Draper Tools 04570 Instructions

EN

Original Instructions

Version 1

5kW & 9kW PTC

ELECTRIC
SPACE HEATER

04568, 04570

1. Preface

These are the original product instructions. This
document is part of the product; retain it for the life
of the product, passing it on to subsequent holders.
Read this manual in full before attempting to
assemble, operate, or maintain this product.

This Draper Tools manual describes the purpose
of the product and contains all the necessary
information to ensure its correct and safe use.
Following all the instructions and guidance in
this manual will ensure the safety of both the
product and the operator and increase the
lifespan of the product.

1.1 Product Reference

User Manual for: 5kW PTC Electric Space Heater, 9kW

PTC Electric Space Heater

Stock No: 04568, 04570

Part No: ESH5000PTC, ESH9000PTC

1.2 Revisions

Version 1: May 2022
First release

As our manuals are continually updated, always ensure
that the latest version is used.

Download the latest version from:
drapertools.com/manuals

All photographs and drawings within this manual are
supplied by Draper Tools to help illustrate correct
operation of the product.

Every eort has been made to ensure the

information contained in this manual is accurate.
However, Draper Tools reserves the right to amend
this document without prior warning. Always use the
latest version of the product manual.

1.3 Understanding the Safety Content of
this Manual

WARNING! – Situations or actions that may result in
personal injury or death.

CAUTION! – Situations or actions that may result in
damage to the product or surroundings.

Important: – Information or instructions of particular
importance.

1.4 Copyright © Notice

Copyright © Draper Tools Limited.

Permission is granted to reproduce this manual for
personal and educational use ONLY. Commercial
copying, redistribution, hiring, or lending is strictly
prohibited.

No part of this manual may be stored in a retrieval system
or transmitted in any other form or means without written
permission from Draper Tools Limited.

In all cases, this copyright notice must remain intact.

– 2 –

2. Contents

EN

1. Preface 2

1.1 Product Reference 2

1.2 Revisions 2

1.3  Understanding the Safety Content 2

1.4 Copyright © Notice 2

2. Contents 3

3. Warranty 4

4. Product Introduction 5

4.1 Scope 5

4.2 Specication 5

5. Health and Safety Information 6

5.1 General Health and Safety Precautions for this

Heater 6

5.2 Connection to the Power Supply 7

6. Identication and Unpacking 8

6.1  Product Overview 8

6.2  Packaging 8

7. Operating Instructions 9

7.1 Positioning the Heater 9

7.2 The Operation Control Dial 9

7.3 The Thermostat Control Dial 9

7.4 The Safety Tab 10

7.5 Switching O the Heater After Use 10

7.6 Thermal Cut-Out 10

8. Maintenance and Troubleshooting 11

8.1 General Maintenance and Storage 11

8.2 Troubleshooting 11

9. Disposal 12

10. Explanation of Symbols 13

– 3 –

3. Warranty

Draper Tools products are carefully tested and inspected
before shipment and are guaranteed to be free from
defective materials and workmanship.

Should the tool develop a fault, return the complete tool
to your nearest distributor or contact Draper Tools
directly. Contact information can be found at the back of
this manual.

Proof of purchase must be provided.

If, upon inspection, it is found that the fault occurring is
due to defective materials or workmanship, repairs will
be carried out free of charge.
parts and labour for 12 months from the date of purchase.
Where tools have been hired out, the warranty period
covers 90 days from the date of purchase.

This warranty does not apply to any consumable parts,
batteries or normal wear and tear, nor does it cover any
damage caused by misuse, careless or unsafe handling,
alterations, accidents, or repairs attempted or made by
any personnel other than the authorised Draper Tools
repair agent.

In all cases, to make a claim for faulty workmanship or
materials within the standard warranty period, please
contact or return the product to the place of purchase.
Proof of purchase may be required.

This warranty period covers

If the place of purchase is no longer trading or if you

experience any diculties with your warranty, please

contact Customer Services with the product details and
your proof of purchase. Contact details can be found at
the back of this manual.

If the tool is not covered by the terms of this warranty,
repairs and carriage charges will be quoted and charged
accordingly.

This warranty supersedes any other guarantees
expressed or implied and variations of its terms are not
authorised.

Your Draper Tools guarantee is not eective until you can

produce, upon request, a dated receipt or invoice to
verify your purchase within the guarantee period.

Please note that this warranty is an additional benet
and does not aect your statutory rights.

Draper Tools Limited

– 4 –

4. Product Introduction

EN

4.1 Scope

This heater is intended to raise the ambient temperature
in garages and workshop environments and is suitable
for domestic and light commercial use only. Any other
application beyond the conditions established for use
will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.

Part of our core range, this product is suitable for
enthusiasts and tradespersons alike.

4.2 Specication

Stock No. 04568 04570
Part No. ESH5000PTC/B ESH9000PTC
Rated voltage 400V 400V
Rated input 5,000W 9,000W
Rated frequency 50Hz 50Hz
Rated current 7.2–7.6A 13.0–13.6A
Position settings
O 0W 0W
Fan only 50W 80W
Half power 3,300W 6,000W
Full power 5,000W 9,000W
Max. heat output 17,060 BTU 30,708 BTU
Dimensions W 300 x H 345 x D 235mm W 395 x H 455 x D 307mm
Heating area 48m³ 80m³
Thermal cut-out 75°C 70°C
Weight 4.32kg 6.9kg

WARNING! This product is not a toy and must be
respected.

Read this manual in full before attempting to assemble,
operate or maintain the product, and retain it for later use.

– 5 –
