INTRODUCTION
4
Thank you for choosing the new Draminski GMM mini
grain moisture meter. This excellent device will be very
useful in your activity. It is small and light, easy to take to
the eld, and gives quick and precise measurements, allowing to determine the exact grain moisture.
Innovative solutions, state-of-the-art technology and
great versatility due to the possibility of updating through
the USB port, make it a good long-term investment.
Increase your crops and enjoy your work with the Draminski GMM mini grain moisture meter.
The manufacturer – DRAMIŃSKI S.A. oers its users great
knowledge and reserves the right to introduce hardware
and rmware modications. DRAMIŃSKI S.A. reserves the
right to amend the contents of this instruction manual.
Read this instruction manual thoroughly before putting
this device into operation. It will guarantee the safety
of operation as well as long and reliable functioning of
the tool.
Declaration of conformity is available for review at the
seat of DRAMIŃSKI S.A. at 17 Owocowa st., 10-860 Olsztyn,
Poland.
For more information and data, visit our website
www.draminski.com
Please note that electronic equipment
and batteries must not be disposed of
in household waste containers. Used
equipment and appliances should
be delivered to special disposal facilities, according to the valid regulations.
Proper waste disposal helps to save the
natural environment.
INTRODUCTION
EN
5
COMPONENTS
SECTION
1
6 SECTION 1 | COMPONENTS
COMPONENTS:
1. Draminski GMM mini grain moisture meter
2. mini-USB port rubber cap
3. 2 AA type batteries, 1.5 V (LR6)
4. reusable transport packaging (made of plastic)
5. special dispenser with a damper
6. instruction manual
7. USB cabel for computer connection
1
2
3
4
6
5
7
EN
7
PRODUCT DESCRIPTION
SECTION
2
8 SECTION 2 | PRODUCT DESCRIPTION
PRODUCT DESCRIPTION
1. heavy duty ABS plastic casing
2. measuring chamber with digital temperature sensor
3. graphic LCD display with LED backlight
4. membrane keyboard
5. battery compartment for 2 AA type batteries, 1.5V (LR6)
6. mini-USB port with rubber dust cap
7. dispenser
8. dispenser damper
1
2
4
5
3
7
8
6
EN
9
APPROXIMATE DIMENSIONS
12,5 cm
19,0 cm
SECTION 2 | PRODUCT DESCRIPTION
8,0 cm
11,0 cm
8,0 cm
15,0 cm
10 SECTION 2 | PRODUCT DESCRIPTION
EN
11
KEYBOARD FUNCTIONS
SECTION
3
12
– device on/o
– hold for 5 seconds to switch o the device
(Note: the GMM mini can be switched o
also by using the menu option “Shutdown”. If the device is not in use for a long
time, it will switch o automatically to
save the batteries)
– hold for 2 seconds to switch on the main
menu
– program function cancel
– program function enter
– measuring program start
– menu scrolling
– setting values of menu options
– grain selection from the list
– delete average result in given sample
moisture measurement
SECTION 3 | KEYBOARD FUNCTIONS
EN
13
DEVICE OPERATION
SECTION
4
14
The GMM mini is ready for use when batteries are
properly installed in their compartment (check polarity).
Switch on the device using
.
a) a welcome message will be displayed, showing
the device name, software version, calibration version and serial number:
www.draminski.com
Grain Moisture Meter mini
Firmware v: 1.42 K:1.10
SN: GM010007
b) next, a list of available species will be displayed
and device model and current battery status will
appear in the upper part of the screen (recently
tested species will be backlit):
GMM mini
Choose species
Rye
Canola
Spring barley
Oat
Caution! If batteries are too weak to continue work,
the device will display the following message:
GMM mini
Change batteries
which indicates that batteries must be replaced.
c) in order to save batteries, when no key is pressed
for a certain time, the device will go to a standby
mode and the backlight will turn o (that time can
be changed through the proper menu option –
see SETTINGS section). Press any button to return
to the operation mode.
SECTION 4 | DEVICE OPERATION
EN
15
d) if the GMM mini remains in the standby mode for
several minutes, it will shut o automatically (time
setting possible in menu). Countdown from 10 to
0 will display on the screen – press any button to
stop, or the device will shut o automatically to
save power:
GMM mini
Power o in 5 s
GMM mini
Power o in 1 s
e) for manual switch o, hold button for 5 sec-
onds, or select “Turn o!” in the main menu.
SECTION 4 | DEVICE OPERATION
16 SECTION 4 | DEVICE OPERATION
EN
17
INSTRUCTIONS
FOR MEASUREMENTS
SECTION
5
18
Following the manual as well as experience gained
in time will largely facilitate reaching the expected
accuracy and repetition of sample moisture measurements.
– size of grains and purity of test sample deter-
mine obtaining a correct result. Cha, screenings and dirt content within the sample should
be as low as possible.
– water remaining on top of the sample (e. g. dew)
can aect measurement result. Samples should be
aired before measurement to avoid it,
– the dispenser included in the set must be used
to dose a proper amount of grain because the
way the measuring chamber is lled is important and determines measurement accuracy.
Fill the dispenser with small surplus and remove the damper always the same way,
– while measuring, when „Chamber empty?”
message displays, check whether the chamber
is empty, clean and dry and then press button to conrm, because the device reads the parameters of the chamber before it is lled with
grain,
– the nal result of measuring should be the aver-
age value of e.g. 3 recent tests of a given sample,
which is calculated automatically and displayed in
the bottom right corner of the screen (number of
measurements used for calculation of the average
value can be changed in the menu),
– make sure that the measuring chamber tempera-
ture is the same as the sample temperature (do
not pour cool grain into hot device (e.g. after being
exposed to sunlight) and vice-versa). The temperature sensor may react with a certain delay, since
the measurement chamber walls have brass lining,
SECTION 5 | INSTRUCTIONS FOR MEASUREMENTS
EN
19
– each species has a dierent range of measured
moisture. Results beyond the set range are marked
with a proper sign:
„<8.5%” (below the range), when moisture of tested
sample is lower than 8.5%,
„>35.0%” (above the range), when moisture of tested sample is higher than 35%,
– if signicant departures are found in the result for
a given species, either too high or too low by a
similar value within the entire measurement range
in comparison with the drying-and-weighing test
method, indications must be modied (see: MODIFYING MOISTURE INDICATIONS).
SECTION 5 | INSTRUCTIONS FOR MEASUREMENTS
20 SECTION 5 | INSTRUCTIONS FOR MEASUREMENTS
EN
21
MEASUREMENTS
SECTION
6
22 SECTION 6 | MEASUREMENTS
In order to measure grain moisture:
a) switch the device on using , button. After a
short welcome message, the list of available species will appear on screen. The GMM mini will always indicate the name of the recently selected
species e.g Canola:
GMM mini
Choose species
Canola
Spring barley
Oat
Sunower seeds
b) use or button to select the species to be
tested and conrm with
c) when proper grain is selected, the device will ask
if the measurement chamber is empty and display
the current chamber temperature:
GMM mini
temp: 23.7 °C
Is chamber empty?
Canola
at that point, check if the measurement
chamber is really empty and clean. Conrm
with
button,
d) when the status is conrmed, “Wait!” message will
be displayed for 1 second:
GMM mini
Wait!
Canola
do not touch the measurement chamber or
put anything inside when that message is
displayed because the device has to read the
chamber parameters before sample insertion,
in order to improve the measurement accuracy.
e) now the device is ready for sample insertion. Use
the dispenser to place grain inside the chamber.
(Placing the device on an even and rm foundation is recommended)
EN
23
GMM mini
temp: 23.7 °C
Pour in sample
Canola
Filling the measurement chamber using the
dispenser:
Place the damper in the dispenser slot until it
locks. Place grain inside the dispenser with a small
surplus.
CAUTION!
If the dispenser is not lled completely, large
measurement error may occur. Overlling has
smaller eect on the result.
Do not compress grain in the dispenser.
When these actions are completed, place the lled
dispenser on the chamber (bottom edge of the
dispenser is specially proled to match the GMM
mini casing). Then remove the damper to ll the
measurement chamber with grain.
CAUTION!
To ll the measurement chamber, remove the
damper with a quick and smooth movement
within around 1 second (it is important that the
damper is removed always the same way).
When pouring our, remove the damper slowly, for
2-3 seconds, letting our to pour in portions into
the chamber.
Upper edges of the measurement chamber
must be completely covered.
SECTION 6 | MEASUREMENTS
24
f) after lling the measurement chamber, the GMM
mini will automatically display „Press OK”
GMM mini
temp: 23.7 °C
Press OK
Canola
do not move or shake the device after that, just
press .
The dispenser should stay on the device until
the result is displayed.
g) after conrming with , the device will display
„Analysing” message. After 2 seconds moisture
measurement result (%) and sample temperature
will appear (temp. in °C or °F, as set by the user):
GMM mini
temp: 23.7 °C
Analysing
Canola
GMM mini
temp: 23.9 °C
8.8%
Canola
the displayed result reects temperature eect
(automatic temperature compensation)
CAUTION!
Pour grain into the chamber only if the display
shows „Pour in sample” message
h) when the measurement is completed, empty the
chamber and press to start a new measurement procedure (follow the messages displayed
on screen), or press to return to the list and
select another species.
CAUTION!
The measurement chamber must be cleaned care-
fully when changing the tested grain type and
when testing samples with varied or high moisture.
SECTION 6 | MEASUREMENTS
EN
25SECTION 6 | MEASUREMENTS
i) the nal result of moisture measurement should be
the average of e.g. 3 recent tests of a given sample.
The device determines the average value automatically and displays it in the bottom right corner of
the screen
GMM mini
temp: 23.9 °C
8.8%
Canola
avg: 8.9%
the number of measurements used for calculation
of the average value can be changed in the main
menu (see SETTINGS section). Results above and
below the set range are not included in the average value. In order to start calculating a new average value, press to clear or return to the list of
species using
j) when measurements are completed, switch o the
device to save batteries, holding button for 5
seconds or by selecting “Turn o!” option in the
main menu.
26 SECTION 6 | MEASUREMENTS
EN
27
LIST OF AVAILABLE SPECIES AND
ADDING NEW TYPES OF GRAIN
SECTION
7
28 SECTION 7 | LIST OF AVAILABLE SPECIES AND ADDING NEW TYPES OF GRAIN
The Draminski GMM mini grain moisture meter is capable of storing in its memory a few hundred dierent types of grain to be used in measurements. The
list of available species may vary in each device, depending on current oer in the country of purchase.
Current list of all available species is available on the
manufacturer’s website www.draminski.com in
Products / Moisture Meters / GMM mini.
Users of the Draminski GMM mini grain moisture
meters may activate additional species by entering
a special code in the main menu, after selecting the
option “Add species” (see: SETTINGS). In order to get
the special actvation code for a chosen grain type,
please contact us:
e-mail: wilgo@draminski.com
tel: +48 89 527 11 30
or your local authorised distributor of Draminski
products.
Contact us if you have a grain type not included in
the list on our website or a special grain type that
you would like to test. We are open for remote cooperation to add new species congured according
to your needs, that could be activated in your device
using a special code.
These unique possibilities make the GMM mini a universal device that will oer its unlimited capabilities
even after many years of use.
EN
29
UPDATING VIA USB
SECTION
8
30 SECTION 8 | UPDATING VIA USB
The Draminski GMM mini is equipped with a miniUSB port that allows the user to update the rmware,
data stored in the device memory, list of available
language versions and also activate new functions
of the device, or change the list of available species.
Check availability of new updates on the manufacturer’s website www.draminski.com in Products /
Moisture Meters / GMM mini.
To get through the update procedure, follow the
step-by-step guide available on our website.
Our programmers have strived for making the update as easy as possible, so even most inexperienced
users will be able to do it.
Any questions or doubts? Do not hesitate to contact
our specialists:
e-mail: wilgo@draminski.com
tel: +48 89 527 11 30
EN
31
MODIFICATION
OF MOISTURE INDICATIONS
SECTION
9
32 SECTION 9 | MODIFICATION OF MOISTURE INDICATIONS
The Draminski GMM mini grain moisture meter
stores moisture curves for each species, determined
on the basis of results for normalised samples (bulk
density of grain and mass of 1000 seeds), which
guarantees accurate and repeatable results. However, it may happen that crop of a given year varies
from normalised seeds (due to various factors) and
departures may occur in moisture indications.
Such factors include:
1. seed formation and maturity
– weak and badly formed seeds = results under-
rated,
2. specic features of a given grain
– very tiny seeds = results underrated,
– very large seeds = results overrated,
3. degree of contamination and screenings = results
usually underrated,
4. degree of damage caused by pests and fungi.
NOTE!
Results of measurements should be compared only
with the laboratory drying-and-weighing test, not
with results of other moisture meters, as they may
be misleading.
The Draminski GMM mini grain moisture meter
enables the user to modify (adjust) measurement
indications.
In any case of modication, each grain type is
treated individually. When a modication is made,
an asterisk (*) will be displayed next to the grain
name, while during the measurement, a note will
be displayed in the upper right corner of the screen,
showing the value of adjustment of indication for a
given grain (the result will automatically reect the
modication):
EN
33
before after
GMM mini
temp: 24.0 °C
9.9%
Canola
GMM mini
temp: 24.0 °C
mod: -0.3 %
9.6%
*Canola
We recommend restoring factory settings in
each following year and make another adjustment of indications (modication) if required.
When factory settings are restored, the asterisk
(*) next to the grain name disappears.
For a step-by-step guide for modication of
moisture indications see SETTINGS section.
SECTION 9 | MODIFICATION OF MOISTURE INDICATIONS
34 SECTION 9 | MODIFICATION OF MOISTURE INDICATIONS
EN
35
SETTINGS
SECTION
10
36 SECTION 10 | MAIN MENU / SETTINGS
Functions included in the main menu of the device
enable the user to switch o the device quickly, adjust settings to individual needs, add new species
and much more. In order to access the MAIN MENU,
hold button for 2 seconds.
1. Turn o!
To switch o the device, go to the Main Menu using
and pres or to select the Turn o! op-
tion. Conrm with .
GMM mini
Main menu
Turn o!
Species list
>
Settings
Resoult modication
This function allows the user to switch the device o
in a quick and comfortable way, without the necessity to hold
for 5 seconds or to wait until the au-
tomatic shutdown option activates.
2. List of species
To return to the list of species from the Main menu,
use or select the Species list option using or
buttons. Conrm with .
GMM mini
Main menu
Turn o!
Species list
>
Settings
Resoult modication
3. Settings
GMM mini
Main menu
Turn o!
Species list
>
Settings
Resoult modication
GMM mini
Settings
International >
Display >
Power auto o
Number of averages
3.1. International:
GMM mini
Settings
International >
Display >
Power auto o
Number of averages
GMM mini
International
Language >
Temperature scale >
EN
37SECTION 10 | MAIN MENU / SETTINGS
3.1a) language – to change the language version of
the system, select Main menu / Settings / In-
ternational / Language, and choose the language version using or buttons. Conrm with :
GMM mini
International
Language >
Temperature scale >
GMM mini
Language
English
Deutsh
Français
Polski
3.1b) temperature scale – to switch between Celsius
and Fahrenheit scale, select Main menu / Set-
tings / International / Temperature scale,
choose proper temperature scale using or
buttons and conrm with :
GMM mini
International
Language >
Temperature scale >
GMM mini
Temperature scale
Celsius
Fahrenheit
3.2 Display
GMM mini
Settings
International >
Display >
Power auto o
Number of averages
GMM mini
Display
Backlight intensity
Backlight o time
LCD contrast
3.2a) backlight intensity – the device has an energysaving LED-backlit display, however you should
remember that setting stronger backlight results in faster battery discharge. To change
display backlight intensity, go to Main menu
/ Settings / Display / Backlight intensity and
select required value using or buttons.
Conrm your selection with :
GMM mini
Display
Backlight intensity
Backlight o time
LCD contrast
GMM mini
Display
0 100
30%
Backlight intesity
38 SECTION 10 | MAIN MENU / SETTINGS
3.2b) backlight o time – adjust the time after which
the display backlight turns o until any button
is pressed again (the time is measured after the
last use of any keyboard button). To modify
backlight time, go to Main menu / Settings /
Display / Backlight o time, select required
value using or buttons and conrm
with :
GMM mini
Dispay
Backlight intensity
Backlight o time
LCD contrast
GMM mini
Display
Backlight o time
3 250
20 sec
3.2c) contrast – in order to change display contrast,
go to Main menu / Settings / Display / LCD
contrast, select required value using or
buttons and conrm with :
GMM mini
Display
Backlight intensity
Backlight o time
LCD contrast
GMM mini
Display
LCD contrast
0 30
14
3.3 Power auto o
Adjustment of time after which the device shuts
down automatically, starting from the last use of
any keyboard button. To change the automatic shutdown time, go to Main menu / Settings / Power
auto o , select required value using or but-
tons and conrm with :
GMM mini
Settings
International >
Display >
Power auto o
Number of averages
GMM mini
Settings
Power auto o
1 30
2 min
3.4 Numbers of averages
The device automatically calculates the average of
recent measurements. In order to determine how
many measurements should be included in the average, go to Main menu / Settings / Numbers of
averages, select required number using or
buttons and conrm with :
EN
39SECTION 10 | MAIN MENU / SETTINGS
GMM mini
Settings
International
Display
>
>
Power auto o
Number of averages
GMM mini
Settings
Numbers of averages
2 20
3
The average value will appear in the bottom right
corner of the screen (after the third measurement, if
the averaging count is set to „3”):
GMM mini
temp: 23.9 °C
8.8%
Canola
avg: 8.9%
NOTE!
To clear the average value, hold button until the
device displays „Clear average?”. Press to conrm, or to cancel (the average will also clear if you
return to the list and select another species).
4. Resoult modication
Before modifying (adjusting) moisture indications, read MODIFICATION OF MOISTURE INDICATIONS section.
To modify indications for a given type of grain, go
to Main menu / Resoult modication, use or
button to select grain to be modied and determine the value of moisture indication increase or
decrease. Conrm your selection with :
GMM mini
Main menu
Turn o!
Species list
>
Settings
Resoult modication
GMM mini
Choose species
Canola
Spring barley
Oat
Sunower seeds
GMM mini
Canola
Value of change
-6.0 6.0
-0.3 %
40 SECTION 10 | MAIN MENU / SETTINGS
When modication is made, an asterisk (*) appears
next to the grain name, informing on the alteration
of factory settings. During the measurement, the
modication value will be displayed in the upper
right corner of the screen:
GMM mini
Choose species
*
Canola
Spring barley
Oat
Sunower seed
GMM mini
temp: 24.0 °C
mod: -0.3 %
9.6%
*Canola
To restore factory settings, set the modication value
to “0.0%”, the asterisk beside the grain name will dis-
appear:
GMM mini
Canola
Value of change
-6.0 6.0
0.0 %
5. Add species
Before adding a new type of grain, see LIST OF AVAILABLE SPECIES AND ADDING NEW TYPES OF GRAIN.
To add a new type of grain to the list installed in the
device, go to Main menu using , then select Add
species option using or buttons and con-
rm with :
GMM mini
Main menu
Species list
Settings
>
Resoult modication
Add species
GMM mini
Enter code:
< 0 1 2 3 4 5 6 7 8 9
A B C D E F
To enter the special code, select appropriate characters using or buttons and conrm with
(use „<” to delete characters, conrm with ).
When all characters are entered, the device will ask
for conrmation. Press to conrm:
Accept code?
GMM mini
Enter code:
EN
41
Caution! re-entering the same code will result in removing the given grain type from the list available in
the device. Codes are dedicated for one device – to
activate a new grain type in two GMM mini moisture
meters, you will need two dierent codes.
6. About
In order to check device data and contact details of
the manufacturer, go to Main menu using and
select the option About using or buttons.
Press to conrm.
This option allows the user to view the device model, rmware version, serial number and (on page 2)
address and contact details of the manufacturer,
DRAMIŃSKI S.A.
GMM mini
Main menu
Settings
Resoult modication
>
Add species
About
www.draminski.com
Grain Moisture Meter mini
Firmware v:1.42 K:1.10
SN: GM010007
DRAMIŃSKI S.A.
10-860 Olsztyn, Owocowa 17
info@draminski.com
tel: +48 89 527 11 30
Made in Poland
SECTION 10 | MAIN MENU / SETTINGS
42 SECTION 10 | MAIN MENU / SETTINGS
EN
43
BATTERY REPLACEMENT
SECTION
11
44
The device gives an automatic warning when batteries are discharged. In such case, immediately after
switch-on or during the use a graphic symbol and a
message will display. After that, the GMM mini will
switch o automatically.
GMM mini
Change batteries
The moisture meter is powered with two AA type batteries 1.5V (LR6).
In order to change batteries:
– unlock the battery compartment cover on the
underside and remove discharged batteries by
pulling up the ribbon,
– place the ribbon inside the battery compartment,
– install new batteries according with their polarity
signs +/– (pressing the ribbon inside),
– close the battery compartment with the cover.
Press it carefully until it locks with a click, which
indicates that the battery compartment is properly
secured and there is no risk of batteries falling out.
SECTION 11 | BATTERY REPLACEMENT
EN
45
FINAL NOTES
SECTION
12
46 SECTION 12 | FINAL NOTES
– Protect your grain moisture meter against direct
exposure to water. Avoid operating the device in
extreme temperatures. Do not allow moisture con-
densing out of the air to accumulate on metal parts
of the device, as it may aect measurements.
– At the end of the season, clean and dry the measur-
ing chamber carefully. Leaving the device dry guar-
antees long and reliable operation.
– Store the device in dry and warm conditions.
– Before any prolonged storage, remove batteries
from their compartment in order to eliminate the
risk of damage caused by battery leak. We recom-
mend using batteries of leading manufacturers.
– In case of any problems with the device or dicul-
ties in interpretation of the results, please contact
the manufacturer DRAMIŃSKI S.A. or your local au-
thorised distributor before sending the device for
repair.
– Do not dismantle the device on your own. Any
modications or repairs performed by unauthorised persons are unacceptable, as they may result
in permanent damage and void the warranty.
– Always check if the mini-USB port rubber cap is in
place, otherwise dirt might get inside and cause
damage.
EN
47
TECHNICAL DATA
SECTION
13
48 SECTION 13 | TECHNICAL DATA
Approximate weight of device 700 g (with batteries)
Approximate weight of dispenser 140 g
Approximate dimensions 19.0 x 12.5 x 8.0 cm
Power source 2 AA type batteries 1.5 V (LR6)
Current battery status indicator graphic
Battery discharge notication automatic
Power consumption 8.5 mA up to 74 mA (depending on set backlight intensity)
Approximate length of continuous work on one set of batteries 270 hours, with backlight intensity set to 0% / 100 hours with backlight intensity set to 30%
Moisture measurement method capacity
Measurement control Single-chip microcomputer
Measurement chamber lling method Manual, using a dedicated dispenser
Sample volume 270 ml
Moisture measurement accuracy ±1% in range up to 10% / ±1.5% in range above 10% and may increase along with sample moisture
Temperature measurement range -10 °C up to + 85 °C / 14 °F up to 185 °F
Temperature indication resolution 0.1 °C / 0.1 °F
Temperature indication accuracy ± 0.5 °C / ± 0.9 °F
Display graphic LCD with LED backlight, display size 2”
Keyboard membrane
Update through USB
Data storage Internal memory
Internal memory capacity over 400 species in 40 language versions
Additional functions
automatic temperature compensation, pop-up menu, display parameters setting, language version selection, temperature scale
selection, auto-o time adjustment, data and rmware update
Recommended operating temperature range 10 °C up to 35 °C / 50 °F up to 95 °F
Recommended storage temperature 5 °C up to 45 °C / 41 °F up to 113 °F
Loading...
