Accuset Mounts for
LCD-DLP Projectors

Please Mark Appropriate Selections

Accuset Low Profi le Mount
Accuset Adjustable Mount Kit

Consists of Ceiling Plate, Pipe, Extension Adapter, Bracket Adapter and
Universal Projector Bracket.

Select Size Range

153/8" - 173/4" 213/8" - 293/4" 293/4" - 463/4"
443/4" - 773/4" 573/8" - 1013/4" 693/8" - 1253/4"
813/8" - 1493/4"

Accuset Fixed Extension Mount Kit

Consists of Ceiling Plate, 11/2" Pipe, Bracket Adapter and Universal
Projector Bracket.

Select Overall Height

141/2" 201/2" 261/2"
321/2" 441/2" 561/2"
681/2" 801/2" 921/2"
1041/2" 1161/2" 1281/2"

Accuset Component Kit

Consists of Ceiling Plate, Bracket Adapter and Universal Projector
Bracket. You furnish 1
threaded on both ends.

Build Your Own Aero Accuset Kit

Order just the pieces you want.

Ceiling Plate
11/2" Fixed Pipe Section (Ceiling Plate not included)

6" 12" 18"
24" 36" 48"
60" 72" 84"
96" 108" 120"

Adjustable Pipe Sections (Ceiling Plate and Extension Adapter included)

73/8" - 103/8" 133/8" - 223/8" 22" - 391/2"
373/8" - 703/8" 493/8" - 943/8" 613/8" - 1183/8"

733/8" - 1423/8"
Bracket Adapter
Extension Adapter
Universal Projector Bracket

Options

Angled Ceiling Plate (must be used with ceiling plate)

Flush Extension (allows you to attach ceiling plate to Bracket Adapter)

Suspended Ceiling Panel

11/2" 2"
Low Profi le Ceiling Panel (11/2" only)
Universal Projector Bracket (provided with all pre-made mount kits)
Chrome Escutcheon Ring

Security Lock Kit

2

Height includes Universal Projector Bracket.

2

:

2

:

1

/2" NPT pipe in the required length. Pipe must be

Accuset Fixed

Extension

by

Accuset

Adjustable

Projector Manufacturer and Model Number:

Copyright © 2006 Draper Inc. Form Accuset_Sub06 Printed in U.S.A.

PROJECT:

ARCHITECT:

CONTRACTOR:

SUPPLIER:

DATE: REVISED:

Accuset Mounts for LCD/DLP Projectors by Draper

9

Page 2 of 4

Specifi cations—Accuset Mounts for LCD/DLP Projectors
by Draper

_______ Accuset Mounts for LCD/DLP projectors, by Draper, Inc.
Universal Projector Bracket: shall be provided for any LCD/DLP projector
under 26 lbs., with threaded ceiling-mounting holes on bottom of projector.
Bracket shall be of steel, with matt black powdercoat fi nish. Machined steel
center column to attach securely to SMS or Accuset ball joint with twist-lock
engagement. Short and long arms interchangeable to fi t virtually any projector
mounting-hole spacing. Infi nite adjustment in both horizontal and vertical axes.
Must enable installer to simply fi nd and easily secure projector’s center of
gravity. Universal Projector Bracket to suspend projector from mount. Clamp/
shelf type brackets not acceptable. Hardware for attaching bracket to projector
provided by Draper—a full set of screws, washers, threaded vertical spacers,
and short and long arms to fi t virtually any projector model. Universal bracket
shall be compatible with all SMS Mounts and Accuset Mounts for LCD/DLP
Projectors. Patent pending.
Accuset Adjustable Mount: Consists of 10-gauge cold rolled steel Ceiling
Plate; two piece telescoping, schedule-40 steel NPT pipe (2" dia. upper pipe

1

/2" dia. lower pipe), threaded and slotted on each end, in choice of

and 1
seven adjustable ranges; Extension Adapter; Bracket Adapter and Universal
Projector Bracket. Mount shall be infi nitely adjustable within its specifi ed
range. Size ranges to be (153/8"–173/4"] [213/8"–293/4" [293/4"–463/4"] [443/4"–
773/4"] [573/4"–1013/4"] [693/8"–1253/4"] [813/8"-1493/4"]). Telescoping movement
of lower pipe shall provide infi nite height adjustability. Positive stop shall
prevent separation of columns. Extension Adapter shall be used to lock lower
column in position. Bracket Adapter shall have steel ball joint to which the
Universal Projector Bracket attaches with twist-lock engagement. Steel ball
joint shall have up to 30° roll or pitch adjustment and 360° yaw adjustment.
Two setscrews shall be used to lock ball joint in position. Lower pipe and
Bracket Adapter can be further secured using supplied Torx or security
screws. Matt black powdercoat fi nish. Accuset Adjustable Mount to provide
built-in cable management. Maximum load shall be 26 lbs. Installer shall
provide mounting hardware appropriate to ceiling conditions.
Accuset Fixed-Extension Mount: Consists of 10-gauge cold rolled steel
Ceiling Plate; one piece of 11/2" dia., schedule-40 steel NPT pipe, threaded
and slotted on each end, in choice of 12 fi xed lengths; Bracket Adapter and
Universal Projector Bracket. Mount shall have overall fi xed length of ([141/2
"][201/2"][261/2"][321/2"][441/2"][561/2"][681/2"][801/2"][921/2"]
[1041/2"] [1161/2"][1281/2"]). Bracket Adapter shall have steel ball joint to
which the Universal Projector Bracket attaches with twist-lock engagement.
Steel ball joint shall have up to 30° roll or pitch adjustment and 360° yaw
adjustment. Two setscrews shall be used to lock ball joint in position. Pipe
and Bracket Adapter can be further secured using supplied Torx or security
screws. Matt black powdercoat fi nish. Accuset Fixed Extension Mount to
provide built-in cable management. Maximum load shall be 26 lbs. Installer
shall provide mounting hardware appropriate to ceiling conditions.
Accuset Component Kit: Consists of Ceiling Plate, Bracket Adapter and
Universal Projector Bracket. Installer to furnish 11/2" NPT pipe in required
length. Pipe must be threaded on both ends.
Accuset Low Profi le Fixed Mount: Ceiling mount shall consist of a steel ball
joint and Aero Universal Projector Bracket. Mount shall be 2” long, and shall
securely attach to ceiling with steel mounting plate (provided). Installer shall
provide mounting hardware appropriate to ceiling conditions. Steel ball joint
attaches to the Aero Universal Projector Bracket with twist-lock engagement.
Min. overall height of assembled unit shall be 47/8". Mount shall provide up
to 30° roll or pitch adjustment and 360° yaw adjustment at ball joint. Two
setscrews lock ball joint in position. Maximum load to be 26 lbs.

to Accuset Ceiling Plate and the other to a Bracket Adapter and Universal
Projector Bracket. Max. load 26 lbs.
Accuset Suspended-Ceiling Panel: 23
panel, fi nished white, with threaded collar for attaching threaded pipe or Flush
Extension (provided) and adjustable collar to allow a 10" range of left-to-right
or front-to-back projector adjustment, depending on orientation of panel.
Knockouts provided for electrical wiring; knockouts fi t standard j-box cover
plate. Four turnbuckles and four 50" lengths of 62/1000 steel wire provided for
suspending panel. Max. load 26 lbs.
Accuset Low Profi le Suspended-Ceiling Panel: Same as Suspended­Ceiling Panel (above), but with ball joint and Universal Projector Bracket. Max.
load 26 lbs.

Please Note: Accuset Mount accessories will work with schedule 40
steel pipe, but not schedule 80 steel pipe.

Optional Accessories:

Angled Ceiling Plate: 8" x 6" x 2" (W x L x H) 10-gauge cold rolled steel
plate attaches to vaulted or angled ceilings. Matt black powdercoat fi nish. Max.
load 26 lbs. Adjusts from 0-25° allowing the projector to remain level. Must be
used with Accuset Ceiling Plate.
Flush Extension: 11/2" long x 11/2" dia. steel NPT pipe, threaded the entire
length. For fi xed mounting projector close to the ceiling. Connect one end

3

/4" x 233/4" 16-gauge cold rolled steel

Accuset Low Profi le Projector Mount

with Universal Projector Bracket

Accuset Low Profi le Projector Mount Dimensions

with Universal Projector Bracket

33/8"

3

/16"

47/8"

Universal Projector Bracket Coverage Area

Max. approx.

O 15"

(380 mm)

"

2

/

1

Min. approx.

O 5

(140 mm)

www.draperinc.com

(765) 987-799
