INSTRUCTIONS FOR

Face

Protection

Stock Nos.82480/82481 - FFP1
82561/82562 - FFP1
82563/82564 - FFP1

IMPORTANT: PLEASE READ THESE INSTRUCTIONS

82482/82483 - FFP2

CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE

82484/82485 - FFP2
82486 - FFP2
82565/82566 - FFP2
82487/82488 - FFP3
82489 - FFP3
82567/82569 - FFP3

These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.

This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.

AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools policy

of continuous improvement determines the right to make modifications without prior warning.

OF THIS PRODUCT.

EN 149:2001+A1:2009

GENERAL INFORMATION

1. TITLE PAGE

1.1 INTRODUCTION:

USER MANUAL FOR:

FACE PROTECTION

Stock nos. 82480/82481, 82482/82483, 82484/82485, 82486, 82487/82488, 82489, 82561/82562,
82563/82564, 82565/82566, 82567/82569

1.2 REVISIONS:

Date first published August 2015

As our user manuals are continually updated, users should make sure that they use the very
latest version.

Downloads are available from: http://www.drapertools.com/b2c/b2cmanuals.pgm

DRAPER TOOLS LIMITED WEBSITE: www.drapertools.com

HURSLEY ROAD PRODUCT HELPLINE: [phone]

CHANDLER’S FORD GENERAL FAX: [phone]

EASTLEIGH

HAMPSHIRE

SO53 1YF

UK

1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:

WARNING! Information that draws attention to the risk of injury or death.

CAUTION! Information that draws attention to the risk of damage to the product or

surroundings.

1.4 COPYRIGHT © NOTICE:

Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal & educational use only.

Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other

form or means without written permission from Draper Tools Limited.

In all cases this copyright notice must remain intact.

2. CONTENTS

2.1 CONTENTS
Page content

1 TITLE PAGE

1.1 INTRODUCTION ...............................................................................................2

1.2 REVISION HISTORY........................................................................................... 2

1.3 UNDERSTANDING THIS MANUAL ..................................................................2

1.4 COPYRIGHT NOTICE .........................................................................................2

2 CONTENTS

2.1 CONTENTS ........................................................................................................3

3. HEALTH & SAFETY INFORMATION

3.1 APPLICATIONS ..................................................................................................4

4. FITTING INSTRUCTIONS

4.1 CHECK PRIOR TO USE ......................................................................................4

4.2 FITTING INSTRUCTIONS....................................................................................5

5. EXPLANATION OF SYMBOLS .............................................................................................5

Page

3

3. HEALTH & SAFETY INFORMATION

IMPORTANT: EN149:2001+A1:2009 single-use respirators against solid and
liquid aerosols are classified according to one of three categories - FFP1,
FFP2 and FFP3.

Before reading the following information, please check the category to
which the respirator belongs - this is indicated on the packaging and on
the respirator.

3.1 APPLICATIONS

• FFP1: Protection against non-toxic solid and liquid

• FFP2: Protection against non-toxic and low-to-average

• FFP3: Protection against non-toxic, low-to-average

• CHARCOAL FILTERS: 82484/82485 and 82561/82562 include charcoal

*NOTE: .noitartnecnoC elbissimdA mumixaM = CAM

aerosols (e.g. oil-mists) in concentrations up to
4 x MAC/OEL/TLV, [i.e. NPF = 4 ] or 4 x WEL,
[i.e. APF = 4].

toxicity solid and liquid aerosols (e.g. oil-mists) in
concentrations up to 12 x MAC/OEL/TLV,
[i.e. NPF = 12] or 10 x WEL, [i.e. APF = 10].

toxicity and high toxicity solid and liquid aerosols
(e.g. oil-mists) in concentrations up to 50 x
MAC/OEL/TLV,
[i.e. NPF = 50] or 20 x WEL, [i.e. APF = 20].

filters that offer added comfort by eliminating
fumes when welding or decorating respectively.

OEL = Occupational Exposure Limit.

.eulaV timiL dlohserhT = VLT

.rotcaF noitcetorP lanimoN = FPN

.timiL erusopxE ecalpkroW = LEW
.rotcaF noitcetorP dengissA = FPA

4. FITTING INSTRUCTIONS

Clear vision

Low profile design lets you see
where you are going and what
you are doing. Glasses or safety
goggles can be worn without
affecting vision.

Contour fit

Soft metal nose piece adjusts
closely over bridge of nose.
Non-woven filter material fits
comfortably over facial features.

Easy breathing/speaking

Lightweight

Maintenance free

After use dispose of
it safely.

4.1 CHECK PRIOR TO USE

Inspect respirator, including any component parts, for holes, tears or
damage prior to use.

Should any damage be identified, DO NO USE IT. Get a new one.

4.2 FITTING INSTRUCTIONS

1. Hold the respirator in hand with the
nosepiece at your fingertips.
Allow headbands to hang freely below
hand.

2. Cup the respirator firmly against your
face with the nosepiece on the bridge
of your nose.

3. Stretch and pull the lower headband
over the head and position below your
ears. Stretch and pull the top headband
on the back of your head above your
ears.

* Respirators with adjustable headbands

only:
while maintaining the position of the
respirator, adjust tension by pulling lab
of each headband. (Tension may be
decreased by pushing out the back of
the buckle.)

4. Press soft nosepiece to conform snugly
around the nose.

5. (a) To test fit for respirator without

exhalation valve:
Cup both hands over the respirator
and exhale vigorously.

(b) To test fit for respirator with

exhalation valve:
Cup both hands over the respirator
and inhale sharply.

A negative pressure should be felt inside

respirator. If air flows around your nose,
tighten the nosepiece. If air leaks
around the edges, reposition the
headband for better fit.

*NOTE: Change respirator immediately if breathing becomes difficult or
respirator becomes damaged or distorted, or a proper face fit can not be
maintained.

Careful observance of these instructions is an important step in safe
respirator use.

WARNING:

1. Failure to follow all instructions and limitations on the use of this
product could reduce the effectiveness of respirator and result in
sickness or death.

2. A properly selected respirator is essential to protect your health.
Before using this respirator, consult an Industrial Hygienist or
Occupational Safety Professional to determine the suitability for your
intended use.

3. This product does not supply oxygen. Use only in adequately
ventilated areas containing sufficient oxygen to support life. Do not
use this respirator when oxygen concentration is less than 19%

4. Do not use when concentrations of contaminants are immediately
dangerous to health or life.

5. Do not use in explosive atmospheres.

6. Leave work area immediately and return to fresh air if (a) breathing
becomes difficult, or (b) dizziness or other distress occurs.

7. Facial hairs or beards and certain facial characteristics may reduce the
effectiveness of this respirator.

8. Never alter or modify this respirator in any way.

9. Only for single shift use. No maintenance necessary. Discard the used
respirator after single shift use.

10. Keep respirators in the display box away from direct sunlight until use.

5. EXPLANATION OF SYMBOLS

This respirator is limited to
single shift use only (with a
maximum of 8 hours) and
shall not be re-used,

This respirator passes the
optional Dolomite clogging
test for more comfortable
breathing.

-5°C

<70%

yyyy/mm

See user information

+50°C

Temperature range of
storage condition.

Maximum relative humidity of storage condition.

End of shelf life. yyyy = Year; mm = Month.

NR

D

54
