230V 135/165BAR
PRESSURE
WASHERS
00786, 03095, 03096
Stock No.03095
Stock No.00786
These instructions accompanying the product are the original instructions. This document is part of the product, keep
it for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed,
and contains all the necessary information to ensure its correct and safe use. By following all the general safety
instructions contained in this manual, it will ensure both product and operator safety, together with longer life of the
product itself.
All photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools
policy of continuous improvement determines the right to make modifications without prior warning.
Stock No.03096
2. CONTENTS
2.1 TABLE OF CONTENTS
1. TITLE PAGE
1. TITLE PAGE
2. CONTENTS
3. WARRANTY
4. INTRODUCTION
5. HEALTH AND SAFETY INFORMATION
6. TECHNICAL DESCRIPTION
7. UNPACKING AND CHECKING
8
. ASSEMBLY
9
. ACCESSORIES
10. OPERATION
11. MAINTENANCE AND TROUBLESHOOTING
12. DISPOSAL
13. EXPLANATION OF SYMBOLS
1.1 INTRODUCTION:
USER MANUAL FOR: 230V 135/165bar Pressure Washers
Stock No’s: 00786, 03095, 03096
Part No’s: PW1600/90D/RED, PW2200/110D/GRN, PW2200/110D/YEL
1.2 REVISIONS:
Date first published August 2021.
As our user manuals are continually updated, users should make
sure that they use the very latest version.
Downloads are available from: http://drapertools.com/manuals
Draper Tools Limited
Hursley Road
Chandler’s Ford
Eastleigh
Hampshire
SO53 1YF
UK
Website: drapertools.com
Product Help Line: +44 (0) 23 8049 4344
General Fax: +44 (0) 23 8026 0784
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
Warning! – Information that draws attention to the risk of injury or death.
Important – Information that draws attention to the risk of damage to the product or surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal and educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or
means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
– 2 –
2. CONTENTS
2.1 TABLE OF CONTENTS
1. TITLE PAGE
1.1 INTRODUCTION: ......................................................................................................... 2
1.2 REVISIONS: ................................................................................................................. 2
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT: ......................................... 2
1.4 COPYRIGHT © NOTICE: ............................................................................................. 2
2. CONTENTS
2.1 TABLE OF CONTENTS ...............................................................................................3
3. WARRANTY
3.1 WARRANTY ................................................................................................................. 4
4. INTRODUCTION
4.1 SCOPE ......................................................................................................................... 5
4.2 SPECIFICATION .......................................................................................................... 5
4.3 HANDLING AND STORAGE ........................................................................................5
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE ............................... 6
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR PRESSURE WASHER USE .............. 7
5.3 RESIDUAL RISK .......................................................................................................... 8
5.4 CONNECTION TO THE POWER SUPPLY.................................................................. 8
6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION ......................................................................................................... 9
7. UNPACKING AND CHECKING
7.1 PACKAGING .............................................................................................................. 10
7.2 WHAT’S IN THE BOX ................................................................................................ 10
. ASSEMBLY
8
8.1 FITTING THE TRANSPORT HANDLE SECTION ..................................................... 12
8.2 FITTING THE LANCE HOLDER AND CABLE HOOK ...............................................12
8.3 ATTACHING THE LANCE .......................................................................................... 13
8.4 ATTACHING THE NOZZLES TO THE LANCE .......................................................... 13
8.5 ATTACHING THE INTEGRATED HOSE REEL (03095 AND 03096) ......................... 14
8.6 ATTACHING THE HIGH PRESSURE HOSE ............................................................. 14
8.7 CONNECTING THE WATER SUPPLY ...................................................................... 15
. ACCESSORIES
9
9.1 DETERGENT BOTTLE (07786) ................................................................................. 16
9.2 INTEGRATED DETERGENT BOTTLE (03095 & 03096) .......................................... 16
9.3 TURBO NOZZLE ....................................................................................................... 16
9.4 FIXED BRUSH ........................................................................................................... 17
9.5 PATION CLEANER ATTACHMENT (03095 ONLY) .................................................... 17
9.6 SNOW FOAM PRODUCER ACCESSORY (03096 ONLY) ........................................ 17
10. OPERATION
10.1 TOTAL STOP DEVICE ............................................................................................... 18
10.2 SWITCHING ON ........................................................................................................ 18
11. MAINTENANCE AND TROUBLESHOOTING
11.1 TROUBLESHOOTING GUIDE ................................................................................... 19
11.2 CLEANING PIN .......................................................................................................... 19
11.3 BLEEDING AIR FROM THE SYSTEM .......................................................................19
12. DISPOSAL
12.1 DISPOSAL ................................................................................................................. 19
13. EXPLANATION OF SYMBOLS
13.1 EXPLANATION OF SYMBOLS .................................................................................. 20
– 3 –
4. INTRODUCTION
4.1 SCOPE
Compact, lightweight and mobile pressure washer for cleaning vehicles, caravans, motor vans,
driveways, boats and other domestic duties. Any other application is considered misuse.
4.2 SPECIFICATION
Stock No .................................................. 00786 ................................... 03095 ............................................ 03096
Part No ............................................
Rated voltage ................................. 230-240V~50Hz ................... 230-240V~50Hz ....................230-240V~50Hz
Rated input ............................................ 1600W .................................. 2200W ......................................... 2200W
Working pump pressure ...................90bar (1305psi) ...................110bar (1595psi) .................. 110bar (1595psi)
Max. pump pressure ........................135bar (1958psi) ..................165bar (2393psi) ..................165bar (2393psi)
Max. flow rate ............................. 7.1L/min (426L/hour) ............ 8.2L/min (492L/hour) ........ 8.2L/min (492L/hour)
Type of protection .................................... IPX5 ......................................IPX5 ............................................... IPX5
Max. water feed temperature .................... 50°C ..................................... 50°C ...............................................50°C
Sound pressure level (LpA) ....................77dB(A) ................................77dB(A) .......................................77dB(A)
Sound power level (LWA) .......................93dB(A) ................................94dB(A) ....................................... 94dB(A)
Uncertainty (K) ..............................3dB(A) ..................................3dB(A) ..........................................3dB(A)
Vibration level
Weight (machine and accessories)
4.3 HANDLING AND STORAGE
Note: Every machine is tested in its operating conditions, so it is normal for a few drops of water to
be left inside it.
− This pressure washer and accompanying accessories should not be stored at, or below 0°C.
− Frozen water inside the machine can cause critical damage to pump and other components.
− Care must be taken when handling this product.
• Dropping this power tool could have an effect on its accuracy and could also result in
− Environmental conditions can have a detrimental effect on this product if neglected.
• Exposure to damp air can gradually corrode components. If the product is unprotected from
• If not cleaned and maintained correctly or regularly, the machine will not perform at its best.
3. WARRANTY
3.1 WARRANTY
Draper tools have been carefully tested and inspected before shipment and are guaranteed to be
free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor or
contact:
Draper Tools Limited, Chandler’s Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: +44 (0) 8049 4333 or Product Help Line +44 (0) 23 8049 4344.
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or workmanship,
repairs will be carried out free of charge. This warranty period covering labour is 12 months from
the date of purchase except where tools are hired out when the warranty period is 90 days from
the date of purchase. The warranty is extended to 24 months for parts only. This warranty does not
apply to any consumable parts, any type of battery or normal wear and tear, nor does it cover any
damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges will
be quoted and made accordingly.
This warranty applies in lieu of any other warranty expressed or implied and variations of its terms
are not authorised.
Your Draper warranty is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the warranty period.
Please note that this warranty is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.
– 4 –
4. INTRODUCTION
4.1 SCOPE
Compact, lightweight and mobile pressure washer for cleaning vehicles, caravans, motor vans,
driveways, boats and other domestic duties. Any other application is considered misuse.
4.2 SPECIFICATION
Stock No .................................................. 00786 ................................... 03095 ............................................ 03096
Part No ............................................
Rated voltage ................................. 230-240V~50Hz ................... 230-240V~50Hz ....................230-240V~50Hz
Rated input ............................................ 1600W .................................. 2200W ......................................... 2200W
Working pump pressure ...................90bar (1305psi) ...................110bar (1595psi) .................. 110bar (1595psi)
Max. pump pressure ........................135bar (1958psi) ..................165bar (2393psi) ..................165bar (2393psi)
Max. flow rate ............................. 7.1L/min (426L/hour) ............ 8.2L/min (492L/hour) ........ 8.2L/min (492L/hour)
Type of protection .................................... IPX5 ......................................IPX5 ............................................... IPX5
Max. water feed temperature .................... 50°C ..................................... 50°C ...............................................50°C
Sound pressure level (LpA) ....................77dB(A) ................................77dB(A) .......................................77dB(A)
Sound power level (LWA) .......................93dB(A) ................................94dB(A) ....................................... 94dB(A)
Uncertainty (K) ..............................3dB(A) ..................................3dB(A) ..........................................3dB(A)
Vibration level†: ....................................... 2.5m/s² ................................ 2.5m/s² ......................................... 2.5m/s²
Weight (machine and accessories)
4.3 HANDLING AND STORAGE
Note: Every machine is tested in its operating conditions, so it is normal for a few drops of water to
be left inside it.
− This pressure washer and accompanying accessories should not be stored at, or below 0°C.
− Frozen water inside the machine can cause critical damage to pump and other components.
− Care must be taken when handling this product.
• Dropping this power tool could have an effect on its accuracy and could also result in
personal injury. This product is not a toy and must be respected.
− Environmental conditions can have a detrimental effect on this product if neglected.
• Exposure to damp air can gradually corrode components. If the product is unprotected from
dust and debris, components will become clogged.
• If not cleaned and maintained correctly or regularly, the machine will not perform at its best.
PW1600/90D/RED
................. 8kg ..................................... 11.5kg .......................................... 11.2kg
.................
PW2200/110D/GRN .................. PW2200/110D/YEL
– 5 –
5. HEALTH AND SAFETY INFORMATION
Wait for the machine to stop. Unless the machine is fitted with a safety brake, some parts may
continue to move due to momentum. Wait for all parts to stop, then unplug it from the power supply
before making any adjustments, carrying out maintenance operations or just finishing using the
tool.
Remove and check setting tools. Some machinery requires the use of additional tools or keys to
set, load or adjust the power tool. Before starting the power tool always check to make certain they
have been removed and are safely away from the machine.
Prevent unintentional starting. Before plugging any machine in to the power supply, make sure
the switch is in the OFF position. If the machine is portable, do not hold the machine near the
switch and take care when putting the machine down, that nothing can operate the switch.
Carefully select an extension lead. Some machines are not suitable for use with extension
leads. If the tool is designed for use outdoors, use an extension lead also suitable for that
environment. When using an extended lead, select one capable of handling the current (amps)
drawn by the machine in use. Fully extend the lead regardless of the distance between the power
supply and the tool. Excess current (amps) and a coiled extension lead will both cause the cable to
heat up and can result in fire.
Concentrate and stay alert. Distractions are likely to cause an accident. Never operate a power
tool if you are under the influence of drugs (prescription or otherwise), including alcohol or if you
are feeling tired. Being disorientated will result in an accident.
Have this tool repaired by a qualified person. This tool is designed to conform to the relevant
international and local standards and as such should be maintained and repaired by someone
qualified, using only original parts supplied by the manufacturer. This will ensure the tool remains
safe to use.
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR PRESSURE WASHER USE
Warning!
− This appliance is for outdoor use only.
− Always disconnect the electricity and water supplies on completion of every job.
− Never use the appliance if the electrical cable or important parts of the appliance are damaged,
− This appliance has been designed for use with a neutral shampoo based on biodegradable
− Never use the appliance with people in the vicinity, unless they are wearing protective clothing.
− Do not direct the nozzle toward mechanical parts containing lubricant grease, as the grease
− High pressure jets may be dangerous if improperly used. Jets must never be pointed at people,
− The hoses, accessories and high pressure couplings are important for the appliance’s safety.
− The gun is fitted with a safety catch. Whenever use of the machine is interrupted it is important
− Never point the jet at yourself or others to clean clothing or footwear.
− Never allow children or untrained people to use the appliance.
5. HEALTH AND SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE
When using any type of power tool there are steps that should be taken to make sure that you, as
the user, remain safe.
Common sense and a respect for the tool will help reduce the risk of injury.
Read the instruction manual fully. Do not attempt any operation until you have read and
understood this manual.
Most important you must know how to safely start and stop this machine, especially in an
emergency.
Keep the work area tidy and clean. Attempting to clear clutter from around the machine during
use will reduce your concentration. Mess on the floor creates a trip hazard. Any liquid spilt on the
floor could result in you slipping.
Find a suitable location. If the machine is bench mounted, the location should provide good
natural light or artificial lighting as a replacement. Avoid damp and dust locations as it will have a
negative effect on the machine’s performance. If the machine is portable do not expose the tool to
rain. In all cases do not operate power tools near any flammable materials.
Keep bystanders away. Children, onlookers and passers by must be restricted from entering the
work area for their own protection. The barrier must extend a suitable distance from the tool user.
Unplug and house all power tools that are not in use. A power tool should never be left unattended
while connected to the power supply. They must be housed in a suitable location, away locked up
and from children. This includes battery chargers.
Do not overload or misuse the tool. All tools are designed for a purpose and are limited to what
they are capable of doing. Do not attempt to use a power tool (or adapt it in any way) for an
application it is not designed for. Select a tool appropriate for the size of the job. Overloading a tool
will result in tool failure and user injury. This covers the use of accessories.
Dress properly. Loose clothing, long hair and jewellery are all dangerous because they can
become entangled in moving machinery. This can also result in parts of body being pulled into the
machine. Clothing should be close fitted, with any long hair tired back and jewellery and neck ties
removed. Footwear must be fully enclosed and have a non-slip sole.
Wear personal protective equipment (PPE). Dust, noise, vibration and swarf can all be
dangerous if not suitably protected against. If the work involving the power tool creates dust or
fumes wear a dust mask. Vibration to the hand, caused by operating some tools for longer periods
must be protected against. Wear vibration reducing gloves and allow long breaks between uses.
Protect against dust and swarf by wearing approved safety goggles or a face shield. These are
some of the more common hazards and preventions, however, always find out what hazards are
associated with the machine/work process and wear the most suitable protective equipment
available.
Do not breathe contaminated air. If the work creates dust or fumes connect the machine (if
possible) to an extraction system either locally or remotely. Working outdoors can also help if
possible.
Move the machine as instructed. If the machine is hand held, do not carry it by the power supply
cable. If the product is heavy, employ a second or third person to help move it safely or use a
mechanical device. Always refer to the instructions for the correct method.
Do not overreach. Extending your body too far can result in a loss of balance and you falling. This
could be from a height or onto a machine and will result in injury.
Maintain your tools correctly. A well maintained tool will do the job safely. Replace any damaged
or missing parts immediately with original parts from the manufacturer. As applicable, keep blades
sharp, moving parts clean, oiled or greased, handles clean, and emergency devices working.
– 6 –
5. HEALTH AND SAFETY INFORMATION
Wait for the machine to stop. Unless the machine is fitted with a safety brake, some parts may
continue to move due to momentum. Wait for all parts to stop, then unplug it from the power supply
before making any adjustments, carrying out maintenance operations or just finishing using the
tool.
Remove and check setting tools. Some machinery requires the use of additional tools or keys to
set, load or adjust the power tool. Before starting the power tool always check to make certain they
have been removed and are safely away from the machine.
Prevent unintentional starting. Before plugging any machine in to the power supply, make sure
the switch is in the OFF position. If the machine is portable, do not hold the machine near the
switch and take care when putting the machine down, that nothing can operate the switch.
Carefully select an extension lead. Some machines are not suitable for use with extension
leads. If the tool is designed for use outdoors, use an extension lead also suitable for that
environment. When using an extended lead, select one capable of handling the current (amps)
drawn by the machine in use. Fully extend the lead regardless of the distance between the power
supply and the tool. Excess current (amps) and a coiled extension lead will both cause the cable to
heat up and can result in fire.
Concentrate and stay alert. Distractions are likely to cause an accident. Never operate a power
tool if you are under the influence of drugs (prescription or otherwise), including alcohol or if you
are feeling tired. Being disorientated will result in an accident.
Have this tool repaired by a qualified person. This tool is designed to conform to the relevant
international and local standards and as such should be maintained and repaired by someone
qualified, using only original parts supplied by the manufacturer. This will ensure the tool remains
safe to use.
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR PRESSURE WASHER USE
Warning!
− This appliance is for outdoor use only.
− Always disconnect the electricity and water supplies on completion of every job.
− Never use the appliance if the electrical cable or important parts of the appliance are damaged,
e.g. safety devices, high pressure hose, gun, etc.
− This appliance has been designed for use with a neutral shampoo based on biodegradable
anionic surface active detergents. The use of other detergents or chemicals may put the
appliance’s safety at risk.
− Never use the appliance with people in the vicinity, unless they are wearing protective clothing.
− Do not direct the nozzle toward mechanical parts containing lubricant grease, as the grease
will dissolve and spread over the surrounding ground. Vehicle tyres/tyre valves may only be
cleaned from a minimum distance of 30cm, otherwise the vehicle tyre/tyre valve could be
damaged by the high-pressure jet. The first indication of this is a discolouration of the tyre.
Damaged vehicle tyres/tyre valves can be deadly dangerous.
− High pressure jets may be dangerous if improperly used. Jets must never be pointed at people,
animals, live electrical equipment or the appliance itself.
− The hoses, accessories and high pressure couplings are important for the appliance’s safety.
Use only hoses, accessories and couplings recommended (it is extremely important to protect
these components against damage by avoiding their improper use and protecting them against
bending, knocks and scratches).
− The gun is fitted with a safety catch. Whenever use of the machine is interrupted it is important
to operate the safety catch to prevent accidental activation of the jet.
− Never point the jet at yourself or others to clean clothing or footwear.
− Never allow children or untrained people to use the appliance.
– 7 –
Loading...
