Draytek 2832 Users Manual

i

Vigor2832 Series

ADSL2/2+ Security Firewall

Quick Start Guide

Version: 1.0

Firmware Version: V3.8.3_RC2

(For future update, please visit DrayTek web site)

Date: June 13, 2016

ii

Intellectual Property Rights (IPR) Information

Copyrights

Trademarks

© All rights reserved. This publication contains information that is protected
by copyright. No part may be reproduced, transmitted, transcribed, stored in
a retrieval system, or translated into any language without written permission
from the copyright holders.

The following trademarks are used in this document:

 Microsoft is a registered trademark of Microsoft Corp.
 Windows, Windows 95, 98, Me, NT, 2000, XP, Vista, 7, 8 and

Explorer are trademarks of Microsoft Corp.

 Apple and Mac OS are registered trademarks of Apple Inc.
 Other products may be trademarks or registered trademarks of

their respective manufacturers.

Safety Instructions and Approval

Safety
Instructions

 Read the installation guide thoroughly before you set up the router.
 The router is a complicated electronic unit that may be repaired

only be authorized and qualified personnel. Do not try to open or
repair the router yourself.

 Do not place the router in a damp or humid place, e.g. a bathroom.
 Do not stack the routers.
 The router should be used in a sheltered area, within a

temperature range of 0 to +45 Celsius.

 Do not expose the router to direct sunlight or other heat sources.

The housing and electronic components may be damaged by direct
sunlight or heat sources.

 Do not deploy the cable for LAN connection outdoor to prevent

electronic shock hazards.

 Keep the package out of reach of children.
 When you want to dispose of the router, please follow local

regulations on conservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the router will be free
from any defects in workmanship or materials for a period of two (2) years
from the date of purchase from the dealer. Please keep your purchase receipt
in a safe place as it serves as proof of date of purchase. During the warranty
period, and upon proof of purchase, should the product have indications of
failure due to faulty workmanship and/or materials, we will, at our discretion,
repair or replace the defective products or components, without charge for
either parts or labor, to whatever extent we deem necessary tore-store the
product to proper operating condition. Any replacement will consist of a new
or re-manufactured functionally equivalent product of equal value, and will
be offered solely at our discretion. This warranty will not apply if the produ ct
is modified, misused, tampered with, damaged by an act of God, or subjected
to abnormal working conditions. The warranty does not cover the bundled or
licensed software of other vendors. Defects which do not significantly affect
the usability of the product will not be covered by the warranty. We reserve
the right to revise the manual and online documentation and to make changes
from time to time in the contents hereof without obligation to notify any
person of such revision or changes.

i

European Community Declarations

Manufacturer: DrayTek Corp.
Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu

County, Taiwan 303

Product: Vigor2832 Series
DrayTek Corp. declares that Vigor2832 Series of routers are in compliance with the following

essential requirements and other relevant provisions of R&TTE 1999/5/EC, ErP 2009/125/EC
and RoHS 2011/65/EU

The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive
2004/108/EC by complying with the requirements set forth in EN55022/Class B and
EN55024/Class B.

The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by
complying with the requirements set forth in EN60950-1.

This product is designed for the POTS, DSL and 2.4GHz WLAN network throughout the EC region.
Please see the user manual for the applicable networks on your product.

.

Regulatory Information

Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protect ion
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by tur ning
the equipment off and on, the user is encouraged to try to correct the interference by one of
the following measures:

 Reorient or relocate the receiving
 Increase the
 Connect the equipment into an outlet on a circuit different from that to which the receive

is connected.
 Consult the dealer or an experienced radio/TV technician fo
This de

conditions:
(1) This device may not cause harmful interference, and
(2) This de

undesired operation.

More update, please visit www.draytek.com.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.

FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.

vice complies with Part 15 of the FCC Rules. Operation is subject to the following two

vice may accept any interference received, including interference that may caus

separation between the equipment an

antenna.

d receiver.

r help.

e

r

ii

Be a Registered Owner

Web registration is preferred. You can register your Vigor router via http://www.draytek.com.

Firmware & Tools Updates

Due to the continuous evolution of DrayTek technology, all routers will be regularly upgraded.
Please consult the DrayTek web site for more information on newest firmware, tools and
documents.

http://www.draytek.com

iii

TTaabbllee ooff CCoonntteennttss

1. Introduction........................................................................................................... 1

2. Package Content .................................................................................................. 2

3. Panel Explanation................................................................................................. 3

4. Hardware Installation ........................................................................................... 6

5. Software Configuration........................................................................................ 7

6. Customer Service............................................................................................... 12

iv
