Drawmer TS2 User Manual

DRAWMER

Dual Channel Vacuum

Tube Compressor

OPERATORS MANUAL

CONTENTS

SAFETY CONSIDERATIONS page 1
INTRODUCTION page 2
INSTALLATION page 2

• Audio Connections page 2

• Power Connection page 3

• Digital Module page 4
CONTROL DESCRIPTIONS

• Analogue page 5

• Digital page 7
OPERATION page 8
IF A FAULT DEVELOPS page 10
CONTACTING DRAWMER page 10
TECHNICAL SPECIFICATION page 11
BLOCK DIAGRAM page 12

i

COPYRIGHT

This manual is copyrighted © 2002 by Drawmer Electronics, Ltd. With all rights
reserved. Under copyright laws, this manual may not be duplicated in whole
or in part without the written consent of Drawmer.

ONE YEAR LIMITED WARRANTY

Drawmer Electronics Ltd., warrants the Drawmer Tube Station 2 audio
processor to conform substantially to the specifications of this manual for a
period of one year from the original date of purchase when used in accordance
with the specifications detailed in this manual. In the case of a valid warranty
claim, your sole and exclusive remedy and Drawmer’s entire liability under
any theory of liability will be to, at Drawmer’s discretion, repair or replace the
product without charge, or, if not possible, to refund the purchase price to
you. This warranty is not transferable. It applies only to the original purchaser
of the product.

For warranty service please call your local Drawmer dealer. Alternatively call
Drawmer Electronics Ltd. at [phone]. Then ship the defective
product, with transportation and insurance charges pre-paid, to Drawmer
Electronics Ltd., Coleman Street, Parkgate, Rotherham, S62 6EL UK. Write the
RA number in large letters in a prominent position on the shipping box.
Enclose your name, address, telephone number, copy of the original sales
invoice and a detailed description of the problem. Drawmer will not accept
responsibility for loss or damage during transit.

This warranty is void if the product has been damaged by misuse, modification
or unauthorised repair.

THIS WARRANTY IS IN LIEU OF ALL WARRANTIES, WHETHER ORAL OR
WRITTEN, EXPRESSED, IMPLIED OR STATUTORY. DRAWMER MAKES NO
OTHER WARRANTY EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. PURCHASER’S
SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY SHALL BE REPAIR
OR REPLACEMENT AS SPECIFIED HEREIN.

IN NO EVENT WILL DRAWMER ELECTRONICS LTD. BE LIABLE FOR ANY
DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY DEFECT IN THE PRODUCT, INCLUDING LOST
PROFITS, DAMAGE TO PROPERTY, AND, TO THE EXTENT PERMITTED BY
LAW, DAMAGE FOR PERSONAL INJURY, EVEN IF DRAWMER HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Some states and specific countries do not allow the exclusion of implied
warranties or limitations on how long an implied warranty may last, so the
above limitations may not apply to you. This warranty gives you specific legal
rights. You may have additional rights that vary from state to state, and
country to country.

In the interests of product development, Drawmer reserve the right to modify
or improve specifications of this product at any time, without prior notice.

ii

Tube Station 2 OPERATORS’ MANUAL 1

DRAWMER Tube Station 2

Dual Channel Vacuum Tube

Compressor

SAFETY CONSIDERATIONS

CAUTION - MAINS FUSE

TO REDUCE THE RISK OF FIRE REPLACE THE MAINS FUSE ONLY WITH
THE SAME TYPE, WHICH MUST BE A CLASS 3, 250 VOLT, TIME DELAY

TYPE, RATED AT 160mA WHERE THE MAINS INPUT IS SET TO 230 VOLTS

AC. AND 315mA WHERE THE MAINS INPUT VOLTAGE IS 115 VOLTS AC.

ALL FUSES MUST COMPLY WITH IEC127-2.

THE FUSE BODY SIZE IS 20mm x 5mm.

CAUTION - MAINS CABLE

DO NOT ATTEMPT TO CHANGE OR TAMPER WITH THE SUPPLIED MAINS

CABLE.

CAUTION - SERVICING

DO NOT PERFORM ANY SERVICING. REFER ALL SERVICING TO

QUALIFIED SERVICE PERSONNEL.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE

THIS EQUIPMENT TO RAIN OR MOISTURE.

Tube Station 2 OPERATORS’ MANUAL2

INTRODUCTION

The Tube Station 2 is a high quality Dual Channel Vacuum Tube Compressor. It has
an optional Digital Output module which enables SPDIF to be output from the unit.
The Tube Station 2 is suitable for both live sound and studio applications. All buttons
have status LEDs.

INSTALLATION

The TS1 is designed for standard 19" rack mounting and occupies 1U of rack space.
Because the tube circuitry generates more heat than an equivalent solid-state design,
it is recommended that 1u of space is left above and below the unit, where space is
available, to allow the heat to dissipate. In addition the rack should be fan cooled,
with air blowing onto the TS2, this will extend the life and reliability of the units.
Avoid mounting the unit directly above power amplifiers or power supplies that
radiate significant amounts of heat and always connect the mains earth to the unit.

AUDIO CONNECTIONS

Input and Output connections are provided for use at +4dBu via balanced XLRs. If
unbalanced operation at +4dBu is required, simply connect the unused terminal to
Ground inside the balanced jack socket. This applies to both inputs and outputs. The
wiring convention for XLR being: pin 1 Ground, pin 2 Hot and pin 3 Cold. For use with
unbalanced systems, the Cold pin 3 must be grounded at both input and output XLRs.
For jack operation refer to diagram.

Interference: If the unit is to be used where it maybe exposed to high levels of

disturbance such as found close to a TV or radio transmitter, we
suggest that the unit be operated using the XLR connectors. The
screens of the signal cables should be connected to the chassis
connection on the XLR connector as opposed to connecting to
pin1. The TS2 fully conforms to the EMC standards.

Ground Loops: If ground loop problems are encountered, never disconnect the

mains earth, but try disconnecting the signal screen on one end
of each of the cables connecting the outputs of the TS2 to the
patchbay. If such measures are necessary, balanced operation
is recommended.

AUDIO CONNECTION DIAGRAM

Tube Station 2 OPERATORS’ MANUAL 3

POWER CONNECTION

If the unit is required to operate at a mains input voltage which is different to that as
supplied:
The following procedure must be carried out by a qualified technical engineer.

1: Disconnect the unit from the mains.
2: Remove the twelve screws that retain the top cover.

Accessing the internal power switch and fuse

3. Set the voltage rating and replace the fuse.
Mains Voltage 230V Fuse Value 160mA.
Mains Voltage 115V Fuse Value 315mA.

4. Replace the cover.
