Vigor2930 Series
Dual-WAN Security Firewall
User’s Guide
Version: 1.2
Date: 2008/03/10
Copyright 2008 All rights reserved.
This publication contains information that is protected by copyright. No part may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language without written permission from the copyright
holders. The scope of delivery and other details are subject to change without prior notice.
Microsoft is a registered trademark of Microsoft Corp.
Windows, Windows 95, 98, Me, NT, 2000, XP, Vista and Explorer are trademarks of Microsoft Corp.
Apple and Mac OS are registered trademarks of Apple Inc.
Other products may be trademarks or registered trademarks of their respective manufacturers.
Copyright Information
Copyright
Declarations
Trademarks
Copyright 2008 All rights reserved. This publication contains information that is
protected by copyright. No part may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language without written
permission from the copyright holders.
The following trademarks are used in this document:
z Microsoft is a registered trademark of Microsoft Corp.
z Windows, Windows 95, 98, Me, NT, 2000, XP, Vista and Explorer are
trademarks of Microsoft Corp.
z Apple and Mac OS are registered trademarks of Apple Inc.
z Other products may be trademarks or registered trademarks of their
respective manufacturers.
Safety Instructions and Approval
Safety
Instructions
Warranty
z Read the installation guide thoroughly before you set up the router.
z The router is a complicated electronic unit that may be repaired only be
authorized and qualified personnel. Do not try to open or repair the router
yourself.
z Do not place the router in a damp or humid place, e.g. a bathroom.
z The router should be used in a sheltered area, within a temperature range
of +5 to +40 Celsius.
z Do not expose the router to direct sunlight or other heat sources. The
housing and electronic components may be damaged by direct sunlight or
heat sources.
z Do not deploy the cable for LAN connection outdoor to prevent electronic
shock hazards.
z Keep the package out of reach of children.
z When you want to dispose of the router, please follow local regulations on
conservation of the environment.
We warrant to the original end user (purchaser) that the router will be free from
any defects in workmanship or materials for a period of two (2) years from the
date of purchase from the dealer. Please keep your purchase receipt in a safe
place as it serves as proof of date of purchase. During the warranty period, and
upon proof of purchase, should the product have indications of failure due to
faulty workmanship and/or materials, we will, at our discretion, repair or replace
the defective products or components, without charge for either parts or labor, to
whatever extent we deem necessary tore-store the product to pr o per o perating
condition. Any replacement will consist of a new or re-manufactured
functionally equivalent product of equal value, and will be offered solely at our
discretion. This warranty will not apply if the product is modified, misused,
tampered with, damaged by an act of God, or subjected to abnormal working
conditions. The warranty does not cover the bundled or licensed software of
other vendors. Defects which do not significantly affect the usability of the
product will not be covered by the warranty. We reserve the right to revise the
manual and online documentation and to make changes from time to time in th e
contents hereof without obligation to notify any person of such revision or
changes.
Be a Registered
Owner
Firmware & Tools
Updates
ii
Web registration is preferred. You can register your Vigor router via
http://www.draytek.com.
Due to the continuous evolution of DrayTek technology, all routers will be
regularly upgraded. Please consult the DrayTek web site for more information on
newest firmware, tools and documents.
http://www.draytek.com
Vigor2930 Series User’s Guide
European Community Declarations
Manufacturer: DrayTek Corp.
Address: No. 26, Fu Shing Road, HuKou County, HsinChu Industrial Park, Hsin-Chu, Taiwan 303
Product: Vigor2930 Series Router
DrayTek Corp. declares that Vigor2930 Series of routers are in compliance with the following essential
requirements and other relevant provisions of R&TTE Directive 1999/5/EEC.
The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by
complying with the requirements set forth in EN55022/Class B and EN55024/Class B.
The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by complying with the
requirements set forth in EN60950.
Regulatory Information
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or televisio n recept i on , whi ch can be determined by turning the equipment of f and
on, the use is encouraged to try to correct the interference by one of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different form that to which the receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device may accept any interference received, including interference that may cause undesired operation.
.
Please visit http://www.draytek.com/about_us/R_TTE_Certification.php.
This product is designed for the ISDN and 2.4GHz WLAN network throughout the EC region and Switzerland
with restrictions in France. Please see the user manual for the applicable networks on your product.
Vigor2930 Series User’s Guide
iii
TTaabbllee ooff CCoonntteennttss
1
Preface ...............................................................................................................1
1.1 Web Configuration Buttons Explanation.................................................................................1
1.2 LED Indicators and Connectors.............................................................................................. 2
1.2.1 For Vigor2930................................................................................................................... 3
1.2.2 For Vigor2930n................................................................................................................. 4
1.2.3 For Vigor2930Vn............................................................................................................... 6
1.2.4 For Vigor2930VS.............................................................................................................. 8
1.2.5 For Vigor2930VSn..........................................................................................................10
1.3 Hardware Installation ............................................................................................................ 12
1.4 ISDN Phone Adapter Installation.......................................................................................... 13
2
Configuring Basic Settings ............................................................................15
2.1 Changing Password.............................................................................................................. 15
2.2 Quick Start Wizard................................................................................................................ 17
3
2.2.1 PPPoE ............................................................................................................................ 18
2.2.2 PPTP............................................................................................................................... 20
2.2.3 Static IP........................................................................................................................... 21
2.2.4 DHCP.............................................................................................................................. 22
2.3 Online St atus......................................................................................................................... 23
2.4 Saving Configuration............................................................................................................. 25
A d v a n c e d Web Con f i g ura t i o n..................................................................................27
3.1 WAN...................................................................................................................................... 27
3.1.1 Basics of Internet Protocol (IP) Network......................................................................... 27
3.1.2 General Setup................................................................................................................. 28
3.1.3 Internet Access............................................................................................................... 30
3.1.4 Load-Balance Policy.......................................................................................................36
3.2 LAN ....................................................................................................................................... 39
3.2.1 Basics of LAN ................................................................................................................. 39
3.2.2 General Setup................................................................................................................. 41
3.2.3 Static Route.................................................................................................................... 43
3.2.4 VLAN............................................................................................................................... 46
3.2.5 Bind IP to MAC............................................................................................................... 47
iv
3.3 NAT ....................................................................................................................................... 48
3.3.1 Port Redirection.............................................................................................................. 49
3.3.2 DMZ Host........................................................................................................................ 51
3.3.3 Open Ports...................................................................................................................... 54
3.4 Objects Settings.................................................................................................................... 56
Vigor2930 Series User’s Guide
3.4.1 IP Object......................................................................................................................... 56
3.4.2 IP Group ......................................................................................................................... 58
3.4.3 Service Type Object .......................................................................................................59
3.4.4 Service Type Group........................................................................................................60
3.4.5 CSM-IM Object............................................................................................................... 61
3.4.6 CSM-P2P Object ............................................................................................................62
3.4.7 CSM-Misc Object............................................................................................................ 64
3.5 CSM ...................................................................................................................................... 65
3.5.1 IM/P2P Profile................................................................................................................. 65
3.5.2 URL Content Filter Profile............................................................................................... 66
3.5.3 Web Content Filter Profile............................................................................................... 68
3.6 Firewall.................................................................................................................................. 70
3.6.1 Basics for Firewall........................................................................................................... 70
3.6.2 General Setup................................................................................................................. 72
3.6.3 Filter Setup ..................................................................................................................... 73
3.6.4 DoS Defense .................................................................................................................. 79
3.7 Bandwidth Management....................................................................................................... 82
3.7.1 Sessions Limit................................................................................................................. 82
3.7.2 Bandwidth Limit .............................................................................................................. 84
3.7.3 Quality of Service............................................................................................................ 85
3.8 Applications........................................................................................................................... 92
3.8.1 Dynamic DNS................................................................................................................. 92
3.8.2 Schedule......................................................................................................................... 94
3.8.3 RADIUS.......................................................................................................................... 95
3.8.4 UPnP............................................................................................................................... 97
3.8.5 Wake on LAN.................................................................................................................. 98
3.9 VPN and Remote Access.................................................................................................... 100
3.9.1 Remote Access Control................................................................................................ 100
3.9.2 PPP General Setup ...................................................................................................... 100
3.9.3 IPSec General Setup.................................................................................................... 102
3.9.4 IPSec Peer Identity....................................................................................................... 103
3.9.5 Remote Dial-in User ..................................................................................................... 105
3.9.6 LAN to LAN................................................................................................................... 108
3.9.7 Connection Management.............................................................................................. 116
3.10 Certificate Management.....................................................................................................117
3.10.1 Local Certificate.......................................................................................................... 117
3.10.2 Trusted CA Certificate ................................................................................................ 119
3.10.3 Certificate Backup....................................................................................................... 120
3.11 VoIP................................................................................................................................... 120
3.11.1 DialPlan ...................................................................................................................... 121
3.11.2 SIP Accounts.............................................................................................................. 129
3.11.3 Phone Settings ........................................................................................................... 133
3.11.4 Status.......................................................................................................................... 149
3.12 ISDN.................................................................................................................................. 150
3.12.1 Basic Concept............................................................................................................. 150
3.12.2 General Settings......................................................................................................... 151
3.12.3 Dial to Single/Dual ISPs.............................................................................................. 154
3.12.4 Call Control................................................................................................................. 157
3.13 Wireless LAN .................................................................................................................... 159
3.13.1 Basic Concepts........................................................................................................... 159
3.13.2 General Setup............................................................................................................. 161
Vigor2930 Series User’s Guide
v
3.13.3 Security....................................................................................................................... 163
3.13.4 Access Control............................................................................................................ 164
3.13.5 WPS............................................................................................................................ 166
3.13.6 WDS............................................................................................................................ 168
3.13.7 AP Discovery.............................................................................................................. 172
3.13.8 Station List.................................................................................................................. 172
3.13.9 Rate Control................................................................................................................ 174
3.14 System Maintenance......................................................................................................... 174
3.14.1 System Status............................................................................................................. 175
3.14.2 TR-069 Setting............................................................................................................ 176
3.14.3 Administrator Password.............................................................................................. 177
3.14.4 Configuration Backup ................................................................................................. 177
3.14.5 Syslog/Mail Alert......................................................................................................... 180
3.14.6 Time and Date............................................................................................................ 181
3.14.7 Management............................................................................................................... 182
3.14.8 Reboot System........................................................................................................... 183
3.14.9 Firmware Upgrade...................................................................................................... 184
3.15 Diagnostics........................................................................................................................ 185
3.15.1 Dial-out Trigger........................................................................................................... 185
3.15.2 Routing Table ............................................................................................................. 186
3.15.3 ARP Cache Table....................................................................................................... 186
3.15.4 DHCP Table................................................................................................................ 187
3.15.5 NAT Sessions Table................................................................................................... 187
3.15.6 Data Flow Monitor....................................................................................................... 188
3.15.7 Traffic Graph............................................................................................................... 190
3.15.8 Ping Diagnosis............................................................................................................ 191
3.15.9 Trace Route................................................................................................................ 192
4
5
Application and Examples............................................................................193
4.1 Create a LAN-to-LAN Connection Between Remote Office and Headquarter................... 193
4.2 Create a Remote Dial-in User Connection Between the Teleworker and Headquarter...... 200
4.3 QoS Setting Example.......................................................................................................... 204
4.4 LAN – Created by Using NAT ............................................................................................. 207
4.5 Calling Scenario for VoIP function ...................................................................................... 209
4.5.1 Calling via SIP Sever.................................................................................................... 209
4.5.2 Peer-to-Peer Calling..................................................................................................... 211
4.6 Upgrade Firmware for Y our Router..................................................................................... 213
4.7 Request a certificate from a CA server on Windows CA Server......................................... 215
4.8 Request a CA Certificate and Set as Trusted on Windows CA Server............................... 219
Trouble Shooting...........................................................................................221
5.1 Checking If the Hardware Status Is OK or Not....................................................................221
5.2 Checking If the Network Connection Settings on Your Computer Is OK or Not ................. 222
vi
5.3 Pinging the Router from Your Computer............................................................................. 224
5.4 Checking If the ISP Settings are OK or Not........................................................................ 225
Vigor2930 Series User’s Guide
5.5 Backing to Factory Default Setting If Necessary ................................................................ 227
5.6 Contacting Your Dealer....................................................................................................... 228
Vigor2930 Series User’s Guide
vii
1
Prreeffaaccee
P
Vigor2930 is a broadband router with dual-WAN interface. It provides policy-based
load-balance, fail-over and BOD (Bandwidth on Demand), also it integrates IP layer QoS,
NAT session/bandwidth management to help users control works well with large bandwidth.
By adopting hardware-based VPN platform, hardware encryption of AES/DES/3DS and
hardware key hash of SHA-1/MD5, the router increases the performance of VPN greatly,
and offers several protocols (such as IPSec/PPTP/L2TP) with up to 100 VPN tunnels.
The object-originated design used in SPI (Stateful Packet Inspection) firewall allows users to
set firewall policy with ease. CSM (Content Security Management) provides users control
and management in IM (Instant Messenger) and P2P (Peer to Peer) more efficiency than
before. By the way, DoS/DDoS prevention and URL/Web content filter strengthen the
security outside and control inside.
Vigor2930 “S” series models support two ISDN ports. ISDN S0 (1) port is dedicated for
ISDN phone and ISDN S0 (2) port is configurable for ISDN line and phone if required. It
can support multiple SIP registrars with high flexible configuration and call handling
options.
Object-oriented firewall is flexible and allows your network be safe. In addition, through
VoIP function, the communication fee for you and remote people can be reduced.
11..11 WWeebb CCoonnffiigguurraattiioonn BBuuttttoonnss EExxppllaannaattiioonn
Several main buttons appeared on the web pages are defined as the following:
Save and apply current settings.
Cancel current settings and recover to the previous saved settings.
Clear all the selections and parameters settings, including selection from
drop-down list. All the values must be reset with factory default settings.
Add new settings for specified item.
Edit the settings for the selected item.
Delete the selected item with the corresponding settings.
Note: For the other buttons shown on the web pages, please refer to Chapter 4 for detailed
explanation.
Vigor2930 Series User’s Guide
1
11..22 LLEEDD IInnddiiccaattoorrss aanndd CCoonnnneeccttoorrss
Before you use the Vigor router, please get acquainted with the LED indicators and
connectors first.
The displays of LED indicators and connectors for the routers are different slightly. The
following sections will introduce them respectively.
DDeeffiinniittiioonnss ffoorr IISSDDNN PPoorrttss
Below shows the names that displayed on front panel of the device and the WEB UI of this
device.
ISDN TE (Terminal Equipment) means an interface for transmitting analog signal through
Internet between Switching and router. Such interface is also named with ISDN S0 extern in
Germany.
ISDN NT (Network Terminator) is a port that used to connect general phone. Such interface
is also named with ISDN S0 intern in Germany.
The ISDN S0 (1) port on Vigor2930 series is fixed to connect phone forever and the LED on
the connecter will light orange always. However ISDN S0 (2) port on this device is
configurable for connecting phone or accessing Internet according to the settings that you
adjust on WEB UI (please refer to VoIP>>Phone Setting for detailed information).
Warning: When the orange LED lights (means ISDN NT mode), the ISDN
port can be used to connect phone only. Wrong ISDN connection might cause
severe damage on your device.
2
Vigor2930 Series User’s Guide
11..22..11 FFoorr VViiggoorr22993300
LED Status Explanation
Blinking The router is powered on and runni n g no rmally. ACT (Activity)
Off The router is powered off.
On The DoS/DDoS function is active. DoS
Blinking It will blink while deleting an attack.
CSM On The profile of CSM (Content Security
Management) for IM/P2P application is active. (It
is enabled from CSM >> IM/P2P Profile).
CPA (Content Portal Authority) On The Web Content Filter is active. (It is enabled
from CSM >> Web Content Filter Profile).
On The WAN1 or WAN2 port is connected. WAN1/2
Blinking It will blink while transmitting data.
On The router is managed (handled) by Telnet. MGMT
Blinking It will blink while being managed by IE browser.
VPN On The VPN tunnel is active.
QoS
On The QoS function is active.
LED on Connector
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
WAN 1/2
LAN 1/2/3/4
Left LED
(Green)
Right LED
(Green)
Left LED
(Green)
Right LED
(Green)
Interface Description
Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is blinking).
Restart Restart the router forcefully.
WAN(1/2) Connecters for remote networked devices.
LAN (1-4) Connecters for local networked devices.
PWR
ON/OFF
Vigor2930 Series User’s Guide
Press the hole and keep for more than 5 seconds. When you see the ACT LED
begins to blink rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
Connecter for a power adapter.
Power Switch.
3
11..22..22 FFoorr VViiggoorr22993300nn
LED Status Explanation
Blinking The router is powered on and running normally. ACT (Activity)
Off The router is powered off.
On The DoS/DDoS function is active. DoS
Blinking It will blink while deleting an attack.
CSM On The profile of CSM (Content Security
Management) for IM/P2P application is active. (It
is enabled from CSM >> IM/P2P Profile).
WLAN
VPN On The VPN tunnel is active.
QoS
On
Blinking
On The WAN1 or WAN2 port is connected. WAN1/2
Blinking It will blink while transmitting data.
On The router is managed (handled) by Telnet. MGMT
Blinking It will blink while being managed by IE browser.
On The QoS function is active.
Wireless access point is ready.
It will blink while wireless traffic goes through.
It will blink fast when WPS is working and it will
return to normal condition after two minutes.
(You need to setup WPS within 2 minutes.)
LED on Connector
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
WAN 1/2
LAN 1/2/3/4
Left LED
(Green)
Right LED
(Green)
Left LED
(Green)
Right LED
(Green)
Interface Description
Factory Reset Press "Factory Reset" button once to make network connection through WPS.
Press "Factory Reset" button twice to enable or disable WLAN function.
Press "Factory Reset" button for 5 seconds to do the factory reset.
Restore the default settings. Usage: Turn on the router (ACT LED is blinking).
Press the hole and keep for more than 5 seconds. When you see the ACT LED
begins to blink rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
Restart Restart the router forcefully.
Phone (1/2) Connecters for PSTN phones.
WAN (1/2) Connecters for remote networked devices.
4
Vigor2930 Series User’s Guide
LAN (1-4) Connecters for local networked devices.
PWR
ON/OFF
Connecter for a power adapter..
Power Switch.
Vigor2930 Series User’s Guide
5
11..22..33 FFoorr VViiggoorr22993300VVnn
LED Status Explanation
Blinking The router is powered on and runni n g no rmally. ACT (Activity)
Off The router is powered off.
On The DoS/DDoS function is active. DoS
Blinking It will blink while deleting an attack.
CSM On The profile of CSM (Content Security
Management) for IM/P2P application is active. (It
is enabled from CSM >> IM/P2P Profile).
WLAN
Phone 1/2
On
Blinking
On The WAN1 or WAN2 port is connected. WAN1/2
Blinking It will blink while transmitting data.
On The router is managed (handled) by Telnet. MGMT
Blinking It will blink while being managed by IE browser.
On The phone connected to this port is off-hook.
Off The phone connected to this port is on-hook.
Blinking A phone call comes.
Wireless access point is ready.
It will blink while wireless traffic goes through.
It will blink fast when WPS is working and it will
return to normal condition after two minutes.
(You need to setup WPS within 2 minutes.)
LED on Connector
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
WAN 1/2
LAN 1/2/3/4
Left LED
(Green)
Right LED
(Green)
Left LED
(Green)
Right LED
(Green)
Interface Description
Factory Reset Press "Factory Reset" button once to make network connection through WPS.
Press "Factory Reset" button twice to enable or disable WLAN function.
Press "Factory Reset" button for 5 seconds to do the factory reset.
Restore the default settings. Usage: Turn on the router (ACT LED is blinking).
Press the hole and keep for more than 5 seconds. When you see the ACT LED
begins to blink rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
Restart Restart the router forcefully.
Phone (1/2) Connecters for PSTN phones.
WAN (1/2) Connecters for remote networked devices.
6
Vigor2930 Series User’s Guide
LAN (1-4) Connecters for local networked devices.
PWR
ON/OFF
Connecter for a power adapter.
Power Switch.
Vigor2930 Series User’s Guide
7
11..22..44 FFoorr VViiggoorr22993300VVSS
LED Status Explanation
Blinking The router is powered on and run ni n g normally. ACT (Activity)
Off The router is powered off.
On The DoS/DDoS function is active. DoS
Blinking It will blink while deleting an attack.
CSM On The profile of CSM (Content Security
Management) for IM/P2P application is active. (It
is enabled from CSM >> IM/P2P Profile).
CPA (Content Portal Authority) On The Web Content Filter is active. (It is enabled
from CSM >> Web Content Filter Profile)
On The WAN1 or WAN2 port is connected. WAN1/2
Blinking It will blink while transmitting data.
On The router is managed (handled) by Telnet. MGMT
Blinking It will blink while transmitting data.
Phone 1/2
On The phone connected to this port is off-hook.
Off The phone connected to this port is on-hook.
Blinking A phone call comes.
LED on Connector
On ISDN NT (ISDN S0 intern) mode is active and an
ISDN S0 1
ISDN S0 2
WAN 1/2
Left LED
(Orange)
Right LED
(Green)
Left LED
(Orange)
Right LED
(Green)
Left LED
(Green)
Right LED
(Green)
ISDN phone adapter is connected.
Blinking ISDN NT (ISDN S0 intern) mode is active and an
ISDN phone adapter is not connected.
On A phone has been connected. If not, green LED will
be off.
Blinking An ISDN phone is off-hook or a phone call comes.
On ISDN NT (ISDN S0 intern) mode is active
configured from VoIP>>Phone Settings and an
ISDN phone adapter is connected.
Blinking ISDN NT (ISDN S0 intern) mode configured from
VoIP>>Phone Settings is active and an ISDN
phone adapter is not connected.
Off It means ISDN TE mode is active which is
configured from VoIP>>Phone Settings.
On A phone adapter with phone set has been connected
(ISDN S0 intern mode) or ISDN line has been
connected (ISDN S0 extern mode). It will be off if
there is nothing connected.
Blinking In ISDN NT (ISDN S0 intern) mode, it means an
ISDN phone is off-hook or a phone call comes.
In ISDN TE mode, it means data, fax or voice
(phone call) is transmitting.
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
8
Vigor2930 Series User’s Guide
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
LAN 1/2/3/4
Left LED
(Green)
Right LED
(Green)
Interface Description
Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is blinking).
Press the hole and keep for more than 5 seconds. When you see the ACT LED
begins to blink rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
Restart Restart the router forcefully.
Phone (1/2) Connecters for PSTN phones.
ISDN S0 1 Connecter for ISDN phone(s) only via ISDN phone adapter. Do not connect any
other device to such port or connect ISDN line, otherwise the router might be
damaged.
ISDN S0 2 Connecter for ISDN line or ISDN phone adapter in particular condition. Refer to
section 2.2 for more details.
WAN (1/2) Connecters for remote networked devices.
LAN (1-4) Connecters for local networked devices.
PWR
ON/OFF
Connecter for a power adapter.
Power Switch.
Vigor2930 Series User’s Guide
9
11..22..55 FFoorr VViiggoorr22993300VVSSnn
LED Status Explanation
Blinking The router is powered on and running normally. ACT (Activity)
Off The router is powered off.
On The DoS/DDoS function is active. DoS
Blinking It will blink while deleting an attack.
CSM On The profile of CSM (Content Security
Management) for IM/P2P application is active. (It
is enabled from CSM >> IM/P2P Profile).
WLAN
Phone 1/2
On
Blinking
On The WAN1 or WAN2 port is connected. WAN1/2
Blinking It will blink while transmitting data.
On The router is managed (handled) by Telnet. MGMT
Blinking It will blink while being managed by IE browser.
On The phone connected to this port is off-hook.
Off The phone connected to this port is on-hook.
Blinking A phone call comes.
Wireless access point is ready.
It will blink while wireless traffic goes through.
It will blink fast when WPS is working and it will
return to normal condition after two minutes.
(You need to setup WPS within 2 minutes.)
LED on Connector
On ISDN NT (ISDN S0 intern) mode is active and an
ISDN S0 1
ISDN S0 2
WAN 1/2
Left LED
(Orange)
Right LED
(Green)
Left LED
(Orange)
Right LED
(Green)
Left LED
(Green)
Right LED On Th e port is connected with 100Mbps.
Blinking ISDN NT (ISDN S0 intern) mode is active and an
On A phone has been connected. If not, green LED will
Blinking An ISDN phone is off-hook or a phone call comes.
On ISDN NT (ISDN S0 intern) mode is active
Blinking ISDN NT (ISDN S0 intern) mode configured from
Off It means ISDN TE mode is active which is
On A phone adapter with phone set has been connected
Blinking In ISDN NT (ISDN S0 intern) mode, it means an
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
ISDN phone adapter is connected.
ISDN phone adapter is not connected.
be off.
configured from VoIP>>Phone Settings and an
ISDN phone adapter is connected.
VoIP>>Phone Settings is active and an ISDN
phone adapter is not connected.
configured from VoIP>>Phone Settings.
(ISDN S0 intern mode) or ISDN line has been
connected (ISDN S0 extern mode). It will be off if
there is nothing connected.
ISDN phone is off-hook or a phone call comes.
In ISDN TE mode, it means data, fax or voice
(phone call) is transmitting.
10
Vigor2930 Series User’s Guide
LAN 1/2/3/4
(Green)
Left LED
(Green)
Right LED
(Green)
Off The port is disconnected with 10Mbps.
On The port is connected.
Off The port is disconnected.
Blinking The data is transmitting.
On The port is connected with 100Mbps.
Off The port is disconnected with 10Mbps.
Interface Description
Factory Reset Press "Factory Reset" button once to make network connection through WPS
Press "Factory Reset" button twice to enable or disable WLAN function.
Press "Factory Reset" button for 5 seconds to do the factory reset.
Restore the default settings. Usage: Turn on the router (ACT LED is blinking).
Press the hole and keep for more than 5 seconds. When you see the ACT LED
begins to blink rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
Restart Restart the router forcefully.
Phone (1/2) Connecters for PSTN phones.
ISDN S0 1 Connecter for ISDN phone(s) only via ISDN phone adapter. Do not connect any
other device to such port or connect ISDN line, otherwise the router might be
damaged.
ISDN S0 2 Connecter for ISDN line or ISDN phone adapter in particular condition. Refer to
section 2.2 for more details.
WAN (1/2) Connecters for remote networked devices.
LAN (1-4) Connecters for local networked devices.
PWR
ON/OFF
Connecter for a power adapter.
Power Switch.
Vigor2930 Series User’s Guide
11
11..33 HHaarrddwwaarree IInnssttaallllaattiioonn
Before starting to configure the router, you have to connect your devices correctly.
1. Connect the cable Modem/DSL Modem/Media Converter to any WAN port of router
with Ethernet cable (RJ-45). The WAN1/WAN2 LED (Left or Right) will light up
according to the speed (100 or 10) of the device that it connected.
2. Connect one end of an Ethernet cable (RJ-45) to one of the LAN ports of the router and
the other end of the cable (RJ-45) into the Ethernet port on your computer. The LAN
LED (Left or Right) will light up according to the speed (100 or 10) of the device that it
connected.
3. Connect the telephone sets with phone lines (for using VoIP function). For the model
without phone ports, skip this step.
4. Connect one end of the power adapter to the router’s power port on the rear panel, and
the other side into a wall outlet.
5. Power on the device by pressing down the power switch on the rear panel.
6. The system starts to initiate. After completing the system test, the ACT LED will light
up and start blinking.
(For the detailed information of LED status, please refer to section 1.2.)
12
Caution: Each of the Phone ports can be connected to an analog phone only. Do not
connect the phone ports to the telephone wall jack. Such connection might damage
your router.
Vigor2930 Series User’s Guide
11..44 IISSDDNN PPhhoonnee AAddaapptteerr IInnssttaallllaattiioonn
Such information is provided for Vigor2930 S models (e.g., Vigor2930VS).
ISDN S0 1 is always fixed to connect ISDN phone. However, ISDN S0 2 is configurable as
ISDN line or ISDN phone. When the user configures ISDN S0 2 as ISDN phone in VoIP>>
Phone Settings, the orange LED will light on to indicate ISDN2-S0 mode is selected. And
by using ISDN phone adapters (coming from the router package), the user can connect
several phones (the maximum is six) to Vigor2930VS for communication. Refer to the
following figure for reference.
However, if the user configures ISDN S0 2 as ISDN line in VoIP>> Phone Settings, the
green LED will light on to indicate ISDN2-TE mode is selected. Then, the port is specified
for ISDN line only. Refer to the following figure for reference.
Vigor2930 Series User’s Guide
13
This page is left blank.
14
Vigor2930 Series User’s Guide
2
Coonnffiigguurriinngg
C
For use the router properly, it is necessary for you to change the password of web
configuration for security and adjust primary basic settings.
This chapter explains how to setup a password for an administrator and how to adjust basic
settings for accessing Internet successfully. Be aware that only the administrator can change
the router configuration.
22..11 CChhaannggiinngg PPaasssswwoorrdd
To change the password for this device, you have to access into the web browse with default
password first.
1. Make sure your computer connects to the router correctly.
Notice: You may either simply set up your computer to get IP
dynamically from the router or set up the IP address of the computer to be
the same subnet as the default IP address of Vigor router 192.168.1.1.
For the detailed information, please refer to the later section - Trouble
Shooting of this guide.
Baassiicc
B
Seettttiinnggss
S
2. Open a web browser on your PC and type http://192.168.1.1. A pop-up window will
open to ask for username and password. Please type default values (both username and
password are Null) on the window for the first time accessing and click OK for next
screen.
3. Now, the Main Screen will pop up.
Vigor2930 Series User’s Guide
15
Note: The home page will change slightly in accordance with the router you have.
4. Go to System Maintenance page and choose Administrator Password.
5. Enter the login password (the default is blank) on the field of Old Password. Type a
new one in the field of New Password and retype it on the field of Retype New
Password. Then click OK to continue.
6. Now, the password has been changed. Next time, use the new password to access the
Web Configurator for this router.
16
Vigor2930 Series User’s Guide
22..22 QQuuiicckk SSttaarrtt WWiizzaarrdd
If your router can be under an environment with high speed NAT, the configuration provide
here can help you to deploy and use the router quickly. The first screen of Quick Start
Wizard is entering login password. After typing the password, please click Next.
On the next page as shown below, please select the WAN interface that you use. Choose
Auto negotiation as the physical type for your router. Then click Next for next step.
On the next page as shown below, please select the appropriate Internet access type
according to the information from your ISP. For example, you should select PPPoE mode if
the ISP provides you PPPoE interface. Then click Next for next step.
Vigor2930 Series User’s Guide
17
In the Quick Start Wizard, you can configure the router to access the Internet with different
protocol/modes such as PPPoE, PPTP, Static IP or DHCP. The router supports the DSL
WAN interface for Internet access.
22..22..11 PPPPPPooEE
PPPoE stands for Point-to-Point Protocol over Ethernet. It relies on two widely accepted
standards: PPP and Ethernet. It connects users through an Ethernet to the Internet with a
common broadband medium, such as a single DSL line, wireless device or cable modem. All
the users over the Ethernet can share a common connection.
PPPoE is used for most of DSL modem users. All local users can share one PPPoE
connection for accessing the Internet. Your service provider will provide you information
about user name, password, and authentication mode.
If your ISP provides you the PPPoE connection, please select PPPoE for this router. The following page will be shown:
18
User Name Assign a specific valid user name provided by the ISP.
Password Assign a valid password provided by the ISP.
Confirm Password Retype the password.
Click Next for viewing summary of such connection.
Vigor2930 Series User’s Guide
Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system
status of this protocol will be shown.
Vigor2930 Series User’s Guide
19
22..22..22 PPPPTTPP
Click PPTP as the protocol. Type in all the information that your ISP provides for this protocol.
Click Next for viewing summary of such connection.
20
Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system
status of this protocol will be shown.
Vigor2930 Series User’s Guide
22..22..33 SSttaattiicc IIPP
Click Static IP as the protocol. Type in all the information that your ISP provides for this protocol.
After finishing the settings in this page, click Next to see the following page.
Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system
status of this protocol will be shown.
Vigor2930 Series User’s Guide
21
22..22..44 DDHHCCPP
Click DHCP as the protocol. Type in all the information that your ISP provides for this protocol.
After finishing the settings in this page, click Next to see the following page.
22
Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system
status of this protocol will be shown.
Vigor2930 Series User’s Guide
22..33 OOnnlliinnee SSttaattuuss
The online status shows the system status, WAN status, ADSL Information and other status
related to this router within one page. If you select PPPoE/PPTP as the protocol, you will
find out a link of Dial PPPoE/PPPoA or Drop PPPoE/PPPoA in the Online Status web
page.
Online status for PPPoE
Online status for PPTP (for WAN2)
Online status for Static IP (for WAN1)
Vigor2930 Series User’s Guide
23
Online status for DHCP
Detailed explanation is shown below:
Primary DNS Displays the IP address of the primary DNS.
Secondary DNS Displays the IP address of the secondary DNS.
LAN Status
IP Address Displays the IP address of the LAN interface.
TX Packets Displays the total transmitted packets at the LAN interface.
RX Packets Displays the total number of received packets at the LAN interface.
WAN1/2 Status
Line Displays the physical connection (Ethernet) of this interface.
Name Displays the name set in WAN1/WAN web page.
Mode Displays the type of WAN connection (e.g., PPPoE).
Up Time Displays the total uptime of the interface.
IP Displays the IP address of the WAN interface.
GW IP Displays the IP address of the default gateway.
TX Packets Displays the total transmitted packets at the WAN interface.
TX Rate Displays the speed of transmitted octets at the WAN interface.
RX Packets Displays the total number of received packets at the WAN
interface.
RX Rate Display s the speed of received octets at the WAN interface.
ISDN Status
24
Channel Active Conn. Displays the active connection status for each channel.
TX Pkts Displays the total transmitted packets at the ISDN interface.
TX Rate Displays the speed of transmitted octets at the ISDN interface.
RX Pkts Display s the total number of received packets at the ISDN
interface.
RX Rate Display s the speed of received octets at the ISDN interface.
Up Time Displays the total uptime of the interface.
AOC Displays the charge information of the interface.
Vigor2930 Series User’s Guide
Dial ISDN Allows you to dial ISDN connection.
Drop B1/B2 Allows you to drop B1 or B2 connection.
Note: The words in green mean that the WAN connection of that interface
(WAN1/WAN2) is ready for accessing Internet; the words in red mean that the WAN
connection of that interface (WAN1/WAN2) is not ready for accessing Internet.
22..44 SSaavviinngg CCoonnffiigguurraattiioonn
Each time you click OK on the web page for saving the configuration, you can find
messages showing the system interaction with you.
Ready indicates the system is ready for you to input settings.
Settings Saved means your settings are saved once you click Finish or OK button.
Vigor2930 Series User’s Guide
25
This page is left blank.
26
Vigor2930 Series User’s Guide
3
Addvvaanncceedd
A
After finished basic configuration of the router, you can access Internet with ease. For the
people who want to adjust more setting for suiting his/her request, please refer to this chapter
for getting detailed information about the advanced configuration of this router. As for other
examples of application, please refer to chapter 4.
33..11 WWAANN
33..11..11 BBaassiiccss ooff IInntteerrnneett PPrroottooccooll ((IIPP)) NNeettwwoorrkk
Quick Start Wizard offers user an easy method to quick setup the connection mode for the router. Moreover, if you want to adjust more settings for different WAN modes, please go to WAN group and click the Internet Access link.
IP means Internet Protocol. Every device in an IP-based Network including routers, print
server, and host PCs, needs an IP address to identify its location on the network. To avoid
address conflicts, IP addresses are publicly registered with the Network Information Centre
(NIC). Having a unique IP address is mandatory for those devices participated in the public
network but not in the private TCP/IP local area networks (LANs), such as host PCs under
the management of a router since they do not need to be accessed by the public. Hence, the
NIC has reserved certain addresses that will never be registered publicly. These are known as
private IP addresses, and are listed in the following ranges:
Weebb
W
Coonnffiigguurraattiioonn
C
From 10.0.0.0 to 10.255.255.255
From 172.16.0.0 to 172.31.255.255
From 192.168.0.0 to 192.168.255.255
WWhhaatt aarree PPuubblliicc IIPP AAddddrreessss aanndd PPrriivvaattee IIPP AAddddrreessss
As the router plays a role to manage and further protect its LAN, it interconnects groups of
host PCs. Each of them has a private IP address assigned by the built-in DHCP server of the
Vigor router. The router itself will also use the default private IP address: 192.168.1.1 to
communicate with the local hosts. Meanwhile, Vigor router will communicate with other
network devices through a public IP address. When the data flow passing through, the
Network Address Translation (NAT) function of the router will dedicate to translate
public/private addresses, and the packets will be delivered to the correct host PC in the local
area network. Thus, all the host PCs can share a common Internet connection.
GGeett YYoouurr PPuubblliicc IIPP AAddddrreessss ffrroomm IISSPP
In ADSL deployment, the PPP (Point to Point)-style authentication and authorization is
required for bridging customer premises equipment (CPE). Point to Point Protocol over
Ethernet (PPPoE) connects a network of hosts via an access device to a remote access
concentrator or aggregation concentrator. This implementation provides users with
significant ease of use. Meanwhile it provides access control, billing, and type of service
according to user requirement.
When a router begins to connect to your ISP, a serial of discovery process will occur to ask
for a connection. Then a session will be created. Your user ID and password is authenticated
via PAP or CHAP with RADIUS authentication system. And your IP address, DNS server,
and other related information will usually be assigned by your ISP.
Vigor2930 Series User’s Guide
27
Below shows the menu items for Internet Access.
33..11..22 GGeenneerraall SSeettuupp
This section will introduce some general settings of Internet and explain the connection
modes for WAN1 and WAN2 in details.
This router supports dual WAN function. It allows users to access Internet and combine the
bandwidth of the dual WAN to speed up the transmission through the network. Each WAN
port can connect to different ISPs, Even if the ISPs use different technology to provide
telecommunication service (such as DSL, Cable modem, etc.). If any connection problem
occurred on one of the ISP connections, all the traffic will be guided and switched to the
normal communication port for proper operation. Please configure WAN1 and WAN2
settings.
This webpage allows you to set general setup for WAN1 and WAN respectively.
Note: In default, WAN1 and WAN2 are enabled.
28
Enable Choose Yes to invoke the settings for this WAN interface.
Choose No to disable the settings for this WAN interface.
Display Name Type the description for the WAN1/WAN2 interface.
Physical Mode For WAN1, the physical connection is done through ADSL
port; yet the physical connection for WAN2 is done through
an Ethernet port (P1). You cannot change it.
Vigor2930 Series User’s Guide
Physical Type You can change the physical type for WAN2 or choose Auto
negotiation for determined by the system.
Load Balance Mode If you know the practical bandwidth for your WAN interface,
please choose the setting of According to Line Speed.
Otherwise, please choose Auto Weigh to let the router reach
the best load balance.
Line Speed If your choose According to Line Speed as the Load
Balance Mode, please type the line speed for downloading
and uploading through WAN1/WAN2. The unit is kbps.
Active Mode Choose Always On to make the WAN connection
(WAN1/WAN2) being activated always; or choose Active on
demand to make the WAN connection (WAN1/WAN2)
activated if it is necessary.
If you choose Active on demand, the Idle Timeout will be
available for you to set for PPPoE and PPTP access modes in
the Details Page of WAN>>Internet Access. In addition,
there are three selections for you to choose for different
purposes.
WAN2 Fail – It means the connection for WAN1 will be
activated when WAN2 is failed.
WAN2 Upload speed exceed XX kbps – It means the
connection for WAN1 will be activated when WAN2 Upload
speed exceed certain value that you set in this box for 15
seconds.
WAN2 Download speed exceed XX kbps– It means the
connection for WAN1 will be activated when WAN2
Download speed exceed certain value that you set in this box
for 15 seconds.
WAN1 Fail – It means the connection for WAN2 will be
activated when WAN1 is failed.
WAN1 Upload speed exceed XX kbps – It means the
connection for WAN2 will be activated when WAN1 Upload
speed exceed certain value that you set in this box for 15
seconds.
WAN1 Download speed exceed XX kbps– It means the
connection for WAN2 will be activated when WAN1
Download speed exceed certain value that you set in this box
for 15 seconds.
Vigor2930 Series User’s Guide
29
33..11..33 IInntteerrnneett AAcccceessss
For the router supports dual WAN function, the users can set different WAN settings (for
WAN1/WAN2) for Internet Access. Due to different physical mode for WAN1 and WAN2,
the Access Mode for these two connections also varies slightly.
Index It shows the WAN modes that this router supports. WAN1 is the
Display Name It shows the name of the WAN1/WAN2 that entered in general
Physical Mode It shows the physical port for WAN1/WAN2.
Access Mode Use the drop down list to choose a proper access mode. The details
default WAN interface for accessing into the Internet. WAN2 is
the optional WAN interface for accessing into the Internet when
WAN 1 is inactive for some reason.
setup.
page of that mode will be popped up. If not, click Details Page for
accessing the page to configure the settings.
There are three access modes provided for PPPoE, Static or
Dynamic IP and PPTP.
Details Page This button will open different web page according to the access
mode that you choose in WAN1 or WAN2.
30
Vigor2930 Series User’s Guide
DDeettaaiillss PPaaggee ffoorr PPPPPPooEE
To use PPPoE as the accessing protocol of the internet, please choose Internet Access from
WAN menu. Then, select PPPoE mode for WAN2. The following web page will be shown.
PPPoE Client Mode Click Enable for activating this function. If you click Disable, this
function will be closed and all the settings that you adjusted in this
page will be invalid.
ISP Access Setup Enter your allocated username, password and authentication
parameters according to the information provided by your ISP. If
you want to connect to Internet all the time, you can check Always
On.
Username – Type in the username provided by ISP in this field.
Password – Type in the password provided by ISP in this field.
Index (1-15) in Schedule Setup - You can type in four sets of time
schedule for your request. All the schedules can be set previously
in Application – Schedule web page and you can use the number
that you have set in that web page.
ISDN Dial Backup
Setup
This setting is available for the routers supporting ISDN function
only. Before utilizing the ISDN dial backup feature, you must
create a dial backup profile first. Please click ISDN > Dialing to
a Single ISP to create the backup profile.
None - Disable the backup function.
Packet Trigger -The backup line is not on until a packet from a
local host triggers the router to establish a connection.
WAN Connection
Detection
Vigor2930 Series User’s Guide
This setting is available for i model only.
Such function allows you to verify whether network connection is
alive or not through ARP Detect or Ping Detect.
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you have
31
to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference. TTL
value is set by telnet command.
PPP/MP Setup PPP Authentication – Select PAP only or PAP or CHAP for
PPP.
Idle Timeout – Set the timeout for breaking down the Internet
after passing through the time without any action. This setting is
active only when the Active on demand option for Active Mode is
selected in WAN>> General Setup page.
IP Address
Assignment Method
(IPCP)
Usually ISP dynamically assigns IP address to you each time you
connect to it and request. In some case, your ISP provides service
to always assign you the same IP address whenever you request.
In this case, you can fill in this IP address in the Fixed IP field.
Please contact your ISP before you want to use this function.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use WAN
IP Alias. You can set up to 8 public IP addresses other than the
current one you are using. Notice that this setting is available for
WAN1 only.
32
Fixed IP – Click Yes to use this function and type in a fixed IP
address in the box of Fixed IP Address.
Default MAC Address – You can use Default MAC Address or
specify another MAC address by typing on the boxes of MAC
Address for the router.
Specify a MAC Address – Type the MAC address for the router
manually.
After finishing all the settings here, please click OK to activate them.
DDeettaaiillss PPaaggee ffoorr SSttaattiicc oorr DDyynnaammiicc IIPP
For static IP mode, you usually receive a fixed public IP address or a public subnet, namely
multiple public IP addresses from your DSL or Cable ISP service providers. In most cases, a
Vigor2930 Series User’s Guide
Cable service provider will offer a fixed public IP, while a DSL service provider will offer a
public subnet. If you have a public subnet, you could assign an IP address or many IP
address to the WAN interface.
To use Static or Dynamic IP as the accessing protocol of the internet, please choose
Internet Access from WAN menu. Then, select Static or Dynamic IP mode for WAN2.
The following web page will be shown.
Static or Dynamic IP
(DHCP Client)
Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you adjusted
in this page will be invalid.
ISDN Dial Backup
Setup
This setting is available for the routers supporting ISDN function
only. Before utilizing the ISDN dial backup feature, you must
create a dial backup profile first. Please click Internet Access
Setup > Dialing to a Single ISP to enter the backup profile.
None - Disable the backup function.
Packet Trigger -The backup line is not on until a packet from a
local host triggers the router to establish a connection.
This setting is available for i model only.
Keep WAN
Connection
Normally, this function is designed for Dynamic IP environments
because some ISPs will drop connections if there is no traffic
within certain periods of time. Check Enable PING to keep alive
box to activate this function.
PING to the IP - If you enable the PING function, please specify
the IP address for the system to PING it for keeping alive.
PING Interval - Enter the interval for the system to execute the
PING operation.
RIP Protocol Routing Information Protocol is abbreviated as RIP (RFC1058)
specifying how routers exchange routing tables information. Click
Enable RIP for activating this function.
Vigor2930 Series User’s Guide
33
WAN Connection
Detection
WAN IP Network
Settings
Such function allows you to verify whether network connection is
alive or not through ARP Detect or Ping Detect.
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you have
to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference. TTL
value is set by telnet command.
This group allows you to obtain an IP address automatically and
allows you type in IP address manually.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use WAN
IP Alias. You can set up to 8 public IP addresses other than the
current one you are using. Notice that this setting is available for
WAN1 only.
34
DNS Server IP
Address
Obtain an IP address automatically – Click this button to obtain
the IP address automatically if you want to use Dynamic IP mode.
Router Name: Type in the router name provided by ISP.
Domain Name: Type in the domain name that you have assigned.
Specify an IP address – Click this radio button to specify some
data if you want to use Static IP mode.
IP Address: Type the IP address.
Subnet Mask: Type the subnet mask.
Gateway IP Address: Type the gateway IP address.
Default MAC Address : Click this radio button to use default MAC
address for the router.
Specify a MAC Address: Some Cable service providers specify a
specific MAC address for access authentication. In such cases you
need to click the Specify a MAC Address and enter the MAC
address in the MAC Address field.
Type in the primary IP address for the router if you want to use
Static IP mode. If necessary, type in secondary IP address for
Vigor2930 Series User’s Guide
necessity in the future.
DDeettaaiillss PPaaggee ffoorr PPPPTTPP
To use PPTP as the accessing protocol of the internet, please choose Internet Access from
WAN menu. Then, select PPTP mode for WAN2. The following web page will be shown.
PPTP Setup PPTP Link - Click Enable to enable a PPTP client to establish a
tunnel to a DSL modem on the WAN interface.
PPTP Server - Specify the IP address of the PPTP server.
ISP Access Setup Username -Type in the username provided by ISP in this field.
Password -Type in the password provided by ISP in this field.
Index (1-15) in Schedule Setup - You can type in four sets of time
schedule for your request. All the schedules can be set previously
in Application – Schedule web page and you can use the number
that you have set in that web page.
ISDN Dial Backup
Setup
This setting is available for the routers supporting ISDN function
only. Before utilizing the ISDN dial backup feature, you must
create a dial backup profile first. Please click Internet Access
Setup > Dialing to a Single ISP to enter the backup profile.
None - Disable the backup function.
Packet Trigger -The backup line is not on until a packet from a
local host triggers the router to establish a connection.
This setting is available for i model only.
PPP Setup PPP Authentication - Select PAP only or PAP or CHAP for PPP.
Idle Timeout - Set the timeout for breaking down the Internet after
passing through the time without any action. This setting is active
only when the Active on demand option for Active Mode is
selected in WAN>> General Setup page.
IP Address
Assignment
Method(IPCP)
Fixed IP - Usually ISP dynamically assigns IP address to you
each time you connect to it and request. In some case, your ISP
provides service to always assign you the same IP address
whenever you request. In this case, you can fill in this IP address
in the Fixed IP field. Please contact your ISP before you want to
use this function. Click Yes to use this function and type in a
Vigor2930 Series User’s Guide
35
fixed IP address in the box.
Fixed IP Address -Type a fixed IP address.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use WAN
IP Alias. You can set up to 8 public IP addresses other than the
current one you are using. Notice that this setting is available for
WAN1 only.
WAN IP Network
Settings
33..11..44 LLooaadd--BBaallaannccee PPoolliiccyy
This router supports the function of load balancing. It can assign traffic with protocol type,
IP address for specific host, a subnet of hosts, and port range to be allocated in WAN1 or
WAN2 interface. The user can assign traffic category and force it to go to dedicate network
interface based on the following web page setup. Twenty policies of load-balance are
supported by this router.
Note: Load-Balance Policy is running only when both WAN1 and WAN2 are activated.
Default MAC Address – Click this radio button to use default
MAC address for the router.
Specify a MAC Address - Some Cable service providers specify a
specific MAC address for access authentication. In such cases you
need to click the Specify a MAC Address and enter the MAC
address in the MAC Address field.
Obtain an IP address automatically – Click this button to obtain
the IP address automatically.
Specify an IP address – Click this radio button to specify some
data.
IP Address – Type the IP address.
Subnet Mask – Type the subnet mask.
36
Vigor2930 Series User’s Guide
Index Click the number of index to access into the load-balance policy
configuration web page.
Enable Check this box to enable this policy.
Protocol Use the drop-down menu to change the protocol for the WAN
interface.
WAN Use the drop-down menu to change the WAN interface.
Src IP Start Display the IP address for the start of the source IP.
Src IP End Display the IP address for the end of the source IP.
Dest IP Start Display the IP address for the start of the destination IP.
Dest IP End Display the IP address for the end of the destination IP.
Dest Port Start Display the IP address for the start of the destination port.
Dest Port End Display the IP address for the end of the destination port.
Click Index 1 to access into the following page for configuring load-balance policy.
Vigor2930 Series User’s Guide
37
Enable Check this box to enable this policy.
Protocol Use the drop-down menu to choose a proper protocol for the WAN
interface.
Binding WAN
Choose the WAN interface (WAN1 or WAN2) for binding.
interface
Src IP Start Type the source IP start for the specified WAN interface.
Src IP End Type the source IP end for the specified WAN interface. If this
field is blank, it means that all the source IPs inside the LAN will
be passed through the WAN interface.
Dest IP Start Type the destination IP start for the specified WAN interface.
Dest IP End Type the destination IP end for the specified WAN interface. If this
field is blank, it means that all the destination IPs will be passed
through the WAN interface.
Dest Port Start Type the destination port start for the destination IP.
Dest Port End Type the destination port end for the destination IP. If this field is
blank, it means that all the destination ports will be passed through
the WAN interface.
38
Vigor2930 Series User’s Guide
33..22 LLAANN
Local Area Network (LAN) is a group of subnets regulated and ruled by router. The design
of network structure is related to what type of public IP addresses coming from your ISP.
33..22..11 BBaassiiccss ooff LLAANN
The most generic function of Vigor router is NAT. It creates a private subnet of your own. As
mentioned previously, the router will talk to other public hosts on the Internet by using
public IP address and talking to local hosts by using its private IP address. What NAT does is
to translate the packets from public IP address to private IP address to forward the right
packets to the right host and vice versa. Besides, Vigor router has a built-in DHCP server that
assigns private IP address to each local host. See the following diagram for a briefly
understanding.
In some special case, you may have a public IP subnet from your ISP such as
220.135.240.0/24. This means that you can set up a public subnet or call second subnet that
each host is equipped with a public IP address. As a part of the public subnet, the Vigor
router will serve for IP routing to help hosts in the public subnet to communicate with other
public hosts or servers outside. Therefore, the router should be set as the gateway for public
hosts.
Vigor2930 Series User’s Guide
39
WWhhaatt iiss RRoouuttiinngg IInnffoorrmmaattiioonn PPrroottooccooll ((RRIIPP))
Vigor router will exchange routing information with neighboring routers using the RIP to
accomplish IP routing. This allows users to change the information of the router such as IP
address and the routers will automatically inform for each other.
WWhhaatt iiss SSttaattiicc RRoouuttee
When you have several subnets in your LAN, sometimes a more effective and quicker way
for connection is the Static routes function rather than other method. You may simply set
rules to forward data from one specified subnet to another specified subnet without the
presence of RIP.
WWhhaatt aarree VViirrttuuaall LLAANNss aanndd RRaattee CCoonnttrrooll
You can group local hosts by physical ports and create up to 4 virtual LANs. To manage the
communication between different groups, please set up rules in Virtual LAN (VLAN)
function and the rate of each.
40
Vigor2930 Series User’s Guide
33..22..22 GGeenneerraall SSeettuupp
This page provides you the general settings for LAN. Click LAN to open the LAN settings page and choose General Setup.
1st IP Address Type in private IP address for connecting to a local private network
(Default: 192.168.1.1).
1st Subnet Mask Type in an address code that determines the size of the network.
(Default: 255.255.255.0/ 24)
For IP Routing Usage Click Enable to invoke this function. The default setting is
Disable.
nd
IP Address Type in secondary IP address for connecting to a subnet.
2
(Default: 192.168.2.1/ 24)
nd
Subnet Mask An address code that determines the size of the network.
2
(Default: 255.255.255.0/ 24)
nd
DHCP Server You can configure the router to serve as a DHCP server for the 2nd
2
subnet.
Vigor2930 Series User’s Guide
41
Start IP Address: Enter a value of the IP address pool for the
DHCP server to start with when issuing IP addresses. If the 2nd IP
address of your router is 220.135.240.1, the starting IP address
must be 220.135.240.2 or greater, but smaller than
220.135.240.254.
IP Pool Counts: Enter the number of IP addresses in the pool. The
maximum is 10. For example, if you type 3 and the 2nd IP address
of your router is 220.135.240.1, the range of IP address by the
DHCP server will be from 220.135.240.2 to 220.135.240.11.
MAC Address: Enter the MAC Address of the host one by one
and click Add to create a list of hosts to be assigned, deleted or
edited IP address from above pool. Set a list of MAC Address for
nd
2
DHCP server will help router to assign the correct IP address of
the correct subnet to the correct host. So those hosts in 2
won’t get an IP address belonging to 1
st
subnet.
nd
subnet
RIP Protocol Control Disable deactivates the RIP protocol. It will lead to a stoppage of
the exchange of routing information between routers. (Default)
1st Subnet - Select the router to change the RIP information of the
1st subnet with neighboring routers.
2nd Subnet - Select the router to change the RIP information of
the 2nd subnet with neighboring routers.
DHCP Server
Configuration
DHCP stands for Dynamic Host Configuration Protocol. The
router by factory default acts a DHCP server for your network so
it automatically dispatch related IP settings to any local user
configured as a DHCP client. It is highly recommended that you
leave the router enabled as a DHCP server if you do not have a
DHCP server for your network.
If you want to use another DHCP server in the network other than
the Vigor Router’s, you can let Relay Agent help you to redirect the
DHCP request to the specified location.
Enable Server - Let the router assign IP address to every host in
the LAN.
Disable Server – Let you manually assign IP address to every host
in the LAN.
Relay Agent – (1
st
subnet/2nd subnet) Specify which subnet that
DHCP server is located the relay agent should redirect the DHCP
request to.
Start IP Address - Enter a value of the IP address pool for the
DHCP server to start with when issuing IP addresses. If the 1st IP
address of your router is 192.168.1.1, the starting IP address must
be 192.168.1.2 or greater, but smaller than 192.168.1.254.
IP Pool Counts - Enter the maximum nu mber of PCs t hat you
want the DHCP server to assign IP addresses to. The default is 50
and the maximum is 253.
Gateway IP Address - Enter a value of the gateway IP address for
the DHCP server. The value is usually as same as the 1st IP address
42
Vigor2930 Series User’s Guide
of the router, which means the router is the default gateway.
DHCP Server IP Address for Relay Agent - Set the IP address of
the DHCP server you are going to use so the Relay Agent can help
to forward the DHCP request to the DHCP server.
DNS Server
Configuration
DNS stands for Domain Name System. Every Internet host must
have a unique IP address, also they may have a human-friendly,
easy to remember name such as www.yahoo.com. The DNS
server converts the user-friendly name into its equivalent IP
address.
Force DNS manual setting -
servers in this page instead of DNS servers given by the Internet
Access server (PPPoE, PPTP, L2TP or DHCP server).
Primary IP Address -You must specify a DNS server IP address
here because your ISP should provide you with usually more than
one DNS Server. If your ISP does not provide it, the router will
automatically apply default DNS Server IP address: 194.109.6.66
to this field.
Secondary IP Address - You can specify secondary DNS server IP
address here because your ISP often provides you more than one
DNS Server. If your ISP does not provide it, the router will
automatically apply default secondary DNS Server IP address:
194.98.0.1 to this field.
The default DNS Server IP address can be found via Online Status:
If both the Primary IP and Secondary IP Address fields are left
empty, the router will assign its own IP address to local users as a
DNS proxy server and maintain a DNS cache.
Force Vigor router to use DNS
There are two common scenarios of LAN settings that stated in Chapter 4. For the
configuration examples, please refer to that chapter to get more information for your
necessity.
33..22..33 SSttaattiicc RRoouuttee
Go to LAN to open setting page and choose Static Route.
If the IP address of a domain name is already in the DNS cache, the
router will resolve the domain name immediately. Otherwise, the
router forwards the DNS query packet to the external DNS server
by establishing a WAN (e.g. DSL/Cable) connection.
Vigor2930 Series User’s Guide
43
Index The number (1 to 10) under Index allows you to open next page to
set up static route.
Destination Address Displays the destination address of the static route.
Status Displays the status of the static route.
Viewing Routing Table Displays the routing table for your reference.
AAdddd SSttaattiicc RRoouutteess ttoo PPrriivvaattee aanndd PPuubblliicc NNeettwwoorrkkss
Here is an example of setting Static Route in Main Router so that user A and B locating in
different subnet can talk to each other via the router. Assuming the Internet access has been
configured and the router works properly:
z use the Main Router to surf the Internet.
z create a private subnet 192.168.10.0 using an internal Router A (192.168.1.2)
z create a public subnet 211.100.88.0 via an internal Router B (192.168.1.3).
z have set Main Router 192.168.1.1 as the default gateway for the Router A 192.168.1.2.
Before setting Static Route, user A cannot talk to user B for Router A can only forward
recognized packets to its default gateway Main Router.
44
1. Go to LAN page and click General Setup, select 1st Subnet as the RIP Protocol
Control. Then click the OK button.
Vigor2930 Series User’s Guide
Note: There are two reasons that we have to apply RIP Protocol Control on 1st
Subnet. The first is that the LAN interface can exchange RIP packets with the
neighboring routers via the 1st subnet (192.168.1.0/24). The second is that those
hosts on the internal private subnets (ex. 192.168.10.0/24) can access the Internet
via the router, and continuously exchange of IP routing information with different
subnets.
2. Click the LAN - Static Route and click on the Index Number 1. Check the Enable
box. Please add a static route as shown below, which regulates all packets destined to
192.168.10.0 will be forwarded to 192.168.1.2. Click OK.
3. Return to Stati c Route Setup page. Click on another Index Number to add another
static route as show below, which regulates all packets destined to 211.100.88.0 will be
forwarded to 192.168.1.3.
4. Go to Diagnostics and choose Routing Table to verify current routing table.
Vigor2930 Series User’s Guide
45
33..22..44 VVLLAANN
Virtual LAN function provides you a very convenient way to manage hosts by grouping them based on the physical port. You can also manage the in/out rate of each port. Go to LAN page and select VLAN. The following page will appear. Click Enable to invoke VLAN function.
To add or remove a VLAN, please refer to the following example.
1. If, VLAN 0 is consisted of hosts linked to P1 and P2 and VLAN 1 is consisted of hosts
linked to P3 and P4.
46
Vigor2930 Series User’s Guide
2. After checking the box to enable VLAN function, you will check the table according to
the needs as shown below.
To remove VLAN, uncheck the needed box and click OK to save the results.
33..22..55 BBiinndd IIPP ttoo MMAACC
This function is used to bind the IP and MAC address in LAN to have a strengthen control in
network. When this function is enabled, all the assigned IP and MAC address binding
together cannot be changed. If you modified the binding IP or MAC address, it might cause
you not access into the Internet.
Click LAN and click Bind IP to MAC to open the setup page.
Enable Click this radio button to invoke this function. However, IP/MAC
Disable Click this radio button to disable this function. All the settings on
Strict Bind Click this radio button to block the connection of the IP/MAC
Vigor2930 Series User’s Guide
which is not listed in IP Bind List also can connect to Internet.
this page will be invalid.
which is not listed in IP Bind List.
47
ARP Table This table is the LAN ARP table of this router. The information
for IP and MAC will be displayed in this field. Each pair of IP
and MAC address listed in ARP table can be selected and added
to IP Bind List by clicking Add below
.
Add and Edit IP Address – Type the IP address that will be used for the
specified MAC address.
Mac Address – Type the MAC address that is used to bind with
the assigned IP address.
Refresh It is used to refresh the ARP table. When there is one new PC
added to the LAN, you can click this link to obtain the newly
ARP table information.
IP Bind List It displays a list for the IP bind to MAC information.
Add It allows you to add the one you choose from the ARP table or
the IP/MAC address typed in Add and Edit to the table of IP
Bind List.
Edit It allows you to edit and modify the selected IP address and MAC
address that you create before.
33..33 NNAATT
Remove You can remove any item listed in IP Bind List. Simply click
and select the one, and click Remove. The selected item will be
removed from the IP Bind List.
Note: Before you select Strict Bind, you have to bind one set of IP/MAC address for one
PC. If not, no one of the PCs can access into Internet. And the web configurator of the router
might not be accessed.
Usually, the router serves as an NAT (Network Address Translation) router. NAT is a
mechanism that one or more private IP addresses can be mapped into a single public one.
Public IP address is usually assigned by your ISP, for which you may get charged. Private IP
addresses are recognized only among internal hosts.
When the outgoing packets destined to some public server on the Internet reach the NAT
router, the router will change its source address into the public IP address of the router, select
the available public port, and then forward it. At the same time, the router shall list an entry
in a table to memorize this address/port-mapping relationship. When the public server
response, the incoming traffic, of course, is destined to the router’s public IP address and the
router will do the inversion based on its table. Therefore, the internal host can communicate
with external host smoothly.
The benefit of the NAT includes:
z Save cost on applying public IP address and apply efficient usage of IP address.
NAT allows the internal IP addresses of local hosts to be translated into one public IP
address, thus you can have only one IP address on behalf of the entire internal hosts.
48
z Enhance security of the internal network by obscuring the IP address. There are
many attacks aiming victims based on the IP address. Since the attacker cannot be
aware of any private IP addresses, the NAT function can protect the internal network.
On NAT page, you will see the private IP address defined in RFC-1918. Usually we use
the 192.168.1.0/24 subnet for the router. As stated before, the NAT facility can map one
or more IP addresses and/or service ports into different specified services. In other words,
the NAT function can be achieved by using port mapping methods.
Vigor2930 Series User’s Guide
Below shows the menu items for NAT.
33..33..11 PPoorrtt RReeddiirreeccttiioonn
Port Redirection is usually set up for server related service inside the local network (LAN), such as web servers, FTP servers, E-mail servers etc. Most of the case, you need a public IP address for each server and this public IP address/domain name are recognized by all users. Since the server is actually located inside the LAN, the network well protected by NAT of the router, and identified by its private IP address/port, the goal of Port Redirection function is to forward all access request with public IP address from external users to the mapping private IP address/port of the server.
The port redirection can only apply to incoming traffic.
To use this function, please go to NAT page and choose Port Redirection web page. The
Port Redirection Table provides 20 port-mapping entries for the internal hosts.
Vigor2930 Series User’s Guide
49
Press any number under Index to access into next page for configuring port redirection.
50
Enable Check this box to enable such port redirection setting.
Mode Two options (Single and Range) are provided here for you to
choose. To set a range for the specific service, select Range. In
Range mode, if the public port (start port and end port) and the
starting IP of private IP had been entered, the system will calculate
and display the ending IP of private IP automatically.
Service Name Enter the description of the specific network service.
Protocol Select the transport layer protocol (TCP or UDP).
WAN IP Select the WAN IP used for port redirection. There are eight WAN
IP alias that can be selected and used for port redirection. The
default setting is All which means all the incoming data from any
port will be redirected to specified range of IP address and port.
Public Port Specify which port can be redirected to the specified Private IP
and Port of the internal host. If you choose Range as the port
redirection mode, you will see two boxes on this field. Simply type
Vigor2930 Series User’s Guide
the required number on the first box. The second one will be
assigned automatically later.
Private IP Specify the private IP address of the internal host providing the
service. If you choose Range as the port redirection mode, you will
see two boxes on this field. Type a complete IP address in the first
box (as the starting point) and the fourth digits in the second box
(as the end point).
Private Port Specify the private port number of the service offered by the
internal host.
Note that the router has its own built-in services (servers) such as Telnet, HTTP and FTP etc.
Since the common port numbers of these services (servers) are all the same, you may need to
reset the router in order to avoid confliction.
For example, the built-in web configurator in the router is with default port 80, which may
conflict with the web server in the local network, http://192.168.1.13:80. Therefore, you need
to change the router’s http port to any one other than the default port 80 to avoid
conflict, such as 8080. This can be set in the System Maintenance >>Management Setup.
You then will access the admin screen of by suffixing the IP address with 8080, e.g.,
http://192.168.1.1:8080 instead of port 80.
33..33..22 DDMMZZ HHoosstt
As mentioned above, Port Redirection can redirect incoming TCP/UDP or other traffic on particular ports to the specific private IP address/port of host in the LAN. However, other IP protocols, for example Protocols 50 (ESP) and 51 (AH), do not travel on a fixed port. Vigor router provides a facility DMZ Host that maps ALL unsolicited data on any protocol to a single host in the LAN. Regular web surfing and other such Internet activities from other clients will continue to work without inappropriate interruption. DMZ Host allows a defined internal user to be totally exposed to the Internet, which usually helps some special applications such as Netmeeting or Internet Games etc.
Vigor2930 Series User’s Guide
51
The inherent security properties of NAT are somewhat bypassed if you set up DMZ host.
We suggest you to add additional filter rules or a secondary firewall.
Click DMZ Host to open the following page:
If you previously have set up WAN Alias in Internet Access>>PPPoE/PPPoA or Internet
Access>>MPoA, you will find them in Aux. WAN IP list for your selection.
52
Vigor2930 Series User’s Guide
Enable Check to enable the DMZ Host function.
Private IP Enter the private IP address of the DMZ host, or click Choose PC
to select one.
Choose PC Click this button and then a window will automatically pop up, as
depicted below. The window consists of a list of private IP
addresses of all hosts in your LAN network. Select one private IP
address in the list to be the DMZ host.
When you have selected one private IP from the above dialog, the
IP address will be shown on the following screen. Click OK to
save the setting.
Vigor2930 Series User’s Guide
53
33..33..33 OOppeenn PPoorrttss
Open Ports allows you to open a range of ports for the traffic of special applications. Common application of Open Ports includes P2P application (e.g., BT, KaZaA, Gnutella, WinMX, eMule and others), Internet Camera etc. Ensure that you keep the application involved up-to-date to avoid falling victim to any security exploits.
Click Open Ports to open the following page:
Index Indicate the relative number for the particular entry that you want to
offer service in a local host. You should click the appropriate index
number to edit or clear the corresponding entry.
Comment Specify the name for the defined network service.
WAN Interface Display the WAN interface for the entry.
Local IP Address Display the private IP address of the local host offering the service.
Status Display the state for the corresponding entry. X or V is to represent
the Inactive or Active state.
To add or edit port settings, click one index number on the page. The index entry setup page
will pop up. In each index entry, you can specify 10 port ranges for diverse services.
54
Vigor2930 Series User’s Guide
Enable Open Ports Check to enable this entry.
Comment Make a name for the defined network application/service.
WAN Interface Specify the WAN interface that will be used for this entry.
Local Computer Enter the private IP address of the local host or click Choose PC to
select one.
Choose PC Click this button and, subsequently, a window having a list of
private IP addresses of local hosts will automatically pop up. Select
the appropriate IP address of the local host in the list.
Protocol Specify the transport layer protocol. It could be TCP, UDP, or -----
(none) for selection.
Start Port Specify the starting port number of the service offered by the local
host.
End Port Specify the ending port number of the service offered by the local
host.
Vigor2930 Series User’s Guide
55
33..44 OObbjjeeccttss SSeettttiinnggss
For IPs in a range and service ports in a limited range usually will be applied in configuring
router’s settings, therefore we can define them with objects and bind them with groups for
using conveniently. Later, we can select that object/group that can apply it. For example, all
the IPs in the same department can be defined with an IP object (a range of IP address).
Besides, you can define object profiles for different policy of IM (Instant Messenger)/P2P
(Peer to Peer)/Misc application.
33..44..11 IIPP OObbjjeecctt
You can set up to 192 sets of IP Objects with different conditions.
56
Set to Factory Default Clear all profiles.
Click the number under Index column for settings in detail.
Vigor2930 Series User’s Guide
Name Type a name for this profile. Maximum 15 characters are
allowed.
Interface Choose a proper interface (WAN, LAN or Any).
For example, the Direction setting in Edit Filter Rule will
ask you specify IP or IP range for WAN or LAN or any IP
address. If you choose LAN as the Interface here, and choose
LAN as the direction setting in Edit Filter Rule, then all the
IP addresses specified with LAN interface will be opened for
you to choose in Edit Filter Rule page.
Address Type Determine the address type for the IP address.
Select Single Address if this object contains one IP address
only.
Select Range Address if this object contains several IPs
within a range.
Select Subnet Address if this object contains one subnet for
IP address.
Select Any Address if this object contains any IP address.
Start IP Address Type the start IP address for Single Address type.
End IP Address Type the end IP address if the Range Address type is selected.
Subnet Mask Type the subnet mask if the Subnet Address type is selected.
Invert Selection If it is checked, all the IP addresses except the ones listed
above will be applied later while it is chosen.
Below is an example of IP objects settings.
Vigor2930 Series User’s Guide
57
33..44..22 IIPP GGrroouupp
This page allows you to bind several IP objects into one IP group.
Set to Factory Default Clear all profiles.
Click the number under Index column for settings in detail.
Name Type a name for this profile. Maximum 15 characters are
allowed.
Interface Choose WAN, LAN or Any to display all the available IP
objects with the specified interface.
Available IP Objects All the available IP objects with the specified interface chosen
above will be shown in this box.
58
Selected IP Objects Click >> button to add the selected IP objects in this box.
Vigor2930 Series User’s Guide
33..44..33 SSeerrvviiccee TTyyppee OObbjjeecctt
You can set up to 96 sets of Service Type Objects with different conditions.
Set to Factory Default Clear all profiles.
Click the number under Index column for settings in detail.
Name Type a name for this profile.
Protocol Specify the protocol(s) which this profile will apply to.
Source/Destination Port Source Port and the Destination Port column are available
Vigor2930 Series User’s Guide
for TCP/UDP protocol. It can be ignored for other protocols.
The filter rule will filter out any port number.
(=) – when the first and last value are the same, it indicates
one port; when the first and last values are different, it
indicates a range for the port and available for this profile.
59
(!=) – when the first and last value are the same, it indicates
all the ports except the port defined here; when the first
and
last values are different, it indicates that all the ports
except the range defined here are available for this service
type.
(>) – the port number greater than this value is available.
(<) – the port number less than this value is available for this
profile.
Below is an example of service type objects settings.
33..44..44 SSeerrvviiccee TTyyppee GGrroouupp
This page allows you to bind several service types into one group.
Set to Factory Default Clear all profiles.
60
Click the number under Index column for settings in detail.
Vigor2930 Series User’s Guide
Name Type a name for this profile.
Available Service Type
Objects
Selected Service Type
Objects
33..44..55 CCSSMM--IIMM OObbjjeecctt
You can define policy profiles for IM (Instant Messenger) application. The object profile(s)
configured here will be seen and adopted in CSM>>IM/P2P Profile page.
You can add IP objects from IP Objects page. All the
available IP objects will be shown in this box.
Click >> button to add the selected IP objects in this box.
Set to Factory Default Clear all profiles.
Click the number under Index column for settings in detail.
Vigor2930 Series User’s Guide
61
Profile Name Type a name for the CSM profile.
Check for Disallow Check the items that disallow to use. Any device that uses
33..44..66 CCSSMM--PP22PP OObbjjeecctt
You can define policy profiles for P2P (Point-to-Point) application. The object profile(s)
configured here will be seen and adopted in CSM>>IM/P2P Profile page.
such profile might not be allowed to access into the forbidden
items.
62
Vigor2930 Series User’s Guide
Set to Factory Default Clear all profiles.
Click the number under Index column for settings in detail.
Profile Name Type a name for the CSM profile.
Check for Disallow Check the items that disallow to use. Any device that uses
such profile might not be allowed to access into the forbidden
items.
In the above figure, BitTorrent protocol is disallowed if you apply such object profile as
filtering rule (setting in Firewall).
Vigor2930 Series User’s Guide
63
33..44..77 CCSSMM--MMiisscc OObbjjeecctt
You can define policy profiles for Misc application. The object profile(s) configured here
will be seen and adopted in CSM>>IM/P2P Profile page.
Set to Factory Default Clear all profiles.
Click the number under Index column for settings in detail.
Profile Name Type a name for the CSM profile.
64
Check for Disallow Check the items that disallow to use. Any device that uses
such profile might not be allowed to access into the forbidden
items.
Vigor2930 Series User’s Guide
33..55 CCSSMM
CSM stands for Content Security Management. As the popularity of all kinds of instant
messenger application arises, communication cannot become much easier. Nevertheless,
while some industry may leverage this as a great tool to connect with their customers, some
industry may take reserve attitude in order to reduce employee misusage during office hour
or prevent unknown security leak. It is similar situation for corporation towards peer-to-peer
applications since file-sharing can be convenient but insecure at the same time. To address
these needs, we provide CSM functionality.
33..55..11 IIMM//PP22PP PPrrooffiillee
IM/P2P Profile page can integrate objects profiles configured in Objects
Setting>>CSM-IM Object/CSM-P2P Object/CSM-Misc Object into single IM/P2P
profile.
Profile Name Type a name for the IM/P2P profile.
Later, in the Firewall>>General Setup and Firewall>>Edit Filter Set>>Edit Filter Rule
pages, you can use IM/P2P drop down list to choose the proper CSM-IM profile as the
standard for the host(s) to follow. See the following example.
Vigor2930 Series User’s Guide
65
33..55..22 UURRLL CCoonntteenntt FFiilltteerr PPrrooffiillee
To provide an appropriate cyberspace to users, Vigor router equips with URL Content Filter
not only to limit illegal traffic from/to the inappropriate web sites but also prohibit other web
feature where malicious code may conceal.
Once a user type in or click on an URL with objectionable keywords, URL keyword blocking
facility will decline the HTTP request to that web page thus can limit user’s access to the
website. You may imagine URL Content Filter as a well-trained convenience-store clerk
who won’t sell adult magazines to teenagers. At office, URL Content Filter can also provide
a job-related only environment hence to increase the employee work efficiency. How can
URL Content Filter work better than traditional firewall in the field of filtering? Because it
checks the URL strings or some of HTTP data hiding in the payload of TCP packets while
legacy firewall inspects packets based on the fields of TCP/IP headers only.
On the other hand, Vigor router can prevent user from accidentally downloading malicious
codes from web pages. It’s very common that malicious codes conceal in the executable
objects, such as ActiveX, Java Applet, compressed files, and other executable files. Once
downloading these types of files from websites, you may risk bringing threat to your system.
For example, an ActiveX control object is usually used for providing interactive web feature.
If malicious code hides inside, it may occupy user’s system.
Based on the list of user defined keywords, the URL Content Filter facility in Vigor router
inspects the URL string in every outgoing HTTP request. No matter the URL string is found
full or partial matched with a keyword, the Vigor router will block the associated HTTP
connection.
For example, if you add key words such as “sex”, Vigor router will limit web access to web
sites or web pages such as “www.sex.com”, ”www.backdoor.net/images/sex/p_386.html”.
Or you may simply specify the full or partial URL such as “www.sex.com” or “sex.com”.
Also the Vigor router will discard any request that tries to retrieve the malicious code. Click CSM and click URL Content Filter Profile to open the setup page.
66
Vigor2930 Series User’s Guide
Enable URL Access
Check the box to activate URL Access Control.
Control
Black List (block those
matching keyword)
White List (pass those
matching keyword)
Click this button to restrict accessing into the corresponding
webpage with the keywords listed on the box below.
Click this button to allow accessing into the corresponding
webpage with the keywords listed on the box below.
Keyword The Vigor router provides 8 frames for users to define keywords
and each frame supports multiple keywords. The keyword could be
a noun, a partial noun, or a complete URL string. Multiple
keywords within a frame are separated by space, comma, or
semicolon. In addition, the maximal length of each frame is
32-character long. After specifying keywords, the Vigor router will
decline the connection request to the website whose URL string
matched to any user-defined keyword. It should be noticed that the
more simplified the blocking keyword list, the more efficiently the
Vigor router perform.
Prevent web access
from IP address
Check the box to deny any web surfing activity using IP address,
such as http://202.6.3.2. The reason for this is to prevent someone
Vigor2930 Series User’s Guide
67
dodges the URL Access Control.
You must clear your browser cache first so that the URL content
filtering facility operates properly on a web page that you visited
before.
Enable Restrict Web
Feature
Check the box to activate the function.
Java - Check the checkbox to activate the Block Java object
function. The Vigor router will discard the Java objects from the
Internet.
ActiveX - Check the box to activate the Block ActiveX object
function. Any ActiveX object from the Internet will be refused.
Compressed file - Check the box to activate the Block Compressed
file function to prevent someone from downloading any
compressed file. The following list shows the types of compressed
files that can be blocked by the Vigor router. .
zip, rar, .arj, .ace, .cab, .sit
Executable file - Check the box to reject any downloading
behavior of the executable file from the Internet.
.exe, .com, .scr, .pif, .bas, .bat, .inf, .reg
Cookie - Check the box to filter out the cookie transmission from
inside to outside world to protect the local user's privacy.
Proxy - Check the box to reject any proxy transmission. To control
efficiently the limited-bandwidth usage, it will be of great value to
provide the blocking mechanism that filters out the multimedia
files downloading from web pages. Accordingly, files with the
following extensions will be blocked by the Vigor router.
.mov .mp3 .rm .ra .au .wmv
.wav .asf .mpg .mpeg .avi .ram
Enable Excepting
Subnets
Four entries are available for users to specify some specific IP
addresses or subnets so that they can be free from the URL Access
Control. To enable an entry, click on the empty checkbox, named
as ACT, in front of the appropriate entry.
Time Schedule Specify what time should perform the URL content filtering
facility.
33..55..33 WWeebb CCoonntteenntt FFiilltteerr PPrrooffiillee
We all know that the content on the Internet just like other types of media may be
inappropriate sometimes. As a responsible parent or employer, you should protect those in
your trust against the hazards. With Web filtering service of the Vigor router, you can protect
your business from common primary threats, such as productivity, legal liability, network and
security threats. For parents, you can protect your children from viewing adult websites or
chat rooms.
Once you have activated your Web Filtering service in Vigor router and chosen the categories
of website you wish to restrict, each URL address requested (e.g.www.bbc.co.uk) will be
checked against our server database, powered by SurfControl. The database covering over 70
languages and 200 countries, over 1 billion Web pages divided into 40 easy-to-understand
categories. This database is updated as frequent as daily by a global team of Internet
researchers. The server will look up the URL and return a category to your router. Your Vigor
router will then decide whether to allow access to this site according to the categories you have
selected. Please note that this action will not introduce any delay in your Web surfing because
each of multiple load balanced database servers can handle millions of requests for
categorization.
68
Vigor2930 Series User’s Guide
Click CSM and click Web Content Filter to open the setup page.
For this section, please refer to Web Content Filter user’s guide.
Vigor2930 Series User’s Guide
69
33..66 FFiirreewwaallll
33..66..11 BBaassiiccss ffoorr FFiirreewwaallll
While the broadband users demand more bandwidth for multimedia, interactive applications,
or distance learning, security has been always the most concerned. The firewall of the Vigor
router helps to protect your local network against attack from unauthorized outsiders. It also
restricts users in the local network from accessing the Internet. Furthermore, it can filter out
specific packets that trigger the router to build an unwanted outgoing connection.
The most basic security concept is to set user name and password while you install your
router. The administrator login will prevent unauthorized access to the router configuration
from your router.
If you did not set password during installation; you can go to System Maintenance to set up
your password.
FFiirreewwaallll FFaacciilliittiieess
The users on the LAN are provided with secured protection by the following firewall
facilities:
z User-configurable IP filter (Call Filter/ Data Filter).
z Stateful Packet Inspection (SPI): tracks packets and denies unsolicited incoming data
z Selectable Denial of Service (DoS) /Distributed DoS (DDoS) attacks protection
70
Vigor2930 Series User’s Guide
IIPP FFiilltteerrss
Depending on whether there is an existing Internet connection, or in other words “the WAN
link status is up or down”, the IP filter architecture categorizes traffic into two: Call Filter
and Data Filter.
z Call Filter - When there is no existing Internet connection, Call Filter is applied to all
traffic, all of which should be outgoing. It will check packets according to the filter
rules. If legal, the packet will pass. Then the router shall “initiate a call” to build the
Internet connection and send the packet to Internet.
z Data Filter - When there is an existing Internet connection, Data Filter is applied to
incoming and outgoing traffic. It will check packets according to the filter rules. If legal,
the packet will pass the router.
The following illustrations are flow charts explaining how router will treat incoming traffic
and outgoing traffic respectively.
SSttaatteeffuull PPaacckkeett IInnssppeeccttiioonn ((SSPPII))
Stateful inspection is a firewall architecture that works at the network layer. Unlike legacy
static packet filtering, which examines a packet based on the information in its header,
stateful inspection builds up a state machine to track each connection traversing all interfaces
of the firewall and makes sure they are valid. The stateful firewall of Vigor router not just
examine the header information also monitor the state of the connection.
Vigor2930 Series User’s Guide
71
DDeenniiaall ooff SSeerrvviiccee ((DDooSS)) DDeeffeennssee
The DoS Defense functionality helps you to detect and mitigate the DoS attack. The attacks
are usually categorized into two types, the flooding-type attacks and the vulnerability attacks.
The flooding-type attacks will attempt to exhaust all your system's resource while the
vulnerability attacks will try to paralyze the system by offending the vulnerabilities of the
protocol or operation system.
The DoS Defense function enables the Vigor router to inspect every incoming packet based
on the attack signature database. Any malicious packet that might duplicate itself to paralyze
the host in the secure LAN will be strictly blocked and a Syslog message will be sent as
warning, if you set up Syslog server.
Also the Vigor router monitors the traffic. Any abnormal traffic flow violating the pre-defined
parameter, such as the number of thresholds, is identified as an attack and the Vigor router
will activate its defense mechanism to mitigate in a real-time manner.
The below shows the attack types that DoS/DDoS defense function can detect:
1. SYN flood attack
2. UDP flood attack
3. ICMP flood attack
4. TCP Flag scan
5. Trace route
6. IP options
7. Unknown protocol
8. Land attack
9. Smurf attack
10. SYN fragment
11. ICMP fragment
12. Tear drop attack
13. Fraggle attack
14. Ping of Death attack
15. TCP/UDP port scan
Below shows the menu items for Firewall.
33..66..22 GGeenneerraall SSeettuupp
General Setup allows you to adjust settings of IP Filter and common options. Here you can
enable or disable the Call Filter or Data Filter. Under some circumstance, your filter set can
be linked to work in a serial manner. So here you assign the Start Filter Set only. Also you
can configure the Log Flag settings, Apply IP filter to VPN incoming packets, and Accept
incoming fragmented UDP packets.
Click Firewall and click General Setup to open the general setup page.
72
Vigor2930 Series User’s Guide
Call Filter Check Enable to activate the Call Filter function. Assign a start
filter set for the Call Filter.
Data Filter Check Enable to activate the Data Filter function. Assign a start
Action/Profile Select Pass or Block for the packets that do not match with the
Log For troubleshooting needs you can specify the filter log and/or CSM
IM/P2P
Some on-line games (for example: Half Life) will use lots of fragmented UDP packets to
transfer game data. Instinctively as a secure firewall, Vigor router will reject these
fragmented packets to prevent attack unless you enable “Accept Incoming Fragmented
UDP Packets”. By checking this box, you can play these kinds of on-line games. If security
concern is in higher priority, you cannot enable “Accept Incoming Fragmented UDP
Packets”.
33..66..33 FFiilltteerr SSeettuupp
Click Firewall and click Filter Setup to open the setup page.
filter set for the Data Filter.
filter rules.
log here by checking the box. The log will be displayed on Draytek
Syslog window.
Select an IM/P2P profile for global IM/P2P application blocking.
All the hosts in LAN must follow the standard configured in the
selected profile selected here. For detailed information, refer to
the section of CSM profile setup.
Vigor2930 Series User’s Guide
73
To edit or add a filter, click on the set number to edit the individual set. The following page
will be shown. Each filter set contains up to 7 rules. Click on the rule number button to edit
each rule. Check Active to enable the rule.
Filter Rule Click a button numbered (1 ~ 7) to edit the filter rule. Click the
button will open Edit Filter Rule web page. For the detailed
information, refer to the following page.
Active Enable or disable the filter rule.
Comment Enter filter set comments/description. Maximum length is
23–character long.
Move Up/Down Use Up or Down link to move the order of the filter rules.
Next Filter Set Set the link to the next filter set to be executed after the current
filter run. Do not make a loop with many filter sets.
To edit Filter Rule, click the Filter Rule index button to enter the Filter Rule setup page.
74
Check to enable the
Filter Rule
Check this box to enable the filter rule.
Vigor2930 Series User’s Guide
Comments Enter filter set comments/description. Maximum length is 14-
character long.
Index(1-15) Set PCs on LAN to work at certain time interval only. You may
choose up to 4 schedules out of the 15 schedules pre-defined in
Applications >> Schedule setup. The default setting of this filed is
blank and the function will always work.
Direction Set the direction of packet flow (LAN->WAN/WAN->LAN). It is
for Data Filter only. For the Call Filter, this setting is not
available since Call Filter is only applied to outgoing traffic.
Source/Destination IP Click Edit to access into the following dialog to choose the
source/destination IP or IP ranges.
To set the IP address manually, please choose Any Address/Single
Address/Range Address/Subnet Address as the Address Type
and type them in this dialog. In addition, if you want to use the IP
range from defined groups or objects, please choose Group and
Objects as the Address Type.
From the IP Group drop down list, choose the one that you want
to apply. Or use the IP Object drop down list to choose the object
that you want.
Service Type Click Edit to access into the following dialog to choose a suitable
service type.
Vigor2930 Series User’s Guide
75
To set the service type manually, please choose User defined as
the Service Type and type them in this dialog. In addition, if you
want to use the service type from defined groups or objects, please
choose Group and Objects as the Service Type.
Protocol - Specify the protocol(s) which this filter rule will apply to.
Source/Destination Port -
(=) – when the first and last value are the same, it indicates one
port; when the first and last values are different, it indicates a range
for the port and available for this service type.
(!=) – when the first and last value are the same,
the ports except the port defined here; when the first and
it indicates all
last
values are different, it indicates that all the ports except the range
defined here are available for this service type.
(>) – the port number greater than this value is available.
(<) – the port number less than this value is available for this
profile.
Service Group/Object - Use the drop down list to choose the one
that you want.
Fragments Specify the action for fragmented packets. And it is used for Data
Filter only.
Don’t care -No action will be taken towards fragmented packets.
Unfragmented -Apply the rule to unfragmented packets.
Fragmented - Apply the rule to fragmented packets.
Too Short - Apply the rule only to packets that are too short to
contain a complete header.
76
Filter Specifies the action to be taken when packets match the rule.
Block Immediately - Packets matching the rule will be dropped
immediately.
Pass Immediately - Packets matching the rule will be passed
immediately.
Block If No Further Match - A packet matching the rule, and that
does not match further rules, will be dropped.
Pass If No Further Match - A packet matching the rule, and that
does not match further rules, will be passed through.
Vigor2930 Series User’s Guide
Branch to other Filter
Set
If the packet matches the filter rule, the next filter rule will branch
to the specified filter set. Select next filter rule to branch from the
drop-down menu. Be aware that the router will apply the
specified filter rule for ever and will not return to previous filter
rule any more.
IM/P2P
All the packets/connections within the range configured in the
above conditions must follow the standard configured in the
IM/P2P profile selected here. For detailed information, refer to
the section of IM/P2P profile setup.
SysLog For troubleshooting needs you can specify the filter log and/or CSM
log here. Check the corresponding box to enable the log function.
Then, the filter log and/or CSM log will be shown on Draytek
Syslog window.
Vigor2930 Series User’s Guide
77
EExxaammppllee
As stated before, all the traffic will be separated and arbitrated using on of two IP filters: call
filter or data filter. You may preset 12 call filters and data filters in Filter Setup and even
link them in a serial manner. Each filter set is composed by 7 filter rules, which can be
further defined. After that, in General Setup you may specify one set for call filter and one
set for data filter to execute first.
78
Vigor2930 Series User’s Guide
33..66..44 DDooSS DDeeffeennssee
As a sub-functionality of IP Filter/Firewall, there are 15 types of detect/ defense function in the DoS Defense setup. The DoS Defense functionality is disabled for default.
Click Firewall and click DoS Defense to open the setup page.
Enable Dos Defense Check the box to activate the DoS Defense Functionality.
Enable SYN flood
defense
Check the box to activate the SYN flood defense function. Once
detecting the Threshold of the TCP SYN packets from the Internet
has exceeded the defined value, the Vigor router will start to
randomly discard the subsequent TCP SYN packets for a period
defined in Timeout. The goal for this is prevent the TCP SYN
packets’ attempt to exhaust the limited-resource of Vigor router.
By default, the threshold and timeout values are set to 50 packets
per second and 10 seconds, respectively.
Enable UDP flood
defense
Check the box to activate the UDP flood defense function. Once
detecting the Threshold of the UDP packets from the Internet has
exceeded the defined value, the Vigor router will start to randomly
discard the subsequent UDP packets for a period defined in
Timeout. The default setting for threshold and timeout are 150
packets per second and 10 seconds, respectively.
Enable ICMP flood
defense
Check the box to activate the ICMP flood defense function. Similar
to the UDP flood defense function, once if the Threshold of ICMP
packets from Internet has exceeded the defined value, the router
will discard the ICMP echo requests coming from the Internet. The
default setting for threshold and timeout are 50 packets per second
and 10 seconds, respectively.
Enable PortScan
detection
Vigor2930 Series User’s Guide
Port Scan attacks the Vigor router by sending lots of packets to
many ports in an attempt to find ignorant services would respond.
Check the box to activate the Port Scan detection. Whenever
detecting this malicious exploration behavior by monitoring the
79
port-scanning Threshold rate, the Vigor router will send out a
warning. By default, the Vigor router sets the threshold as 150
packets per second.
Block IP options Check the box to activate the Block IP options function. The Vigor
router will ignore any IP packets with IP option field in the
datagram header. The reason for limitation is IP option appears to
be a vulnerability of the security for the LAN because it will carry
significant information, such as security, TCC (closed user group)
parameters, a series of Internet addresses, routing messages...etc.
An eavesdropper outside might learn the details of your private
networks.
Block Land Check the box to enforce the Vigor router to defense the Land
attacks. The Land attack combines the SYN attack technology with
IP spoofing. A Land attack occurs when an attacker sends spoofed
SYN packets with the identical source and destination addresses, as
well as the port number to victims.
Block Smurf Check the box to activate the Block Smurf function. The Vigor
router will ignore any broadcasting ICMP echo request.
Block trace router Check the box to enforce the Vigor router not to forward any trace
route packets.
Block SYN fragment Check the box to activate the Block SYN fragment function. The
Vigor router will drop any packets having SYN flag and more
fragment bit set.
Block Fraggle Attack Check the box to activate the Block fraggle Attack function. Any
broadcast UDP packets received from the Internet is blocked.
Activating the DoS/DDoS defense functionality might block some
legal packets. For example, when you activate the fraggle attack
defense, all broadcast UDP packets coming from the Internet are
blocked. Therefore, the RIP packets from the Internet might be
dropped.
Block TCP flag scan Check the box to activate the Block TCP flag scan function. Any
TCP packet with anomaly flag setting is dropped. Those scanning
activities include no flag scan, FIN without ACK scan, SYN FINscan,
Xmas scan and full Xmas scan.
Block Tear Drop Check the box to activate the Block Tear Drop function. Many
machines may crash when receiving ICMP datagrams (packets) that
exceed the maximum length. To avoid this type of attack, the Vigor
router is designed to be capable of discarding any fragmented ICMP
packets with a length greater than 1024 octets.
Block Ping of Death Check the box to activate the Block Ping of Death function. This
attack involves the perpetrator sending overlapping packets to the
target hosts so that those target hosts will hang once they
re-construct the packets. The Vigor routers will block any packets
realizing this attacking activity.
80
Block ICMP Fragment Check the box to activate the Block ICMP fragment function. Any
ICMP packets with more fragment bit set are dropped.
Block Unknown
Protocol
Check the box to activate the Block Unknown Protocol function.
Individual IP packet has a protocol field in the datagram header to
indicate the protocol type running over the upper layer. However,
Vigor2930 Series User’s Guide
the protocol types greater than 100 are reserved and undefined at
this time. Therefore, the router should have ability to detect and
reject this kind of packets.
Warning Messages We provide Syslog function for user to retrieve message from Vigor
router. The user, as a Syslog Server, shall receive the report sending
from Vigor router which is a Syslog Client.
All the warning messages related to DoS Defense will be sent to
user and user can review it through Syslog daemon. Look for the
keyword DoS in the message, followed by a name to indicate what
kind of attacks is detected.
Vigor2930 Series User’s Guide
81
33..77 BBaannddwwiiddtthh MMaannaaggeemmeenntt
Below shows the menu items for Bandwidth Management.
33..77..11 SSeessssiioonnss LLiimmiitt
A PC with private IP address can access to the Internet via NAT router. The router will
generate the records of NAT sessions for such connection. The P2P (Peer to Peer)
applications (e.g., BitTorrent) always need many sessions for procession and also they will
occupy over resources which might result in important accesses impacted. To solve the
problem, you can use limit session to limit the session procession for specified Hosts.
In the Bandwidth Management menu, click Sessions Limit to open the web page.
82
To activate the function of limit session, simply click Enable and set the default session
limit.
Enable Click this button to activate the function of limit session.
Disable Click this button to close the function of limit session.
Default session limit Defines the default session number used for each computer in
LAN.
Limitation List Displays a list of specific limitations that you set on this web
page.
Start IP Defines the start IP address for limit session.
End IP Defines the end IP address for limit session.
Vigor2930 Series User’s Guide
Maximum Sessions Defines the available session number for each host in the
specific range of IP addresses. If you do not set the session
number in this field, the system will use the default session
limit for the specific limitation you set for each index.
Add Adds the specific session limitation onto the list above.
Edit Allows you to edit the settings for the selected limitation.
Delete Remove the selected settings existing on the limitation list.
Index (1-15) in Schedule
Setup
You can type in four sets of time schedule for your request.
All the schedules can be set previously in Application –
Schedule web page and you can use the number that you have
set in that web page.
Vigor2930 Series User’s Guide
83
33..77..22 BBaannddwwiiddtthh LLiimmiitt
The downstream or upstream from FTP, HTTP or some P2P applications will occupy large
of bandwidth and affect the applications for other programs. Please use Limit Bandwidth to
make the bandwidth usage more efficient.
In the Bandwidth Management menu, click Bandwidth Limit to open the web page.
To activate the function of limit bandwidth, simply click Enable and set the default upstream
and downstream limit.
Enable Click this button to activate the function of limit bandwidth.
Disable Click this button to close the function of limit bandwidth.
Default TX limit Define the default speed of the upstream for each computer in
LAN.
Default RX limit Define the default speed of the downstream for each computer
in LAN.
Allow auto adjustment to
make the best utilization
of available bandwidth
Router will detect if there is enough bandwidth remained for
using according to the bandwidth limit set by the user. If yes,
the router will adjust the available bandwidth for users to
enhance the total utilization.
Limitation List Display a list of specific limitations that you set on this web
page.
Start IP Define the start IP address for limit bandwidth.
End IP Define the end IP address for limit bandwidth.
Each/Shared Select Each to make each IP within the range of Start IP and
End IP having the same speed defined in TX limit and RX
84
Vigor2930 Series User’s Guide
limit fields; select Shared to make all the IPs within the range
of Start IP and End IP share the same speed defined in TX
limit and RX limit fields.
TX limit Define the limitation for the speed of the upstream. If you do
not set the limit in this field, the system will use the default
speed for the specific limitation you set for each index.
RX limit Define the limitation for the speed of the downstream. If you
do not set the limit in this field, the system will use the default
speed for the specific limitation you set for each index.
Add Add the specific speed limitation onto the list above.
Edit Allows you to edit the settings for the selected limitation.
Delete Remove the selected settings existing on the limitation list.
Index (1-15) in Schedule
Setup
33..77..33 QQuuaalliittyy ooff SSeerrvviiccee
Deploying QoS (Quality of Service) management to guarantee that all applications receive
the service levels required and sufficient bandwidth to meet performance expectations is
indeed one important aspect of modern enterprise network.
One reason for QoS is that numerous TCP-based applications tend to continually increase
their transmission rate and consume all available bandwidth, which is called TCP slow start.
If other applications are not protected by QoS, it will detract much from their performance in
the overcrowded network. This is especially essential to those are low tolerant of loss, delay
or jitter (delay variation).
Another reason is due to congestions at network intersections where speeds of
interconnected circuits mismatch or traffic aggregates, packets will queue up and traffic can
be throttled back to a lower speed. If there’s no defined priority to specify which packets
should be discarded (or in another term “dropped”) from an overflowing queue, packets of
sensitive applications mentioned above might be the ones to drop off. How this will affect
application performance?
You can type in four sets of time schedule for your request.
All the schedules can be set previously in Application –
Schedule web page and you can use the number that you
have set in that web page.
There are two components within Primary configuration of QoS deployment:
z Classification: Identifying low-latency or crucial applications and marking them for
high-priority service level enforcement throughout the network.
z Scheduling: Based on classification of service level to assign packets to queues and
associated service types
The basic QoS implementation in Vigor routers is to classify and schedule packets based on
the service type information in the IP header. For instance, to ensure the connection with the
headquarter, a teleworker may enforce an index of QoS Control to reserve bandwidth for
HTTPS connection while using lots of application at the same time.
One more larger-scale implementation of QoS network is to apply DSCP (Differentiated
Service Code Point) and IP Precedence disciplines at Layer 3. Compared with legacy IP
Precedence that uses Type of Service (ToS) field in the IP header to define 8 service classes,
DSCP is a successor creating 64 classes possible with backward IP Precedence compatibility.
In a QoS-enabled network, or Differentiated Service (DiffServ or DS) framework, a DS
domain owner should sign a Service License Agreement (SLA) with other DS domain
Vigor2930 Series User’s Guide
85
owners to define the service level provided toward traffic from different domains. Then each
DS node in these domains will perform the priority treatment. This is called
per-hop-behavior (PHB). The definition of PHB includes Expedited Forwarding (EF),
Assured Forwarding (AF), and Best Effort (BE). AF defines the four classes of delivery (or
forwarding) classes and three levels of drop precedence in each class.
Vigor routers as edge routers of DS domain shall check the marked DSCP value in the IP
header of bypassing traffic, thus to allocate certain amount of resource execute appropriate
policing, classification or scheduling. The core routers in the backbone will do the same
checking before executing treatments in order to ensure service-level consistency throughout
the whole QoS-enabled network.
However, each node may take different attitude toward packets with high priority marking
since it may bind with the business deal of SLA among different DS domain owners. It’s not
easy to achieve deterministic and consistent high-priority QoS traffic throughout the whole
network with merely Vigor router’s effort.
In the Bandwidth Management menu, click Quality of Service to open the web page.
This page displays the QoS settings result of the WAN interface. Click the Setup link to
access into next page for the general setup of WAN (1/2) interface. As to class rule, simply
click the Edit link to access into next for configuration.
You can configure general setup for the WAN interface, edit the Class Rule, and edit the
Service Type for the Class Rule for your request.
GGeenneerraall SSeettuupp ffoorr WWAANN IInntteerrffaaccee
86
When you click Setup, you can configure the bandwidth ratio for QoS of the WAN interface.
There are four queues allowed for QoS control. The first three (Class 1 to Class 3) class rules
can be adjusted for your necessity. Yet, the last one is reserved for the packets which are not
suitable for the user-defined class rules.
Vigor2930 Series User’s Guide
Enable the QoS Control The factory default for this setting is checked.
Please also define which traffic the QoS Control settings will
apply to.
IN- apply to incoming traffic only.
OUT-apply to outgoing traffic only.
BOTH- apply to both incoming and outgoing traffic.
Check this box and click OK, then click Setup link again.
You will see the Online Statistics link appearing on this page.
WAN Inbound Bandwidth It allows you to set the connecting rate of data input for WAN.
For example, if your ADSL supports 1M of downstream and
256K upstream, please set 1000kbps for this box. The default
value is 10000kbps.
WAN Outbound Bandwidth It allows you to set the connecting rate of data output for
WAN. For example, if your ADSL supports 1M of
downstream and 256K upstream, please set 256kbps for this
box. The default value is 10000kbps.
Note: The rate of outbound/inbound must be smaller than the real bandwidth to ensure
correct calculation of QoS. It is suggested to set the bandwidth value for inbound/outbound
as 80% - 85% of physical network speed provided by ISP to maximize the QoS
performance.
Reserved Bandwidth Ratio It is reserved for the group index in the form of ratio of
Enable UDP Bandwidth
Control
Outbound TCP ACK
Prioritize
Vigor2930 Series User’s Guide
reserved bandwidth to upstream speed and reserved
bandwidth to downstream speed.
Check this and set the limited bandwidth ratio on the right
field. This is a protection of TCP application traffic since
UDP application traffic such as streaming video will exhaust
lots of bandwidth.
The difference in bandwidth between download and upload
are great in ADSL2+ environment. For the download speed
might be impacted by the uploading TCP ACK, you can
87
check this box to push ACK of upload faster to speed the
network traffic.
Limited_bandwidth Ratio The ratio typed here is reserved for limited bandwidth of UDP
application.
Online Statistics Display an online statistics for quality of service for your
reference. This link will be seen only if you click OK in
WAN1/WAN2 General Setup web page and click Setup again
(for WAN1/WAN2) on the Bandwith
Management>>Quality of Service.
EEddiitt tthhee CCllaassss RRuullee ffoorr QQooSS
The first three (Class 1 to Class 3) class rules can be adjusted for your necessity. To add, edit
or delete the class rule, please click the Edit link of that one.
After you click the Edit link, you will see the following page. Now you can define the name
for that Class. In this case, “Test” is used as the name of Class Index #1.
88
Vigor2930 Series User’s Guide
For adding a new rule, click Add to open the following page.
ACT Check this box to invoke these settings.
Local Address Click the Edit button to set the local IP address (on LAN) for
the rule.
Remote Address Click the Edit button to set the remote IP address (on
LAN/WAN) for the rule.
Edit It allows you to edit source address information.
Address Type – Determine the address type for the source
address.
For Single Address, you have to fill in Start IP address.
For Range Address, you have to fill in Start IP address and
End IP address.
For Subnet Address, you have to fill in Start IP address and
Subnet Mask.
DiffServ CodePoint All the packets of data will be divided with different levels
Vigor2930 Series User’s Guide
and will be processed according to the level type by the
system. Please assign one of the levels of the data for
processing with QoS control.
89
Service Type It determines the service type of the data for processing with
QoS control. It can also be edited. You can choose the
predefined service type from the Service Type drop down list.
Those types are predefined in factory. Simply choose the one
that you want for using by current QoS.
By the way, you can set up to 20 rules for one Class. If you want to edit an existed rule,
please select the radio button of that one and click Edit to open the rule edit page for
modification.
EEddiitt tthhee SSeerrvviiccee TTyyppee ffoorr CCllaassss RRuullee
To add a new service type, edit or delete an existed service type, please click the Edit link
under Service Type field.
After you click the Edit link, you will see the following page.
90
Vigor2930 Series User’s Guide
For adding a new service type, click Add to open the following page.
Service Name Type in a new service for your request.
Service Type Choose the type (TCP, UDP or TCP/UDP) for the new
service.
Port Configuration Click Single or Range as the Type. If you select Range, you
have to type in the starting port number and the end porting
number on the boxes below.
Port Number – Type in the starting port number and the end
porting number here if you choose Range as the type.
By the way, you can set up to 40 service types. If you want to edit/delete an existed service
type, please select the radio button of that one and click Edit/Edit for modification.
Vigor2930 Series User’s Guide
91
33..88 AApppplliiccaattiioonnss
Below shows the menu items for Applications.
33..88..11 DDyynnaammiicc DDNNSS
The ISP often provides you with a dynamic IP address when you connect to the Internet via
your ISP. It means that the public IP address assigned to your router changes each time you
access the Internet. The Dynamic DNS feature lets you assign a domain name to a dynamic
WAN IP address. It allows the router to update its online WAN IP address mappings on the
specified Dynamic DNS server. Once the router is online, you will be able to use the
registered domain name to access the router or internal virtual servers from the Internet. It is
particularly helpful if you host a web server, FTP server, or other server behind the router.
Before you use the Dynamic DNS feature, you have to apply for free DDNS service to the
DDNS service providers. The router provides up to three accounts from three different
DDNS service providers. Basically, Vigor routers are compatible with the DDNS services
supplied by most popular DDNS service providers such as www.dyndns.org,
www.no-ip.com, www.dtdns.com, www.changeip.com, www.dynamic- nameserver.com.
You should visit their websites to register your own domain name for the router.
Enable the Function and Add a Dynamic DNS Account
1. Assume you have a registered domain name from the DDNS provider, say
hostname.dyndns.org, and an account with username: test and password: test.
2. In the DDNS setup menu, check Enable Dynamic DNS Setup.
Set to Factory Default Clear all profiles and recover to factory settings.
Enable Dynamic DNS Setup Check this box to enable DDNS function.
Index Click the number below Index to access into the setting
page of DDNS setup to set account(s).
92
WAN Interface Display current WAN interface used for accessing
Internet.
Domain Name Display the domain name that you set on the setting page
of DDNS setup.
Vigor2930 Series User’s Guide
Loading...
