1. Introduction
Module A-160 (Clock Divider) is a frequency divider
for clock signals, designed to be a source of lower
frequencies, particularly for rhythm uses.
The Trigger input will take clock signals from, eg., an
LFO, MIDI sync, or the gate from a MIDI-CV interface.
At the outputs, you have access to the sub-divided
clock signals
1/64.
Clock Divider A-160
, from half the clock frequency down to
/ 4
/ 8
/ 16
/ 32
/ 64
The A-160 also has a reset input. Whenever a reset
signal is sensed, all outputs are set to zero, until the
reset voltage disappears.
The Clock Divider can be used in combination with the
A-161 Clock Sequencer
to produce stepped sequen-
ces with a length of from one to eight events.
1
A-160
Clock Divider
System A - 100
doepfer
2. Overview
➀
➁
➂
➃
➄
➅
A-160
CLOCK
DIVIDER
Trig.
In
Res.
In
/ 2
/ 4
/ 8
/ 16
/ 32
/ 64
Indicators:
LED : Clock / 2 indicator
1
2 LED : Clock / 4 indicator
: Clock / 8 indicator
LED
3
LED : Clock / 16 indicator
4
5 LED : Clock / 32 indicator
: Clock / 64 indicator
LED
6
In / Outputs:
! Trig. In : clock signal input
Res. In
"
/2 : 1/2 clock frequency output
§
$ /4 : 1/4 clock frequency output
/8 : 1/8 clock frequency output
%
/16 : 1/16 clock frequency output
&
/ /32 : 1/32 clock frequency output
/64 : 1/64 clock frequency output
(
: reset input
2
doepfer
System A - 100
Clock Divider A-160
3. Indicators
LED ... 6 LED
1
LEDs 1 to 6 indicate the status of each of the subdivided frequencies at outputs § to (.
4. In / Outputs
! Trig. In
Trigger input
here.
" Res. In
Socket " is the
reset voltage is sensed, all outputs go to zero, for as
long as the reset voltage is present. (ie. a ‘static
reset’)
H With a Clock Sequencer (A-161) connected,
P
: patch the frequency to be divided in
reset input
every time the A-160 senses a reset signal,
the A-161 returns to output ! .
With the help of the reset input, you can
produce sequences with less than eight
steps. For instance, by patching output / of
the A-161 to the reset input socket " of the
A-160 you get a six-step sequence. (Instead
of going to step seven, it resets to step one.)
for the A-160. When a
§ /2 ... ( /64
Sockets § to ( are the A-160
sub-divided clock signals are available.
outputs
, from which the
5. User examples
"Ping-Pong" effect
The patch in Fig. 1 produces a "Ping-Pong" effect: with
each note on the keyboard (gate signal) the audio
jumps between left and right outputs - Out
The A-160 is halving the gate frequency, and triggering the A-150 VCS, so that each of its outputs is
active only every other note.
ADSR envelope with re-triggering
In the patch in Fig. 2, an ADSR is re-triggered by a
square wave LFO, sub-divided in the A-160 by a factor
of four (output $). The original whole LFO oscillation is
patched to the re-trigger input on the ADSR. In this
way, a new repeating envelope is created.
and Out
L
R
.
3
A-160
Clock Divider
System A - 100
doepfer
O/ I
Audio
A-150
Gate
A-160
CLOCK
DIVIDER
Trig.
In
/ 2
ADSR
Fig. 1: Ping-Pong effect
CV
I/ O 1
I/ O 2
A-131
A-131
Out
Out
A-160
CLOCK
DIVIDER
L
R
LFO
: ADSR envelope with retriggering
Fig. 2
Tri g.
In
/ 4
Gate
Ret ri g ge r
ADSR
P By using different outputs on the A-160 it’s
possible to have envelopes re-triggering different numbers of times, from two to thirtytwo.
In addition, by using an A-161, 3-, 5-, 6- or 7step triggering is possible as well. You patch
the A-161’s $, %, & or / output to the gate
input of the ADSR. Output %, &, / or ( is
patched to the A-160’s " reset input socket.
H Other suggestions for using the A-160 are in
the A-161 Clock Sequencer’s section of the
manual.
4
doepfer
System A - 100
Clock Divider A-160
5
A-160
Clock Divider
System A - 100
6. Patch-Sheet
The following diagrams of the module can help you
recall your own
Patches
complete 19” rack of modules will fit onto an A4
sheet of paper.
Photocopy this page, and cut out the pictures of this
and your other modules. You can then stick them
onto another piece of paper, and create a diagram of
your own system.
. They’re designed so that a
