3.7V
INSPECTION LAMP
71145
IMPORTANT: Please read these instructions carefully to ensure the safe and effective use of this product and save
these instructions for future reference. This manual has been compiled by Draper Tools and is an integrated part of the
product with which it is enclosed and should be kept with it for future references.
This manual describes the purpose for which the product has been designed and contains all the necessary information
to ensure its correct and safe use. We recommend that this manual is read before any operation or, before performing
any kind of adjustment to the product and prior to any maintenance tasks. By following all the general
instructions contained in this manual, it will ensure both product and operator safety, together with longer life of the
product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the Draper Tools policy
of continuous improvement determines the right to make modifications without prior warning.
safety
1. TITLE PAGE
1.1 INTRODUCTION:
USER MANUAL FOR:
3.7V INSPECTION LAMP
Stock no. 71145.
Part no. RIL10.
1.2 REVISIONS:
Date first published March 2017
As our user manuals are continually updated, users should make sure that they use the
very latest version.
Downloads are available from: http://www.drapertools.com/manuals
DRAPER TOOLS LIMITED WEBSITE: drapertools.com
HURSLEY ROAD PRODUCT HELPLINE: +44 (0) 23 8049 4344
CHANDLER’S FORD GENERAL FAX: +44 (0) 23 8026 0784
EASTLEIGH
HAMPSHIRE
SO53 1YF
UK
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
WARNING! Information that draws attention to the risk of injury or death.
CAUTION! Information that draws attention to the risk of damage to the product or
surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other
form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
2
2. CONTENTS
2.1 CONTENTS
Page content
1 TITLE PAGE
1.1 INTRODUCTION ................................................................................................ 2
1.2 REVISION HISTORY .......................................................................................... 2
1.3 UNDERSTANDING THIS MANUAL ................................................................... 2
1.4 COPYRIGHT NOTICE ........................................................................................2
2 CONTENTS
2.1 CONTENTS ........................................................................................................ 3
3 GUARANTEE
3.1 GUARANTEE...................................................................................................... 4
4 INTRODUCTION
4.1 SCOPE................................................................................................................ 4
4.2 SPECIFICATION................................................................................................. 4
4.3 HANDLING & STORAGE.................................................................................... 4
5 HEALTH & SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS ................................................................ 4
5.2 CONNECTION TO THE POWER SUPPLY (CHARGER)................................... 5
6 IDENTIFICATION.............................................................................................................. 5
7 UNPACKING & CHECKING
7.1 PACKAGING....................................................................................................... 5
7.2 WHAT´S IN THE BOX?....................................................................................... 5
8 PREPARING THE INSPECTION LAMP
8.1 CHARGING......................................................................................................... 5
9 OPERATING THE INSPECTION LAMP
9.1 OPERATION....................................................................................................... 5
10 MAINTENANCE ................................................................................................................ 5
11 EXPLANATION OF SYMBOLS
11.1 EXPLANATION OF SYMBOLS...........................................................................5
12 DISPOSAL
12.1 DISPOSAL .......................................................................................................... 5
DECLARATION OF CONFORMITY............................................................................ ENCLOSED
.............................................................................. Page
3
3. GUARANTEE
3.1 GUARANTEE
Draper tools have been carefully tested and inspected before shipment and are guaranteed to be free
from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor or contact
Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: (023) 8049 4333 or Product Helpline (023) 8049 4344.
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or workmanship,
repairs will be carried out free of charge. This guarantee period covering parts/labour is 12 months
from the date of purchase except where tools are hired out when the guarantee period is 90 days
from the date of purchase. This guarantee does not apply to normal wear and tear, nor does it cover
any damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges will be
quoted and made accordingly.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms
are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the guarantee period.
Please note that this guarantee is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.
4. INTRODUCTION
4.1 SCOPE
10 SMD LED rechargeable inspection lamp, 10 LEDs to be used as an inspection lamp or 7 LEDs for
use as a torch. Magnets on the base and on the rear, two 360° swivel hooks. Base pivots 180°,
supplied with mains charger and 12V charger.
4.2 SPECIFICATION
Stock no........................................................................................................................................ 71145
Part no...........................................................................................................................................RIL10
SMD LED...........................................................................................................................................5W
Lumins:
High ..............................................................................................................................................385
Low............................................................................................................................................... 190
Battery:
Type .......................................................................................................................................... Li-ion
Rated Voltage ............................................................................................................................ 3.7V
Rating ...................................................................................................................................... 1.8Ah
Charging time ..............................................................................................................4 hrs (approx.)
Charger:
Rated Voltage ......................................................................................................................... 230V~
Rated Frequency ...................................................................................................................... 50Hz
Rated Power Input ....................................................................................................................... 9W
Rated D.C. Output Voltage .................................................................................................. 3.7V DC
Rated D.C. Output Current .................................................................................................. 1000mA
Construction ............................................................................................................................. Class II
Lamp operating time:
7 LED torch...............................................................................................................10 hrs (approx.).
10 SMD LED inspection lamp
low setting............................................................................................................4.5 hrs (approx.).
high setting .............................................................................................................3 hrs (approx.).
4.3 HANDLING & STORAGE
Do not drop the inspection lamp as this can damage and shorten the life span of the unit.
Store in a dry location as damp conditions can damage the inspection lamp.
Charging on a regular basses in advised to prolong the life of the battery cells.
5. HEALTH & SAFETY INFORMATION
5.1 GENERAL SAFETY
INSTRUCTIONS
General Power Tools Safety Warnings
WARNING: Read all instructions. Failure to follow
all instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains
operated (corded) power tool or battery operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2) Electrical Safety
a) Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electrical shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal Safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
4
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust related hazards.
4) Power Tool Use And Care
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tools
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations
different from intended could result in a hazardous
situation.
5) Battery tool use and care
a. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
b. Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
c. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a fire.
d. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6) Service
a. Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is
maintained.
5.2 CONNECTION TO THE POWER
SUPPLY (CHARGER)
Make sure the power supply information on the machine’s
rating plate are compatible with the power supply you
intend to connect it to.
This lamp comes supplied with a UK standard 3 pin
transformer. It is designed for connection to a domestic
power supply rated at 230V AC.
6. IDENTIFICATION
It is Class 2 (double insulated); is designed for connection
to a power supply matching that detailed on the rating label
and compatible with the plug fitted.
If an extension lead is required, use an approved and
compatible lead rated for this appliance. Follow all the
instruction supplied with the extension lead.
This product requires no earth connection as
supplementary insulation is applied to the basic insulation
to protect against electric shock in the event of failure of
the basic insulation.
(1)
(2)
(3)
(4)
(5)
(1) 7 LED torch
(2) 10 SMD LED
inspection lamp
(3) Change indicator
(4) On/off switch
(5) 180° jointed body
(6)
(6) 360° swivel hooks
(7) Magnet rear
(8) Charger socket
7.2 WHAT´S IN THE BOX?
As well as the product; there are several parts not
fitted or attached to it.
(7)
(8)
(9)
(10)
(9) Magnetic base
(10) 230V charger
(11) 12V DC charger
(12) Micro USB
charging lead
(11)
(12)
7. UNPACKING & CHECKING
7.1 PACKAGING
Carefully remove the product from the packaging and examine it for any sign of damage caused
during shipping. Lay the contents out and check them. If any part is damaged or missing, do not
attempt to use the tool and contact the Draper Helpline immediately (see back page for details).
Retain the packaging material at least during the guarantee period: in case the machine needs to be
returned for repair.
Warning! Some of the packaging materials used may be harmful to children, keep them out of reach
from children.
Disposed of any packaging correctly and according to local regulations.
8. PREPARING THE INSPECTION LAMP
8.1 CHARGING - FIG.1
Connect the charger into the charging socket (8), which is
located on the rear of inspection lamp. Connect the 230V charger
or 12V DC charger to a power supply and turn it on.
The charging indicator LED (3) will illuminate to show the
charging has started.
NOTE: The charging indicator remains lit and does not extinguish
when the lamp is fully charged.
Disconnect the charger from the inspection lamp when it has been
charged for a sufficient time.
(3)
FIG.1
9. OPERATING THE INSPECTION LAMP
9.1 OPERATION - FIG.2
CAUTION: Never shine the LED light directly into your or any one
elses eyes.
To run through the sequence of modes (10 SMD LEDs, 7 LEDs
and off) Press the on/off (4) button.
The lamp can be suspended and swivel 360° hooks (6) or the
magnets (7) and (9) located on the rear on base of the lamp.
10. MAINTENANCE
Keep the inspection lamp clean from dirt and grease, using a damp cloth.
Do not submerge in water.
(4)
FIG.2
11. EXPLANATION OF SYMBOLS
10.1 EXPLANATION OF SYMBOLS
Carefully remove the product from the packaging and examine it for any sign of damage
Class II construction
(Double insulated).
WEEE
Do not dispose of Waste Electrical &
Electronic Equipment in with
domestic rubbish
For indoor use only.
Do not expose to rain.
130°C
Non-Self-Resetting protective
device.
Short-circuit-proof safety isolating
transformer.
F
Polarity indication.
12. DISPOSAL
12.1 DISPOSAL
- At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is
disposed of according to national regulations.
- Contact your local authority for details of collection schemes in your area.
In all circumstances:
• Do not dispose of power tools with domestic waste.
• Do not incinerate.
• Do not abandon in the environment.
• Do not dispose of WEEE* as unsorted municipal waste.
* Waste Electrical & Electronic Equipment.
5
CONTACT US
Draper Tools Limited, Hursley Road,
Chandler's Ford, Eastleigh, Hampshire. SO53 1YF. U.K.
Helpline:
Sales Desk:
+44 (0) 23 8049 4344
+44 (0) 23 8049 4333
Internet: www.drapertools.com
E-mail: sales@drapertools.com
General Enquiries: (023) 8026 6355
Service/Warranty Repair Agent:
For aftersales servicing or warranty repairs, please contact the
Draper Tools Helpline for details of an agent in your local area.
YOUR DRAPER STOCKIST
©Published by Draper Tools Limited.
No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means,
electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
DBMC0217
Loading...
