attachment of side panel onto the back
panel.
1) Slide the bottom panel into the unit.
STEP 5
STEP 4
STEP 6
4 of 7
ASSEMBLY
1) Assembly of the front panel onto side
frame.
ng panel onto
1) Slot in the Drawers.
1) Attachment of leg to center rail.
STEP 9
STEP 8
STEP 7
Ensvre the center
leg place on floor
5 of 7
ASSEMBLY
NOTE: Slats not supplied shown
for reference only.
Both slats on “step 10---step 13”
can be assembled to the
bedstead. You can make a
choice between the two slats.
1) Support leg height have the four
position, you can adjust according to the
bed height to choose the right position to
fix in the “STEP 10”.
2) If need, you can adjust by screwing in or
out the support leg leveler at the bottom.
1) Use the pcs bolts, supplied with the
slat frame to fix the leg onto the slats
frame.
1) Carefully place the slat frame onto the
bed.
2）Use bolt (F) and JCN nut (G) to fix the
slat frame onto the bed.
STEP 12
○
1
○
2
○
3
○
4
Select correct height for your bedstead
STEP 10
STEP 11
6 of 7
ASSEMBLY
Solid Slat System:
1) Carefully place the slat frame onto
the bed.
2）Use bolt (F) and JCN nut (G) to fix the
Slat frame onto the bed.
STEP 13
7 of 7
