ST-HB-SOLAR: Dotworkz S-Type Power Saver Heater Blower for Solar Applications
Off-Grid, Low-Wattage,
Dotworkz-Durable
The ST-HB-Solar is the ideal enclosure for
off-grid and remote locations, providing the
Dotworkz standard of durability in a lowwattage solution.
The thermostatically controlled Heater Ring
& Blower system delivers IP66 outdoorrated protection for virtually all brands of
traditional “brick” or static cameras.
The heavy-duty Polycarbonate Thermal
Plastic case is non-metallic, non-corrosive,
vandal tough, with space to spare for
wireless radios, cellular routers, encoders
and small form NVR devices.
66
IP
OUTDOOR RATED
Description:
Dotworkz S-Type Solar Heater & Blower is the
most versatile solar application outdoor camera
protection system on the market.
The ST-HB-Solar is designed for all brands of traditional “brick” or static cameras, and is thermostatically controlled to protect camera humidity and
condensation in temperate climates.
The Solar Heater & Blower protects camera
systems in an ideal temperature range of 30° F to
95° F. To combat the cold, the unit’s thermostatically regulated low wattage heater “Ring” encircles
lens window for direct de-fogging & heating within
the enclosure. The blower remains on at all times,
keeping cameras cool and fog free.
The S-Type housing is a complete air/water tight
solution for the protection of sensitive CCTV, megapixel, HDTV or other long body cameras.
Features:
• Enables all IP and analog cameras to operate in temps. ranging from 30° F to 95° F
• Thermostatically Controlled Low wattage heater “Ring” encircles the camera lens
for de-fogging lens & heating within enclosure
• Dual Layer Foam/Foil insulation has been Specially Engineered by Dotworkz, and
integrated for optimal thermal protection and stability
• Dedicated 12 VDC assures no system conversion power loss
• Vandal-tough casing designed to protect valuable electronics from sabotage and
theft
• Comes standard with heavy-duty “Strong Arm” wall mounting system for maximum
wind and vibration resistance (product #BR-STWP)
• Constructed from Heavy-duty, Non-Metallic, Non-corrosive, flame-resistant, Polycarbonate Thermal Plastic alloy
• Housing exceeds IP66 rating: sealed against outside air, dust, insects, saltwater,
humidity and other environmentally harsh conditions
• Extends the operating life and temperature of all integrated electronics
• Internal mounting space for additional IP hardware, including routers, cell networks,
Specs:
Operating Temperature (Absolute/Rec.):
-40° to 140°F (-40°C to 60°C)
30° to 95°F (-1.11 °C to 35°C)
Operating Humidity :
5 - 95% Non-Condensing RH
Power Consumption: (not including camera load)
Under 7 Watts Peak @ 12 VDC (nominal)
Input Power Source Options: 12 VDC
Dedicated
Output for Camera Power:
Internal Power Available for Camera:
2 amps @ 12 VDC
Shipping: 24” x 10” x 10” 15 lbs (6.8 Kg)
Standard with
NVR, hard drives, UPS, WiMax, mesh hardware, etc.
12 VDC
1
1 depends on camera being integrated
