Optimized to meet the
environmental challenges of
severe climate applications
The revolutionary D-Series and S-Type
environmental housings reset
the standard, providing heavy-duty
protection for PT Z and Static Cameras
from the rigors of outdoor exposure,
vandalism and physical damage.
Model Number
HD or H.264 PTZ Camera Support
IP PTZ Camera Support
Analog PTZ Camera Support (
HD or H.267 Fixed Camera Support
IP Fixed Camera Support
Analog Fixed Camera Support
Mount Type
ENVIRONMENTAL
Ideal For
Operating Temperature (Absolute)
Operating Temperature (Recommended)
Heating Element Activates
Heating Element Deactivates
Cooling Element Activates
Cooling Element Deactivates
INTERNAL ENVIRONMENTAL CONTROLS
Active Systems Thermostatically Controlled
Cooling and Heating
Internal Fan(s) included (Quantity, Size Output)
Solar Guard Insulation Kit
Humidity Control Package
ELECTRICAL
Power Consumption
Input Power Source options for MVP Series
Outputs for Camera Power for MVP Series
Internal Power Available for Camera
AC Frequency
Input Current
CONSTRUCTION
Enclosure Construction
Lens (colors)
NEMA 4X Certified
Shipping Dimensions
Shipping Weight
ACCESSORIES (recommended)
24 VAC
)
Dotworkz D-Series Camera Enclosures
D2/D3 Standard D2/D3 Tornado D2/D3 Ring-of-Fire D2 COOLDOME™
D2-BASE / D3-BASE
Yes
Yes
Yes
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Integrated Wall Mount (See Accessories)
Indoor; vandal protection
NA
NA
NA
NA
NA
NA
NA
NA
NA
Available, Sold Separately
Available, Sold Separately
NA
NA
NA
NA
NA
NA
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Acrylic, .098” (clear or tinted)
IP66 NEMA 4X
17” x 13” x 16” / 22” x 13” x 16”
9 lbs. (4.1 kg) / 10 lbs. (4.5 kg)
Dotworkz Pole Mount Adapter (BR-MPM1)
Dotworkz Power Pole Mount Adapter (BR-MPM2)
Tilt Angle Correction Plate (BR-MPM1-AC)
Wireless P/S accessory tray for 15, 12 and 5volts (KT-WACC)
Dotworkz Accessory Mounting Plate (BR-ACC1)
External Accessory Bracket (BR-ACC2)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tinted Lens (KT-TLNS)
Vandal Lens Tinted & Clear (KT-TLNS-VT / KT-CLNS-VT)
Upper & Lower Insulation Kit (KT-INS1 / KT-INS2)
D2/D3 Heater Blower
D2-HB-MVP / D3-HB-MVP
Yes
Yes
Yes add on “-AC” (CCTV) to the Model Number when ordering
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Integrated Wall Mount (See Accessories)
Cold, warm temperate climates
-25° to 140° F (-32° to 60° C)
0° to 120° F (-17° to 49° C)
55° F (13° C)
70° F (21° C)
Blower always on
Blower always on
NA
NA
(1) 50 x 50 x 50mm, 10 cfm
Available, Sold Separately
Available, Sold Separately
2 amps @ 115 VAC typical at full load
24 VAC/VDC, 110 VAC or 220 VAC
12 VDC and 24 VDC
2.2 amps @ 12 VDC / 1.0 amp @ 24 V
47-63 Hz
2 amps @ 115 VAC max including camera
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Acrylic, .098” (clear or tinted)
IP66 NEMA 4X
17” x 13” x 16” / 22” x 13” x 16”
12 lbs. (5.4 kg) / 13 lbs. (5.9 kg)
Dotworkz Pole Mount Adapter (BR-MPM1)
Dotworkz Power Pole Mount Adapter (BR-MPM2)
Tilt Angle Correction Plate (BR-MPM1-AC)
Wireless P/S accessory tray for 15, 12 and 5volts (KT-WACC)
Dotworkz Accessory Mounting Plate (BR-ACC1)
External Accessory Bracket (BR-ACC2)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tinted Lens (KT-TLNS)
Vandal Lens Tinted & Clear (KT-TLNS-VT / KT-CLNS-VT)
Upper & Lower Insulation Kit (KT-INS1 / KT-INS2)
D2-TR-MVP / D3-TR-MVP
Yes
Yes
Yes add on “-AC” (CCTV) to the Model Number when ordering
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Integrated Wall Mount (See Accessories)
Milder, humid and wet climates; marine locations
-20° to 140° F (-29° to 60°C)
30° to 120° F (1° to 49°C)
NA
NA
Blower always on
Blower always on
Twin High Output Blowers
NA
(2) 50 x 50 x 50mm = 20cfm
Dual Ply, Solar guard insulation kit installed
Available, Sold Separately
2 amps @ 115 VAC typical at full load
24 VAC/VDC, 110 VAC or 220 VAC
12 VDC and 24 VDC
2.2 amps @ 12 VDC / 1.0 amp @ 24 V
47-63 Hz
2 amps @ 115 VAC max including camera
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Acrylic, .098” (clear or tinted)
IP66 NEMA 4X
17” x 13” x 16” / 22” x 13” x 16”
12 lbs. (5.4 kg) / 13 lbs. (5.9 kg)
Dotworkz Pole Mount Adapter (BR-MPM1)
Dotworkz Power Pole Mount Adapter (BR-MPM2)
Tilt Angle Correction Plate (BR-MPM1-AC)
Wireless P/S accessory tray for 15, 12 and 5volts (KT-WACC)
Dotworkz Accessory Mounting Plate (BR-ACC1)
External Accessory Bracket (BR-ACC2)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tinted Lens (KT-TLNS)
Vandal Lens Tinted & Clear (KT-TLNS-VT / KT-CLNS-VT)
Upper & Lower Insulation Kit (KT-INS1 / KT-INS2)
D2-RF-MVP / D3-RF-MVP
Yes
Yes
Yes add on “-AC” (CCTV) to the Model Number when ordering
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Integrated Wall Mount (See Accessories)
Cold and snow, icy climates
-40° to 140° F (-40° to 60° C)
-40° to 120° F (-40° to 49° C)
De-Icing Element on at 55° F (13° C)
De-Icing Element off at 70° F (21° C)
Blower always on
Blower always on
Active Heating: 65 watt Ring of Fire
Active Heating/Fan Cooling
(2) 50 x 50 x 50mm = 20cfm
Not advised
Available, Sold Separately
3 amps @ 115 VAC typical at full load
24 VAC/VDC, 110 VAC or 220 VAC
12 VDC and 24 VDC
2.2 amps @ 12 VDC / 1.0 amp @ 24 V
47-63 Hz
3 amps @ 115 VAC max including camera
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Acrylic, .098” (clear or tinted)
IP66 NEMA 4X
17” x 13” x 16” / 22” x 13” x 16”
12 lbs. (5.4 kg) / 13 lbs. (5.9 kg)
Dotworkz Pole Mount Adapter (BR-MPM1)
Dotworkz Power Pole Mount Adapter (BR-MPM2)
Tilt Angle Correction Plate (BR-MPM1-AC)
Wireless P/S accessory tray for 15, 12 and 5volts (KT-WACC)
Dotworkz Accessory Mounting Plate (BR-ACC1)
External Accessory Bracket (BR-ACC2)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tinted Lens (KT-TLNS)
Vandal Lens Tinted & Clear (KT-TLNS-VT / KT-CLNS-VT)
Upper & Lower Insulation Kit (KT-INS1 / KT-INS2)
D2-CD / D2-CD-24V
Yes
Yes
No / Yes
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Integrated Wall Mount (See Accessories)
Hot climates; desert locations
-20° to 160° F (-29° to 71° C)
30° to 145° F (-1° to 63° C)
NA
NA
100° F (38° C)
70° F (21° C)
Active Cooling
Active Cooling, 400btu w/fan
(1) 80 x 80 x 15mm = 40 cfm
Dual Ply, Solar guard insulation kit installed
Included as Standard with COOLDOME™
12VDC / 24VDC, 150W peak @ encl. when cooler active
12 VDC @ Enclosure, 110 VAC or 220 VAC
12 VDC / 24 VDC
3.0 amps @ 12 VDC
47-63 Hz
External P/S, 4.8 A @ 115 VAC, 2.8 A @ 230 VAC, full load
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Acrylic, .098” (clear or tinted)
IP66 NEMA 4X
17” x 13” x 16”
15 lbs. (6.8 kg)
Dotworkz Pole Mount Adapter (BR-MPM1)
Dotworkz Power Pole Mount Adapter (BR-MPM2)
Tilt Angle Correction Plate (BR-MPM1-AC)
Wireless P/S accessory tray for 15, 12 and 5volts (KT-WACC)
Dotworkz Accessory Mounting Plate (BR-ACC1)
External Accessory Bracket (BR-ACC2)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tinted Lens (KT-TLNS)
Vandal Lens Tinted & Clear (KT-TLNS-VT / KT-CLNS-VT)
Upper & Lower Insulation Kit (KT-INS1 / KT-INS2)
NEMA for COOLDOME Power Supply (NM-CDPS)
Ext. Manually Switched
D3 COOLDOME™
D3 XERO
D3-CD-12V D3-XERO / D3-XERO-XL
Yes
Yes
Available for Custom Orders Only
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Integrated Wall Mount (See Accessories)
Extreme hot climates; desert locations
-20° to 160° F (-29° to 71° C)
30° to 145° F (-1° to 63° C)
NA
NA
105° F (40° C)
90° F (32° C)
Active Cooling
Active Cooling, 800btu w/fan
(2) 80 x 80 x 15mm = 80 cfm
Dual Ply, Solar guard insulation kit installed
Included as Standard with COOLDOME™
12 VDC, 300W peak @ encl. when coolers active
12 VDC @ Enclosure, 110 VAC or 220 VAC
12 VDC, optional 24 VDC model available
3.0 amps @ 12 VDC
47-63 Hz
External P/S, 7 A @ 115 VAC, 3.5 A @ 230 VAC, full load
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Acrylic, .098” (clear or tinted)
IP66 NEMA 4X
22” x 13” x 16”
19 lbs. (8.6 kg)
Dotworkz Pole Mount Adapter (BR-MPM1)
Dotworkz Power Pole Mount Adapter (BR-MPM2)
Tilt Angle Correction Plate (BR-MPM1-AC)
Wireless P/S accessory tray for 15, 12 and 5volts (KT-WACC)
Dotworkz Accessory Mounting Plate (BR-ACC1)
External Accessory Bracket (BR-ACC2)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tinted Lens (KT-TLNS)
Vandal Lens Tinted & Clear (KT-TLNS-VT / KT-CLNS-VT)
Upper & Lower Insulation Kit (KT-INS1 / KT-INS2)
NEMA for COOLDOME Power Supply (NM-CDPS-XERO)
Auto Sensing
Yes
Yes
Available for Custom Orders Only
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Fixed Mini Dome and many other Dome Cameras
Integrated Wall Mount (See Accessories)
Edge recording
-20° to 160° F (-29° to 71° C)
30° to 145° F (-1° to 63° C)
NA
NA
105° F (40° C)
90° F (32° C)
Active Cooling
Active Cooling, 800btu w/fan
(2) 80 x 80 x 15mm = 80 cfm
Dual Ply, Solar guard insulation kit installed
Included as Standard with COOLDOME™
12 VDC, 300W peak @ encl. when coolers active
12 VDC @ Enclosure, 110 VAC or 220 VAC
12 VDC, optional 24 VDC model available
3.0 amps @ 12 VDC
47-63 Hz
External P/S, 7 A @ 115 VAC, 3.5 A @ 230 VAC, full load
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Acrylic, .098” (clear or tinted)
IP66 NEMA 4X
22” x 13” x 16”
20 lbs. (9 kg)
Dotworkz Pole Mount Adapter (BR-MPM1)
Dotworkz Power Pole Mount Adapter (BR-MPM2)
Tilt Angle Correction Plate (BR-MPM1-AC)
Wireless P/S accessory tray for 15, 12 and 5volts (KT-WACC)
Dotworkz Accessory Mounting Plate (BR-ACC1)
External Accessory Bracket (BR-ACC2)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tinted Lens (KT-TLNS)
Vandal Lens Tinted & Clear (KT-TLNS-VT / KT-CLNS-VT)
Upper & Lower Insulation Kit (KT-INS1 / KT-INS2)
NEMA for COOLDOME Power Supply (NM-CDPS-XERO)
Auto Sensing
Dotworkz S-Type Camera EnclosuresDotworkz D-Series Camera Enclosures
Heater-Blower
IP
OUTDOOR RATED
ST-HB-MVP
HD Ready - brick style
No
No
Yes
Yes
Yes add on “-AC” (CCTV) to the Model # when ordering
Arm for wall mount and Pole Mount (to 1/2”dia.)
Cold, warm temperate climates
-25° to 140° F (-32° to 60° C)
0° to 120° F (-17° to 49° C)
55° F (13° C)
70° F (21° C)
Blower always on
Blower always on
Heater system, fan blower
Blower (always on)
(1) 50 x 50 x 10mm = 10 cfm
Standard single ply included
Available, sold separately
2 amps @ 115 VAC typical at full load
24 VDC / VAC, 110 VAC or 220 VAC
12 VDC and 24 VDC
2.2 amps @ 12 VDC / 1.0 amp @ 24 V
47-63 Hz
2 amps @ 115 VAC max including camera
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Lexan PC, 0.118” (Clear)
IP67
24”x14”x10”
13 lbs (5.9 kg)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
Tornado
67
ST-TR-MVP
HD Ready - brick style
No
No
Yes
Yes
Yes add on “-AC” (CCTV) to the Model # when ordering
Arm for wall mount and Pole Mount (to 1/2”dia.)
Milder, humid / wet climates; marine locations
-20° to 140°F (-7° to 60° C)
30° to 120°F (18° to 49° C)
NA
NA
Blower always on
Blower always on
Twin High Output Blowers
Blower (always on)
(2) 50 x 50 x 10mm = 20 cfm
Standard single ply included
Available, sold separately
2 amps @ 115 VAC typical at full load
24 VDC / VAC, 110 VAC or 220 VAC
12 VDC and 24 VDC
2.2 amps @ 12 VDC / 1.0 amp @ 24 V
47-63 Hz
2 amps @ 115 VAC max including camera
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Lexan PC, 0.118” (Clear)
IP67
24”x14”x10”
16 lbs (7.2 kg)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
67
IP
OUTDOOR RATED
Ring-of-Fire
IP
OUTDOOR RATED
ST-RF-MVP
HD Ready - brick style
No
No
Yes
Yes
Yes add on “-AC” (CCTV) to the Model # when ordering
Arm for wall mount and Pole Mount (to 1/2”dia.)
Cold, Icy climates
-40° to 140° F (-40° to 60° C)
-40° to 120° F (-40° to 49° C)
De-Icing Element on at 55° F (13° C)
De-Icing Element off at 70° F (21° C)
Blower always on
Blower always on
Active Heating: 65 Watt Ring of Fire
Active Heating/Fan Cooling
(2) 50 x 50 x 10 = 20 cfm
Not advised
Available, sold separately
3 amps @ 115 VAC typical at full load
24 VDC / VAC, 110 VAC or 220 VAC
12 VDC and 24 VDC
2.2 amps @ 12 VDC / 1.0 amp @ 24 V
47-63 Hz
3 amps @ 115 VAC max including camera
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Lexan PC, 0.118” (Clear)
IP67
24”x14”x10”
16 lbs (7.2 kg)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
COOLDOME™
67
ST-CD / 24V
HD Ready - brick style
No
No
Yes
Yes
Available for Custom Orders Only
Arm for wall mount and Pole Mount (to 1/2”dia.)
Hot climates; desert locations
-20° to 160° F (-29° to 71° C)
30° to 145°F (-1° to 63° C)
NA
NA
105° F (40° C)
90° F (32° C)
Active Cooling
Active Cooling: 800btu w/fan
(1) 80 x 80 x 15 = 40 cfm
Standard Single Ply Included
Included as Standard with COOLDOME™
12VDC / 24VDC, 150W peak @ encl.
12 VDC / 24 VDC, 110/220 VAC
12 VDC / 24 VDC
2.2 amps @ 12 VDC / 1.0 amp @ 24 VDC
47-63 Hz
4.8 A @ 115 VAC, 2.8 A @ 230 VAC, full load
Dotworkz Polycarbonate Thermoplastic Alloy
High Impact Lexan PC, 0.118” (Clear)
IP67
24”x14”x10”
19 lbs (8.6 kg)
S-Type COOLDOME™ Power arm kit (KT-CDR-ST)
Dome Wizard Cleaner Package (DW-PKG1)
Humidity Removal Pack (KT-HRC1)
67
IP
OUTDOOR RATED
Dotworkz Enclosures Accessories
Dome Wizard Lens Replacement Accessory Plate Pole Mount Adapter
DW-PKG1 KT-CLNS / KT-TLNS BR-ACC1 BR-MPM1 KT-CDR2 / CDR3 Additional Brackets
The DomeWizard™ revolutionizes
the maintenance of security cameras.
By keeping lenses sparkling clean,
it improves the overall lowlight performance of video systems while increasing safety for your maintenance
personnel - no ladders or lifts needed.
(ship 85” x 6” x 4” / 10 lbs)
Dotworkz Dome Cleaner Package
• Dome Wizard Cleaning Head
• 8 oz Rexton Cleaning Solution
• Doworkz Replacement Mitt 3-pack
• Professional Grade Extension Pole
extends up to 30’
Wireless Integration
KT-WACC
Dotworkz wireless accessory and
components tray was designed for
integrators.
This easy to install integration kit
provides the proper mounting location
and power to many types of hardware
devices.
• Cellular air cards
• WiMAX
• 900 MHz
• 2.4 - 5.8 GHz
• 4.8 and other
Lens replacements for Dotworkz D2/D3
camera enclosures. Available in clear
or tinted lens designs. Both are heavy
duty high impact acrylic for increased
vandal resistance. Also available in
Vandal Tough option. (KT-CLNS-VT /
KT-TLNS-VT)
(ship 9” x 9” x 9” / 1 lb)
Features
• Clear lens optimized for night time
viewing.
• Tinted lens hides daytime viewing
in bright conditions and increases
camera privacy.
The BR-ACC1 is an accessory component mounting plate especially designed
for he Dotworkz D-Series camera
enclosures. The BR-ACC1 allows you
to securely install custom components
within the D2/D3 cargo bay to enable
such applications as Wireless, Mesh
WiMax, onboard NVR and more.
(ship 7.25” x 12” padded envelope)
Dotworkz Enclosures Features
MVP - Multi Volt Power system greatly simplifies installation
and ordering by accepting multiple camera voltages and
multiple input voltage options in one “ready to install” unit.
This makes setting up outdoor camera systems simpler
than ever.
• Vari-Fit internal bracket included for perfect fit for PTZ,
megapixel or mini domes
• Switchable upper and lower camera mounting locations
for maximum versatility and internal
storage space
• Extreme Impact, UV
resistant Dotworkz
engineered Thermoplastic will not rust
or corrode
• IP66 rated against
dust, water, and salt
water air
• IP68 (waterproof)
connection ports
MU LTI VO LT P L AT FO RM
• Universal input voltages option 220
VAC, 110 VAC and 24 VAC/ VDC
• 24 VDC /12 VDC camera and
component power
• Easier, faster installation process less time
• Works with all cameras brands and
models*
Dotworkz EZ Lock™ Pole Mount Adapter
is a feature-rich mounting adapter. Easily
secures to poles with a minimum of
3/4” diameter.
(ship 8.5” x 8 x 2.5” / 3 lbs)
Additional Components
Angle Correction Plate: Corrects up to
10 degrees of angle. (BR-MPM1-AC)
Antenna Mount: the Dotworkz antenna
mount provides additional antenna mount
locations, allowing for easy application of
ingress/egress omni antennas. Mounting
off of the EZ Lock Pole mount allows
for installation without drilling into
existing pole.
Dotworkz new Power Pole Mount
Adapter opens up options for the further
expandability of our D2 or D3 camera
housings. With room to spare we redesigned our standard pole mount to include a protected area behind the housing for a ruggedized IP68 COOLDOME™
power supply. This new feature simplifies
and beautifies outdoor video power
solutions for the D Series COOLDOME™
and XERO outdoor enclosures. Designed
with the integrator in mind but made for
unsurpassed versatility.
Additional BracketsPower Adapter
Dotworkz mounting brackets for all types
of installs.
Works with EZ Lock Pole Mount Adapter.
Enables the positioning of cameras at the
exact viewing angle.
Model Numbers
• Parapet Swing Arm: BR-PSA1
• External Component mount: BR-ACC2
• Corner Mount: BR-CNR1
Page 2
www.dotworkz.com 866.575.4689
Industrial-strength commercial NVR machines,
boasting world-class technology at affordable
prices
Video processing requires high performance computing
equipment to support digital image recording and playback.
Dotworkz NVR machines offer the perfect blend of fail safe
features, high performance and data storage simplicity, with
remote management flexibility and control. Our open-platform NVR machines are expandable, upgradeable, available
in multiple configurations, and can be pre-configured with
many popular VMS software solutions.
Model Number
# of IP Cameras (Recommended)*
Capacity
Form Factor
Operating System
Processor (Primary)
Processor (Secondary)
RAM
Hot Swappable Drive Bays
Hard Disk
Type
Interface
RAID Controller
RAID Configuration
Optical Disk
Display Output
1080p Support
Ethernet
Additional Network Cards
Power
Misc. Components
Operating Temperature
Dimensions (W x H x D inch)
Weight (lbs)
Shipping Dimensions (W x H x D inch)
Shipping Weight
Warranty
Supported IP NVR Software (Preinstalled 30-Day Demo Versions)
Included Accessories
Optional Accessories
Dotworkz NVR Series
COMING
or
SOON
D3-XERO / XERO-XL ST-XERO
up to 8
500GB / 1TB
Slim Line Case
Windows Embedded Standard 2009
Intel Atom 1.6GHz N270
N/A
2GB (Max)
N/A
Rugged 7200 RPM (16MB buffer)
SATA
N/A
N/A
N/A
VGA x 1, DVI x 1
Yes
1000BaseT(GigaBit) x 2
N/A
60W@12VDC, 22 / 30 Watt Actual
N/A
7.2” x 1.98” x 7.16”
3 lbs (1.3 kg)
22” x 13” x 16”
20 lbs. (9 kg)
1 Year
Milestone, ONSSI, Sony, Axis, Canon
60 Watt Power Supply
KT-CDR3: Pole Mount Power Adapter for
D3 COOLDOME™ and XERO with ruggedized IP68 power supplies.
up to 8
500GB
Slim Line Case
Windows Embedded Standard 2009
Intel Atom Based
N/A
2GB (Max)
N/A
Hybrid HDD (4GB SSD)
SATA
N/A
N/A
N/A
VGA x 1
No
1000BaseT(GigaBit) x 1
N/A
60W@12VDC, 15 Watt Actual
N/A
4” x 4” x 4”
2.5 lbs (1.1 kg)
22” x 13” x 16”
20 lbs. (9 kg)
1 Year
Milestone, ONSSI, Sony, Axis, Canon
60 Watt Power Supply
KT-CDR-ST: outdoor rated rugged IP68
power supply.
New for
2011
NVR-XERO
up to 8
500GB
Slim Line Case
Windows Embedded Standard 2009
Atom 1.6GHz N270
N/A
2GB (Max)
N/A
Rugged 7200 RPM (16MB buffer)
SATA
N/A
N/A
N/A
VGA x 1, DVI x 1
Yes
1000BaseT(GigaBit) x 1
N/A
60W@12VDC, 22 Watt Actual
N/A
7.2” x 1.49” x 7.16”
2.5 lbs (1.1 kg)
10” x 11” x 18”
2.5 lbs (1.1 kg)
1 Year
Milestone, ONSSI, Sony, Axis, Canon
60 Watt Power Supply
KT-XERO:
XERO Integration Kit - for
installing XERO IP Edge Recorder inside
the D Series enclosures.
LIVE RECORDING WITH ARCHIVING
Slim, Compact & Portable
New for
2011
1UEnclosure Integrated 2U, NAS & Custom
COMING
SOON
NVR-XERO-XL NVR-XERO-ST NVR-1TB-SMALL NVR-2TB-MED NVR-3TB-LARGE NVR-4TB-XLARGE NVR Custom & NAS
up to 8
1TB
Slim Line Case
Windows Embedded Standard 2009
Intel Atom 1.6GHz N270
N/A
2GB (Max)
N/A
Rugged 7200 RPM (16MB buffer)
SATA
N/A
N/A
N/A
VGA x 1
Yes
1000BaseT(GigaBit) x 2
N/A
60W@12VDC, 30 Watt Actual
N/A
7.2” x 1.98” x 7.16”
3 lbs (1.3 kg)
10” x 11” x 18”
3 lbs (1.3 kg)
1 Year
Milestone, ONSSI, Sony, Axis, Canon
60 Watt Power Supply
KT-XERO:
XERO Integration Kit - for
installing XERO IP Edge Recorder inside
the D Series enclosures.
up to 8
500GB
Slim Line Case
Windows Embedded Standard 2009
Intel Atom Based
N/A
2GB (Max)
N/A
Hybrid HDD (4GB SSD)
SATA
N/A
N/A
N/A
VGA x 1
No
1000BaseT(GigaBit) x 1
N/A
60W@12VDC, 15 Watt Actual
N/A
4” x 4” x 4”
2.5 lbs (1.1 kg)
10” x 11” x 18”
2.5 lbs (1.1 kg)
1 Year
Milestone, ONSSI, Sony, Axis, Canon
60 Watt Power Supply
up to 50
1TB
Rackmount (1U)
Embedded Server 2008
Intel Quad Core Xeon 2.5 GHz
Upgradeable with 2nd CPU
4GB (Upgradeable to 48GB)
4
Enterprise Rated Drives (32MB buffer)
SATA
On board
Not Recommended
Slimline DVD-R
VGA x 1
NA
1000BaseT(GigaBit) x 2
3rd 1000BaseT(GigaBit) or Fiber Chanel NIC
520 W Power Supply
Floppy
41° to 104° F (5° to 40° C)
17.2” x 1.7” x 25.6”
35 to 38 lbs (16 to 17 kg)
27” x 34” x 12”
36 lbs (16 kg)
3 Years
Milestone, ONSSI, Sony, Axis, Canon
4 Post Rackmount Rail Kit, Keyboard & Mouse
up to 50
2TB
Rackmount (1U)
Embedded Server 2008
Intel Quad Core Xeon 2.5 GHz
Upgradeable with 2nd CPU
4GB (Upgradeable to 48GB)
4
Enterprise Rated Drives (32MB buffer)
SATA
On board
Not Recommended
Slimline DVD-R
VGA x 1
NA
1000BaseT(GigaBit) x 2
3rd 1000BaseT(GigaBit) or Fiber Chanel NIC
520 W Power Supply
Floppy
41° to 104° F (5° to 40° C)
17.2” x 1.7” x 25.6”
35 to 38 lbs (16 to 17 kg)
27” x 34” x 12”
37 lbs (16.5 kg)
3 Years
Milestone, ONSSI, Sony, Axis, Canon
4 Post Rackmount Rail Kit, Keyboard & Mouse
up to 50
3TB
Rackmount (1U)
Embedded Server 2008
Intel Quad Core Xeon 2.5 GHz
Upgradeable with 2nd CPU
4GB (Upgradeable to 48GB)
4
Enterprise Rated Drives (32MB buffer)
SATA
On board
Not Recommended
Slimline DVD-R
VGA x 1
NA
1000BaseT(GigaBit) x 2
3rd 1000BaseT(GigaBit) or Fiber Chanel NIC
520 W Power Supply
Floppy
41° to 104° F (5° to 40° C)
17.2” x 1.7” x 25.6”
35 to 38 lbs (16 to 17 kg)
27” x 34” x 12”
38 lbs (17 kg)
3 Years
Milestone, ONSSI, Sony, Axis, Canon
4 Post Rackmount Rail Kit, Keyboard & Mouse
up to 50
4TB
Rackmount (1U)
Embedded Server 2008
Intel Quad Core Xeon 2.5 GHz
Upgradeable with 2nd CPU
4GB (Upgradeable to 48GB)
4
Enterprise Rated Drives (32MB buffer)
SATA
On board
Not Recommended
Slimline DVD-R
VGA x 1
NA
1000BaseT(GigaBit) x 2
3rd 1000BaseT(GigaBit) or Fiber Chanel NIC
520 W Power Supply
Floppy
41° to 104° F (5° to 40° C)
17.2” x 1.7” x 25.6”
35 to 38 lbs (16 to 17 kg)
27” x 34” x 12”
39 lbs (17.5 kg)
3 Years
Milestone, ONSSI, Sony, Axis, Canon
4 Post Rackmount Rail Kit, Keyboard & Mouse
NVR BOP Series
up to 50
5TB to 12TB
Rackmount (2U)
Embedded Server 2008
Intel Quad Core Nehalem 2.0 GHz
Upgradeable with 2nd CPU
6GB DDR3 (Upgradeable to 48GB)
12
Enterprise Rated Drives (32MB buffer)
SATA
Dedicated Controller Card
2 x 80GB Enterprise for OS (internal)
Slimline DVD-R
VGA x 1
NA
1000BaseT(GigaBit) x 2
3rd 1000BaseT(GigaBit) or Fiber Chanel NIC
700 W Redundant Power Supply
NA
41° to 104° F (5° to 40° C)
17.2” x 3.5” x 25.6”
45 to 55 lbs (20.5 to 25 kg)
27” x 35” x 18”
68 to 80 lbs (31 to 36 kg)
3 Years
Milestone, ONSSI, Sony, Axis, Canon
4 Post Rackmount Rail Kit, Keyboard & Mouse
up to 50
16TB and up
Rackmount (2U and up)
Embedded Server 2008
Intel Quad Core Nehalem 2.0 GHz
Upgradeable with 2nd CPU
6GB DDR3 (Upgradeable to 48GB)
12
Enterprise Rated Drives (32MB buffer)
SATA
Dedicated Controller Card
2 x 80GB Enterprise for OS (internal)
Slimline DVD-R
VGA x 1
NA
1000BaseT(GigaBit) x 2
3rd 1000BaseT(GigaBit) or Fiber Chanel NIC
700 W Redundant Power Supply
NA
41° to 104° F (5° to 40° C)
17.2” x 3.5” x 25.6”
45 to 55 lbs (20.5 to 25 kg)
27” x 35” x 18”
68 to 80 lbs (31 to 36 kg)
3 Years
Milestone, ONSSI, Sony, Axis, Canon
4 Post Rackmount Rail Kit, Keyboard & Mouse
Dotworkz in Action
Over the last 12 years Dotworkz D2 /
D3 climate protection systems have
addressed the wide range of environmental challenges to protect mission
critical video surveillance electronics
on every continent.
Dotworkz Systems, Inc.
3688 Midway Drive
San Diego, CA 92110
Toll Free Phone: +1 866.575.4689
Outside USA: +1 619.224.5483
www.dotworkz.com
There are many ways to find Dotworkz products, based on the type
of customer you are.
Authorized Retailers: If you are an end user, you can go to the
Dotworkz Authorized Retailers list to find a retailer in your region. To
find retailers, go to the “Where to Buy” section at www.dotworkz.com
and select one of the Where to Buy options.
Authorized Distributors: If you are reseller or a systems integrator,
you can search for a distributor on the Dotworkz Authorized Distributor
page. To find distributors, go to the “Where to Buy” section at
www.dotworkz.com and click on Dealers and VARs Quick List.
Presales Support: If you have a question you would like answered
before buying, please call 866.575.4689 or fax 619.639.9914.
Dotworkz Online: The Dotworkz online features a rich selection of
Dotworkz products, informational videos, datasheets and even our
own live training center.
Visit us at www.dotworkz.com.
For more information on how to become a Dotworkz partner, please
go to www.dotworkz.com and click on Contact Us.
All Dotworkz Systems products are made in USA.
Loading...
