Piggyback lets you use an Mhouse gate
remote to operate any automation systems
E.g. garage doors, watering systems or
garden lights.
WARNING: Disconnect mains
power before starting.
watch the video
easygate.com.au
Simply wire it to the control panel of any 24v
or 12v automation.
12v
Piggyback comes ready for connection
to 24v. If conecting to a 12v system, t
the ‘jumper’ onto the pin-terminals on
Piggyback (right).
The jumper is packed seperate in the
plastic bag.
WIRING
Let’s assume we are connecting
Piggyback two garage doors.
Refer to garage door manufacturer’s
1
manual for which terminals to add a
receiver or push-button.
JUMPER >
easygate.com.au
RED
BLACK
WHITE
WHITE
VIOLET
VIOLET
+ (~)
- (~)
OUTPUT 1
OUTPUT 2
24V
ac/dc
Connect Piggyback’s red, black and
2
both white wires to the control board
on main garage door motor.
No manual? Call garage door
company with the model.
Mount Piggyback with
3
double-sided tape supplied.
2nd GARAGE door
Only the two violet wires need to be
OUTPUT 1 = Automation 1
OUTPUT 2 = Automation 2
---------------------------------------------
Examples of possible installations:
OUTPUT 1 = Garage door 1
OUTPUT 2 = Garage door 2
run to the second garage door
controller.
Piggyback is now ready to have the
remote connected to it.
OUTPUT 1 = Garage door
OUTPUT 2 = Garden lights
OUTPUT 1 = Watering system
OUTPUT 2 = Garden lights
2
PL Instrukcje instalacji i użyt-
kowania i ostrzeżeni
NL Aanwijzingen en aanbeve-
lingen voor installering en
gebruik
IS0033A00MM
23-02-2011
RED
BLACK
+ (~)
- (~)
WHITE
WHITE
VIOLET
OUTPUT 2
OUTPUT 1
24V
ac/dc
VIOLET
T1
T2
T3
T4
Mhouse R2
Photocells
EN Installation and use
instruc tions and warnings
IT Istruzioni ed avvertenze
per l’installazione e l’uso
FR Instructions et avertisse-
ments pour l’installation et
l’utilisation
ES Instrucciones y adverten-
cias para la instalación y el
uso
DE Anweisungen und Hinwei-
se für die Installation und
die Bedienung
PL Instrukcje instalacji i użyt-
kowania i ostrzeżeni
NL Aanwijzingen en aanbeve-
lingen voor installering en
gebruik
IS0033A00MM
23-02-2011
1
RED
BLACK
+ (~)
- (~)
WHITE
WHITE
VIOLET
OUTPUT 2
OUTPUT 1
24V
ac/dc
VIOLET
EN Installation and use
instruc tions and warnings
IT Istruzioni ed avvertenze
per l’installazione e l’uso
FR Instructions et avertisse-
ments pour l’installation et
l’utilisation
ES Instrucciones y adverten-
cias para la instalación y el
uso
DE Anweisungen und Hinwei-
se für die Installation und
die Bedienung
PL Instrukcje instalacji i użyt-
kowania i ostrzeżeni
NL Aanwijzingen en aanbeve-
lingen voor installering en
gebruik
IS0033A00MM
23-02-2011
RED
BLACK
+ (~)
- (~)
WHITE
WHITE
VIOLET
OUTPUT 2
OUTPUT 1
24V
ac/dc
VIOLET
connect REMOTEs
Before a remote can connect with
Piggyback the gate motor control
board must be reset.
Press top button on gate motor (right)
1
until light shows. Then simultaneously
press a remote button.
Release both after light ashes ve
2
times.
OUTPUT 1: Main Garage door
Press P1 once (once = OUTPUT 1). Light
1
shows single ashes.
Press and hold a T-button (assigned to
2
door 1). Release button after third ash of
P1 light.
Add other Mhouse remotes while light
3
shows single ashes.
OUTPUT 2: 2nd Garage door
Gate open
T1
OUTPUT 1
T3
x
Pedestrian
T2
access
T4
OUTPUT 2
Example of button
conguration.
These steps are for OUTPUT 2 and only
needed if a second system is added .
Press P1 button twice (twice = OUTPUT
1
2). Light will double-ash.
Press and hold the T-button (dedicated
2
to door 2). Release button after third
ash of P1.
P1
Add other Mhouse remotes while light
3
shows double ashes.
AERIAL
The aerial is the white wire in terminal
1-2.
The remote’s signal range can be extend-
<< Internal aerial can be replaced with a
longer cable to improve signal range.
ed by tting a longer cable or an external
aerial tted outdoors as high as possible.
External aerial
When using coaxial cable connect the
Code: AAC-ANT433
centre part of the cable to terminal 2, and
the braid to terminal 1. See pic.
3
