STORM
INSTRUCTIONS FOR
2000W 230V
Hot Air Gun
Stock No.15225 Part No.HG2000SF
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.
IMPORTANT:
The heating wire element of this
hot air gun has a protective coating.
Please note that due to the
vaporization of this coating, some
smoke may be generated during
the first 20-30 seconds
use only.
GENERAL INFORMATION
These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools
policy of continuous improvement determines the right to make modifications without prior warning.
1. TITLE PAGE
1.1 INTRODUCTION:
USER MANUAL FOR:
2000W 230V Hot Air Gun
Stock no. 15225.
Part no. HG2000SF.
1.2 REVISIONS:
Date first published April 2016
As our user manuals are continually updated, users should make sure that they use the very
latest version.
Downloads are available from: http://www.drapertools.com/manuals
DRAPER TOOLS LIMITED WEBSITE: drapertools.com
HURSLEY ROAD PRODUCT HELP LINE: +44 (0) 23 8049 4344
CHANDLER’S FORD GENERAL FAX: +44 (0) 23 8026 0784
EASTLEIGH
HAMPSHIRE
SO53 1YF
UK
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
WARNING! Information that draws attention to the risk of injury or death.
CAUTION! Information that draws attention to the risk of damage to the product or
surroundings.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other
form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
2. CONTENTS
2.1 CONTENTS
PAGE CONTENT PAGE
1 TITLE PAGE
1.1 INTRODUCTION ............................................................................................... 2
1.2 REVISION HISTORY........................................................................................... 2
1.3 UNDERSTANDING THIS MANUAL ................................................................... 2
1.4 COPYRIGHT NOTICE......................................................................................... 2
2 CONTENTS
2.1 CONTENTS ........................................................................................................ 3
3 GUARANTEE
3.1 GUARANTEE ..................................................................................................... 4
4 INTRODUCTION
4.1 SCOPE ............................................................................................................... 5
4.2 SPECIFICATION ................................................................................................. 5
4.3 HANDLING & STORAGE ...................................................................................5
5 HEALTH & SAFETY INFORMATION
5.1 GENERAL POWER TOOL SAFETY WARNINGS ................................................. 6
5.2 ADDITIONAL SAFETY RULES FOR HOT AIR GUNS .......................................... 7
5.3 CONNECTION TO THE POWER SUPPLY ........................................................... 7
6 TECHNICAL DESCRIPTION
6.1 IDENTIFICATION ............................................................................................... 8
7 UNPACKING & CHECKING
7.1 PACKAGING...................................................................................................... 9
7.2 WHAT’S IN THE BOX ........................................................................................ 9
8 BASIC HOT AIR GUN OPERATIONS
8.1 ON/OFF SWITCH ...............................................................................................10
8.2 FREESTANDING OPERATION............................................................................ 10
8.3 PAINT REMOVAL FROM WINDOW FRAMES................................................... 11
8.4 HEATING AND SHAPING PLASTIC TUBING...................................................... 11
8.5 DEFROSTING WATER PIPES.............................................................................. 11
9 MAINTENANCE
9.1 .......................................................................................................................... 12
10 EXPLANATION OF SYMBOLS
10.1 EXPLANATION OF SYMBOLS ...........................................................................13
11 DISPOSAL
11.1 DISPOSAL .........................................................................................................14
DECLARATION OF CONFORMITY .....................................................................................ENCLOSED
3
3. GUARANTEE
3.1 GUARANTEE
Draper tools have been carefully tested and inspected before shipment and are guaranteed
to be free from defective materials and workmanship.
Should the tool develop a fault, please return the complete tool to your nearest distributor
or contact Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: (023) 8049 4333 or Product Help Line (023) 8049 4344.
A proof of purchase must be provided with the tool.
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee period covering
parts/labour is 12 months from the date of purchase except where tools are hired out when
the guarantee period is 90 days from the date of purchase. The guarantee is extended to 24
months for parts only. This guarantee does not apply to normal wear and tear, nor does it
cover any damage caused by misuse, careless or unsafe handling, alterations, accidents, or
repairs attempted or made by any personnel other than the authorised Draper warranty
repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges
will be quoted and made accordingly.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of
its terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated receipt
or invoice to verify your proof of purchase within the guarantee period.
Please note that this guarantee is an additional benefit and does not affect your statutory
rights.
Draper Tools Limited.
4
4. INTRODUCTION
4.1 SCOPE
Ideal for paint stripping, thawing etc. It is intended for domestic and light commercial use
only. Any other application is considered misuse.
4.2 SPECIFICATION
Stock No... .......................................................................................................................... 15225
F S0002GH .......................................................................................................................... . oN tr aP
Rated voltage .............................................................................................................230V~50Hz
Rated input........................................................................................................................ 2000W
Temperature (approx.)
Setting 1 ..................................................................................................................... 50ºC
Setting 2 ................................................................................................................... 450ºC
Setting 3 ................................................................................................................... 600ºC
Air flow volume
Setting 1 ............................................................................................................. 500L/min
Setting 2 ............................................................................................................. 250L/min
Setting 3 ............................................................................................................. 500L/min
Weight (machine only) ..................................................................................................... 0.83kg
4.3 HANDLING & STORAGE
IMPORTANT: Please note this machine is fitted with a safety thermal overload protection. If
the product is used continuously too close to the work piece (i.e. misused) resulting in over
heating and the machine potentially catching fire, the thermal overload protection will be
activated and stop the heating element from operating within the machine. This will cause
the gun to blow cool air until the inner components of the heat gun have cooled sufficiently.
This process takes approximately 2 minutes. Repeat overloading will lead to permanent
damage.
Remember the nozzle will remain hot for sometime - a safe storage location should be used.
Store in a dry location out of the reach of children.
5
5. HEALTH & SAFETY INFORMATION
5.1 GENERAL POWER TOOL SAFETY
WARNINGS
WARNING: Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your
mains operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, nonskid safety shoes, hard hat, or hearing
protection used for appropriate conditions will
reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off position before connecting to power
source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools
that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of these
devices can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source
and/or battery pack from the power tool before
making any adjustments, changing accessories,
or storing power tools. Such preventive safety
measures reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with
edges are less likely to bind and are easier
sharp cutting
to control.
g) Use the power tool, accessories and tool
bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
6
5. HEALTH & SAFETY INFORMATION
5.2 ADDITIONAL SAFETY RULES FOR HOT AIR GUNS
NOTE: A FIRE COULD ARISE IF THIS HOT AIR GUN IS NOT USED WITH CARE.
1. Ensure that the hot air gun is switched OFF before connecting to the power supply.
2. Do not use this hot air gun as a hair dryer.
3. Do not touch the hot metal nozzle.
4. Allow the hot air gun to cool down completely before storing.
5. Do not direct the flow of hot air at persons or animals.
6. Do not hold the metal nozzle too close to the work piece as the air flow will be restricted
and may cause the hot air gun to overheat. Position the nozzle at least 25mm from the
work surface.
7. Use in a well ventilated area as poisonous or inflammable fumes or gases may be
produced from certain plastics, paints or similar materials.
8. When working with or near easily combustible materials and inflammable gases, take
special care. (Do not apply heat to any one area for long periods of time).
9. Heat may be conducted to combustible materials which are not visible from the
work area.
10. Never leave the hot air gun running whilst unattended.
11. Do not look directly into the metal nozzle when the machine is switched on.
12. Place the hot air gun in its free standing position (page 10) after use and allow it to cool
down before storing it away.
5.3 CONNECTION TO THE POWER SUPPLY
Make sure the power supply information on the machine’s rating plate are compatible with
the power supply you intend to connect it to.
This product comes supplied with a UK standard 3 pin plug fitted. It is designed for
connection to a domestic power supply rated at 230V AC.
This appliance is Class II† and is designed for connection to a power supply matching that
detailed on the rating label and compatible with the plug fitted.
If an extension lead is required, use an approved and compatible lead rated for this
appliance. Follow all the instruction supplied with the extension lead.
†Double insulated : This product requires no earth connection as supplementary insulation
is applied to the basic insulation to protect against electric shock in the event of failure of
the basic insulation.
Apart from replacing the fuse in the plug, no other electrical work is recommended on this
hot air gun.
7
6. TECHNICAL DESCRIPTION
6.1 IDENTIFICATION
Plug & cable
Switch On & Off (3 settings)
Metal nozzle
8
Support foot
Air intake vents
7. UNPACKING & CHECKING
7.1 PACKAGING
Carefully remove the product from the packaging and examine it for any sign of damage
that may have happened during shipping. Lay the contents out and check them against the
parts shown below. If any part is damaged or missing; please contact the Draper Help Line
(the telephone number appears on the Title page) and do not attempt to use the tool.
The packaging material should be retained at least during the guarantee period: in case the
machine needs to be returned for repair.
Warning! Some of the packaging materials used may be harmful to children. Do not leave
any of these materials in the reach of children.
If any of the packaging is to be thrown away, make sure they are disposed of correctly;
according to local regulations.
7.2 WHAT´S IN THE BOX?
As well as the product; there are several parts not fitted or attached to it.
Concentrator nozzle
Glass protection nozzle
Hooked nozzle
Edge nozzle
Paint Scraper
9
8. BASIC HOT AIR GUN OPERATIONS
NOTE: Remove the plug from the socket before carrying
out adjustment, servicing or maintenance.
IMPORTANT: Ensure that the machine is switched OFF
before connecting to the power supply.
8.1 ON/OFF SWITCH - FIG.1
The ON/OFF switch has four positions/settings.
Position 0 is off.
Position 1 is “cool heat” which is a steady 50°C heat
(approx.) at 500 L/min
Position 2 is heat approximately 450°C (approx.)
at 250L/min.
Position 3 is heat approximately 600°C (approx.)
at 500L/min.
8.2 FREESTANDING OPERATION - FIG.2
This hot air gun can be positioned freestanding. This
allows the user to have both hands free which is
essential for certain applications, e.g. pipe bending,
plastic welding, etc. Position the hot air gun on it’s end,
only on a level suitable surface.
NOTE: Never leave the hot air gun unattended or
switched on.
The following instructions on next page should only be
used as a guide as the ideal temperature should be
ascertained by performing a test on the workpiece.
Heating efficiency will vary depending on the properties
of the workpiece, and the distance kept between the
metal nozzle and the workpiece itself.
FIG.1
FIG.2
IMPORTANT: THERMAL OVERLOAD PROTECTION:
Please note this machine is fitted with a safety thermal
overload protection. If the product is continuously used
too close to the workpiece resulting in over heating and
the machine potentially catching fire, the thermal
overload protection will be activated and stop the
machine. This feature will reset once temperature has
fallen (approx 2mins).
NOTE: The heat gun fan continues to run when the
thermal overload protection is activated, this draws cool
air through the heat gun to cool it down as quickly as
possible.
WARNING: Remember the nozzle will remain hot for
sometime - a safe storage location should be used.
10
8. BASIC HOT AIR GUN OPERATIONS
8.3 PAINT REMOVAL FROM WINDOW
FRAMES - FIG.3
IMPORTANT: Do not direct the hot air gun at the glass
during use as it may crack. Always use the glass
protection nozzle . Do not touch the glass with the
hot nozzle.
8.4 HEATING AND SHAPING PLASTIC
TUBING - FIG.4
Fit the reflector hook nozzle . Switch the hot air gun
on to the low heat setting and, carefully heat the
tubing evenly moving it from side to side.
8.5 DEFROSTING WATER PIPES - FIG.5
IMPORTANT: Do not defrost plastic tubing/piping.
Fit the reflector hook nozzle . Switch the hot air gun
on to one of the lowest heat settings and, gently heat
the frozen area of the pipe starting from the edge of
the area and moving in towards the centre.
IMPORTANT: Take care not to heat the pipe too quickly
as this could cause the pipe to crack and burst. Do not
overheat water pipe joints as these are only soldered
together (max. 200ºC).
FIG.3
FIG.5
FIG.4
11
9. MAINTENANCE
9.1 MAINTENANCE
Regular inspection and cleaning reduces the necessity for maintenance operations and will
keep your tools in good working condition.
If the replacement of the supply cord is necessary, this has to be done by the manufacturer or
his agent in order to avoid a safety hazard.
12
10. EXPLANATION OF SYMBOLS
10.1 EXPLANATION OF SYMBOLS
WEEE
Do not dispose of Waste Electrical
& Electronic Equipment in with
domestic rubbish
Class II construction
(Double insulated)
For indoor use.
Do not expose to rain.
Warning!
Wear goggles.
Warning!
Wear gloves.
Warning!
Read the instruction manual
13
11. DISPOSAL
11.1 DISPOSAL
- At the end of the machine’s working life, or when it can no longer be repaired, ensure
that it is disposed of according to national regulations.
- Contact your local authority for details of collection schemes in your area.
In all circumstances:
• Do not dispose of power tools with domestic waste.
• Do not incinerate.
• Do not abandon in the environment.
• Do not dispose of WEEE*
as unsorted municipal waste.
* Waste Electrical & Electronic Equipment.
14
NOTES
15
CONTACTS
- DRAPER TOOLS LIMITED,
Hursley Road, Chandler's Ford,
Eastleigh, Hampshire. SO53 1YF. U.K.
- Help Line: (023) 8049 4344
- Sales Desk: (023) 8049 4333
- General Enquiries: (023) 8026 6355
- Service/Warranty Repair Agent
For aftersales servicing or warranty repairs, please
contact the Draper Tools Help Line for details of an
agent in your local area.
YOUR DRAPER STOCKIST
RDDH0416
drapertools.com
Loading...
