1. We suggest you spend a short time reading through this leaflet and then
follow the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the assembly
should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they remain
fully tightened.
7. Keep glue and fittings out of children’s reach.
In the unlikely event that this product has missing or damaged parts, please
call 08442 920000 to obtain spares
Before you
start, here
is some
helpful advice
Minimum No. of people
recommended to assemble
this product.
Approx assembly time:
ASPEN BED
Assembly Instructions
NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that
the bed will be used in.
1 of 5
Component parts and fittings contained in the box
PARTS
Fittings（A）
(Hardware to fit on bed frame)
A
B
C
D
E
F
G
H
I
J
K
M6 JCN Nut 6pc s
5MM Allen key 1pc
Connector 8pcs
Connecting bolt 8pcs
Spanner 1pc
Ф8 Spring Washer 8pcs
M8 Nut 8pcs
M6x35mm Bolt 6pcs
Dowel 8pcs
M8x60 Bolt 8pcs
1 piece
2 pieces
1 piece
4 pieces
4MM Allen key 1pc
2 of 5
ASSEMBLY
1) Fix the Wooden leg (4) onto the headboard
(1) and footboard (2) using bolt (I).
Tighten with Allen key (J).
1) Screw the connecting bolt (B) into the
holes on the headboard/footboard (1&2).
Then Knock the dowels (H) into the holes
indicated on the side rail.
2) Carefully fit the side Frames to the
headboard and footboard.
Use connectors (A), Spring Washer (D)
and Nuts (C) to fix the unit. (See inset).
STEP 1
STEP 2
3 of 5
ASSEMBLY
NOTE: Slats not supplied shown
for reference only.
Both slats on “step 3---step 6”
can be assembled to the
bedstead. You can make a
choice between the two slats.
1) Support leg height have the four
position, you can adjust according to the
bed height to choose the right position to
fix in the “STEP 3”.
2) If need, you can adjust by screwing in or
out the support leg leveler at the bottom.
1) Use the 8 pcs bolts, supplied with the
slat frame to fix the leg onto the slats
frame.
STEP 3
STEP 4
○
1
○
2
○
3
○
4
Select correct height for your bedstead
4 of 5
ASSEMBLY
1) Carefully locate the slats onto the unit.
Use bolt (F) and JCN Nut (G) to fix the slats
frame onto the bed. Tighten with spanner
(E) and Allen key (K)
DREAMS SOLID SLATS
1) Carefully locate the slats onto the unit.
2) Use bolt (F) and JCN Nut (G) to fix the
slats frame onto the bed . Tighten with
spanner (E) and Allen key (K)
STEP 6
STEP 5
5 of 5
