SUBMERSIBLE
WATER PUMP
98918.
These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these
instructions before assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been
designed, and contains all the necessary information to ensure its correct and safe use. By following all the
general safety instructions contained in this manual, it will ensure both product and operator safety, together
with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.
1. INTRODUCTION NOTES
1.1 INTRODUCTION:
USER MANUAL FOR: Submersible pump.
Stock No: 98918.
Part No: SWP220IFS.
1.2 REVISIONS:
Date first published June 2019.
As our user manuals are continually updated, users should make sure that they use
the very latest version.
Downloads are available from: http://drapertools.com/manuals
Draper Tools Limited
Hursley Road
Chandler’s Ford
Eastleigh
Hampshire
SO53 1YF
UK
Website: drapertools.com
Product Helpline: +44 (0) 23 8049 4344
General Fax: +44 (0) 23 8026 0784
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
WARNING! – Information that draws attention to the risk of injury or death.
CAUTION! – Information that draws attention to the risk of damage to the product or
surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal and educational use
only. Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any
other form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
- 2 -
1. TITLE PAGE
1.1 INTRODUCTION..........................................................................................................2
1.2 REVISION HISTORY ..................................................................................................2
1.3 UNDERSTANDING THIS MANUAL .............................................................................2
1.4 COPYRIGHT NOTICE..................................................................................................2
2. CONTENTS
2.1 CONTENTS ....................................................................................................................3
3. WARRANTY
3.1 WARRANTY.................................................................................................................4
4. INTRODUCTION
4.1 SCOPE.........................................................................................................................5
4.2 SPECIFICATION..........................................................................................................5
4.3 HANDLING AND STORAGE........................................................................................ 5
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE ...............................6
– 1) Work area safety ................................................................................................6
– 2) Electrical safety..................................................................................................6
– 3) Personal safety................................................................................................... 6
– 4) Power tool use and care....................................................................................7
– 5) Service ................................................................................................................7
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR SUBMERSIBLE WATER PUMPS ......8
5.3 CONNECTION TO THE POWER SUPPLY .................................................................9
6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION.......................................................................................................10
6.2 MAIN COMPONENT DESCRIPTIONS ...................................................................... 10
7. UNPACKING AND CHECKING
7.1 PACKAGING ............................................................................................................. 11
8. READYING THE PUMP
8.1 INSTALLATION OF PARTS ....................................................................................... 12
9. INSTALLING THE PUMP
9.1 PUMPING DISTANCE AND VOLUME .......................................................................13
9.2 FLOATING SWITCH...................................................................................................14
9.3 SET CT OFF FLOAT HEIGHT....................................................................................15
9.4 SET INTEGRAL FLOAT HEIGHT...............................................................................15
9.5 PLACEMENT ............................................................................................................. 16
9.6 CONNECTING TO POWER VIA RCD ....................................................................... 17
9.7 SWITCHING ON THE PUMP.....................................................................................17
10. MAINTENANCE
10.1 CLEARING OBSTRUCTIONS IN THE IMPELLER HOUSING ..................................18
11. OPTIONAL ACCESSORIES ....................................................................................................19
12. TROUBLESHOOTING
12.1 TROUBLESHOOTING CHECKLIST..........................................................................20
13. EXPLANATION OF SYMBOLS
13.1 EXPLANATION OF SYMBOLS ................................................................................... 21
14. DISPOSAL
14.1 DISPOSAL ................................................................................................................. 22
DECLARATION OF CONFORMITY ..............................................................................ENCLOSED
- 3 -
3. WARRANTY
3.1 WARRANTY
Draper tools have been carefully tested and inspected before shipment and are guaranteed to be
free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor or
contact
Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: (023) 8049 4333 or Product Help Line (023) 8049 4344.
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or workmanship,
repairs will be carried out free of charge. This warranty period covering labour is 12 months from
the date of purchase except where tools are hired out when the warranty period is 90 days from
the date of purchase. The warranty is extended to 24 months for parts only. This warranty does not
apply to any consumable parts, any type of battery or normal wear and tear, nor does it cover any
damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges will
be quoted and made accordingly.
This warranty applies in lieu of any other warranty expressed or implied and variations of its terms
are not authorised.
Your Draper warranty is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the warranty period.
Please note that this warranty is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.
- 4 -
4. INTRODUCTION
4.1 SCOPE
This machine was designed for pumping clear or dirty water. It is ideally suited to pumping out
garden ponds where the water is free of debris.
These pumps are not designed for use in fish ponds.
4.2 SPECIFICATION
Stock No. ................................................................................................................. 98918
Part No. ........................................................................................................SWP220IFS
Motor:
Rated voltage ................................................................................................................230V
Rated frequency............................................................................................................. 50Hz
Rated input ................................................................................................................. 750W
Output aperture size.................................................................................................... 25-32mm
Max. flow rate .............................................................................................................216L/min
Max. head height ............................................................................................................... 8.5M
Max. Particle Size............................................................................................................... 5mm
Degree of protection against moisture.................................................................................IPX8
Warning: This product must be used in conjunction with a residual current device (RCD)
4.3 HANDLING AND STORAGE
These submersible pumps are designed to be moved to different locations. Ensure they are
always operated on a level surface.
- 5 -
5. HEALTH AND SAFETY INFORMATION
Have this tool repaired by a qualified person. This tool is designed to conform to the relevant
international and local standards and as such should be maintained and repaired by someone
qualified; using only original parts supplied by the manufacturer: This will ensure the tool remains
safe to use.
5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE
Warning: Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adaptor plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools
with your finger on the switch or energising power tools that have the switch on invites
accidents.
- 6 -
5. HEALTH AND SAFETY INFORMATION
3) Personal safety continued...
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts &
any other condition that may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained power tools.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
IMPORTANT
If using an extension lead, follow the instructions that came with your lead regarding
maximum load while cable is wound. If in doubt, ensure that the entire cable is unwound.
Using a coiled extension lead will generate heat which could melt the lead and cause a fire.
- 7 -
5. HEALTH AND SAFETY INFORMATION
5.2
ADDITIONAL SAFETY INSTRUCTIONS FOR SUBMERSIBLE WATER PUMPS
- When carrying or lifting the submersible pump always use the transport handle, DO NOT
carry or lift using the power cable or float switch cable.
- Before connecting to the power supply:
• A residual current circuit breaker (RCD) must be used for all applications
(Draper Stock No.69307 or 89301).
• The electrical supply should be the same as that stated on the rating plate.
- Submersible water pumps should always be transported, stored, and submersed vertically.
- Always ensure that your hands are dry when connecting and disconnecting the
power supply.
- Never operate the pump below the top of the water inlet.
- The area being pumped should be kept clear, and nobody should enter the area while pump is
operating.
- Do not pump explosive or flammable liquids.
Important: please read before use.
The following additional instructions must be followed at all times. Failure to do so could
invalidate the guarantee of this submersible water pump.
- The float switch must be clamped in position using the cable clamp recess.
NOTE: The pump, should be suspended using a rope, chain or stood on a brick to prevent
any gravel etc. being sucked into the pump and damaging the impeller.
- If the pump fails to operate, disconnect from mains supply. Remove the base and gently turn
the impeller using a screwdriver. Check for obstruction in the impeller, i.e. stones/gravel etc.
- The float switch fitted to the pump is NOT suitable for continuous use as an ON/OFF switch.
- If the power cable becomes damaged it must be changed by the manufacturer or it’s service
agents.
IMPORTANT: Any pump returned to Draper Tools Limited under warranty must be clean. If a pump
is received that has NOT been cleaned, it will be returned to you at your cost.
Make sure the power supply information on the machine’s rating plate are compatible with the
power supply you intend to connect it to.
THE FOLLOWING ADDITIONAL INSTRUCTIONS MUST BE FOLLOWED AT ALL TIMES.
FAILURE TO DO SO COULD INVALIDATE THE GUARANTEE OF THIS SUBMERSIBLE WATER
PUMP.
1. The float switch must be clamped in position using cable clamp recess.
2. Clean water pumps are not suitable for use in dirty water.
3. These water pumps are designed for pumping water only.
The addition of any chemicals, chlorine or additives to the water could damage the pump, this
would be considered misuse and would not be covered under warranty.
4. When using clean water pumps in a pond or where there is gravel, mud, leaves, etc.
NOTE: The pump, should be suspended using a rope or chain or stood on a brick to prevent
any gravel, etc., being sucked into the pump.
5. If the pump fails to operate, disconnect from mains supply. Remove output elbow and turn the
impeller using a screwdriver or finger. Check for obstruction in the impeller, i.e. stones/gravel,
etc.
6. The float switch fitted to this pump is not suitable for continuous use as an on/off switch.
IMPORTANT: ANY PUMP RETURNED TO DRAPER TOOLS UNDER WARRANTY MUST BE
CLEAN. IF A PUMP IS RECEIVED THAT IS NOT, OR HAS NOT BEEN CLEANED, IT WILL BE
RETURNED TO YOU AT YOUR COST.
- 8 -
Loading...
