Vigor2862
Series
VDSL2 Security Firewall
VDSL2/ADSL2+ Router
Ethernet WAN for Load Balancing or Failover
32 Simultaneous VPN Tunnels
SPI Firewall with Content Filtering
USB port for 3G/4G modem or extra storage
Central Management for VigorAP & Vigor Switch
Built-in 3G/4G/LTE cellular connectivity covering worldwide LTE networks
Built-in 802.11ac Wave 2 dual-band Wi-FI, delivers speed up to 1733Mbps + 300Mbps (ac model)
(L model)
Vigor2862 Series is a VDSL2/ADSL2+ Security
Firewall router which is compatible with variants of
ADSL and VDSL, VDSL bonding is also supported
on model Vigor2862B and Vigor2862Bn. Except the
DSL interface, there is also a Gigabit Ethernet WAN
port that can be used for any types of connection to
share the traffic load. 3G/4G/LTE USB modem can
also be attached to the USB ports of the router, and
offer wireless Internet connectivity in case the fixed
lines are not available. Vigor2862L/Ln/Lac have a
built-in 3G/4G/LTE modem, cellular connectivity can
be added by simply inserting a SIM card.
Vigor2862 Series can also be a central management
portal for Vigor APs and Vigor Switches, providing
Network Administrator a simpler way to maintain all
the network devices.
Flexible LAN Management
Vigor2862 Series supports 802.1Q standard and
can build a Tag-based VLAN system with an
802.1Q-support switch, Port-based VLAN is also
supported that each LAN port can be configured as
a member of different VLAN and be isolated from
each other without the use of VLAN tag.
Secure Business Network
Vigor2862 Series has implemented Stateful Packet
Inspection (SPI) Firewall, flexible filtering rules can be
set up to accept or deny packets based on source IP,
destination IP, protocol, port number, or even the
packet's contents. Content Filtering by URL keyword
or application can help you to prevent time and
network resource wasting on inappropriate network
activities.
Vigor2862 Series is also a robust VPN server which is
perfect for a company based on multiple locations or
has teleworkers. The VPN is compliant with all
common industry standard protocols, and its
compatible with third-party VPN devices.
Central Management
Vigor2862 Series can act as a Central Management
portal for the other Vigor devices on the network,
including VigorAPs, Vigor Switches, and even Vigor
Routers. With Central Management feature, device
main t enan c e ( such as f i rmwa r e u pgra d ing,
configuration backup and restore) and monitoring can
all be done from a single portal, which is the Web
User Interface of Vigor2862 Series
VigorAP
DSL
WAN 1
LAN
P1 P2
Vigor2862
VDSL2 Security Firewall
P3
VigorSwitch
3G/4G USB
mobile
1
2
P4
P5 / WAN2
WAN 2
USB
Modem
3G
4G
Printer
File Sharing
Temperature
Sensor

Vigor2862
Series
Connectivity
VDSL2/ADSL2/2+
ITU-T G.993.2 (VDSL2)
ITU-T G.992.1/3/5 (ADSL1/2/2+)
Annex A & Annex B
DSL Forum Performance Specification:
ADSL TR-048/67, TR-100; VDSL: WT-114
Erasure Decoding, Increased Interleaver
Depth and Re-transmission
EFM (IEEE 802.3 ah)
VDSL/Bonding Profile: up to 30a
Ethernet WAN
IPv4 - DHCP Client, Static IP, PPPoE, PPTP,
L2TP, 802.1q Multi-VLAN Tagging
IPv6 - Tunnel Mode: TSPC, AICCU, 6rd,
Static 6in4
Dual Stack: PPP, DHCPv6 Client,
Static IPv6
WAN Connection Fail-over
WAN Budgets
Load Balance/Route Policy
Ethernet LAN
IPv4/IPv6 DHCP Server
Static Routing/RIP
Multiple Subnet
Port/Tag-based VLAN
USB
3G/4G Modem as WAN3/WAN4
/Printer Server/File Sharing
/Temperature Sensor
VPN
Up to 32 VPN Tunnels
Protocol : PPTP, IPsec, L2TP, L2TP over IPsec
Encryption : MPPE and Hardware-based
AES/DES/3DES
Authentication : MD5, SHA-1
IKE Authentication : Pre-shared Key and
Digital Signature (X.509)
LAN-to-LAN, Teleworker-to-LAN
DHCP over IPsec
IPsec NAT-traversal (NAT-T)
Dead Peer Detection (DPD)
VPN Pass-through
VPN Wizard
mOTP
Supports 16 SSL VPN Tunnels
VPN Trunk: VPN Backup and Load Balance
Security
Multi-NAT, DMZ Host, Port-redirection and
Open Port
Object-based Firewall, Object IPv6,
Group IPv6
MAC Address Filter
SPI (Stateful Packet Inspection) (Flow Track)
DoS/DDoS Prevention
IP Address Anti-spoofing
E-mail Alert and Logging via Syslog
Bind IP to MAC Address
Time Schedule Control
Content Security ( IM/P2P, URL, Keywords,
Cookies,...)
Management
System Maintenance
HTTP/HTTPS with 2-level Management
(Admin/User)
Logging via Syslog
SNMP Management MIB-II (v2/v3)
CLI (Command Line Interface, Telnet/SSH)
Administration Access Control
Web-based Diagnostic Functionality
Firmware Upgrade via TFTP/HTTP
/TR-069
CWMP Support (TR-069/TR-104)
LAN Port Monitoring
Network Management
Bandwidth Management by session
/bandwidth
User Management by Time/Data Quota
LAN DNS and DNS Proxy/Cache
Dynamic DNS
IGMP Snooping/Proxy v2 and v3
QoS (DSCP/Class-based/4-level priority)
Guarantee Bandwidth for VoIP
Support Smart Monitor
Central AP Management
Central VPN Management
Support Switch Management
WLAN (Wireless models)
Multiple SSID
Security (Open, 64/128-bit WEP,
WPA/WPA2, 802.1x)
Hidden SSID
Wireless Rate Control by SSID
Wireless VLAN
Wireless LAN Isolation
MAC Address Access Control
Access Point Discovery
Wireless Client List
WDS (Wireless Distribution System)
WMM (Wi-Fi Multimedia)
Bonding
Vigor2862
Vigor2862
Vigor2862
Vigor2862
Vigor2862
Vigor2862
Vigor2862
Vigor2862
Vigor2862
Vac
Lac
Ln
L
ac
n
Bn
B
VoIP (V model)
Protocol: SIP, RTP/RTCP
12 SIP Registrars
G.168 Line Echo-cancellation
Jitter Buffer
Voice codec (G.711/G.723.1/G.726/G.729 A/B
/VAD/CNG)
DTMF Tone (Inband /Outband with RFC-2833/SIP Info)
FAX/Modem Support Tone Detection and G.711
Pass-through
Supplemental Services :
Call Hold/Retrieve/Waiting/Transfer
Call Forwarding (Always, Busy and No Answer)
Call Barring (Incoming/Outgoing)
DND (Do Not Disturb)
MWI (Message Waiting Indicator) (RFC-3842)
Hotline
Secure Phone (ZRTP + SRTP)
PSTN Loop-through When Power Failure
Dial Plan (Phone Book, Digit Map, Call Barring, Regional)
LTE Modem (L models)
LTE Connection Status on Dashboard
Support Sending Short Message Service (SMS) Feature
Support SMS Quota Limitation
Show the SMS Information in SMS Inbox
Hardware Interface
1 x VDSL2/ADSL2/2+ WAN Port (WAN1),
RJ-11 for Annex A/RJ-45 for Annex B
1 x 10/100/1000Base-Tx, RJ-45 (WAN2)
5 x 10/100/1000Base-Tx LAN Switch, RJ-45
(Configurable Physical DMZ on P4),
(P5 is shared by WAN2)
2 x Detachable Antennas (n Model)
4 x Detachable Antennas (ac Model)
2 x Detachable LTE Antennas (L model)
LTE SIM Card Slot (L model)
2 x USB Host 2.0
1 x USB Host 2.0 (L model)
1 x Factory Reset Button
1 x Wireless On/Off/WPS Button (n/ac model)
2 x FXS and 1 x Life Line Port, RJ11 (V Model)
WLAN
VDSL
LTE
2.4 GHz 5 GHz
VoIP
991-2 86 2000- 01 G
Specifications subject to change at any time without notice, for more information please visit www.draytek.com or contact your local representative.
