STORM
INSTRUCTIONS FOR
10-50mm
Air Nailer
Stock No.14607 Part No.SFANK2050
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.
GENERAL INFORMATION
These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools
policy of continuous improvement determines the right to make modifications without prior warning.
1. TITLE PAGE
1.1 INTRODUCTION:
USER MANUAL FOR:
10-50mm AIR NAILER
Stock no. 14607
Part no. SFANK2050
1.2 REVISIONS:
Date first published May 2016
As our user manuals are continually updated, users should make sure that they use the very
latest version.
Downloads are available from: http://www.drapertools.com/manuals
DRAPER TOOLS LIMITED WEBSITE: drapertools.com
HURSLEY ROAD PRODUCT HELPLINE: +44 (0) 23 8049 4344
CHANDLER’S FORD GENERAL FAX: +44 (0) 23 8026 0784
EASTLEIGH
HAMPSHIRE
SO53 1YF
U.K.
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
WARNING! Information that draws attention to the risk of injury or death.
CAUTION! Information that draws attention to the risk of damage to the product or
surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other
form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
2. CONTENTS
2.1 CONTENTS
PAGE CONTENT
1 TITLE PAGE
1.1 INTRODUCTION ........................................................................................................... 2
1.2 REVISION HISTORY....................................................................................................... 2
1.3 UNDERSTANDING THIS MANUAL ............................................................................... 2
1.4 COPYRIGHT NOTICE ..................................................................................................... 2
2 CONTENTS
2.1 CONTENTS .................................................................................................................... 3
3 GUARANTEE
3.1 GUARANTEE .................................................................................................................4
4 INTRODUCTION
4.1 SCOPE ........................................................................................................................... 5
4.2 SPECIFICATION.............................................................................................................. 5
5. HEALTH & SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE .....................................6-7
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR AIR STAPLER/NAILER............................... 8
5.3 RESIDUAL RISK.............................................................................................................. 9
6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION ........................................................................................................ 10
7. UNPACKING & CHECKING
7.1 PACKAGING................................................................................................................ 11
7.2 WHAT'S IN THE BOX?................................................................................................. 11
8. AIR SUPPLY
8.1 AIR TOOL OIL SPECIFICATION.................................................................................... 12
8.2 RECOMMENDED AIR SUPPLY SET UP........................................................................ 12
9. ASSEMBLY
9.1 CONNECTION TO THE AIR SUPPLY............................................................................ 13
10. OPERATION AND USE
10.1 LOADING THE STAPLER/NAILER ................................................................................ 14
10.2 CHECKING THE SAFETY LEVER .................................................................................. 15
10.3 CLEARING A JAM........................................................................................................ 16
11. MAINTENANCE
11.1 EVERY-DAY MAINTENANCE CHECKS........................................................................ 17
11.2 AFTER USE MAINTENANCE CHECKS.......................................................................... 17
12. OPTIONAL ACCESSORIES ......................................................................................................... 18
13. TROUBLESHOOTING
13.1 TROUBLESHOOTING GUIDE....................................................................................... 19
14. DISPOSAL
14.1 DISPOSAL .................................................................................................................... 20
15. EXPLANATION OF SYMBOLS ................................................................................................... 21
DECLARATION OF CONFORMITY ...................................................................................... ENCLOSED
PAGE
3
3. GUARANTEE
3.1 GUARANTEE
Draper tools have been carefully tested and inspected before shipment and are guaranteed
to be free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor
or contact Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: (023) 8049 4333 or Product Helpline (023) 8049 4344.
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee period covering
parts/labour is 6 months from the date of purchase except where tools are hired out when
the guarantee period is 90 days from the date of purchase. This guarantee does not apply to
normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accidents, or repairs attempted or made by any personnel other than
the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges
will be quoted and made accordingly.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of
its terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated receipt
or invoice to verify your proof of purchase within the guarantee period.
Please note that this guarantee is an additional benefit and does not affect your statutory
rights.
Draper Tools Limited.
4
4. INTRODUCTION
4.1 SCOPE
This air nailer is designed to insert steel nails. Any other use is forbidden.
4.2 SPECIFICATION
Stock no. .............................................................................................................................. 14607
Part no. ....................................................................................................................... SFANK2050
Operating Air Pressure..................................................................................... 75-100PSI (5-7Bar)
Max. Safety Working Pressure..................................................................................115PSI (8Bar)
Min. Air Hose Size ...............................................................................................................
Air Inlet Size .......................................................................................................................
Nail length capacity ........................................................................................................10-50mm
Gauge.......................................................................................................................................... 18
Head..................................................................................................................................... 2.0mm
Shank width....................................................................................................................... 1.25mm
Shank thickness ................................................................................................................. 1.05mm
Sound Pressure Level...................................................................................................... 86.7dB(A)
Sound Power Level......................................................................................................... 99.7dB(A)
Vibration Level ..................................................................................................................<2.1m/s
Weight ................................................................................................................................... 1.4kg
† All measurements shown in millimetres.
Warning: Wear approved safety glasses and ear defenders.
3
/8" I.D.
1
/4" BSP
2
*Continuous A-Weighted Sound Pressure Level at the workstation in accordance to prEN ISO
15744:1999 and declared according to EN ISO 4871.
**A-Weighted Sound Power Level in accordance to prEN ISO 15744:1999 and declared
according to EN ISO 4871.
5
5. HEALTH & SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS FOR POWER TOOL USE
When using any type of power tool there are steps that should be taken to make sure that
you, as the user, remain safe.
Common sense and a respect for the tool will help reduce the risk of injury.
Read the instruction manual fully. Do not attempt any operation until you have read and
understood this manual.
Most important you must know how to safely start and stop this machine, especially in an
emergency.
Keep the work area tidy and clean. Attempting to clear clutter from around the machine
during use will reduce your concentration. Mess on the floor creates a trip hazard. Any
liquid spilt on the floor could result in you slipping.
Find a suitable location. If the machine is bench mounted; the location should provide good
natural light or artificial lighting as a replacement. Avoid damp and dust locations as it will
have a negative effect on the machine’s performance.
If the machine is portable; do not expose the tool to rain. In all cases do not operate power
tools near any flammable materials.
Keep bystanders away. Children, onlookers and passers by must be restricted from entering
the work area for their own protection. The barrier must extend a suitable distance from the
tool user.
Disconnect and house all power tools that are not in use. An air tool should never be left
unattended while connected to the power supply. They must be housed in a suitable
location, away locked up and from children.
Do not overload or misuse the tool. All tools are designed for a purpose and are limited to
what they are capable of doing. Do not attempt to use a power tool (or adapt it in any way)
for an application it is not designed for. Select a tool appropriate for the size of the job.
Overloading a tool will result in tool failure and user injury: This covers the use of
accessories.
Dress properly. Loose clothing, long hair and jewellery are all dangerous because they can
become entangled in moving machinery: This can also result in parts of body being pulled
into the machine.
Clothing should be close fitted, with any long hair tired back and jewellery and neck ties
removed. Footwear must be fully enclosed and have a nonslip sole.
Wear personal protective equipment (PPE). Dust, noise, vibration and swarf can all be
dangerous if not suitably protected against. If the work involving the power tool creates dust
or fumes; wear a dust mask. Vibration to the hand, caused by operating some tools for
longer periods must be protected against. Wear vibration reducing gloves and allow long
breaks between uses. Protect against dust and swarf by wearing approved safety goggles or
a face shield. These are some of the more common hazards and preventions; however,
always find out what hazards are associated with the machine/work process and wear the
most suitable protective equipment available.
Do not breathe contaminated air. If the work creates dust or fumes; connect the machine (if
possible) to an extraction system either locally or remotely. Working outdoors can also help
if possible.
6
5. HEALTH & SAFETY INFORMATION
Move the machine as instructed. If the machine is hand held, do not carry it by the air line.
If the product is heavy; employ a second or third person to help move it safely or use a
mechanical device. Always refer to the instructions for the correct method.
Do not overreach. Extending your body too far can result in a loss of balance and you
falling. This could be from a height or onto a machine and will result in injury.
Maintain your tools correctly. A well maintained tool will do the job safely. Replace any
damaged or missing parts immediately with original parts from the manufacturer. As
applicable; keep blades sharp; moving parts clean, oiled or greased; handles clean; and
emergency devices working.
Wait for the machine to stop. Unless the machine is fitted with a safety brake; some parts
may continue to move due to momentum. Wait for all parts to stop; then disconnect it from
the air line before making any adjustments, carrying out maintenance operations or just
finishing using the tool.
Remove and check setting tools. Some machinery requires the use of additional tools or keys
to set, load or adjust the power tool. Before starting the power tool always check to make
certain they have been removed and are safely away from the machine.
Prevent unintentional starting. Before connecting any machine in to the air supply, make
sure the switch is in the OFF position. If the machine is portable; do not hold the machine
near the switch and take care when putting the machine down; that nothing can operate the
switch.
Concentrate and stay alert. Distractions are likely to cause an accident. Never operate a
power tool if you are under the influence of drugs (prescription or otherwise), including
alcohol or if you are feeling tired. Being disorientated will result in an accident.
Have this tool repaired by a qualified person. This tool is designed to confirm to the relevant
international and local standards and as such should be maintained and repaired by someone
qualified; using only original parts supplied by the manufacturer: This will ensure the tool
remains safe to use.
7
5. HEALTH & SAFETY INFORMATION
5.2 ADDITIONAL SAFETY INSTRUCTIONS FOR AIR STAPLER/NAILER
- Only those fasteners listed in the operating instructions may be used in the fastener
driving tools.
- Do not use on scaffoldings and ladders.
- Check prior to each operation that the safety and triggering mechanism is functioning
properly and that all nuts and bolts are tight.
- Do not carry out any alterations to the fastener driving tool.
- Do not disassemble or make inoperative any parts of the fastener driving tool such as the
safety yoke.
- Do not perform any “emergency repairs” without appropriate equipment.
- The fastener driving tool should be serviced properly and at regular intervals in
accordance with the manufacturers instructions.
- Avoid weakening or damaging the tool, for example by:
- punching or engraving;
- modification not authorised by the manufacturer;
- guiding against templates made of hard material such as steel;
- dropping or pushing across the floor;
- using the equipment as a hammer;
- applying excessive force of any kind.
Never point any operational fastener driving tool at yourself or at any other person.
Hold the fastener driving tool during the work operation in such a way that no injuries can
be caused to the head or to the body in the event of a possible recoil consequent upon a
disruption in the energy supply or hard areas within the workpiece.
Never actuate the fastener driving tool into free space. This will avoid any hazard caused by
free flying fasteners and excessive strain of the tool,
The tool shall be disconnected from the compressed air system for the purpose of
transportation, especially where ladders are used or where physical posture is adopted whilst
moving.
Carry the fastener driving tool at the workplace using only the handle, and never with the
trigger actuated.
Take conditions at the workplace into account. Fasteners can penetrate thin workpieces or
slip off corners and edges of workpieces, and thus put people at risk.
For personal safety, use protective equipment such as hearing and eye protection.
- Only those fasteners which are specified in the operating instructions (see Specification)
shall be used in fastener driving tools. The fastener driving tool and the fasteners
specified in the operating instructions are to be considered as one unit safety system;
- Quick-action couplings shall be used for connection to the compressed air system and the
non-sealable nipple must be fitted at the tool in such a way that no compressed air
remains in the tool after disconnection;
- Oxygen or combustible gases shall not be used as an energy source for compressed air
operated fastener driving tools;
- Fastener driving tools shall only be connected to an air-supply where the maximum
allowable pressure of the tool cannot be exceeded by more than 10%; in case of the
higher pressures, a pressure reducing valve which includes a downstream safety valve
shall be built into the compressed air supply.
8
5. HEALTH & SAFETY INFORMATION
5.3 RESIDUAL RISK
Important note:
- Although the safety instructions and operating manuals for our tools contain extensive
instructions of safe working with power tools, every power tool involves a certain
residual risk which can not be completely excluded by safety mechanisms. Power tools
must therefore always be operated with caution!
9
6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION
$
%
&
'
Trigger.
Hand Grip.
Air Inlet.
Magazine Latch.
Magazine.
Safety Lever.
Exhaust.
10
NAIL:
$ Head.
% Length.
& Shank Thickness.
' Shank Width.
7. UNPACKING & CHECKING
7.1 PACKAGING
Carefully remove the product from the packaging and examine it for any sign of damage
that may have happened during shipping. Lay the contents out and check them against the
parts shown below. If any part is damaged or missing; please contact the Draper Helpline
(the telephone number appears on the Title page) and do not attempt to use the product.
The packaging material should be retained at least during the guarantee period: in case
the machine needs to be returned for repair.
Warning! Some of the packaging materials used may be harmful to children. Do not leave
any of these materials in the reach of children.
If any of the packaging is to be thrown away, make sure they are disposed of correctly;
according to local regulations.
7.2 WHAT'S IN THE BOX?
Included accessory part:
3mm hex. key.
4mm hex. key.
11
8. AIR SUPPLY
8.1 AIR TOOL OIL SPECIFICATION
Failure to follow these instructions will lead to premature malfunction of the equipment
which is not covered by the guarantee.
Air tool oil viscosity refers to it’s properties to flow and how it reacts with heat. A low
viscosity is thinner than a high viscosity.
Air tool oil becomes thinner as it heats so choosing the right viscosity is essential. If the
viscosity is too low it may provide insufficient lubrication when heated. Equally, if it is too
high, the fluid may provide excessive resistance to move through the lines when cold.
The ISO (International Standards Organisation) viscosity grading system measures the
kinematic viscosity in centistokes (cSt) at 40º which is todays accepted standard. The SAE
(Society of Automotive Engineers) viscosity grade value is based on a scale.
This equipment is suited to an ISO grade 22 – 32 (SAE grade 5W – 15W) monograde oil.
The oil must be constantly supplied to the equipment during use to ensure complete
lubrication and optimum performance is achieved. It also acts as a rust inhibitor when the
equipment is not in use.
We recommend the use of Draper Air Tool Oil:
250ml = Stock No.34679, 500ml = Stock No.34681, 1Litre = Stock No.34682.
This air tool operates at a maximum pressure of 115psi/8bar and must be controlled via a
combination pressure regulator, in-line lubricator and moisture filter such as the Draper
range (see you local Draper stockist) which with proper maintenance will ensure a constant
supply of dry air and lubricating oil at all times (see illustration below). Always check
machine operating pressure before use.
Water in the compressor tank will cause serious corrosion to your air tools and should be
drained daily to avoid excessive water in your air supply. Dirty wet air rapidly shortens the
life of your air tool.
If you are using an air tool on a hose over 25ft long it is advisable to increase the bore of the
hose to the next larger size available, i.e., ¼" increases
pressure and volume of air to power the machine.
3
⁄8". This will ensure adequate
8.2 RECOMMENDED AIR SUPPLY SET UP – FIG. 1
Water separation
Do not install quick
coupling here.
To your
air tool
FIG.1
After each use and before prolonged storage, lubricate the equipment with approximately
1.5ml of approved air tool oil directly down the air inlet.
12
Nipple
Whip hose
Quick coupler
Air line hose
Nipple
Oiler
Regulator
Drain daily
Air supply
9. ASSEMBLY
9.1 CONNECTION TO THE AIR SUPPLY
- FIG. 2
Whip hose:
To connect the air ratchet to an air line, a ¼"BSP male
thread whip hose* will be required. Wind a length of
PTFE tape** around the thread before securing the hose
in place. The connection must be tight for an airtight
union.
* Draper Stock No.54438.
** Draper Stock No.63389.
FIG.2
13
10. OPERATION AND USE
10.1 LOADING THE NAILER - FIGS. 3 - 6
NOTE: Always disconnect the tool from the air supply
before any adjustment or maintenance is carried out.
Press the magazine latch and gently slide the
magazine back.
To load nails into the magazine, lay the machine onto
one side. Place a strip of nails against the centre bar,
ensuring the point of the fastener is facing
forwards/down.
Close the magazine and ensure the latch correctly
engages and is fully secure.
Connect the tool to the air supply.
Always test that the fastener penetrates by the correct
amount by driving the fastener into a piece of wood. If
needed, the air pressure can be regulated to the
desired level, see specification for details.
DO NOT exceed maximum pressure 115psi/7bar.
FIG.3
FIG.4
14
FIG.5
FIG.6
10. OPERATION AND USE
This tool is fitted with a safety yoke which enables the
driving operation to be carried out only
after the muzzle of the tool is pressed against a
workpiece. These tools are marked with an
inverted triangle ( ) behind the serial number and are
not permitted for use without an
effective safety yoke.
10.2 CHECKING THE SAFETY LEVER FIGS. 7 - 10
Disconnect from the air supply.
Ensure the magazine is empty of all fasteners.
The safety lever should be able to move in and out
without any obstruction.
To test the safety lever is working correctly connect the
tool to the air supply. Push the safety lever against a
piece of wood without pulling the trigger . The tool
must not fire. Should this happen the tool must be
repaired before further use.
Hold the tool away from the piece of wood. The safety
lever should return to its original position. Pull the
trigger. The tool must not fire. Should this happen the
tool must be repaired before further use.
FIG.7
FIG.8
FIG.9
Push the safety lever against a piece of wood this time
pulling the trigger the tool should fire. This is correct
and safe to use.
FIG.10
15
10. OPERATION AND USE
10.3 CLEARING A JAM - FIGS. 11 - 13
Note: Always disconnect the tool from the air supply
before any adjustment or maintenance is carried out.
FASTENER JAMMED INSIDE MAGAZINE
Open the magazine latch and pull open the magazine.
Remove the fastener that is causing the obstruction
using long nose pliers.
Reload the magazine with the required fasteners and
close securely.
FASTENER JAMMED IN CHAMBER
Open the magazine latch and pull open the magazine.
Remove the two hex. socket bolts and remove covering
plate.
Remove the fastener that is causing the obstruction
using long nose pliers.
Re-assemble the nose plate and check the operation of
the safety lever before using the tool.
FIG.11
FIG.12
FIG.13
16
11. MAINTENANCE
11.1 EVERY-DAY MAINTENANCE CHECKS
Before connection to the air supply:
• Drain the compressor reservoir of condensate.
• Drain the air lines of condensate.
• Drain the combined separator filter, regulator, water trap.
• Fill up the combined separator filter, regulator, lubricant reservoir with approved air tool
oil.
• Check the line pressure is correct for the tool.
11.2 AFTER USE MAINTENANCE CHECKS
• Repeat the above procedures.
• Lubricate the tool with approximately 1.5ml of approved air tool oil directly down the air
inlet.
17
12. OPTIONAL ACCESSORIES
0
NAILS
†
Approx.5000 pcs. per box
-0.2
0.7
2
15~50
+
0.9 0.05
-
+0.3
0
STOCK No.
PART No.
Length Gauge
59823 AAN15 15mm 18
59824 AAN20 20mm 18
59825 AAN25 25mm 18
59826 AAN30 30mm 18
59827 AAN32 32mm 18
59828 AAN35 35mm 18
59829 AAN38 38mm 18
59830 AAN40 40mm 18
59831 AAN45 45mm 18
59832 AAN50 50mm 18
18
13. TROUBLESHOOTING
13.1 TROUBLESHOOTING GUIDE
Problems
• Tool fires but will not insert nail
fully.
• Tool will not fire.
• Tools will not fire and air flows
freely from exhaust.
• Tool will not shut off.
Possible cause Required action
• Incorrect air pressure. • Gradually increase air pressure
• Nail jammed.
• No lubrication.
• Piston stuck.
• Trigger faulty.
• Lack of lubrication.
• ‘O’ ring throttle valve dislodged
from seat inlet valve.
until nail is driven fully home.
DO NOT operate above maximum
pressure 115psi/8bar.
• Disconnect from air line and
remove jammed nail.
• Remove nails, lubricate with air
tool oil directly into air inlet,
operate machine to see if piston
un-jams.
• Return to authorised service
centre for repair.
• Replace ‘O’ ring or return to
service centre.
We recommend the use of Draper Air Tool Oil:
250ml = Stock No.34679, 500ml = Stock No.34681, 1Litre = Stock No.34682.
19
14. DISPOSAL
14.1 DISPOSAL
- At the end of the machine’s working life, or when it can no longer be repaired, ensure
that it is disposed of according to national regulations.
- Contact your local authority for details of collection schemes in your area.
In all circumstances:
• Do not dispose of power tools with domestic waste.
• Do not incinerate.
• During decommissioning of the equipment, certain hazards should be understood and
avoided:
- Only with the line pressure released shall the equipment be disassembled.
Goggles should be worn.
20
15. EXPLANATION OF SYMBOLS
Wear safety glasses.
Wear ear defenders.
Warning!
Read the instruction manual
21
NOTES
22
NOTES
23
CONTACTS
- DRAPER TOOLS LIMITED,
Hursley Road, Chandler's Ford,
Eastleigh, Hampshire. SO53 1YF. U.K.
- Helpline: (023) 8049 4344
- Sales Desk: (023) 8049 4333
- General Enquiries: (023) 8026 6355
- Service/Warranty Repair Agent
For aftersales servicing or warranty repairs, please
contact the Draper Tools Helpline for details of an
agent in your local area.
YOUR DRAPER STOCKIST
RWKC0516
drapertools.com
Loading...
