LoRaWAN Temperature & Humidity Sensor
LSN50v2-S31
OVERVIEW:
The Dragino LSN50v2-S31 is a LoRaWAN Temperature and Humidity Sensor for Internet of Things
solution. It is used to measure the surrounding environment temperature and relative air humidity
precisely, and then upload to IoT server via LoRaWAN wireless protocol.
The temperature & humidity sensor used in LSN50v2-S31 is SHT31, which is fully calibrated,
linearized, and temperature compensated digital output from Sensirion, it provides a strong reliability
and long-term stability. The SHT31 is fixed in a waterproof anti-condensation casing for long
term use.
LSN50v2-S31 supports temperature and humidity alarm feature, user can get alarm for instant notice.
LSN50v2-S31 is powered by 8500mAh Li-SOCI2 battery, It is designed for long term use up to
10 years. (Actually Battery life depends on the use environment, update period.Please check related
Power Analyze report).
Each LSN50v2-S31 is pre-load with a set of unique keys for LoRaWAN registration, register these
keys to local LoRaWAN server and it will auto connect after power on.
Features:
LoRaWAN v1.0.3 Class A
Ultro low power consumption
External 3m SHT31 probe
Measure range -40°C ~ 80°C
Temperature and humitidy alarm
Bands: CN470/EU433/KR920/US915
EU868/AS923/AU915/IN865
AT Commands to change parameters
Uplink on periodically
Downlink to change configure
Sensor Spec:
Temperature Sensor:
Range: -40 to + 80°C
Accurancy: ±0.2 @ 0-90 °C
Resolution: 0.01°C
Long Term Shift: <0.03 °C/yr
Humidity Sensor:
Range: 0 ~ 99.9% RH
Accurancy: ± 2%RH ( 0 ~ 100%RH)
Resolution: 0.01% RH
Long Term Shift: <0.25 %RH/yr
Order Info- LSN50v2-S31-XX
XX:
XX: Frequency Bands, options:
EU433,CN470,EU868,IN865,KR920
AS923,AU915,US915
Dragino Technology Co., Limited
Room 202, Block B, BCT Incubation Bases (BaoChengTai), No.8 CaiYunRoad
LongCheng Street, LongGang District ; Shenzhen 518116,China
Dir ect:+86 755 86610829 |Fax:+86 755 86647123
WWW.DRAGINO.COM
