Draper Tools 75442 Instructions

ORIGINAL LANGUAGE



3-IN-1 WET & DRY

VACUUM CLE ANER

WITH SHAMPOO VALETING

75442

These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these instructions
before assembling, operating or maintaining this product.

This manual has been compiled by Draper Tools describing the purpose for which the product has been designed,
and contains all the necessary information to ensure its correct and safe use. By following all the general safety
instructions contained in this manual, it will ensure both product and operator safety, together with longer life of the
product itself.

All photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.

Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.

1. INTRODUCTION



1.1 SCOPE

This machine is designed to pick up both wet and dry
material with the added facility of shampooing.

Part of our core range, this product is suitable for
enthusiasts and trades persons alike. Any application
other than that it was intended for, is considered misuse.

This product is not a toy and must not be used by
children or any person with reduced physical, sensory or
mental capabilities or lack of experience and knowledge,
or people unfamiliar with these instructions.

Local regulations may restrict the age of the operator.

WEEE –
Waste Electrical & Electronic Equipment.

Do not dispose of Waste Electrical & Electronic
Equipment in with domestic rubbish.

Class II construction
(Double insulated).

UK Conformity Assessed.

European conformity.

1.2 UNDERSTANDING THIS MANUALS
SAFETY CONTENT:

Warning! – Information that draws attention to the

risk of injury or death.

Caution! – Information that draws attention to the risk of
damage to the product or surroundings.

1.3 EXPLANATION OF SYMBOLS

Before plugging in your tool, make sure the socket
voltage matches that on the product plate. If the socket
voltage does not match that shown on the type plate, it
can result in a serious hazard and damage to your tool.

Important: Read instruction manuals

before operating and servicing this
equipment.

For indoor use.
Do not expose to rain.

Tank capacity

Motor capacity (Watts).

Rated voltage

Machine weight.

Hose diameter.

Fully approved power cable

2. SPECIFICATION



2.1 SPECIFICATION

Stock no ................................................................. 75442

Part no ..............................................................SWD1500

Motor:

Rated voltage ............................................ 230V~

Rated frequency ...........................................50Hz

Rated input ................................................1500W

Insulation class ............ Class II (double insulated)

Maximum vacuum pressure ................. 18Kpa (180mbar)

Maximum air flow ............................................... 32L/sec

Tank capacity - liquid ................................................. 20L

Fluid capacity ............................................................ 13L

Shampoo tank volume ................................................ 4L

Sound pressure level...........................................75dB(A)

Dimensions (D × W × H) ..... 400mm × 450mm × 560mm

Machine weight (net) ............................................. 12.5kg

3. HEALTH AND SAFETY
INFORMATION

3.1 GENERAL SAFETY
INSTRUCTIONS FOR POWER TOOL
USE

Warning! Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below

may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future
reference.

The term “power tools” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.

1) Work area safety

a) Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

b) Do not operate power tools in explosive

– 2 –– 3



atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

c) Keep children and bystanders away while

operating a power tool. Distractions can cause
you to lose control.

2) Electrical safety

a) Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will

reduce risk of electric shock.

b) Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of

electric shock if your body is earthed or
grounded.

c) Do not expose power tools to rain or wet

conditions. Water entering a power tool will
increase the risk of electric shock.

d) Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled

cords increase the risk of electric shock.

e) When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk
of electric shock.

f) If operating a power tool in a damp location is

unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD

reduces the risk of electric shock.

3) Personal safety

a) Stay alert, watch what you are doing and use

common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or
medication. A moment of inattention while

operating power tools may result in serious
personal injury.

b) Use personal protective equipment Always

wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat
or hearing protection use for appropriate
conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the

switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools

with your finger on the switch or energising power
tools that have the switch on invites accidents.

d) Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.

e) Do not overreach. Keep proper footing and

balance at all times. This enables better control
of the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or

jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or

long hair can be caught in moving parts.

g) If devices are provided for the connection of

dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce

dust-related hazards.

h) Do not let familiarity gained from frequent use

of tools allow you to become complacent and
ignore tool safety principles. A careless action

can cause severe injury within a fraction of a
second.

4) Power tool use and care

a) Do not force the power tool. Use the correct

power tool for your application. The correct

power tool will do the job better and safer at the
rate for which it was designed.

b) Do not use the power tool if the switch does

not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous
and must be repaired.

c) Disconnect the plug from the power source

and/or remove the battery pack, if detachable,
from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such preventive safety measures

reduce the risk of starting the power tool
accidentally.

d) Store idle power tools out of the reach of

children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are

dangerous in the hands of untrained users.

e) Maintain power tools and accessories. Check

for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly

maintained power tools.

f) Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits

etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the

power tool for operations different from those
intended could result in a hazardous situation.

h) Keep handles and grasping surfaces dry,

clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for

–

safe handling and control of the tool in
unexpected situations.

5) Service

a) Have your power tool serviced by a qualified

repair person using only identical
replacements parts. This will ensure that the

safety of the power tool is maintained.

3.2 RESIDUAL RISK

Important: Although the safety instructions and

operating manuals for our tools contain extensive
instructions of safe working with power tools, every
power tool involves a certain residual risk which can not
be completely excluded by safety mechanisms. Power
tools must therefore always be operated with caution!

3.3 CONNECTION TO THE POWER
SUPPLY

Caution: Risk of electric shock. Do not open.

This appliance is supplied with an approved plug and
cable for your safety.

Never use a damaged or incomplete plug.

This appliance is Class II
connection to a power supply matching that detailed on
the rating label and compatible with the plug fitted.

Carefully select an extension lead. Some machines are
not suitable for use with extension leads. If the tool is
designed for use outdoors, only use an extension lead
suitable for that environment in conjunction with an RCD
adaptor. When using an extension lead, select one
capable of handling the current (amps) drawn by the
machine in use. Ensure the cable is fully unwound
regardless of the distance between the power supply
and the tool. Excess current (amps) and a coiled
extension lead will cause the cable to heat up and can
result in fire.

If an extension lead is required, use an approved and
compatible lead rated for this appliance. Follow all the
instructions supplied with the extension lead.

†Double insulated
connection as supplementary insulation is applied to the
basic insulation to protect against electric shock in the
event of failure of the basic insulation.

Important: If using an extension lead, follow the
instructions that came with your lead regarding
maximum load while cable is wound. If in doubt, ensure
that the entire cable is unwound. Using a coiled
extension lead will generate heat which could melt the
lead and cause a fire.

† and is designed for

: This product requires no earth

against the parts shown in Fig A. If any part is damaged
or missing, please contact the Draper Help Line (see
back page). Do not attempt to use the product!

The packaging material should be retained during the
warranty period, in case the product needs to be
returned for repair.

Warning!

• Some of the packaging materials may be harmful to

children. Do not leave any of these materials in
reach of children.

• If any of the packaging is to be thrown away, make

sure they are disposed of correctly, according to local
regulations.

4. UNPACKING AND
CHECKING

4.1 PACKAGING

Carefully remove the product from the packaging and
examine it for any sign of damage. Check contents



– 4 –

5. IDENTIFICATION – FIG.A

(18)

(5)

(19)

(2)
(1)

(20)

(17)

(4)

(3)



(12)

(13)

(14)

(8)

(10)

(9)

(16)

(11)

(6)

(7)

(24)

(23)

(1) Tank.
(2) Shampoo delivery socket.
(3) Vacuum port.
(4) Main vacuum/shampoo

selection.

(5) Power on/off switch.
(6) Tank catches × 2.
(7) Mains plug and cable.
(8) Filter housing.
(9) Attachment tool storage.

FIG.A

Note: For details of our full range of accessories and consumables, please visit drapertools.com

(15)

(10) Shampoo inlet hose and filter.
(11) Shampoo tank.
(12) Carry handle.
(13) Push handle.
(14) Handle fixing knob.
(15) Castors × 2.
(16) Rear wheels × 2.
(17) Flexible vacuum hose.
(18) Shampoo/vacuum control

handle grip.

(22)

(25)

(21)

(19) Retractable extension tube.
(20) Shampoo delivery hose.
(21) Vacuum attachment for floors

and carpets.

(22) Small fluid nozzle for sofa and

upholstery.

(23) Large fluid nozzle.
(24) Crevice attachment.
(25) Round brush attachment for

delicate surfaces.

– 5 –

(18)

(17) (29) (20) (19)

(13)

(27)

(23.1)

(10)

(22.1)

(23)

(22)(11)

(10) Shampoo inlet hose and filter.
(11) Shampoo tank.
(13) Push handle.
(14) Handle fixing knob.
(15) Castors × 2.
(16) Rear wheels × 2.
(17) Flexible vacuum hose.
(18) Shampoo/vacuum control

handle grip.

(19) Retractable extension tube.

FIG.B

(25)

(21)

(15)

(24)

(20) Shampoo delivery hose (main).
(21) Vacuum attachment for floors

and carpets.

(22) Small fluid nozzle for sofa and

upholstery.

(22.1) Shampoo delivery hose (small

fluid nozzle).

(23) Large fluid nozzle.
(23.1) Shampoo delivery hose (large

fluid nozzle).

(24) Crevice nozzle.

(16)

(28)

(16)

(26)

(33)

(31)

(32)

(30)

(25) Brush attachment for delicate

surfaces.

(26) Paper dust bag.
(27) Cartridge filter.
(28) Anti-foam filter.
(29) Hose clips.
(30) Wheel locking pins × 2.
(31) Wheel hub caps × 2.
(32) Wheel washers × 4.
(33) Wheel axle.

6. INITIAL MACHINE
ASSEMBLY

6.1 FITTING THE PUSH HANDLE

– FIGS. 1 - 2

Note: The procedure for attaching the push handle to

the machine must be performed before the fitting of the
2 rear wheels.

− Assemble the main hand grip part of the push handle

(13.1) with the two uprights as (13.2) shown.



(14)

(13.3)

(13.2)

(13.4)

FIG.

1

− Making sure it is the correct way around (see Fig. A),
slide the completed handle assembly through the
holes in the tool storage section at the rear of the
tank (9) and then further down into the slots located
in the base of the vacuum cleaner (1.1), pressing
down firmly until it snap-fits into place.

– 6 –

(13.1)

(14)

(9)

(13)

(16.1)

FIG.

2

− To secure on each side, tighten the supplied screw
through the hole situated inside the rear wheel
housing (16.1) and on through into the hole in the
tubular frame of the handle (13).

(1.1)

6.2 FITTING THE REAR WHEELS
– FIG. 3

− Using one end of the wheel axle (33), pass one of
the 2 wheel locking pins (30) through the hole at the
end of the axle. Assemble making sure that it is the
correct way around as shown.

− Pass the opposite end of the axle (33) through the
open end of the moulded bracket situated inside the
wheel housing (16.2), and out through to the other
side of the machine.

− Repeat assembly on the opposite side. Snap-fit the 2
wheel hub caps (31)in place to complete the rear
wheel assembly.

(33)

(32)

(15)

FIG.

4

7. VACUUMING DRY DUST
AND DIRT

7.1 CHANGING SETUP FROM WET TO

DRY VACUUMING – FIGS. 5 - 6

Empty the tank and dispose of any liquid which may
have been picked up previously.

Remove the anti-foam filter (28) (if fitted) and fit cartidge
filter (27).

(28)



(32)

(16.2)

(16)

FIG.

(30)

3

6.3 FITTING THE CASTORS – FIG. 4

− Snap-fit the 2 castors (15) into the holes located on

the machine base to complete the assembly.

FIG.

5

(27)

FIG.

6

Note: The cleaner comes complete with a cleanable
cartridge filter (27). The cartridge filter should be
cleaned using a soft brush at regular intervals. This will

– 7 –– 8

ensure a longer service life and higher suction power. If
the cartridge filter is not used when vacuuming dry dust
and dirt the motor wil be damaged.

7.2 ATTACHING THE PAPER DUST
BAG – FIG. 7

When using the paper dust bag (26), dirt can be
removed more hygienically and the life of the cartridge
filter will be prolonged.
The paper dust bag NEVER replaces the cartridge filter
but, the filter cartridge can be used without the paper
dust bag.

Note: As suction power decreases, replace the paper
dust bag with a new one.

Place housing on top and secure using the two tank
catches (6).

(26)

FIG.

7

(6)

The vacuum attachment for floors and carpets (21) can
be used on hard floors - parquet, cork, vinyl, ceramic,
etc. Any of the other attachments may be used
depending upon the specific application. They are
attached with a tight push fit.

(19)

(21)

FIG.

9

7.4 SWITCHING ON – FIGS. 10 – 11

Connect the vacuum cleaner to the power supply and
switch the vacuum cleaner ‘on’ by pushing the power on/
off switch (5).

(5)

7.3 CONNECTING ATTACHMENTS –
FIGS. 8 - 9

Insert the the head of flexible vacuum hose (17) into the
shampoo/vacuum control handle grip (18), and twist to
lock in place.

The grip provides a suction power regulating device
(18.1). To obtain full suction power the regulator should
be closed.

The grip also incorporates a remote on/off control (18.2)
to operate the machine for shampoo/vacuuming
operations.

(18.1) (18.2)

FIG.

(17)

8

(18)

FIG.

10

− Use the machine in vacuum only mode by pressing
the button identified by the symbol below situated on
the front panel of the machine (4.1).

Note: After selecting ‘on’ from the main switch, vacuum
cleaning mode can be also selected from the button
(18.1) located on the remote control handle grip.

Vacuum cleaning selection.

–

(18.1)

become noisier, at this point turn off and empty the tank.

8.3 FITTING THE LARGE FLUID
NOZZLE – FIG. 13

Fit the large fluid nozzle (23) to the retractable extension
tube (19).

(4.1)

FIG.

11

Attention: EXPLOSION AND FIRE HAZARD! Never
vacuum asbestos, inflammable fluids, such as petrol, oil,
solvents, etc. Do not work near inflammable fluids or
gas. Never vacuum fluids or material hotter than 60ºC,
such as burning cigarettes, ashes, glowing coals, etc.

If cable becomes damaged replace immediately.

Always keep the filter cartridge clean; for maximum
performance.

8. VACUUMING FLUIDS



8.1 EMPTY TANK

If fitted, remove the paper dust bag and empty the tank
to dispose of any dirt/dust which may have been picked
up previously. If in place, the cartridge filter must now be
removed by turning the fixing knob anti-clockwise and
sliding off the motor head.

8.2 FITTING THE ANTI-FOAM FILTER
– FIG. 12

Slide the filter (28) over the float cage.

NEVER VACUUM DRY DUST AND DIRT WITH THIS
FILTER FITTED AS IT WILL PROVIDE LITTLE OR NO
PROTECTION RESULTING IN MOTOR DAMAGE

(28)

(19)

(23)

FIG.

13

8.4 SWITCH ON

Connect the vacuum cleaner to the power supply and
switch the vacuum cleaner ‘on’ by pushing the power
‘on/off’ switch (5).

− Use the machine in vacuum only mode by pressing
the button identified by the symbol below situated on
the front panel of the machine (4.1).

Vacuum cleaning selection.

Note: After selecting ‘on’ from the main switch, vacuum
cleaning mode can be also selected using the remote
control located on the shampoo/vacuum control handle
grip.

8.5 WATER ON LARGE AREAS
– FIG. 14

Note: The large fluid nozzle (23) should be used on

floors and other flat surface areas where the water to be
picked up has dispersed over a large area but is only
shallow.

FIG.

12

Note: When the fluids have reached the highest
permissible level in the tank, the float regulator will cover
the motor filter causing the motor to work harder, it will

– 9 –

(23)

(2)

(20.1)

(20.2)

FIG.

14

The crevice nozzle attachment (24) should be used
when the water level is too high to use the large fluid
nozzle.

Note: To ensure the air flow is adequate we recommend
that the end of the nozzle is not totally immersed.

9. INJECTION/EXTRACTION
SHAMPOO

9.1 ATTACH THE SHAMPOO DELIVERY

HOSE– FIGS. 15– 16

− Fix the shampoo delivery hose (20) to the vacuum
hose (17) using the clips (29) supplied.

− Fix the large plug end of the shampoo delivery hose
(20.1) into the shampoo delivery socket (2) located
on the front of the motor housing.

− Fix the other end of the shampoo delivery hose with
the screw fitting (20.2) onto the shampoo/vacuum
control handle grip.

(17)

(29)

(20)



FIG.

16

9.2 FILL THE SHAMPOO TANK
– FIG. 17

− Fill the shampoo tank (11) with as much correctly

diluted anti-foam shampoo (Draper Stock No.28801)
as required. Always follow the shampoo
manufacturer’s direction ratios. The shampoo tank
has a capacity of approximately 4 litres.

(11)

FIG.

17

− Fit the shampoo supply tank into its housing on the
base of the machine, situated to the rear.

9.3 CONNECTING SHAMPOO INLET
HOSE AND FILTER – FIGS. 18 – 19

− Place the sponge filter end of the shampoo inlet hose

(10) into the shampoo tank (11) and push fit the cap
(10.1) onto the shampoo tank to close.

− Connect the plastic plug on the other end of the
shampoo inlet hose directly into the shampoo
delivery inlet socket (10.2) on the side of the motor
housing.

FIG.

15

– 10 –

Note: Follow the same procedure above when using the
shampoo upholstery attachment.

(23.1)

(10.1)

FIG.

FIG.

(10)

18

(10.2)

19

(11)

(10)

9.4 ATTACHING THE LARGE FLUID
NOZZLE – FIGS. 20 – 21

− Set up the vacuum cleaner for vacuuming fluids as
section 10.

− If not already fitted, follow the procedure listed above
in 9.1 for attaching the main shampoo delivery hose.

(23.4) (20.2)

FIG.

20

− Attach the shampoo delivery hose (23.1) to the large
fluid nozzle (23) by slotting the spray end (23.2) into
the plastic bracket (23.3) located on the underside of
the nozzle.

− Connect the other screw fitting end of large fluid
delivery hose (23.4) to the shampoo/vacuum control
handle grip.

(23.2)

(23.3)

(23)

FIG.

21

9.5 ATTACHING THE SMALL FLUID
NOZZLE – FIG. 22

The small fluid nozzle (22) connects directly onto the
shampoo/vacuum control handle grip (18) without need
for the retractable extension tube.

(18)

(22.1)

(22.2)

(22)

FIG.

22

− Set up the vacuum cleaner for vacuuming fluids as
section 8.

− If not already fitted, follow the procedure listed in
chapter 11.1 for attaching the main shampoo delivery
hose (20) to the flexible vacuum hose (17) plus
connections to vacuum cleaner and shampoo/
vacuum control handle grip (18).

Note: If the machine is or has been used in conjunction
with the large fluid nozzle (23) and retractable extension
tube (19), remove these and also the large fluid
shampoo delivery hose (23.1) where it joins the
shampoo/vacuum control handle grip by unscrewing and
removing the fitting where it joins onto the handle grip.

− Connect up the small fluid shampoo delivery hose

(22.1) onto the shampoo/vacuum control handle grip
(18) by screwing on the attached fitting (22.2), as

shown in fig. 22.

9.6 SWITCH ON – FIGS. – 23 – 24

Connect the vacuum cleaner to the power supply and

– 11 –

switch the vacuum cleaner ‘on’ by pushing the power on/
off switch (5).

− Use the machine in shampoo mode by pressing the
button identified by the symbol below; this can be
achieved by pressing the button located on the front
of the motor housing (4.2), or preferably by using the
shampoo (18.2) and vacuum button (18.1) located on
the remote control handle grip (18), making for easier
operation when frequently switching between
shampoo and vacuum modes.

Vacuum cleaning selection.

Note: Use rubber sleeve (23.2) for use on hard floors.

Shampoo selection.

HARD FLOORS CARPETS

(23) (23)

(23.2)

for maintenance operations and will keep your tools in
good working condition.

The motor must be correctly ventilated during the tools
operation. For this reason avoid blocking the air inlets.

If the replacement of the supply cord is necessary, this
has to be done by the manufacturer or his agent in order
to avoid a safety hazard.

Remove the plug from the socket before carrying out
adjustment, servicing or maintenance.

• Empty tank regularly. Never leave fluids in the
receptacle as these could damage the material over
a period of time.

• After having picked up fluids, dry extension tubes,
hose and motor parts by running the vacuum cleaner
for a few minutes, AFTER HAVING EMPTIED THE
TANK.

• Always keep spare dust bags and cartridge filters so
that the vacuum cleaner is always ready for use.

• Regularly clean and wash the motor filter located
inside the fluid float cage.

• Use of paper dust bags - as suction pressure
decreases, replace the paper dustbag with a new
one.

• Clean the cartridge filter periodically with a soft
brush. This will prolong the life of the filter.

Note: The filter must be dry before re-using.

FIG.

23

Note: Always clean a small hidden piece of carpet/
material that you are going to clean to check the
fastness of the colour.

(22)

FIG.

24

10. MAINTENANCE



10.1 BASIC MAINTENANCE

Note: Remove the plug from the socket before carrying

out adjustment, servicing or maintenance.

Regular inspection and cleaning reduces the necessity

11. WARRANTY

11.1 WARRANTY

Draper tools have been carefully tested and inspected
before shipment and are guaranteed to be free from
defective materials and workmanship.

Should the tool develop a fault, please return the
complete tool to your nearest distributor or contact:

Draper Tools Limited

UK: Chandler’s Ford, Eastleigh, Hampshire,
SO53 1YF. England.

EU: Oude Graaf 8, 6002 NL Weert (NL).

Telephone Sales Desk: [phone] or:

Product Helpline [phone].

A proof of purchase must be provided.

If upon inspection it is found that the fault occurring is
due to defective materials or workmanship, repairs will
be carried out free of charge. This warranty period
covering parts/labour is 24 months from the date of
purchase except where tools are hired out when the
warranty period is 90 days from the date of purchase.
This warranty does not apply to any consumable parts,
any type of battery or normal wear and tear, nor does it
cover any damage caused by misuse, careless or
unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the
authorised Draper warranty repair agent.

– 12 –



Note: If the tool is found not to be within the terms of
warranty, repairs and carriage charges will be quoted
and made accordingly.

This warranty applies in lieu of any other warranty
expressed or implied and variations of its terms are not
authorised.

Your Draper warranty is not effective unless you can
produce upon request a dated receipt or invoice to verify
your proof of purchase within the warranty period.

Please note that this warranty is an additional benefit
and does not affect your statutory rights.

Draper Tools Limited.

12. DISPOSAL



12.1 DISPOSAL

– At the end of the machine’s working life, or when it

can no longer be repaired, ensure that it is disposed
of according to national regulations.

– Contact your local authority for details of collection

schemes in your area.

In all circumstances:

• Do not dispose of power tools with
domestic waste.

• Do not incinerate.

• Do not dispose of WEEE* as unsorted
municipal waste.

* Waste Electrical & Electronic Equipment.

– 13 –
