Dorma TS93 PT, TS93 PTH Installation Instructions Manual

TS93 PT/PTH
—

Surface applied door closer

Installation instructions:

Push side track mount with dead stop (PT)

Optional hold open (PTH)

TABLE OF CONTENTS
—

Closer overall

Technical specifications

Closer setup

A. Installing the surface closer

B. Adjustments

C. Installing the closer cover

Door templates 2

Size selection chart 2

Exploded parts list

Handing of the door 3

Installing back plate & angle bracket

Installing the surface closer 4

Adjusting the closing speeds

Adjusting the spring force 6

Adjusting the optional hold open 7

Installing the cover 7

Technical specifications

Tem pl at es

Contents

NOTE: Refer to the included drawings for push side door closer, back plate mounting templating.
NOTE: Refer to the included drawings for push side track, angle bracket mounting (soffit mount) templating.

Size selection chart

Door Width

Closer Interior/

Exterior

TS9315

TS9356

Note

1. Drawing is not to scale.

2. Dimensions are in inches/[mm].

3. Left hand door is shown.

4. Caution: sex nuts are required for attachment of

components to unreinforced doors and to wood or
plastic faced composite type fire doors, unless an
alternative method is identified in the individual door
manufacturer's listings.

5. Template is for 4-1/2 x 4-1/2 butt hinges & 3/4" offset
pivots

6. Maximum door opening degree is 110°.

7. Minimum door with 26".

Interior

Exterior

Interior

Exterior

2'-6"

min.

3'-0"
max.

N/AN/A N/A

3'-6"
max.

N/AN/AN/A

8. Hold open range is from 55° to 105° with optional hold

9. Use closer body style "G" for this installation.

10. Arrows on closer mounting plate point upward.

4'-0"
max.

open kit.

4'-6"
max.

N/A N/A

N/A N/A

5'-0 "
max.

DORMA USA, Inc. Dorma Drive, Drawer AC Toll-Free: 800-523-8483 E-mail: [e-mail]
08279211 05/14 Reamstown, PA 17567 Fax: [phone] Subject to change without notice

TS93 PT/PTH
—

Closer setup

Follow included template to properly prepare door and
frame for all accessories of the closer installation.

Know the swing of the door which is being installed prior
to installation.

The surface closer is comprised of the following components.

1. Closer body: "G" body

2. Main arm

3. Tra ck a s sem bl y

4. Pinion

5. Cover and end caps

6. Track cover

7

8

G

Verify closer spring size prior to installation. See "Size
selection chart" on page 2.

Make sure door efficiently operates prior to installing
closer.

7. Closing/sweep speed adjustment

8. Latch speed adjustment

9. Backcheck adjustment

10. Delayed action adjustment

11. Angle bracket

3

2

6

11

10

5

Handing the door

5

Hinge

4

Left hand door (LH)

9

Interior side of door

1

5

Right hand door (RH)

Hinge

Left hand reverse
door (LHR)

DORMA USA, Inc. Dorma Drive, Drawer AC Toll-Free: 800-523-8483 E-mail: [e-mail]

08279211 05/14 Reamstown, PA 17567 Fax: [phone] Subject to change without notice

Exterior side of door

Right hand reverse
door (RHR)

3

TS93 PT/PTH
—

A. Installing the surface closer

Tools recommended

 D rill Bits

Metal: No. 21 & 10-32 Tap
Wood: 9/64"

Installing the back plate and angle bracket

1

Reference template 08279212

NOTE: For use on regular mount applications on the push side

of the door.

Installing the surface closer

1

 #0 Phillips screwdriver
 #2 Phillips screwdriver
 3/16" flat head screwdriver
 M2.5 & M5 Hex key

2

1.1 Attach the angle bracket (1) to the bottom of the soffit
using the three [10-32 machine screws or #10 wood
screws] provided.

1.2 Attach the back plate (2) to the mounting surface using
the four screws [10-32 machine screws or #10 wood
screws] provided with the surface closer.

NOTE: Make sure arrows on
plate point upward.

Toward the
hinge

2

: Orient pinion (1) closest to hinge.

NOTE

3

1

2

1

Left hand door

2

2.1 Attach the closer body (2) to the plate using the four
screws provided with the plate itself.

3.1 Us

ing an adjustable wrench (and looking up at the

bottom of the closer):

 Left hand door - turn the bottom pinion counter-

clockwise 5°.

 Right hand door - turn the bottom pinion clockwise 5°.

3.2 Attach the main arm (1) to the top pinion with an
M6x20 socket head cap screw (2) using an M5 hex key.

Be sure the main arm is parallel to the door during

application.

DORMA USA, Inc. Dorma Drive, Drawer AC Toll-Free: 800-523-8483 E-mail: [e-mail]

4

08279211 05/14 Reamstown, PA 17567 Fax: [phone] Subject to change without notice

TS93 PT/PTH
—

HINGE

Left hand door - No hold open

A

Part No.: TH KIT 93 ONLY

1

B

A

H

E

C

D

Left hand door - With hold open

Right hand door - No hold open

H

G

Right hand door - With hold open

F

F

G

HINGE

E

D

C

B

A

A

3

1

C
viewing of the track assembly.

4

4.1 Position the individual components inside the track

channel and screw down each fitting.

NOTE: For PTH ONLY - orient the hold open mechanism as

seen in the image above. Hold open mechanism and
hold open slide shoe must be installed with the arrows
pointing away from the hinges.

5

Hinge

1

loser is omitted in image for better

4.2 Attach the track channel (1) to the angle bracket (2)

through the end blocks with two flat head Phillips
screws (3).

A. End block

B. Dead stop adjustable anchor

C. Cushion

D. Cushion protector

2

E. Hold open mechanism

F. Track channel

G. Slide shoe

H. Hold open slide shoe

Left hand door

Left hand door

2

5.1 Align the arm (1) with the slide shoe of the track channel.

DORMA USA, Inc. Dorma Drive, Drawer AC Toll-Free: 800-523-8483 E-mail: [e-mail]

08279211 05/14 Reamstown, PA 17567 Fax: [phone] Subject to change without notice

5.2 Attach with one M8x15mm shoulder bolt (2) using an M5
hex key.

5

TS93 PT/PTH
—

B. Adjustments

Confirm closer spring size prior to making any closing
speed adjustments.
Do not back valves out beyond closer casting.

Adjusting the closing speeds: sweep, latch or backcheck and delayed actions

1 [Sweep]

Delayed action

Backcheck

Sweep

1

1.1 Adjust the sweep speed (1) for the area from 70° - 0°

 Increase sweep speed: Turn valve counter-clockwise

 Decrease sweep speed: Turn valve clockwise.

1.2 Adjust the latch speed (2) for the area from 7° - 0°.

 Increase latch speed: Turn valve counter-clockwise

Maximum opening angle is 110º.

Door should close in 3 to 6 seconds from 90º.

Do not close valves completely.

4 [Delayed action]

Latch

1.3 Adjust the backcheck (3) for the area from 65° - 110°.

 Increase resistance: Turn valve clockwise

 Decrease resistance: Turn valve counter-clockwise.

1.4 Adjust the delayed action (4) for the area from
110° - 70°.

 Increase delayed action: Turn valve clockwise

 Decrease delayed action: Turn valve counter-clockwise

2 [Latch]

Decrease

Increase

Increase

Decrease

3 [Backcheck]

Sweep & Latch
Speed

Backcheck &
Delayed actions

Adjusting the spring force

Increase

Decrease

2

TS9315

NOTE: Supplied with a size 2 spring setting.

Barrier free openings: Take an opening force reading from the

pull on the door. If required, adjust the spring force to meet
the barrier-free requirement.

 Decrease force: turn counter-clockwise 5 times (max)

 Increase force: turn clockwise 12 times (max)
Depending on opening conditions, a door adjusted to meet
barrier-free forces may not have sufficient power to reliably
close and latch the door.

TS9356

NOTE: Supplied with a size 6 spring setting.

 Increase force: turn clockwise 6 times (max)

DORMA USA, Inc. Dorma Drive, Drawer AC Toll-Free: 800-523-8483 E-mail: [e-mail]

6

08279211 05/14 Reamstown, PA 17567 Fax: [phone] Subject to change without notice

CLOSER

TYPE

TS9315

TS9356

TS9315

TS9356

MAX DOOR

WEIGHT (LBS)

100 2 0

125 3 +3

150 4 +9

200 5 +12

200 5 -4

250 6 0

DOOR WIDTH

IN T. E XT.

2'6" ----- 0 2

3' 2'6" +3 3

3'6" 3' +9 4

4' 3'6" +12 5

4' 3'6" -4 5

4'6" 4' 0 6

SPRING

SIZE

FULL TURNS OF

SPRING ADJUSTER

FULL TURNS OF

SPRING ADJUSTER

CLOSER

SIZE

TS93 PT/PTH
—

Adjusting the optional hold open

1

2

3

3.1 Slide the hold open mechanism (1) to the desired

location inside the track, to hold the door open to the
desired degree.

NOTE: Refer to section A, step #4 for hold open mechanism

location dependent upon hand of door.

3.2 Using an M2.5 hex key, tighten the set screw (2) to

secure the hold open mechanism.

3

4

2.5mm set screw

(inside the M8x15 hex screw)

3.3 To adjust the force of the hold open force, engage the

hold open feature by opening the door and allowing the
hold open slide shoe (3) to slide over top of the hold open
mechanism and click into place.

3.4 Inside the M8x15mm hex screw (4) is a 2.5mm set
screw. To adjust the hold open force, use an M2.5 hex
key and turn the set screw:

 Clockwise = increase force
 Counter clockwise = decrease force

C. Installing the closer covers

Installing the covers

1

1.1 S

nap both end covers (1) into place.

1.2 Remove the un-needed tab (2), and snap the closer body
cover (3) into place.

1

2

4

3

1

5

3

1.3 Attach with a 4-40 Phillips pan head screw (4) .

1.4 Snap the track cover (5) into place.
