AQUA UNO
TUB DOOR INSTALLATION INSTRUCTIONS
IMPORTANT
DreamLine
without prior notice. For the latest up-to-date technical drawings, manuals or any
TM
reserves the right to alter, modify or redesign products at any time
other details please refer to the support.bathauthority.com
web page.
Please carefully read the instructions before installing. If you have any questions
regarding installation, please call our technical support specialists Monday through
Friday 9:00 AM – 5:00 PM EST at 1-866-731-8378, ext. 3 or e-mail our technical
support group at
For more information on DreamLineTM Tub Doors please visit www.BathAuthority.com
Rev 1.1
support@BathAuthority.com.
1
Preparation
1. After opening all boxes and packages, read this introduction carefully. Check that all of
the needed parts are included in the package, by marking all the components on the
“Detailed Diagram of Tub Door Components”. Examine boxes and packages for shipping
damage. If the unit has been damaged, has a finishing defect, or has missing parts, please
contact our customer support department within 3 business days of the delivery date.
Please note that DreamLine TM will not replace any damaged products or missing
parts free of charge after 3 business days or if the product has been installed. Feel
free to contact DreamLineTM if you have any questions.
2. If this unit is going to be installed in a new construction, please, install all of the required
plumbing and drainage before installing the shower. Use a competent and licensed (if
required by local code) plumber for all plumbing installation
3. Please note that you should consult your local building codes with questions on
installation compliance standards. Building and plumbing codes may vary by
location, and DreamLine is not responsible for code compliance standards for your
project.
4. Please insure that prior to the installation the installation surface is leveled and solid and
will be able to support the total weight of the unit. Also make sure the walls are at right
angles. While some adjustment in leveling of the door is possible, irregular installation
surface level or improper angle of side walls will result in serious problems for your
installation. Please, note that some adjustments and drilling might be necessary during
the installation process.
Rev 1.1
Tape
Measure
Level
Tools Required
Pencil
Electric
Drill
P hillip s
S cre w d rive r
D r ill b it
(Ø 5/16")
Hammer
2
Detailed Diagram of Tub Door Components
4
5
6
3
7
1
2
8
Packing List
01 Glass door 1pc 05 Hinge 2pcs
02 Handle 1pc 06 Side anti-water strip 1pc
03 Wall anchor 6pcs 07 Bottom anti-water strip 1pc
04
Flat head screw ST5×35
6pcs 08 2mm, 4mm Hex wrench 1set
NOTE: Unpack your unit carefully and inspect it. Lay it out and identify all parts using the
detailed diagram and packing list in your manual as a reference. Before discarding the carton,
check for small hardware bags that tend to fall to the bottom of the box. If any parts are
TM
damaged or missing, please contact DreamLine
Rev 1.1
for replacement.
3
