1. Introduction
Module A-180 (MULTIPLES) is a multi-connector.
It has eight inter-connected sockets, so that you can
patch more inputs or outputs into any module.
The sockets can be split into two groups of four by
disconnecting an internal solder bridge.
Modification from Dezember 2003: The module is
shipped in the dual quad version (two groups with 4
connected sockets each, no solder bridge). To obtain
a 8-fold multiple the solder bridge has to be installed.
The modification was made as normally two quad
multiples are more often needed that a 8-fold multiple.
MULTIPLES A-180
1
A-180
MULTIPLES
System A - 100
doepfer
2. Overview
A-180
MULTIPLES
In / Outputs
... (: 8 interconnected sockets
!
H
By removing the internal solder link between
sockets $ and % you can split the multiples
into two groups of four:
Group 1: sockets ! to
Group 2: sockets % to (.
That way, you have two separate four-way
distribution matrices.
$
H From Dezember 2003 this version is the
factory setting !
2
doepfer
3. Patch-Sheet
System A - 100
MULTIPLES A-180
The following diagrams of the module can help
you recall your own Patches. They’re designed so
that a complete 19” rack of modules will fit onto an
A4 sheet of paper.
Photocopy this page, and cut out the pictures of
this and your other modules. You can then stick
them onto another piece of paper, and create a
diagram of your own system.
Make multiple copies of your composite diagram,
and use them for remembering good patches and
set-ups.
P • Draw in patchleads with colored
pens.
A-180
MULTIPLES
8-way multiples
A-180
MULTIPLES
A-180
MULTIPLES
4-way multiples
A-180
MULTIPLES
3
