EN
Original Instructions
Version 1
16” WALL
MOU NT ED
FAN
70975
1. Preface
EN
EN
These are the original product instructions. This
document is part of the product; retain it for the life
of the product, passing it on to subsequent holders.
Read this manual in full before attempting to
assemble, operate or maintain this product.
This Draper Tools manual describes the purpose
of the product and contains all the necessary
information to ensure its correct and safe use.
Following all the instructions and guidance in
this manual will ensure the safety of both the
product and the operator and increase the
lifespan of the product.
1.1 Product Reference
User Manual for: 230V Oscillating Wall Mounted
Fan with Remote Control, 16”/400mm, 3 Speed
Stock No: 70975
Part No: FAN7C
1.2 Revisions
Version 1: August 2022
First release
As our manuals are continually updated, always ensure
that the latest version is used.
Please visit drapertools.com/manuals for the latest
version of this manual and the associated parts list, if
applicable.
All photographs and drawings within this manual are
supplied by Draper Tools to help illustrate correct
operation of the product.
Every eort has been made to ensure the
information contained in this manual is accurate.
However, Draper Tools reserves the right to amend
this document without prior warning. Always use the
latest version of the product manual.
1.3 Understanding the Safety Content of
This Manual
WARNING!
in personal injury or death.
CAUTION! – Situations or actions that may result
in damage to the product or surroundings.
Important: – Information or instructions of particular
importance.
– Situations or actions that may result
1.4 Copyright © Notice
Copyright © Draper Tools Limited.
Permission is granted to reproduce this manual for
personal and educational use ONLY. Commercial
copying, redistribution, hiring or lending is strictly
prohibited.
No part of this manual may be stored in a retrieval system
or transmitted in any other form or means without written
permission from Draper Tools Limited.
In all cases, this copyright notice must remain intact.
2. Contents
1. Preface 2
1.1 Product Reference 2
1.2 Revisions 2
1.3 Understanding the Safety Content of This Manual 2
1.4 Copyright © Notice 2
2. Contents 3
3. Warranty 4
4. Product Introduction 5
4.1 Intended Use 5
4.2 Specication 5
5. Health and Safety Information 6
5.1 General Health and Safety Precautions For This Product 6
5.2 Battery Safety 7
5.3 Connection to the Power Supply 7
5.4 Connection to the Power Supply (Charger) 7
6. Identication and Unpacking 8
6.1 Product Overview 8
6.2 What’s in the Box? 9
6.3 Packaging 9
7. Operating Instructions 10
8. Installation Instructions 12
8.1 Installing the Fan Onto a Wall 12
8.2 Setting the Fan Tilt Angle 12
9 . Operating Instructions 13
9.1 Control Panel Overview 13
9.2 Power and Speed Selection 13
9.3 Oscillation 13
9.4 Fan Modes 14
9.5 Shutdown Timer 15
10 . The Remote Control 16
10.1 The Remote Control 16
10.2 Replacing the Batteries 16
10.3 Mode Selection 16
10.4 Setting the Timer 16
11 . Maintenance and Storage 17
12. Spares, Returns and Disposal 18
13. Explanation of Symbols 19
– 2 –
– 3 –
EN
3. Warranty
EN
4. Product Introduction
Draper Tools products are carefully tested and inspected
before shipment and are guaranteed to be free from
defective materials and workmanship.
Should the tool develop a fault, return the complete tool
to your nearest distributor or contact Draper Tools
directly. Contact information can be found at the back of
this manual.
Proof of purchase must be provided.
If, upon inspection, it is found that the fault occurring is
due to defective materials or workmanship, repairs will
be carried out free of charge. This warranty period covers
parts and labour for 12 months from the date of
purchase. Where tools have been hired out, the warranty
period covers 90 days from the date of purchase.
This warranty does not apply to any consumable parts,
batteries or normal wear and tear, nor does it cover any
damage caused by misuse, careless or unsafe handling,
alterations, accidents, or repairs attempted or made by
any personnel other than the authorised Draper Tools
repair agent.
In all cases, to make a claim for faulty workmanship or
materials within the standard warranty period, please
contact or return the product to the place of purchase.
Proof of purchase may be required.
If the place of purchase is no longer trading or if you
experience any diculties with your warranty, please
contact Customer Services with the product details and
your proof of purchase. Contact details can be found at
the back of this manual.
If the tool is not covered by the terms of this warranty,
repairs and carriage charges will be quoted and charged
accordingly.
This warranty supersedes any other guarantees
expressed or implied and variations of its terms are not
authorised.
Your Draper Tools guarantee is not eective until you can
produce, upon request, a dated receipt or invoice to
verify your purchase within the guarantee period.
Please note that this warranty is an additional benet
and does not aect your statutory rights.
Draper Tools Limited
4.1 Intended Use
This product is designed to improve air circulation in
enclosed spaces and to assist with lowering ambient
temperatures. This product is an oscillating fan intended for
wall mounting only and is supplied with a remote control.
Part of our core range, this product is suitable for regular
use by enthusiasts and tradespersons alike.
WARNING! This product is not a toy and
must be respected.
Read this manual in full before attempting to assemble,
operate or maintain the product and retain it for later use.
4.2 Specication
Stock No. 70975
Part No. FAN7C
Rated voltage: 220–240V
Rated frequency: 50Hz
Rated input: 45W
Fan speed:
Low: 1,050rpm
Medium: 1,150rpm
High: 1,250rpm
Variance: ±100rpm
Fan modes: 3
Blade assembly diameter: 330mm
Guard diameter: 410mm (16” )
3
Airow: 62m
Noise emissions: < 73dB(A)
Timer:
Max. duration: 7.5h
Intervals: 30min
Appliance class: Class II
Dimensions: W 430mm x H 575mm x D 345mm
Weight: 2.3kg
Batteries (remote): 2 x AAA (not supplied)
/min
– 4 –
– 5 –
EN
5. Health and Safety Information
EN
5. Health and Safety Information
Important: Read all Health and Safety instructions
before attempting to operate, maintain or repair this
product. Non-compliance with these instructions may
result in injury or damage to the user or the product.
5.1 General Health and Safety
Precautions For This Product
• Observe all standard safety precautions and good
practices when working with electrical equipment.
Important: DO NOT use this product if it is leaking or
damaged in any way. DO NOT attempt to disassemble
a damaged product; contact Draper Tools to discuss
repair and replacement options.
• Before every use, inspect the product for broken,
cracked, loose or corroded parts and leakages.
• This appliance can be used by children aged eight
years and above and by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards
involved.
– Children must not play with the appliance.
– Cleaning and user maintenance must not be
performed by children without supervision.
• DO NOT modify this product in any way and ONLY
use spare parts supplied by Draper Tools.
• This product is for indoor use ONLY.
WARNING! Risk of shock!
– DO NOT allow the fan to come into contact with
water or any other liquid.
– DO NOT use this fan in the vicinity of a bath,
shower, swimming pool or other body of water.
– DO NOT use the fan in wet environments.
– DO NOT touch the fan with wet hands.
• Observe all standard safety precautions and good
practices when working at heights when installing the
product onto a wall.
• Before installing the product onto a wall or surface,
check for active power lines and other hazards within
the wall.
• This product requires W 600 x H 600 x D 650mm of
space when installed.
• ALWAY S install the fan in its upright position.
• Ensure that the fan is not situated in the vicinity of
loose furnishings, clothing, curtains and other loose
items that could get sucked into the air inlet or jam
the fan blades.
• DO NOT install the fan in dusty environments.
– Dust may get caught in the airow and cause air
pollution or gather in and obstruct the fan motor.
• DO NOT install this product in the vicinity of gas
appliances, open ames, and cooling or heating
appliances.
• ALWAY S ensure that the fan is completely assembled
and mounted securely on the wall before switching it on.
• Ensure that the mains outlet to which the product is
connected is accessible at all times.
• Keep the power cable away from sources of heat,
sharp edges and oil.
• DO NOT run the power cable beneath a carpet or rug.
• If the supply cord is damaged, it must be replaced by
Draper Tools or its authorised service agent in order
to avoid a hazard.
• DO NOT carry the fan by the power cable or
disconnect it from a mains outlet by pulling on the
cable.
• DO NOT insert ngers or other foreign objects
through the grille and avoid contact with moving
parts.
• DO NOT attempt to touch the fan blades while they
are in motion.
• ALWAYS switch o the fan, disconnect it from mains
power and allow the fan blades to completely stop
before removing the grille or performing any cleaning
or maintenance or before moving the product.
• NEVER cover any part of the fan.
• Ensure that the air inlet is clear and unobstructed.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other device
that switches the fan on automatically as it may be
covered or positioned incorrectly when activated and
cause a hazard.
• DO NOT use this fan with an independent, externally
connected speed control device.
• DO NOT leave the fan running unattended.
5.2 Battery Safety
WARNING! ONLY power this product using the
battery type described. DO NOT use or charge
the battery if leakage is evident.
WARNING! NEVER charge non-rechargeable
or damaged batteries.
• DO NOT short-circuit the battery by connecting the
positive and negative terminals while it is outside of the
product.
– Keep the battery away from metallic objects that may
inadvertently allow connection of the terminals.
• DO NOT open, crush or burn the battery as this may
release potentially harmful chemicals.
• DO NOT expose the battery to temperatures greater
than 50°C.
• DO NOT attempt to charge batteries that exhibit a
temperature that is not between 5 and 30°C.
– Allow batteries that are too hot or too cold to
normalise before charging.
• DO NOT expose the battery pack to rain or other wet
conditions.
• ALWAYS remove the battery from the tool before
recycling and dispose of it in accordance with local
regulations.
• If a re occurs, use a CO2 or dry chemical extinguisher.
WARNING! Batteries contain electrolytes, which
are corrosive. Avoid contact with skin.
If contact occurs, ush the area with clean water
and pat it dry. Seek medical attention at the earliest
opportunity. If contact with eyes occurs, ush
immediately with plenty of water ONLY and seek
medical advice at the earliest opportunity.
5.3 Connection to the Power Supply
• This appliance is supplied with an approved plug and
cable for your safety.
• If the power supply cord is damaged, it must be replaced
by Draper Tools, an authorised service agent or similarly
qualied personnel in order to avoid a hazard.
• The damaged or incomplete plug, when cut from the
cable, shall be disabled to prevent connection to a live
electrical outlet.
• This product is Class II* and is designed for connection
to a power supply matching that detailed on the rating
label and compatible with the plug tted.
CAUTION! DO NOT use this product with an
extension lead or multi-socket.
The fuse cover is removable with a small plain slot
screwdriver. The value of the fuse tted is marked on the
pin face of the plug. Should the fuse need replacing,
ensure the substitute is of the correct rating, approved
to BS 1363/A and ASTA or BS Kite marked. This should
only be performed by suitably qualied personnel.
ASTA
BSI
Ensure the fuse cover is replaced before attempting to
connect the plug to an electrical outlet. If the cover is
missing, a replacement must be obtained or the plug
replaced with a suitable type.
*Double Insulated: This product is double insulated
and does not require an earth connection to protect
against electric shock from accessible conductive parts
in the event of failure of the basic insulation.
5.4 Residual Risk
The safety instructions in this manual cannot account
for all possible conditions and situations that may
occur. Exercise common sense and caution when
using this product and protect against any additional
conceivable risks.
– 6 –
– 7 –
Loading...
