Page 1
RIDER’S MANUAL
• Read and understand this manual prior to riding your DSA scooter. Call DSA for assistance if needed.
• Note: Product illustrations are used for assembly purposes only.
Actual product specications are subject to change without notice.
Page 2
SAFETY WARNING
!
This manual contains important information.
For your child’s safety, it is your responsibility
to review this information with your child and
make sure that your child understands all
warnings, cautions, instructions and safety
topics.
DSA recommends that from time to time you
talk about the information in this manual with
younger riders and that you are required to
inspect and maintain your child’s scooter to
insure their safety.
MESSAGE TO PARENTS WARNING
GENERAL WARNING
Freestyle Scooter riding can be a hazardous activity. Performance scooters can
and are intended to move and it is
therefore possible to encounter dangerous situations and/or lose control or fall.
If such actions occur you may be seriously injured or die.
AS WITH ANY MOVING PRODUCT, USING
A SCOOTER CAN BE A DANGEROUS
ACTIVITY AND MAY RESULT IN INJURY OR
DEATH EVEN WHEN USED WITH PROPER
PRECAUTIONS FOR RISK REDUCTION.
RIDE AT YOUR OWN RISK AND USE
COMMON SENSE.
• Please read all enclosed materials including
the safety manual before riding.
• Recommended for riders age 8+ and up to
220Lbs (100kg).
• Always wear safety equipment, helmet, knee
pads, elbow pads and shoes.
• Adults must assist children in the assembly
and adjustment of this scooter.
• Ride on smooth, paved surfaces away from
motor vehicles and pedestrians.
• Do not ride on wet or sandy areas, avoid
steep hills, drainage grates and sudden surface
changes.
• Do not ride at night or in places with poor
visibility.
• Brake will get hot, do not touch after use.
• Check and secure all components before
every ride.
• Replace worn or broken parts immediately.
• Competent adult supervision recommended
at all times.
• This scooter was manufactured for
performance and durability but is not
impervious to damage. Freestyle and trick
riding can cause undue stress, fatigue or
damage to any product. The rider assumes all
risks and responsibilities when engaging in
these types of activities.
• This scooter works optimally with its original
parts. We do not advise removing or
substituting for other parts, it may
compromise the performance of the scooter.
Page 3
KNOW YOUR SCOOTER
PARTS INSPECTION TOOL INCLUDED
Handlebar
SCS clamp
Headset
Fork
Metal core wheels
Deck
Flex brake
Grips
Before you start, remove contents from
box. Inspect the contents for scratches
in the paint and/or dents that may have
occurred during shipping. Your new
scooter was partially assembled at our
factory and there should not be any
problems, even if the box has been
bumped or dented enroute to you.
Allen wrench
5mm
Page 4
ASSEMBLY INSTRUCTIONS
1
WARNING
!
1
3
2
Loosen the bolts of the SCS clamp a
bit. Push the bar into the SCS clamp
until it can't go any further.
Before placing the bars, using a 5mm
Allen wrench check that the SCS
compression is tightened securely
and the headset is not shaking.
Failure to properly install and tighten
the collar clamp may cause the rider
to lose control and fall. If you do not
understand these instructions or the
concept of “tighten securely” seek the
With the front wheel pointed straight
ahead, the bars square to the wheel
and the Dominator logo facing the
front, Use the 6mm Allen wrench to
tight the SCS clamp as shown.
Tighten each bolt securely.
Page 5
SAFETY REMINDER
LOOSE PARTS BE CAREFUL
REPLACEMENT PARTS
SAFETY GEAR
!
Check and secure all fasteners
before every ride. Make sure the
collar clamp is locked properly in
place before riding.
Replace worn or broken parts
immediately. Visit our website
www.dominatorscooters.com
to see our range of spare parts.
Always wear proper protective
equipment such as an approved
safety helmet, elbow pads and
kneepads. Always wear shoes
(lace-up with rubber soles), never
ride barefooted or in sandals, and
keep shoelaces tied and out of the
way of the wheels.
You will see people on TV and maybe
even people you know doing tricks
and stunts. These are people who
have been practicing on scooters for
a very long time. Don’t try something
until you are ready. Avoid steep
inclines and don’t ride too fast, you
can lose control and fall. Skateboard
parks are not designed for scooters.
Never ride in traffic or on the street
and watch your surroundings for
pedestrians, bikers, boarders and
skaters.
Maintain a hold on the handlebars at
all times.
Wheelies and other stunt-type riding
reduces your ability to maneuver and
control your scooter.
Take the necessary precautions, such
as wearing appropriate protective
gear and practice in an area safe for
stunt riding and free from
obstructions.
Page 6
MAINTENANCE
COMPRESSION
WHEELS AND BEARINGS
Under normal circumstances and
conditions DSA Wheels and
wheelbearings are maintenance
free.
Do not allow water to penetrate
the bearings as they will rust.
Lubricating your bearings can be
done by taking off your wheels,
using a dry cloth to remove dirt
from your bearings and wheels,
remove the bearing rubber seal
carefully by using the tip of a
sharp knife and lift the seal on the
edge of the seal. Use 1 or 2 drops
Teon oil (PTFE) and press back
the seal carefully. Your bearings
will make some noise just after
cleaning but it will go away after a
short notice.
If your bar starts to shake or
move, it means that your
compression needs to be tightened. Tighten as explained in the
Assembly Instructions.
We also recommend to tight the
compression just enough to keep
the headset spinning smoothly,
then tighten the bolts of the
clamp well (no too tight though
or it will strip). Be aware to check
your compression (as all other
bolts/axles) on a regular base.
CLEANING YOUR SCOOTER
Wipe with a damp cloth to
remove dirt and dust.
Do not use industrial cleaners or
solvents as they may damage the
surface.
Page 7
LIMITED WARRANTY
Dominator SIX MONTH LIMITED WARRANTY
For a period of six (6) months from the date of purchase by the original
Purchaser, Dominator® warrants its products to be free from defects in material
and workmanship. This warranty is not transferable to any subsequent owner.
This warranty does not cover I) normal wear and tear; II) improper assembly; III)
failure to perform or improper maintenance; IV) the installation of components,
parts, or accessories not provided by Dominator®; V) damage or failure due to
accident, misuse, abuse, or neglect; VI) labor charges for part replacement.
In event of a warranty claim, Purchaser must return the Dominator® product to
the Dealer from whom the product was purchased with proof of purchase.
LIMITATION OF REMEDY
The purchaser's sole remedy shall be the repair or replacement of defective
parts and is at the discretion of the manufacturer, the purchaser must retain
evidence of proof of purchase from an authorized dealer. Shipping to and from
the dealer and or repair facility is the sole responsibility of the customer.
DISCLAIMER OF IMPLIED WARRANTIES
Any and all implied warranties, including those of mechantability and/or tness
for a particular purpose are hereby expressly disclaimed.
LIMITATION OF LIABILITY
Under no circumstance will Dominator® or any seller of its products be liable
for any special, incidental or consequential loss and/or damages.
THIS IS DOMINATOR®’s SOLE AND EXCLUSIVE WARRANTY
Questions? Our freestyle scooter experts are here to help.
Page 8
WWW.DOMINATORSCOOTERS.COM
Eastward Sports Group
390 Meyer Circle
92879 Corona (CA)
USA
