OPERATING AND
INSTALLATION MANUAL
OUTDOOR UNIT
AIR 2,6 kW
AIR 3,5 kW
AIR 5,3 kW
Družstevní závody Dražice-strojírna s.r.o.
Dražice 69, 294 71 Benátky nad Jizerou
tel.: +420 / 326 370 911
fax: +420 / 326 370 980
e-mail: export@dzd.cz
CAREFULLY READ THIS MANUAL BEFORE INSTALLING!
Dear Customer,
The Works Cooperative of Dražice - Machine Plant, Ltd., would like to thank you for your decision to use
a product of our brand.
The product is not intended to be controlled by
a) people (including children) with reduced physical, sensual or mental capacities, or
b) people with insufficient knowledge and experiences unless supervised by responsible person,
or unless properly instructed by such responsible person.
CONTENTS
Safety instructions
Preparation before use
Safety Precautions
Installation instruction
Installation diagram
Select the installation locations
Connecting of the cable 16
Wiring diagram
Outdoor unit installation
Air purging
Please read this use and installation instructions carefully before installing and using this appliance
and keep this manual for future reference.
Caution: Risk of fire / flammable materials
WARNING: Servicing shall only be performed as recommended by the equipment manufacturer.
Maintenance and repair requiring the assistance of other skilled personnel shall be carried out
under the supervision of the person competent in the use of flammable refrigerants.
3
4
5
14
14
15
17
18
18
Safety instructions
• To guarantee the unit work normally, please read the manual carefully before
installation, and try to install strictly according to this manual.
• Do not let air enter the refrigeration system or discharge refrigerant when moving the
air conditioner.
• Properly ground the air conditioner into the earth.
• Check the connecting cables and pipes carefully, make sure they are correct and firm
before connecting the power of the air conditioner.
• There must be an air-break switch.
• After installing, the consumer must operate the air conditioner correctly according
• to this manual, keep a suitable storage for maintenance and moving of the air
conditioner in the future.
• Fuse of indoor unit: T 3.15A 250VAC.
• For 2,6 kW~3,5 kW models, fuse of outdoor unit: T 15A 250VAC.
• For 5,3kW models, fuse of outdoor unit: T 20A 250VAC
• The installation instructions for appliances that are intended to be permanently
connected to fixed wiring and have a leakage current that may exceed 10 mA, shall
state that the installation of a residual current device (RCD) having a rated residual
operating current not exceeding 30 mA is advisable.
• Warning: Risk of electric shock can cause injury or death: Disconnect all remote
electric power supplies before servicing.
• The maximum length of the connecting pipe between the indoor unit and outdoor unit
should be less than 5 meters. It will affect the efficiency of the air conditioner if the
distance longer than that length.
• This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
• The batteries in remote controller must be recycled or disposed of properly. Disposal
of Scrap Batteries - Please discard the batteries as sorted municipal waste
at the accessible collection point.
• If the appliance is fixed wiring, the appliance must be fitted with means
for disconnection from the supply mains having a contact separation in all poles
that provide full disconnection under over voltage category III conditions, and these
means must be incorporated in the fixed wiring in accordance with the wiring rules.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons to avoid a hazard.
• The appliance shall be installed in accordance with national wiring regulations.
Servicing shall only be performed as recommended by the equipment manufacturer.
Maintenance and repair requiring the assistance of other skilled personnel shall be
carried out under the supervision of the person competent in the use of flammable
refrigerants.
• The appliance shall not be installed in the laundry.
- 3 -
Preparation before use
Note
Preset
Safeguarding the environment
• For the multi system, the refrigerant refers to the multi outdoor unit.
• When charging refrigerant into the system, make sure to charge in liquid state,
if the refrigerant of the appliance is R32.Otherwise, chemical composition
of refrigerant (R32) inside the system may change and thus affect performance
of the air conditioner.
• According to the character of refrigerant (R32, the value of GWP is 675), the pressure
of the tube is very high, so be sure to be careful when you install and repair
the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons to avoid a hazard.
• Installation of this product must be done by experienced service technicians’
professional installers only in accordance with this manual.
• The temperature of refrigerant circuit will be high, please keep the interconnection
cable away from the copper tube.
Before using the air conditioner, be sure to check and preset the following.
• Remote Control presetting
Each time after the remote control is replaced with new batteries or is energized, remote control auto
presetting
heat pump. If the air conditioner you purchased is a Cooling Only one, heat pump remote controller can also be
used.
• Back-light function of Remote Control (optional)
Hold down any button on remote control to activate the back light. It automatically shuts off 10 seconds
later.
Note: Back-light is an optional function.
• Auto Restart Presetting
The air conditioner has an Auto-Restart function.
This appliance is made of recyclable or re-usable material. Scrapping must be carried out in compliance
with local waste disposal regulations. Before scrapping it, make sure to cut off the mains cord so that the
appliance cannot be re-used.
For more detailed information on handling and recycling this product, contact your local authorities who
deal with the separate collection of rubbish or the shop where you bought the appliance.
SCRAPPING OF APPLIANCE
This appliance is marked according to the European Directive 2012/19/EC, Waste
Electrical and Electronic Equipment (WEEE).
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal,recycle it responsibly
to promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the product
was purchased. They can take this product for environmentally safe recycling.
- 4 -
OFF
Safety precautions
Symbols in this Use and Care Manual are interpreted as shown below.
Be sure not to do.
Pay attention to such a situation.
Grounding is essential.
Warning: Incorrect handling could
cause a serious hazard, such as death,
serious injury, etc.
Use correct power supply in
accordance with the rating plate
requirement. Otherwise, serious
faults or hazard may occur, or a
fire maybe break out.
ON
Keep the power supply circuit
breaker or plug from dirt.
Connect the power supply cord
to it firmly and correctly, lest an
electric shock or a fire break out
due to insufficient contact.
ON
OFF
Do not use the power supply
circuit breaker or pull off the plug
to turn it off during operation.
This may cause a fire due to
spark, etc.
It is harmful to your health if the cool
air reaches you for a long time. It is
advisable to let the air flow be
deflected to all the room.
Prevent the air flow from reaching
the gas burners and stove.
Do not touch the operation buttons
when your hands are wet.
Never insert a stick or similar obstacle
to the unit. Since the fan rotates at high
speed, this may cause an injury.
Do not repair the appliance by yourself.
If this is done incorrectly, it may cause
an electric shock, etc.
Do not put any objects on the outdoor
unit.
It is the user's responsibility to
make the appliance be grounded
according to local codes or
ordinances by a licenced
technician.
ON
OFF
SMART MODE
TEMP.
SUPER
TEMP.
FEEL SLEEP
CLOCK TIMER ON TIMER O FF
QUI ET DIM MER ECONOM Y
FAN SPEED
Turn off the appliance by remote
control firstly before cutting off
power supply if malfunction occurs.
- 5 -
Do not knit, pull or press the power
supply cord, lest the power supply cord
be broken. An electric shock or fire is
probably caused by a broken power
supply cord.
Precautions for using R32 refrigerant
The basic installation work procedures are the same as the conventional refrigerant
(R22 or R410A). However, pay attention to the following points:
1.
Transport of equipment containing flammable refrigerants
Compliance with the transport regulations
2.
Marking of equipment using signs
Compliance with local regulations
3.
Disposal of equipment using flammable refrigerants
Compliance with national regulations
4.
Storage of equipment/appliances
The storage of equipment should be in accordance with the manufacturer's
instructions.
5.
Storage of packed (unsold) equipment
Storage package protection should be constructed such that mechanical damage
to the equipment inside the package will not cause a leak of the refrigerant charge.
The maximum number of pieces of equipment permitted to be stored together
will be determined by local regulations.
6.
Information on servicing
6-1
Checks to the area
Prior to beginning work on systems containing flammable refrigerants, safety checks
are necessary to ensure that the risk of ignition is minimized. For repair
to the refrigerating system, the following precautions shall be complied with prior
to conducting work on the system.
6-2
Work procedure
Work shall be undertaken under a controlled procedure to minimize the risk
of flammable gas or vapor being present while the work is being performed.
6-3
General work area
All maintenance staff and others working in the local area shall be instructed
on the nature of work being carried out. Work in confined spaces shall be avoided.
The area around the workspace shall be sectioned off. Ensure that the conditions
within the area have been made safe by control of flammable material.
6-4
Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to and during
work, to ensure the technician is aware of potentially flammable atmospheres.
Ensure that the leak detection equipment being used is suitable for use
with flammable refrigerants, i.e. non-sparking, adequately sealed or intrinsically safe.
CAUTION
- 6 -
CAUTION
6-5
Presence of fire extinguisher
If any hot work is to be conducted on the refrigeration equipment or any associated
parts, appropriate fire extinguishing equipment shall be available to hand.
Have a dry powder or CO2 fire extinguisher adjacent to the charging area.
6-6
No ignition sources
No person carrying out work in relation to a refrigeration system which involves
exposing any pipe work that contains or has contained flammable refrigerant shall
use any sources of ignition in such a manner that it may lead to the risk of fire or
explosion.
All possible ignition sources, including cigarette smoking, should be kept sufficiently
far away from the site of installation, repairing, removing and disposal, during which
flammable refrigerant can possibly be released to the surrounding space.
Prior to work taking place, the area around the equipment is to be surveyed to make
sure that there are no flammable hazards or ignition risks. “No Smoking” signs shall
be displayed.
6-7
Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking
into the system or conducting any hot work.
A degree of ventilation shall continue during the period that the work is carried out.
The ventilation should safely disperse any released refrigerant and preferably expel
it externally into the atmosphere.
6-8
Checks to the refrigeration equipment
Where electrical components are being changed, they shall be fit for the purpose and
to the correct specification.
At all times the manufacturer's maintenance and service guidelines shall be followed.
If in doubt consult the manufacturer's technical department for assistance.
The following checks shall be applied to installations using flammable refrigerants:
–
The charge size is in accordance with the room size within which the refrigerant containing
parts are installed;
–
The ventilation machinery and outlets are operating adequately and are not obstructed;
–
If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for
the presence of refrigerant;
–
Marking to the equipment continues to be visible and legible. Markings and signs that are
illegible shall be corrected;
–
Refrigeration pipe or components are installed in a position where they are unlikely to be
exposed to any substance which may corrode refrigerant containing components, unless
the components are constructed of materials which are inherently resistant to being
corroded or are suitably protected against being so corroded.
- 7 -
CAUTION
6-9
Checks to electrical devices
Repair and maintenance to electrical components shall include initial safety checks
and component inspection procedures.
If a fault exists that could compromise safety, then no electrical supply shall be
connected to the circuit until it is satisfactorily dealt with.
If the fault cannot be corrected immediately but it is necessary to continue operation,
an adequate temporary solution shall be used.
This shall be reported to the owner of the equipment, so all parties are advised. Initial
safety checks shall include:
–
That capacitors are discharged: this shall be done in a safe manner to avoid possibility of
sparking;
–
That there no live electrical components and wiring are exposed while charging, recovering
or purging the system;
–
That there is continuity of earth bonding.
7.
Repairs to sealed components
During repairs to sealed components, all electrical supplies shall be disconnected
from the equipment being worked upon prior to any removal of sealed covers, etc.
If it is necessary to have an electrical supply to equipment during servicing, then a
permanently operating form of leak detection shall be located at the most critical point
to warn of a potentially hazardous situation.
Attention shall be paid to the following to ensure that by working on electrical
components, the casing is not altered in such a way that the level of protection is
affected.
This shall include damage to cables, excessive number of connections, terminals not
made to original specification, damage to seals, incorrect fitting of glands, etc.
Ensure that apparatus is mounted securely.
Ensure that seals or sealing materials have not degraded such that they no longer
serve the purpose of preventing the ingress of flammable atmospheres. Replacement
parts shall be in accordance with the manufacturer's specifications.
NOTE:
The use of silicon sealant may inhibit the effectiveness of some types of leak
detection equipment. Intrinsically safe components do not have to be isolated prior
to working on them.
8.
Repair to intrinsically safe components
Do not apply any permanent inductive or capacitance loads to the circuit without
ensuring that this will not exceed the permissible voltage and current permitted for
the equipment in use.
Intrinsically safe components are the only types that can be worked on while live in
the presence of a flammable atmosphere. The test apparatus shall be at the correct
rating.
- 8 -
CAUTION
Replace components only with parts specified by the manufacturer.
Other parts may result in the ignition of refrigerant in the atmosphere from a leak.
9.
Cabling
Check that cabling will not be subject to wear, corrosion, excessive pressure,
vibration, sharp edges or any other adverse environmental effects.
The check shall also consider the effects of aging or continual vibration from sources
such as compressors or fans.
10.
Detection of flammable refrigerants
Under no circumstances shall potential sources of ignition be used in the searching
for or detection of refrigerant leaks.
A halide torch (or any other detector using a naked flame) shall not be used.
11.
Leak detection methods
The following leak detection methods are deemed acceptable for systems containing
flammable refrigerants:
–
Electronic leak detectors shall be used to detect flammable refrigerants, but the sensitivity may
not be adequate, or may need re-calibration. (Detection
equipment shall be calibrated in a refrigerant-free area.)
–
Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant
used.
–
Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall
be calibrated to the refrigerant employed and the appropriate percentage of gas (25 %
maximum) is confirmed.
–
Leak detection fluids are suitable for use with most refrigerants but the use of detergents
containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode
the copper pipe-work.
–
If a leak is suspected, all naked flames shall be removed/ extinguished.
–
If a leakage of refrigerant is found which requires brazing, all the refrigerant shall be recovered
from the system, or isolated (by means of shut
off valves) in a part of the system remote from the leak.
–
Oxygen free nitrogen (OFN) shall then be purged through the system both before and during
the brazing process.
12.
Removal and evacuation
When breaking into the refrigerant circuit to make repairs – or for any other purpose
– conventional procedures shall be used.
However, it is important that best practice is followed since flammability is a consideration.
The following procedure shall be adhered to:
–
Remove refrigerant;
–
Purge the circuit with inert gas;
–
Evacuate;
–
Purge again with inert gas;
–
Open the circuit by cutting or brazing.
- 9 -
CAUTION
The refrigerant charge shall be recovered into the correct recovery cylinders.
The system shall be “flushed” with OFN to render the unit safe. This process may
need to be repeated several times.
Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved by breaking the vacuum in the system with OFN and
continuing to fill until the working pressure is achieved, then venting to atmosphere,
and finally pulling down to a vacuum.
This process shall be repeated until no refrigerant is within the system. When the final
OFN charge is used, the system shall be vented down to atmospheric pressure to
enable work to take place.
This operation is vital if brazing operations on the pipe-work are to take place.
Ensure that the outlet for the vacuum pump is not close to any ignition sources and
there is ventilation available.
13.
Charging procedures
In addition to conventional charging procedures, the following requirements shall be
followed:
–
Ensure that contamination of different refrigerants does not occur when using charging
equipment.
–
Hoses or lines shall be as short as possible to minimize the amount of refrigerant
contained in them.
–
Cylinders shall be kept upright.
–
Ensure that the refrigeration system is earthed prior to charging the system with
refrigerant.
–
Label the system when charging is complete (if not already).
–
Extreme care shall be taken not to overfill the refrigeration system. Prior to recharging the
system, it shall be pressure tested with OFN.
The system shall be leak tested on completion of charging but prior to commissioning.
A follow up leak test shall be carried out prior to leaving the site.
14.
Decommissioning
Before carrying out this procedure, it is essential that the technician is completely
familiar with the equipment and all its detail.
It is recommended good practice that all refrigerants are recovered safely. Prior to
the task being carried out, an oil and refrigerant sample shall be taken in case
analysis is required prior to re-use of reclaimed refrigerant. It is essential that
electrical power is available before the task is commenced.
a)
Become familiar with the equipment and its operation.
b)
Isolate system electrically.
- 10 -
CAUTION
c)
Before attempting the procedure ensure that:
–
Mechanical handling equipment is available, if required, for handling refrigerant
cylinders;
–
All personal protective equipment is available and being used correctly;
–
The recovery process is always supervised by a competent person;
–
Recovery equipment and cylinders conform to the appropriate standards.
d)
Pump down refrigerant system, if possible.
e)
If a vacuum is not possible, make a manifold so that refrigerant can be removed from
various parts of the system.
f)
Make sure that cylinder is situated on the scales before recovery takes place.
g)
Start the recovery machine and operate in accordance with manufacturer's instructions.
h)
Do not overfill cylinders. (No more than 80 % volume liquid charge).
I) Do not exceed the maximum working pressure of the cylinder, even temporarily.
j) When the cylinders have been filled correctly and the process completed, make sure that
the cylinders and the equipment are removed from site promptly and all isolation valves
on the equipment are closed off.
k) Recovered refrigerant shall not be charged into another refrigeration system unless it has
been cleaned and checked.
15.
Labelling
Equipment shall be labelled stating that it has been de-commissioned and emptied
of refrigerant.
The label shall be dated and signed.
Ensure that there are labels on the equipment stating the equipment contains
flammable refrigerant.
16.
Recovery
When removing refrigerant from a system, either for servicing or decommissioning, it
is recommended good practice that all refrigerants are removed safely.
When transferring refrigerant into cylinders, ensure that only appropriate refrigerant
recovery cylinders are employed.
Ensure that the correct number of cylinders for holding the total system charge is
available.
All cylinders to be used are designated for the recovered refrigerant and labelled for
that refrigerant (i.e. special cylinders for the recovery of refrigerant).
Cylinders shall be complete with pressure relief valve and associated shut- off valves
in good working order.
Empty recovery cylinders are evacuated and, if possible, cooled before recovery
occurs.
The recovery equipment shall be in good working order with a set of instructions
concerning the equipment that is at hand and shall be suitable for the recovery of
flammable refrigerants.
- 11 -
CAUTION
In addition, a set of calibrated weighing scales shall be available and in good working
order.
Hoses shall be complete with leak-free disconnect couplings and in good condition.
Before using the recovery machine, check that it is in satisfactory working order, has
been properly maintained and that any associated electrical components are sealed
to prevent ignition in the event of a refrigerant release. Consult manufacturer if in
doubt.
The recovered refrigerant shall be returned to the refrigerant supplier in the correct
recovery cylinder, and the relevant Waste Transfer Note arranged. Do not mix
refrigerants in recovery units and especially not in cylinders.
If compressors or compressor oils are to be removed, ensure that they have
been evacuated to an acceptable level to make certain that flammable
refrigerant does not remain within the lubricant.
The evacuation process shall be carried out prior to returning the compressor to the
suppliers.
Only electric heating to the compressor body shall be employed to accelerate this
process.
When oil is drained from a system, it shall be carried out safely.
CAUTION
When moving or relocating the air conditioner, consult experienced service
technicians for disconnection and reinstallation of the unit.
Do not place any other electrical products or household belongings under indoor unit
or outdoor unit. Condensation dripping from the unit might get them wet and may
cause damage or malfunction of your property.
Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacturer.
The appliance shall be stored in a room without continuously operating ignition
sources (for example, open flames, an operating gas appliance or an operating
electric heater).
Do not pierce or burn.
Be aware that refrigerants may not contain an odor. To keep ventilation openings,
clear of obstruction.
The appliance shall be stored in a well-ventilated area where the room size
corresponds to the room area as specified for operation.
The appliance shall be stored in a room without continuously operating open flames
(for example an operating gas appliance) and ignition sources (for example an
operating electric heater).
- 12 -
This
refrigerant.
If
source,
This symbol shows that the operation manual should be read
carefully.
This symbol shows that a service personnel should be handling this
equipment with reference to the
This symbol shows that information is available such as the
operating manual or installation manual.
CAUTION
Any person who is involved with working on or breaking into a refrigerant circuit
should hold a current valid certificate from an industry-accredited assessment
authority, which authorizes their competence to handle refrigerants safely in
accordance with an industry recognized assessment specification.
Servicing shall only be performed as recommended by the equipment manufacturer.
Maintenance and repair requiring the assistance of other skilled personnel shall be
carried out under the supervision of the person competent in the use of flammable
refrigerants.
Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacturer.
Appliance shall be installed, operated and stored in a room with a floor area larger
than 10 m2.
The installation of pipe-work shall be kept to a a room with a floor area larger than
10 m2.
The pipe-work shall be compliance with national gas regulations. The maximum
refrigerant charge amount is 2.5 kg.
Mechanical connectors used indoors shall comply with ISO 14903. When
mechanical connectors are reused indoors, sealing parts shall be renewed. When
flared joints are reused indoors, the flare part shall be re-fabricated. The installation
of pipe-work shall be kept to a minimum.
Mechanical connections shall be accessible for maintenance purposes.
Explanation of symbols displayed on the indoor unit or outdoor unit.
symbol shows that this appliance uses a flammable
WARNING
CAUTION
the refrigerant is leaked and exposed to an external ignition
there is a risk of fire
CAUTION
CAUTION
- 13 -
installation manual.
Installation diagram
Installation instructions
Air intake distance from
the wall should be
over 250mm
Air intake distance from the wall
should be over 250mm
over 250mm
outdoor unit
Above figure is only a simple presentation of the unit, it may not match the external appearance of the unit
you purchased. Installation must be performed in accordance with the national wiring standards by
authorized personnel only.
- 14 -
Height should
be less than 5m
Height should
be less than 5m
Location for Installing Outdoor Unit
Where it is convenient to install and well ventilated. Avoid installing it where flammable gas could leak.
Keep the required distance apart from the wall.
The distance between Indoor and outdoor unit should be 5 meters and can go up to maximum 15 meters
with additional refrigerant charge.
Keep the outdoor unit away from greasy dirt, vulcanization gas exit. Avoid installing it by the roadside
where there is a risk of muddy water. A fixed base where it is not subject to increased operation noise.
Where there is not any blockage of the air outlet.
Avoid installing under direct sunlight, in an aisle or sideway, or near heat sources and ventilation fans.
Keep away from flammable materials, thick oil fog, and wet or uneven places.
Indoor unit
Outdoor unit
Pipe length is
15 meters Max.
Pipe length is
15 meters Max.
Outdoor unit
Indoor unit
Model
2,1k~5,3kW
7kW
Max. Allowable Tubing
Length at Shipment (m)
5
15
5
15
Limit of Tubing
Length (m)
Limit of Elevation
Difference H (m)
If the height or pipe length is out of the scope of the table, please consult the merchant.
Required amount of
additional refrigerant (g/m)
5
20
5
30
- 15 -
Power connecting cord
Connecting of the Cable
Note: For some models, it is necessary to remove the cabinet to connect to the indoor unit terminal.
Outdoor Unit
1)
Remove the access door from the unit by loosening
the screw. Connect the wires to the terminals on the
control board individually as follows.
2)
Secure the power cord onto the control
board with cable clamp.
3)
Reinstall the access door to the original position
with the screw.
4)
Use a recognized circuit breaker for 24K model between
the power source and the unit. A disconnecting device to
adequately disconnect all supply lines must be fitted.
Caution:
1.
Never fail to have an individual power circuit specifically for the air conditioner. As for the method of
wiring, refer to the circuit diagram posted on the inside of the access door.
2.
Confirm that the cable thickness is as specified in the power source specification.
3.
Check the wires and make sure that they are all tightly fastened after cable connection.
4.
Be sure to install an earth leakage circuit breaker in wet or moist areas.
Cable Specifications
Capacity (kW) Power cord
Access door
Outdoor unit
The figures in this manual are based on the external
view of a standard model. Consequently, the shape
may differ from that of the air conditioner you have
selected.
Type
2,6 ; 3,5 H07RN-F
5,3 H07RN-F
Attention:
The plug must be accessible even after the installation of the appliance in case there is a need
to disconnect it. If not possible, connect appliance to a double-pole switching device with
contact separation of at least 3 mm placed in an accessible position even after installation.
Normal cross
- sectional area
1.0mm2X3
1.5mm2X3
- 16 -
Type
H07RN-F
H07RN-F
Normal cross
- sectional area
1.0mm2X5
1.5mm2X5
Wiring diagram
Make sure that the color of the wires in the outdoor unit and terminal No. are the same as those of
the indoor unit.
2,6kW~5,3kW Model
Indoor unit
Terminal
Outdoor unit
Terminal
0(L)
1(L)
2(N)
4(SI)
Warning:
Before obtaining access to terminals, all supply circuits must be disconnected.
- 17 -
Air purging
Outdoor unit installation
1.
Install Drain Port and Drain Hose (for heat-pump model only)
The condensate drains from the outdoor unit when the unit operates
in heating mode. In order not to disturb your neighbor and protect
the environment, install a drain port and a drain hose to direct the
condensate water. Just install the drain port and rubber washer to
the chassis of the outdoor unit, then connect a drain hose to the
Rubber pad (optional)
Place under the leg pedestal
Drain port
port as the right figure demonstrates.
2.
Install and Fix Outdoor Unit
Fix with bolts and nuts tightly on a flat and strong floor.
If installed on the wall or roof, make sure to fix the supporter well to prevent it
from shaking due to serious vibration or strong wind.
3.
Outdoor Unit Piping Connection
Remove the valve caps from the 2-way and 3-way valve.
Connect the pipes to the 2-way and 3-way valves separately according to the required torque.
4.
Outdoor Unit Cable Connection (see previous page)
Washer
Drain hose
(prepared by user)
The air which contains moisture remaining in the refrigeration cycle may cause a malfunction on the
compressor. After connecting the indoor and outdoor units, release air and moisture from the refrigerant
cycle using a vacuum pump, as shown below.
Note: To protect the environment, be sure not to discharge the refrigerant to the air directly.
See next page for air purging steps.
i
n
d
- 18 -
How to Purge Air Tubes:
(1)
Unscrew and remove caps from 2 and 3-way valves.
(2)
Unscrew and remove cap from service valve.
(3)
Connect vacuum pump flexible hose to the service valve.
(4)
Start vacuum pump for 10-15 minutes until reaching a vacuum of 10 mm Hg absolutes.
(5)
With vacuum pump still running close the low-pressure knob on vacuum pump manifold.
Then stop the vacuum pump.
(6)
Open 2-way valve ,1/4 turn, then close it after 10 seconds. Check tightness of all joints
using liquid soap or an electronic leak detector.
(7)
Turn 2 and 3-way valves stem to fully close the valves. Disconnect the flexible vacuum
pump hose.
(8)
Replace and tighten all valve caps.
22-5-2019
Loading...
