Doepfer D3C User Manual
DOEPFER
Organ Controller
d3c
User's Guide
Operating and Safety Instructions
Please follow the given instructions for use of the instrument because this will guarantee
correct instrument operation. Due to the fact that these instructions touch on Product
Liability, it is absolutely imperative that they be read carefully. Any claim for defect will be
rejected if one or more of the items was observed. Disregard of the instructions can
endanger warranty.
•
The instrument may only be used for the purpose described in this operating manual.
Due to safety reasons, the instrument must never be used for other purposes not
described in this manual. If you are not sure about the intended purpose of the
instrument please contact an expert.
•
The instrument has to be shipped only in the original packaging. Any instruments shipped
to us for return, exchange, warranty repair, update or examination must be in their
original packaging! Any other deliveries will be rejected. Therefore, you should keep the
original packaging and the technical documentation.
•
The instrument may only be operated with the voltage written on the power input on the
rear panel. Before opening the case disconnect the power plug.
•
Every modification has to be carried out only at the manufacturer or an authorized
service company. Any modification not released by the manufacturer leads to the
extinction of the operation permission.
•
With the introduction of a third person the warranty will be lost. In case of a destroyed
warranty seal, any warranty claim will be rejected.
•
The instrument must never be operated outdoors but only in dry, closed rooms. Never
use the instrument in a humid or wet environment nor near inflammables.
•
No liquids or conducting materials must get into the instrument. If this should happen the
instrument must be disconnected from power immediately and be examined, cleaned and
eventually be repaired by a qualified person.
•
Never subject the instrument to temperatures above +50°C or below -10°C. Before
operation the instrument should have a temperature of at least 10°C. Do not place the
instrument into direct sun light. Do not install the instrument near heat sources.
•
Keep the top side of the instrument free in order to guarantee proper ventilation,
otherwise the instrument could be overheated. Never place heavy objects on the
instrument.
•
All cables connected with the instrument must be checked periodically. If there is any
damage the cables must be repaired or replaced by an authorized person.
•
Transport the instrument carefully, never let it fall or overturn. Make sure that during
transport and in use the instrument has a proper stand and does not fall, slip or turn over
because persons could be injured.
•
Never use the instrument in the immediate proximity of interfering electronic devices (e.g.
monitors, computers) since this could create disturbances within the instrument and
corrupt memory data.
•
The exchange of electronic parts (e.g. EPROMs for software update) is allowed only if
the instrument is disconnected from power supply.
•
When using the instrument in Germany, the appropriate VDE standards must be
followed. The following standards are of special importance: DIN VDE 0100 (Teil
300/11.85, Teil 410/11.83, Teil 481/10.87), DIN VDE 0532 (Teil 1/03.82), DIN VDE 0550
(Teil 1/12.69), DIN VDE 0551 (05.72), DIN VDE 0551e (06.75), DIN VDE 0700 (Teil
1/02.81, Teil 207/10.82), DIN VDE 0711 (Teil 500/10.89), DIN VDE 0860 (05.89), DIN
VDE 0869 (01.85). VDE papers can be obtained from the VDE-Verlag GmbH, Berlin.
d3c Page 2 User's Guide V1.0
Servicing / Updates
There are no controls, adjustments or other elements inside the case that have to be
operated by the user.
In case of an firmware update the case has to be opened to replace the main processor by
the new version. This service has to be carried out normally by the representative or dealer
where the device has been purchased. The service is offered by the manufacturer (Doepfer,
Germany) or an authorized dealer or service company too. Please look at the web site
www.doepfer.com for a list of all authorized companies.
Any firmware update is not free of charge. The costs for material, working time and shipment
is charged to the customer.
You may even carry out firmware updates yourself at your own risk. In this case the warranty
is lost if a mistake is made during the firmware update.
Pay attention that cases that are damaged while the device has been opened/closed (e.g.
scratched surface, damaged screws) cannot be taken back and the warranty is void.
The device d3c uses a rechargeable battery (accumulator) for memory backup of preset
data. These electronic parts have a limited lifespan and have to be inspected at least every
two years. This should be carried out by qualified personnel only as technical knowledge and
soldering experience is necessary. If you are able to carry out the inspection and the
possible replacement yourself this is the checking/replacement procedure:
•
Disconnect the device completely from mains voltage (i.e. remove the mains cable,
turning the device off with a mains switch is not sufficient !)
•
Open the case and find out the position of the battery (this is a black or blue cylindric
electronic part with about 15 mm diameter and 15 mm length, the target voltage "3.6V" is
printed on the part).
•
Optical inspection: check if the battery is still sealed and has no leakage.
•
Electrical inspection: measure the battery voltage with a suitable instrument (e.g. digital
multimeter in voltage mode). The voltage has to be within 10% of the target voltage
(3.6V), i.e. between ~ 3.2V and ~ 3.9V.
•
If the optical or electrical inspection indicates any fault the battery has to be replaced by
the same type (i.e. 3.6V rechargeable battery / accumulator with the same dimension).
Suitable batteries are available in electronic stores or from your local Doepfer
representative as spare part.
•
If the battery is defective the old one has to be removed (desoldered) and the new one
put in (soldered).
•
muss der Akkumulator ausgewechselt werden. Der Akkumulator ist im Elektronik-
Fachhandel erhältlich oder kann von uns oder einer unserer Vertretungen als Ersatzteil
bezogen werden.
•
It is not allowed to put the old battery to the normal garbage. Please forward the old
battery for recycling to a suitable receiving office.
Technical data are subject to change without notice.
The topical version of this guide is available for download as pdf file on our website
www.doepfer.com (MANUALS section).
© 2006 by
Doepfer Musikelektronik GmbH
Geigerstr. 13
82166 Gräfelfing
Phone: +49 89 89809510
Fax: +49 89 89809511
www.doepfer.com
d3c Page 3 User's Guide V1.0
Contents
Operating and Safety Instructions................................................................................2
Servicing / Updates ...................................................................................................... 3
Introduction ..................................................................................................................5
Connections (rear panel).............................................................................................. 6
Power Supply
pppp
USB
Midi In
FOOT CONTROL
FOOT SWITCH
Operation ...................................................................................................................10
Operation Modes ....................................................................................................12
B4 Mode .............................................................................................................. 12
Other Modes........................................................................................................13
Appendix .................................................................................................................... 14
Firmware updates ...................................................................................................14
Troubleshooting ......................................................................................................14
.....................................................................................................................7
qqqq
nnnn oooo
/ Midi Out
]]]]
____
...................................................................................................9
................................................................................................6
rrrr
...........................................................................................7
^^^^
/
......................................................................................9
d3c Page 4 User's Guide V1.0
Introduction
d3c is part of the modular organ masterkeyboard system d3 that is intended as a control
unit for organ emulations like Native Instruments B4 or Emagic evb3. The system has two
modules available: the keyboard unit d3m and the drawbar control unit d3c. Each of the
modules can be used alone or in combination with the other modules. The maximum system
consists of two keyboards d3m and one control unit d3c (and one bass pedal d3b as soon as
it is available). The bass pedal d3b is in preparation as the third module of the system.
The second part of the modular concept is drawbar control unit d3c: This unit contains all
elements required to control a typical organ emulation: 9 drawbars for upper manual, 9
drawbars for lower manual, 2 drawbars for bass pedal, 6 rotary controls for the parameters of
tube and percussion and a lot of additional buttons for vibrato, chorus, key click, rotary
speakers and so on. Even the 10 + 12 program selection buttons of the keyboard unit d3m
are available. This is necessary if the (one or two) d3m are mounted with hidden button
sections.
The connection between the d3 modules is established via Midi. The control unit d3c is
equipped with both Midi and USB interface. This allows to connect the d3 combination to
both worlds Midi and USB (e.g. a laptop that runs B4 or evb3).
The control unit d3c can be used as a stand-alone device or in combination with one
or two of the d3m keyboards (or even with other Midi keyboards). The mechanical
connection between the units is made with mounting angles or wooden side plates
that are available as accessories. Details about the available accessories and the
different mounting versions of d3m and dc3 can be found on our website
www.doepfer.com.
d3c Page 5 User's Guide V1.0
