Dreame Cordless V9 User Manual

Dreame Cordless V9 Vacuum Cleaner User Manual
Important safety Instructions
Before using dreame vacuum cleaner please read user manual carefully.
Warning
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
DO NOT allow young children to operate the appliance or use as a toy. Close supervision is necessary when any appliance is used near children.
DO NOT use outdoors or on wet surfaces. Use only on dry surfaces. DO NOT handle charger or vacuum cleaner with wet hands. Inspect Battery Pack and chargers for any damage before use. DO NOT use vacuum cleaner with a damaged power pack or charger. DO NOT immerse in water when cleaning, make sure that all 󽗉lters are thoroughly dry after
routine cleaning. Always turn o󽗈 this appliance before connecting or disconnecting 󽗊oor nozzle. DO NOT use without Soft Roller, dust cup door, and all 󽗉lters in place. Use only with YLS0241A-K300080, YLS0241B-K300080 supply unit. WARNING: For the
purposes of recharging the battery, only use the detachable supply unit provided with this appliance.
DO NOT vacuum up 󽗊ammable or combustible materials (e.g., lighter 󽗊uid, gasoline, or kerosene) or use vacuum in areas where they may be present.
DO NOT vacuum up toxic solutions (e.g., chlorine bleach, ammonia, or drain cleaner). DO NOT vacuum up drywall dust, 󽗉replace ash, or embers. DO NOT use as an attachment to power tools for dust collection. DO NOT vacuum up
smoking or burning objects such as hot coals, cigarette butts, or matches. DO NOT vacuum up hard or sharp objects such as glass, nails, screws, or coins that could
damage the vacuum cleaner. Keep 󽗊oor nozzle and vacuum cleaner away from hair, face, 󽗉ngers, uncovered feet, or loose
clothing. DO NOT put any objects into openings. DO NOT use with any opening blocked, keep free of
dust, lint, hair, and anything that may reduce air󽗊ow. DO NOT place vacuum cleaner on unstable surfaces such as chairs or tables. Appliance should only be serviced by a quali󽗉ed repair person using only identical
replacement parts. DO NOT modify or attempt to repair the appliance or the power pack yourself, except as indicated in the instructions for use and care.
Follow all charging instructions and DO NOT charge the vacuum cleaner outside of the temperature range(0° C~40° C). Charging improperly or at temperatures outside of the speci󽗉ed range may damage the battery pack and increase the risk of 󽗉re.
Do not charge and use vacuum cleaner outdoors, in bathroom or pool, do not use on wet surface or for cleaning rain, water, snow.
2
This appliance complies with the WEEE-Directive 2012/19/EU on the disposal of electrical and electronic equipment (WEEE).
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
sources. To return your used device, please use the return and collection systems or contact the retailer where this product was purchased.
They can take this product for environmental safe recycling. This appliance complies with the European directives for electromagnetic compatibility (EMC)
2014/30/EU and its revisions, as well as Low Voltage Directive (LVD) 2014/35/EU and its revisions.
Please read and keep the instructions properly.
Use only with YLS0241u-x300080 supply unit.
3
Assembly
Getting to know your vacuum cleaner
Product introduction
Suction control switch
ON/OFF Button
Main machine
Cyclone
Dust cup release button
HEPA 󽗉lter
Wand release button
extension wand
4
Mental
Nozzle
Roller release button
Assembly
Accessories list
2-in-1 Crevice tool
2-in-1 Wide tool
Charger
Anti acarids nozzle
Store base
5
Assembly
Assembling Procedures
Assembling the nozzle and the wand as picture shown.
Installing the STORE BASE with the SCREW ,need drill two holes(φ8mm and 30mm depth )on the wall.
6
Assembly
Attaching Accessories
Assembling the accessories as picture shown.
Attaching the accessories and main machine in STORE Base as picture shown
7
Use your cleaner
Battery charging
Battery may be not fully charged when 󽗉rst time used.charge the battery as below picture.
3~4h
Battery Charging method 1 Battery Charging method 2
Indicators status
8
Low battery
Medium battery
High battery
Full battery
Full battery (sleep mode)
Use your cleaner
Operations
you can chose different scution setting from low to high mode by setting suction contorl switch.
Max
Normal
Low
Use of soft-cloth roller
Soft -cloth roller can be used on carpet, hard wood or tile 󽗊oor. Vacuum cleaner will shut o󽗈 nozzle power if nozzle was jamed.
Use of accessories
1. 2-in-1 Flat vacuuming head and anti acarids nozzle;suitable for cleaning suefaces of bed, sofa...etc.
2. 2-in-1 Brush vacuuming head;suitable for cleaning crevices corners...etc.
9
Maintenance
Cleaning dust cup and HEPA
Empty dust cup by dust cup release button when debris reaches the MAX 󽗉ll line.
Clean the cyclone as below picture.
10
2
1
3
Maintenance
Cleaning dust cup and HEPA
Take o󽗈 HEPA as below picture Rinse HEPA with water. Tap loose dirt o󽗈 HEPA between washes as needed. Once HEPA is
completely dry, install HEPA back.
2
Warning
Make sure HEPA completely dry.
1
3
11
Maintenance
Cleaning sofa roller Cleaning anti acarids nozzle
Take o󽗈 soft roller as picture. Remove any string, hair, or debris that
may be wrapped around the soft roller, wheel.
Take o󽗈 anti acarids nozzle cover. Remove any string, hair, or debris that may
be wrapped around the anti acarids nozzle.
12
Storage
Remove wand, nozzle, anti nozzle and accessories from main machine, and storge them at room temperature .
13
Troubleshooting
Problem Possible cause Solution
Low battery Charge battery
cleaner does not work
No suction Clean air path
Dust cup and HEPA are
Weak suction
At starting,the first lamp lights up in red
At starting,the first lamp blinks in red
On startup, the first light 󽗊ashes
Failure on battery charging
If none of the measures solved the problem you experience with the product,please contact dreame customer service for assistance.
dirty
Nozzle jamed Clean nozzle
Battery error Contact dreame for service
Wrong charger Use right charger
Wrong adapter Please select the original
Poor charger connection Make sure of good connection
Connection is good,but still not working
Cleaning cup and HEPA
adapter
Contact dreame for service
14
After-sales services
If assistance is needed in operating dreame vacuum cleaner,please contact customer Service by telephone number: 400 875 9511 ,Send email to www.dreame.tech,or postal
mail to Shangjin wan Headquarters, building E3 economic garden ,2288 Wuzhong boulevard,suzou,jiangsu.
Do not operate near 󽗊ames
Do not rest or charge battery near a heater
Do not try to pick up water or liquid
Do not pick burning subject
Do not put hand close to vacuum head in operation
Do not place main machine on or near a stove
15
