Convertible Rider
Instruction
Important: Keep these instructions for future reference.
This product is designed to comply with USA Standard: ASTM F833-15
Safe Cozy
Fashionable
.
WARNING
IMPORTANT!
Failure to follow these warnings and the assembly instructions could result in
serious injury or death. PLEASE SAVE INSTRUCTION MANUAL FOR FUTURE USE.
WARNING
• ASSEMBLY BY AN ADULT REQUIRED.
• NEVER LEAVE CHILD UNATTENDED. Always keep child in view while in stroller.
• AVOID SERIOUS INJURY from falling or sliding out. Always use seat belt. After fastening buckles,
• AVOID FINGER ENTRAPMENT: Use care when folding and unfolding the stroller. Be certain the
stroller is fully erected and latched before allowing your child near the stroller.
• NEVER USE STROLLER ON STAIRS or escalators. You may suddenly lose control of the stroller or your
child may fall out. Also, use extra care when going up or down a step or curb.
• AVOID STRANGULATION. DO NOT place items with a string around your child’s neck, suspend
strings from this product, or attach strings to toys.
• USE OF THE STROLLER with a child weighing more than 45 lb (20.0 kg) or taller than 37.8 in (96cm)
will cause excessive wear and stress on the stroller. Use the stroller with only one child at a time.
• TO PREVENT A HAZARDOUS, UNSTABLE CONDITION, never place purses, shopping bags, parcels or
accessory items on the handle. Never place anything on the canopy.
• TO PREVENT A HAZARDOUS, UNSTABLE CONDITION, do not place more than 10 lb (4.5 kg) total in
the storage basket including the 2 lb (1 kg) in the basket pocket.(if supplied)
• TO AVOID BURNS, never put hot liquids in the cup holders.(if supplied)
• TO PREVENT TIPPING, do not place more than 3 lb (1.36 kg) total in the cupholders/snack tray.
• DO NOT use storage basket as a child carrier.
• DO NOT ALLOW your child to stand on the basket. It may collapse and cause injury.
• NEVER PLACE child in the stroller with head toward footrest.
• NEVER ALLOW YOUR STROLLER to be used as a toy.
• DISCONTINUE USING YOUR STROLLER should it become damaged or broken.
• STROLLER TO BE USED only at walking speed. Product not intended for use while jogging, skating,
etc.
• CAREGIVER MUST always help child get into and out of the stroller.
• ITEM NO.: #365
• The Rider stroller has been approved in accordance with ASTM F833: 15.
02
WARNING
THE STROLLER IS DESIGNED FOR USE ON FLAT OR GENTLY SLOPING SURFACES, AND MAY BE
UNSTABLE ON HIGHER SLOPING AND UNEVEN SURFACES AND USERS SHOULD BE AWARE OF
THE POSSIBILITY OF THE STROLLER ROLLING AWAY OR TIPPING OVER.
• WITH YOUR HAND THROUGH THE WRIST TETHER STRAP LOOP, PUSH THE STROLLER HOLDING BOTH
HANDLES.
• THE FRONT WHEELS MAY WOBBLE OR OSCILLATE WHEN WALKING FAST.
• THE STROLLER CAN BE TAKEN UP KERBS BY EITHER PRESSING DOWN ON THE HANDLES AND RAISING
THE FRONT WHEELS AND MOUNTING THE KERB OR TURNING THE STROLLER AROUND AND PULLING
THE STROLLER UP THE KERB.
• CAUTION IS REQUIRED WHEN PUSHING THE STROLLER ACROSS STEEP SLOPES OR UNEVEN SURFACES.
THIS MAY CAUSE STROLLER TO BECOME UNSTABLE AND FALL OVER. ALWAYS HOLD THE HANDLES
FIRMLY.
• DO NOT RUN WITH THE STROLLER.
• WHENEVER YOU STOP, ALWAYS APPLY THE BRAKES BEFORE YOU LEAVE THE STROLLER.
• DO NOT HANG BAGS OR GOODS FROM THE HANDLE AS THIS COULD CAUSE THE STROLLER TO TIP OVER.
• THE UPRIGHT POSITIONS ARE NOT SUITABLE FOR A CHILD UNDER 6 MONTHS OLD.
X
12° or less more than 12°
03
WARNING
MANUAL HANDLING TECHNIQUES
The SMART lifting technique
This technique can be used to pick up small light loads from low levels.
Size up the Load
• Assess the load (size, shape and weight).
• Assess whether the load needs to be moved;
• Where is it going to be placed” Check that there are no obstructions;
• Assess whether mechanical or human assistance is required.
Move the Load as close to the body as possible
• A load is heavier to lift or carry if it is not close to the body.
Always bend your knees
• Maintain balance.
• Keep feet apart and in a comfortable position.
• Minimise lower back bending.
• Bend knees preferably, at as large an angle as possible but not at a right angle - use a semi squat
preference to a full squat.
in
Raise the load with your legs
• Achieve the lift smoothly and without jerkiness.
• Maintain the normal curvature of the spine to allow the force of the load to be distributed evenly
from the spine to the pelvis.
Turn your feet in the direction that you want to move the load.
• Avoid unnecessary bending, twisting and reaching.
• Change direction by turning your feet and not your back.
• To set the load down, squat down, keep your head up and let your legs do the work.
• Remember to ‘THINK TALL’. Chest lifted, shoulders relaxed, chin tucked in and head
held level.
This CAUTION Symbol is shown at certain steps in
this Instruction Manual to highlight the danger
of being injured by moving parts.
04
Seat
PARTS LIST
Adjust Button
Handle
Handle Tube
Guard Rail
Guard Rail
Support
Join Point
Front Wheels
Folding Plastic
2nd Lock
Harness
Storage Latch
Brake
Rear Wheel
Frame ConnecterGuard Rail
Front Wheel L & R Rear Wheel L & R
Seat
T-Bar
05
Simple Seat
1.ASSEMBLE THE RIDER
(1)Open storage latch, refer to
Fig. A, then Lift handle of
stroller up, refer to Fig B.
(2)Lift handle of stroller up until
you hear a “Click”, refer to Fig
C/D, CHECK that the stroller is
completely latched every time
you open the stroller and
before continuing with the rest
of the assembly steps.
(3)Front Wheels
Slide each Front wheel onto
the mounting post at the front
of the stroller as shown in Fig.
E, A “Click” will be heard. Pull
wheel to CHECK and ensure
that it is secure.
For easy transport or storage,
Push the wheel release tab on
the side of the stroller frame
and pull the wheel away from
the stroller as shown in Fig. F.
BA
DC
E
F
(4)Rear Wheels
a. Attach Rear Wheel L into
Rear tube until a “Click” is
heard, as shown in Fig. G/H.
b. repeat for Rear Wheel R,
Fig. I.
c. For easy transport or
storage, remove Rear wheel
by pushing the snap button
and taking the rear wheels out.
G
I
H
06
2.ASSEMBLY THE SEAT
(5) Insert Guard Rail
Support through the hole in
Seat and make sure the
seat back is on the inside of
the Gruard Rail as Fig. A.
Fix the Backrest to the
Guard Rail with the two
buckles as shown in Fig. B;
Pressing down on the side
buckle tongues will release
the buckle (Fig C). tongues
will release the buckle (Fig.
C).
(6) Put the Seat/Guard Rail
on the Frame Seat Board as
shown in Fig. D. Press
Guard Rail Support button
and push Guard Rail
Support into Frame Seat
Board until a 'Click' is heard,
as shown in Fig. E.
A
CB
ED
(7) Put the Female Snap
into the Male Snap on the
back of Frame Seat Board
as shown in Fig. F. A total of
6 snaps are available.
(8) Fix the Guard Rail to
Handle Tube by Buckle as
shown Fig. G: Squeeze the
side buckle tongues can
release the buckle(Fig. H).
To detach the he guard
Rail/Seat unit, simple to
reverse operation (8/7/6/5).
F
H
G
I
07
3.FOLD THE RIDER
(9)Press the Guard Rail Support
Button and take the Guard Rail
Support out, then put into seat
as shown in Fig. A/B.
(10) Press the Handle Adjust
Button and push the handle
downward as shown in Fig. C/
D.
(11)
Press the 2nd Lock and
pull the Folding Plastic upward
as shown in Fig. E/F.
BA
DC
Folding
Plastic
(12) Hold the action
(11) and pull the handle
downward untill the
Storage Latch is
locked as shown in
Fig. G/H
08
2nd Lock
FE
HG
4. SECURING YOUR CHILD TO HARNESS
WARNING:
USE THE HARNESS AT ALL TIMES.
When not in use disconnect shoulder straps from the waist
strap and fasten buckle
A five point harness is provided to secure your child. Buckle tongues are
available separately for added safety. To reconnect buckle tongues and to
secure the child in the harness please follow the steps below carefully.
Position the shoulder strap
(13)
tongue (1) on the top of the waist
buckle tongue (2) on both sides
(Fig A).
(14) Push both buckle tongues
(1+2) into the buckle housing (3)
until the buckle tongues lock into
position (Fig B).
to prevent strangulation.
1
Waist
strap
2
A
13
Shoulder
strap
Shoulder straps
Buckle
housing
Crotch strap
3
Buckle
housing
3
Waist
strap
2
Shoulder
strap
1
(15) Tighten or loosen crotch straps by
sliding up and down the 3 bar sliders.
Tighten or loosen the waist straps, hold
and lift the 3 bar slider and then pull the
harness strap, to adjust to the desired
fit. The waist strap needs to fit firmly
around the child (Fig C).
Waist
strap
B
13
13
C
09
1
3 bar
slider
2
Crotch strap
1
3 bar
slider
Crotch strap
2
Waist
strap
5. SECURING YOUR CHILD TO HARNESS
(16) Tighten or loosen the Shoulder strap, hold and lift the slider and then pull the harness
strap, to adjust to the desired fit. The waist strap needs to fit firmly around the child (Fig D).
(17) To release the buckle. Squeeze the top botton and Buckle housing with enough pressure
so the buckle tongues can release from the buckle housing (Fig. E).
loosenTighten
D E
6.USING THE
(18)Parking and loosening the brake:
Push the Brake Rail down to park;
Lift the Brake Rail up to loosen, Fig. A
WARNING:
APPLY THE BRAKES WHEN THE STROLLER
IS STATIONARY.
USING GUARD RAIL ONLY
7.
BRAKES
ALWAYS
A
FOR KIDS MORE THAN 3 YEARS OLD, YOU MAY USE T-BAR OR
GUARD RAIL WITHOUT SEAT.
(19) Detach the Seat unit from the Rider. and add the Simple Seat into the Frame Seat Board
Put the Female Snap into the Male Snap on the back of Frame Seat Board.
10
8. USE T-Bar GUARD RAIL ONLY
Detach the Guard Rail from Guard
(20)
Rail Support Tube as shown in Fig A.
Press the T-Bar quick release
(21)
button and then put T-Bar into Guard
Rail Support Tube as shown in Fig. B.
A
B
9. TO LIFT AND CARRY THE STROLLER
IMPORTANT NOTES: While lifting or carrying the stroller, ensure that
the storage
along the stroller, so the stroller is balanced.
Please refer to page 4 Manual handling techniques.
latch is engaged and grasp the frame approximately halfway
11
11
10. CONNECT THE RIDER TO BABY STROLLER
The connector is designed to be
a universal parts. It can be used
for most baby strollers to convert
the stroller into a rider+stroller.
(22) Press the connecter quick
release botton and then connect
to rider join point as shown in
Fig. A/B/C.
To detach the connecter, simply
press the quick release botton
then ramove from join point.
(23) Fix the connecter to rear leg
of the baby stroller using belt,
make sure the belt is tight
enough and fasten the end of
belt with the velcro provided as
shown in Fig. D/E/F.
BA
DC
ATTENTION:
When using rider join point on
the left,
of the stroller.
When using rider join point on
the right, connect to the left rear
leg of the stroller.
Refer Fig. G/H.
connect to the right leg
FE
HGH
12
CARE AND MAINTENANCE
• To maximize the life of your stroller keep it clean and do not leave it in the direct sunlight or in the
car boot for extended periods of time.
• Removable fabric covers and trims may be cleaned using warm water with a household soap or mild
detergent. Allow to dry fully, preferably away from direct sunlight.
• Non-removable fabric covers and trims may be spot cleaned using a damp sponge with soap or a
mild
detergent. Allow to dry completely before folding or storing away.
• In some climates the covers and trims may be affected by mould and mildew to prevent this from
occurring, do not fold or store the product if it is damp or wet. Always store the product in a well
ventilated area.
• After using your stroller at the beach - Completely clean your stroller to remove the sand and salt
from the mechanisms and wheel assembly. Sand and salt will cause premature wear and corrosion.
• If there are compression marks on the tyres - Use a domestic hair dryer to gently warm (DO NOT
OVERHEAT) the tyre and the compression marks should slowly disappear.
• Always check parts regularly for tightness of screws, nuts, and other fasteners, tighten if required.
• To maintain the safety of your nursery product, seek prompt repairs for bent, torn, worn or
broken parts.
IMPORTED BY:
DREAM ON ME INC.
1532 SOUTH WASHINGTON AVE PISCATAWAY TWP NJ 00854 USA.
For customer service, warranty information or replacement parts,
please call us at: 732-752-7220
or visit us online at: www.dreamonme.com
MADE IN ZHONGSHAN, GUANGDONG, CHINA.
13
Loading...
