Dräger Alcotest 6810 GB Operator's Instruction Manual
Alcotest® 6810 GB
Breath Alcohol Screening Device
with Datamanagement
D
Alcotest 6810
Operator Instructions for Use
ST-207-2004_sw_6810.eps
Contents
For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
What‘s what? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Measuring instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Fixing the hand strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Symbols and readings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Fitting the mouthpiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Switch on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Switch off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Automatic switch off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Performing the Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Requirements of the person to be tested . . . . . . . . . . . . . . . . . . . . . 10
Further measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Removing the mouthpiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Symbols on the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Quick menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Set mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Measuring limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Maintenance intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Changing batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Disposal of the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Waste electrical and electronic equipment . . . . . . . . . . . . . . . . . . . . 23
Fault, Cause, Remedy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Order list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2
For your safety
Strictly follow the instructions for use
Any use of the instrument requires full understanding and strict observation of these instructions.
The instrument is only to be used for the purposes specified herein.
Maintenance
Maintenance must only be performed by experts.
We recommend that a service contract be obtained with Dräger Safety and that all repairs be
carried out by them.
Only authentic spare parts may be used for maintenance.
Observe chapter "Maintenance intervals".
Accessories
Only the accessories specified in the order list may be used.
Liability for proper function or damage
The liability for the proper function of the instrument is irrevocably transferred to the owner or
operator to the extent that the instrument is improperly serviced or repaired by personnel not
employed or authorized by Dräger Safety or if the instrument is used in a manner not conform
ing to its intended use.
Dräger cannot be held responsible for damage caused by non-compliance with the recommendations given above.
The warranty and liability provisions of the terms of sale and delivery of Dräger are likewise not
modified by the recommendations given above.
-
Dräger Safety AG & Co. KGaA
-------------------------
® Alcotest is a registered trademark of Dräger.
3
Intended use
For quick measurement of a person’s alcohol intoxication through measurement of the breath
alcohol concentration. For mobile use with batteries.
Preparation
Alcotest® 6810 GB is supplied with standard calibration by the manufacturer.
The date of the last calibration can be found in the quick menu (page 18).
M
OK
Alcotest 6810
00123973_1.eps
4
What‘s what?
Measuring instrument
1 Display
2 Menu button "UP"
3 "OK" button
4 Menu button "DOWN/MENU"
5 Communication port
6 Indicating LED
7 Mouthpiece receptacle
7
6
1
4
M
OK
Alcotest 6810
2
3
5
00223973_1.eps
5
Preparation
Inserting the batteries
Upon initial operation or if the battery symbol on the display indicates "empty".
● Gently press onto the lock of the battery compartment and remove cover.
● Observe correct polarity when inserting the batteries!
● Close battery cover.
05623973_1.eps
00423973_1.eps00523973_1.eps
Batteries to be used
2 each 1.5 V Type Alkaline (Mignon, LR6, AA)
6
+ +
Fixing the hand strap
● Insert the smaller loop into the hole in the housing.
● Thread the longer loop through the eyelet and pull through.
Symbols and readings
The breath alcohol value is measured in μg/100 ml. The result is displayed as
"ZERO", PASS", "ALERT" or "FAIL". For threshold limits see page 20.
Symbols
In these instructions for use several symbols are used corresponding to the messages
indicated on the display:
Battery symbol
Indicates the battery charging status:
OK
Alcotest 6810
00923973_1.eps
Full battery
Battery capacity 2/3
Battery capacity 1/3
Empty battery
7
Note:
The symbols under the battery flap mean: Attention! Please consult the user instructions!
Before changing batteries, please read the instructions.
Buttons
OK
"OK"-button
Confirms entries or selected functions.
Button to switch instrument on and off.
01223973_1.eps
M
"DOWN" and "UP"
Setting of values and selection of menu functions.
Fitting the mouthpiece
● Open packaging. To ensure the mouthpiece stay hygienic, keep the portion to come in
contact with mouth covered by packaging until mouthpiece is correctly fitted to the
instrument.
● With the grooved markings facing up, press the mouthpiece into mouthpiece receptacle
until you hear it click into place.
8
05723973_1.eps05823973_1.eps
● Remove packaging completely and commence breath test.
Mouthpiece can be used with orientation to right or left side.
M
OK
Alcotest 6810
Switching on and off
Switch on
● Keep - button pressed for approx. 1 second until start window is displayed.
Switch off
Unless the device is at "READY" you are unable to turn the device off.
● Keep - button pressed.
The instrument switches off after 2 seconds.
Automatic switch off
The instrument switches automatically off 4 minutes after the last use.
OK
OK
Alcotest 6810 GB
Alcotest 6810 GB
shut-down in 2 sec.
Alcotest 6810 GB
auto - shut-down
00723973_1.eps
01323973_1_en.eps
01423973_1_en.eps
03323973_1_en.eps
9
When the batteries are discharged the instrument switches automatically off.
Performing the Measurement
Conditions
— A new mouthpiece has to be used for every person tested.
— Do not apply too high alcohol concentrations onto sensor, e.g. by rinsing the mouth with
high-strength alcohol shortly before the measurement. By doing so the sensor service life
is reduced.
— Keep sufficient distance to the antennas of mobile phones and transmitting stations.
Requirements of the person to be tested
— Maintain a waiting period of at least 20 minutes after drinking alcohol!
Residual alcohol in the mouth can distort the measurement. Aromatic drinks (e.g. fruit
juice), mouth sprays containing alcohol, medicines can interfere with measurements.
Rinsing the mouth with water or non-alcoholic drinks does not reduce this waiting period!
— Before sampling the person to be tested must breathe normally. Quick inhaling and
exhaling through the mouth must be avoided.
— The person to be tested must provide the required minimum air volume of 1.2 L (factory
setting). The exhaling breath flow must be constant for at least 2 seconds.
Preparation
● Insert new mouthpiece in the holder (page 8).
● Switch instrument on (page 9).
Followed by the user defined screen.
If the date for next service is expired:
● Unit has to be accuracy checked (see “Fault, Cause, Remedy” on page 24).
10
Alcotest 6810 GB
18.01.2007 12:00
Calibration in: XX days
Acc. Check in: XX days
Temperature: 22
o
C
Policestation 1
01323973_1_en.eps
03623973_en.eps
07023973_en.eps
