INSTRUCTIONS FOR
150kg Log Stand
Stock No.32273 Part No.AGP101
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.
GENERAL INFORMATION
These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools
policy of continuous improvement determines the right to make modifications without prior warning.
1. TITLE PAGE
1.1 INTRODUCTION:
USER MANUAL FOR:
150kg LOG STAND
Stock no. 32273
Part no. AGP101
1.2 REVISIONS:
Date first published May 2013
As our user manuals are continually updated, users should make sure that they use the very
latest version.
Downloads are available from: http://www.drapertools.com/b2c/b2cmanuals.pgm
DRAPER TOOLS LIMITED WEBSITE: www.drapertools.com
HURSLEY ROAD PRODUCT HELPLINE: +44 (0) 23 8049 4344
CHANDLER’S FORD GENERAL FAX: +44 (0) 23 8026 0784
EASTLEIGH
HAMPSHIRE
SO53 1YF
UK
1.3 UNDERSTANDING THIS MANUALS SAFETY CONTENT:
WARNING! Information that draws attention to the risk of injury or death.
CAUTION! Information that draws attention to the risk of damage to the product or
surroundings.
NOTE! Important information.
1.4 COPYRIGHT © NOTICE:
Copyright © Draper Tools Limited.
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other
form or means without written permission from Draper Tools Limited.
In all cases this copyright notice must remain intact.
2. CONTENTS
2.1 CONTENTS
Page content
1 TITLE PAGE
1.1 INTRODUCTION ............................................................................................... 2
1.2 REVISION HISTORY........................................................................................... 2
1.3 UNDERSTANDING THIS MANUAL ................................................................... 2
1.4 COPYRIGHT NOTICE.........................................................................................2
2 CONTENTS
2.1 CONTENTS ........................................................................................................ 3
3 GUARANTEE
3.1 GUARANTEE ..................................................................................................... 4
4 INTRODUCTION
4.1 SCOPE ............................................................................................................... 5
4.2 SPECIFICATION ................................................................................................. 5
4.3 HANDLING & STORAGE ...................................................................................5
5 HEALTH & SAFETY INFORMATION
5.1 GENERAL SAFETY INSTRUCTIONS ...................................................................6
6 TECHNICAL DESCRIPTION
6.1 IDENTIFICATION ............................................................................................... 7
7 OPERATING THE LOG STAND
7.1 OPERATING THE LOG STAND .......................................................................... 8
8 MAINTENANCE
8.1 MAINTENANCE................................................................................................. 10
9 DISPOSAL
9.1 DISPOSAL..........................................................................................................11
10 NOTES
DECLARATION OF CONFORMITY .....................................................................................ENCLOSED
Page
3
3. GUARANTEE
3.1 GUARANTEE
Draper
to be free from defective materials and workmanship.
Should the product develop a fault, please return the complete item to your nearest distributor
or contact Draper Tools Limited, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF. England.
Telephone Sales Desk: (023) 8049 4333 or Product Helpline (023) 8049 4344.
A proof of purchase must be provided with the item.
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee period covering
parts/labour is 12 months from the date of purchase except where items are hired out when the
guarantee period is ninety days from the date of purchase. The guarantee is extended to 24
months for parts only. This guarantee does not apply to normal wear and tear, nor does it cover
any damage caused by misuse, careless or unsafe handling, alterations, accidents, or repairs
attempted or made by any personnel other than the authorised Draper warranty repair agent.
Note: If the tool is found not to be within the terms of warranty, repairs and carriage charges
will be quoted and made accordingly.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your Draper guarantee is not effective unless you can produce upon request a dated receipt or
invoice to verify your proof of purchase within the guarantee period.
Please note that this guarantee is an additional benefit and does not affect your statutory rights.
Draper Tools Limited.
products have been carefully tested and inspected before shipment and are guaranteed
4
4. INTRODUCTION
4.1 SCOPE
This log stand (Stock No.32273) is a manually operated saw horse, designed to enable the
efficient and safe sawing of logs and branches.
Its powder coated steel construction means it is suitable for home/DIY use or by professional
aborists for the sole purpose of sawing logs upto 150kg in weight.
4.2 SPECIFICATION
Stock no ............................................................................................................................ 32273
Part no .......................................................................................................................... AGP101
Max. log length .................................................................................................................... 4M
Min. log diameter ........................................................................................................... 50mm
Max. log diameter ......................................................................................................... 250mm
Max. log weight .............................................................................................................. 150kg
Dimensions (L x W x H) ............................................................................ 1100 x 380 x 900mm
Weight .................................................................................................................... 10.8kg (net)
..................................................................................................................... 12kg (gross)
4.3 HANDLING & STORAGE
Although this machine is strong and durable, care must still be taken when handling and
lifting. Dropping this machine will have an effect on the fixings used in it’s construction and
may also result in personal injury. This machine is not a toy and must be respected.
This product is likely to be used outside and be subjected to all number of weather variables.
Care should be taken to avoid leaving if exposed to the elements as this could cause rusting
which will weaken the product. Best policy is to store in a dry location when not in use.
5
