Doepfer A-112 User Manual

doepfer
System A - 100
1. Introduction
Sampler
A-112
A-112
SAMPLER
MIDI In
MIDI Out
Man. Trig.
Gate In
Audio IN / Wave-CV In
CV In
Audio Out
Modus
Atten.
Tune
Run
Module including a voltage controlled 8 bit Sampler and a voltage controlled Wavetable Oscillator.
The module has the characteristic “grungy“ sound
of the early 8 bit Samplers and is a welcome addi­tion to the A-100’s sound generating capabilities.
But it should not be compared with the polyphonic 16 bit MIDI samplers available on the market.
The module contains an A/D converter (ADC) for recording the audio signal (8 bit resolution), digital
memory converter (DAC) for playback and the control unit.
The memory is divided into two kbyte each. In wavetable mode each bank is arranged as 256
The memory is sampling data in the memory is maintained.
A-112 (SAMPLER
for storage of the the sampled signal, a
of 256 bytes.
pages
non-volatile
) is a combination module,
D/A
banks
, i.e. after power-off the
(S1, S2) with 64
1
A-112
Sampler
System A - 100
doepfer
Sampling mode
In sampling mode the incoming audio signal is sam­pled with a
manually and from the external control voltage input. The audio signal is converted by the ADC into 8
bit digital data and mory (memory address 0 ... 65 535). With a sampling frequency of 32kHz this corresponds to 2 seconds sampling time. During playback the sampling data in the memory is read sequentially (address 0 ... 65535) and converted into the corresponding audio signal by the DAC. The sampling frequency in play mode is controlled manu­ally and from the external control voltage input. Play­back is stopped if the last memory address (65535) is reached.
Via MIDI dump the sampling memory can be sent to a computer for storing the data on hard-disk or any other storage device. The computer may also transmit sampling data to the A-112 via MIDI dump.
Wavetable mode
In wavetable mode the memory access is not sequen­tially but by an external voltage. This voltage can be may genera­ted manually (e.g. with the manual control voltage
sampling frequency
sequentially
. The
page
page number
that is controlled
written into the me-
is selected by
source A-176) or it may come from any other voltage source (e.g. LFO, ADSR, Sequencer). Both record and play take place in a loop whereby the complete page is always passed through. When reaching the end of a page the run control determines if a jump to another page takes place or the loop remains in the same page
- depending upon the voltage controlling the wa­vetable/page. Playback with a dynamic control voltage (e.g. ADSR, LFO, Random, Sequencer, MIDI-to-CV) results in “sweeping through“ the different pages (Wavetable principle). If the memory of the A-112 contains sui­table wavetables in the 256 pages, the result is a voltage controlled Wavetable Oscillator with two con­trol voltages: one for the audio frequency (pitch, tune), one for the wavetable number.
Normally suitable wavetables are generated by a com­puter and transferred to the A-112 via
Effect mode
Additionally the module offers some effects, like De­lay, Reverse Delay
to the 8 bit resolution these effects are not to be compared however with the results from high-end effect devices, but should be considered as a free extra gift for strange sounds.
and
Pitch Shifter
MIDI-Dump.
. Of course, due
2
doepfer
System A - 100
Sampler
A-112
2. SAMPLER Overview
A-112
VC Sampler / Wavetable Osc.
Eff
Dmp
Pit
Loop Wav
Audio In / Wave-CV In
S1
Play
Del
Norm
Gate In
CV In
SAMPLER
MIDI Out
S2
Rec
MIDI In
Rev
FrzLen
Man. Trig.
Run
0
0
Audio Out
10
10
Atten.
Tune
Controls:
1 Atten. : Attenuator for Audio/Wave CV
Input
!
Tune : Manual control for Sampling fre-
2
quency
: Gate indicator LED / overload
Run
3
warning during record
Man. Trig.
4
... 7 Switches: 3-position switches for mode se-
5
: manual trigger/start button
lection
In / Outputs:
Audio /
!
Wave-CV In
CV In : pitch control input (1V/oct.) for
"
§ Gate In
Audio Out
$
% MIDI In : MIDI input
& MIDI Out
: Input for audio signal resp. wa-
vetable control voltage in wa­vetable mode
tuning or sampling frequency
: Gate input
: Audio output
: MIDI output
3
A-112
Sampler
System A - 100
doepfer
3. Controls
1 Atten.
Control 1 attenuates the
!. Depending upon the mode this voltage is the audio signal (in sampling or effect mode) or the wavetable control voltage (in wavetable mode).
2 Tune
The tune control 2 is used to adjust the sampling frequency (during record) or the pitch/tune during
playback (see table below).
Exception: In pages is selected with the tune control (see following table). In this case the sampling frequency defaults to the last frequency that was set prior to switching into wavetable mode.
tune
position
0 0 2,0 6 154 18,5
1 26 2,9 7 179 26,5
2 51 4,2 8 205 38,5
3 77 6,1 9 231 56,2
4 103 8,8 10 255 79,4
5 128 12,7
wavetable record
page
(appr.)
sampling­freq. [kHz]
of the voltage at input
level
mode
tune-
position
one of the 256
page
(appr.)
sampling­freq. [kHz]
H
The voltage generated with the tune control is internally added to the voltage at input ". This input is normally used to control the pitch of the sampler/wavetable oscillator in play mode with an external control voltage following the 1V/oct standard (e.g. the A-190 MIDI-to-CV interface).
3 Run
LED 3 is used for different depending upon the mode selected. A description of the respective function is given in the corresponding paragraph elsewhere in this manual.
monitoring purposes
4 Man. Trig.
Button 4
is used to trigger the sampler Depending upon the mode selected a Trigger or Gate leads to different actions. A description of the respective functions is given in the corresponding paragraph elsewhere in this manual.
manually.
H The manual trigger generated with button 4
and the signal at the gate input § are inter­nally connected, to produce a gate/trigger signal used for all triggered/gated functions.
The data in the table are approximate values
4
doepfer
System A - 100
Sampler
A-112
55556
S1, S2 Play Norm
Eff
67
66
Dmp Norm
Rec Norm
Pit Norm
Del Norm
Rev Norm
7
77
Loop
Wav
Loop
Wav
Loop
Wav
Len
Frz.
Len
Frz.
Len
Frz.
Function
not implemented
Dump a sample
Dump a wave
Play a loop
Play a sample
Play a wave
Record a loop
Record a sample
Record a wave
Input sample length required
Pitch Shift
Pitch Shift with "Freeze"
Input sample length required
Delay
Delay with "Freeze"
Input sample length required
Reverse Delay
Reverse Delay with "Freeze"
5 Switch • 6 Switch • 7 Switch
With the 3-position switches 4 to 6 the operating mode is selected. The table on the left lists all possible modes. The modes are described in the following paragraphs.
In particular the gate signal (gate input § / manual trigger 4) controls different functions in the respective operating modes.
H
Please note that in some modes it is not sufficient to change the switches position to exit the mode. In the following description of the modes you will find detailed information on how to exit a selected mode.
5
A-112
Sampler
System A - 100
doepfer
Normal record mode
55556
67
66
S1,S2Rec Norm
In this mode an audio signal at audio input 1 is recorded into one of the 2 memory banks S1 or S2 (depending upon the position of switch
Gate = low :
In this case the pre-listening mode is active (LED 3 is off); the audio signal at input 1 is digitized by the ADC, re-converted by the DAC and forwarded to audio output 4 for pre-listening.
The pre-listening mode contains an ping function: as soon as the audio signal exceeds a predefined upper or lower threshold the LED 3 lights up for a short moment (about 10 ms). During this time the audio signal is not scanned and the output remains at the last DAC value. The onset of clipping (i.e. overload distortion) is immediately audible.
Audio / Wave-CV In
7
77
Audio signal sampling fre-
Tune / CV
quency (while Gate = low)
5).
overload/ clip-
H The sound quality in the pre-listening mode
is very poor. The quality if a signal is recor­ded and played back is much better!
The pre-listening mode is also used to find out and set the sampling frequency. When record mode is entered (see below) the last sampling frequency in pre-listening mode is used.
Gate = high:
When the gate level changes from low to high Record is triggered and the audio signal is sampled into the memory bank selected with switch on. Recording starts at address 0 and continues until the last address (65 535) is reached and LED 3 turns off. If gate turns low before the end of the sampling memory (address 65 535) is reached the record pro­cess stops. You can use this function to sample cho­sen segments of sound.
5. LED 3 is now
Normal play mode
55556
67
66
S1,S2Play Norm
In this mode a previously recorded sample in the sampling memory (S1 or S2, depending upon the position of switch
Audio / Wave-CV In
7
77
- - - - - - - sampling fre-
5) is played back.
Tune / CV
quency
6
doepfer
System A - 100
Sampler
A-112
Gate = low:
The module is waiting for gate = high; LED 3 is off (see fig. 1 - a).
Gate = high:
When the gate level changes from low to high back is triggered and the audio signal in the memory bank is played back. LED 3 is now on. Playback starts at address 0 and continues until the last address (65
535) is reached and LED 3 turns off. Even if the gate goes low before the end of the sampling memory is reached the playback continues (see fig. 1 - b).
Only if the gate goes low and high again before the end is reached the sample is retriggered, i.e. the playback starts again at address 0 (see fig. 1 - c).
If the gate is still high when the end of the sample memory is reached the playback stops (i.e. no loop if gate remains high). For this purpose the loop mode is used.
Play-
Audio
Out
Gate
fig. 1: normal play mode
55556
S1,S2Rec Loop
This mode is very similar to the normal record mode (see above). The only difference to the normal re-
cord mode is that record continues when the end of the sample memory is reached and the gate level is still high
Sa m p l e
a
b
Loop record mode
67
66
.
Audio / Wave-CV In
7
77
c
Tune / CV
audio signal sampling fre-
quency (only if Gate = low)
7
A-112
Sampler
System A - 100
doepfer
In this case the record starts again at the first memory address. This loop continues (LED 3 on) until gate turns low.
Loop play mode
55556
67
66
S1,S2Play Loop
Audio / Wave-CV In
7
77
- - - - - - - - - sampling fre-
In normal play mode the playback stops if the end of the sample memory is reached. The loop play mode allows the
continuous playback of a pre-defined
section of the sample memory.
Gate function:
As long as the gate level is high the sample is played continuously. When the end of the sample is reached, playback starts again at the beginning (see fig. 2 - a). LED 3 is on.
As soon as the
gate goes low
the present position within the sample is defined as loop end (see fig. 2 - b). Playback starts at the beginning (address 0) and runs continuously from the beginning to the loop end
Tune / CV
quency
as long as the gate level remains low (see fig. 2: loop
1).
If gate turns high (see fig. 1 - c) the loop end is cancelled and the sample playback uses the full range again (i.e. loop end = end of sample memory, see fig. 2 - d).
If the gate goes low again a new loop end is set (see fig. 2 - e, loop 2).
To
loop play mode a short
exit
trigger pulse
(max.
duration 100 ms) is required (see fig. 2 -f).
Audio
Out
Gate
Sam pl e
b
c
a
Loop 1
d
e
Loop 2
fig. 2: Loop play mode
f
8
doepfer
System A - 100
Sampler
A-112
Wave record mode
55556
67
66
S1,S2Rec Wav
In this mode one or more wavetables are recorded into the memory bank selected.
The
number of the wavetable (page)
position of the Tune control 2 and the voltage applied to the CV input
Gate = low :
The pre-listening mode is active (LED 3 is off); the audio signal at input 1 is digitized by the ADC, re­converted by the DAC and forwarded to audio output
for pre-listening.
4
All functions and controls (overload/clipping, adjust­ment of sampling frequency ...) are the same as in the normal record mode (see above).
"
Audio / Wave-CV In
7
77
.
audio signal sampling fre-
Tune / CV
quency (if gate = low) / wavetable number (if gate = high)
results from the
Gate = high:
When the gate goes high The last sampling frequency while gate was low is used as the sampling frequency. The wavetable num­ber (page) is derived from the position of the Tune
control
The audio input is sampled and 256 bytes are written into the wavetable memory (page) selected.
When the last byte of the page (i.e. byte no. 256 of the page) is written record starts again at the first byte of the page. This process continues (LED 3 on) until the gate goes low.
The record process stops immediately at the present position as soon as the gate goes low. You can use this function to sample chosen segments of sound.
When reaching the last position of the current wa­vetable page the number of the next page is defined by the position of the Tune control 2 and the voltage applied to the CV input " (provided that gate is still high). Consequently different pages may be selected during record if the control voltage (e.g. from an ADSR) or the position of the tune knob is changed .
and the voltage applied to the CV input
2
record
starts (
LED 3
is on).
"
.
9
A-112
Sampler
System A - 100
doepfer
In fig. 3, the CV input is fed from the sine output of a LFO. The sampling frequency is 32kHz, the LFO fre­quency 21 Hz. The resulting wavetable pages are shown in the boxes.
251
220
154
64
26
0
+5 V
-5 V
243
238
128
102
8
fig. 3: wave record mode with modulated wavetable
page number
Waves recorded in this way may be played back in the normal play mode, often leading to some fairly drastic effects.
Wave play mode
55556
67
66
S1,S2Play Wav
Audio / Wave-CV In
7
77
Number of wave­page
In this mode A-112 works as a wavetable oscillator. The wavetable number (page) that determines the sound of the audio output is set by the control voltage applied to the audio/wave CV input
Gate = low:
51
The module is waiting for gate = high; LED 3 is off.
The initial sampling frequency (i.e. the first frequency when gate turns to high, see below) is set.
listening mode is also used to find out and set the sampling frequency.
Gate = high:
When the gate goes high the wavetable number (audio/wave input) and the sampling frequency (tune control and CV input) are set, and playback of the recorded wavetable begins, using the sampling fre­quency previously set (LED 3 turns on). When the end of the wavetable is reached the process starts again,
Tune / CV
sampling fre-
quency
!
Pre-
10
doepfer
System A - 100
Sampler
A-112
i.e. the next wavetable and the next sampling fre­quency are determined. This continues until the gate goes low. When a dynamic voltage -2.5...+2.5V is used as the wavetable control voltage (e.g. ADSR output connec­ted to audio/wave input !) wavetable are swept.
memory bank
Speicherbank
12 7118 13 5
Audio In
0,40
0,30
0,20
0, 10
0,00
-0,10
-0,20
-0,30
-0,40
Loop
fig. 4: wavetable selection with CV voltage applied
to audio/wave input
Normal dump mode
55556
67
66
Audio / Wave-CV In
7
77
S1,S2Dmp Norm
In this mode a sample (bank 1 or 2) can be transferred as a MIDI system exclusive string (SysEx Dump) via MIDI out &. You can then record this string with a MIDI computer sequencer or download it using a MIDI dump program for storage on hard disk or any other storage device. The sampling frequency is also transferred within the string.
It is also possible to receive a sample dump via MIDI input %. The dump is written to the memory bank selected (S1 or S2).
Gate = low:
In this state (LED 3 off) MIDI input % is scanned. As soon as an
turns on and the dump data is written into the
3
incoming sample dump
memory bank selected. If a sample dump request is received via MIDI IN the sample memory is transferred via MIDI OUT as a SysEx string. LED 3 turns on as well. Refer to the description of MIDI input and output in chapter 5.
Tune / CV
is detected LED
11
A-112
Sampler
System A - 100
doepfer
H During Data transmission via MIDI OUT the
MIDI input and gate are not scanned. There­fore a new dump cannot be triggered by mistake.
Gate = high:
As soon as the gate goes high (e.g. by pressing button
4) the sample memory is transferred as a SysEx dump via MIDI OUT and LED 3 turns on (same function as sample dump request via MIDI in).
H To trigger a sample dump manually a short
high gate level is sufficient. It is not neces­sary to keep the gate level high.
Wave dump mode
55556
67
66
S1,S2Dmp Wav
This mode is very similar to the normal dump mode (see above). The mode is that the data of a single wavetable (page) of 256 bytes is transferred instead of the complete sampling memory of a bank.
Audio / Wave-CV In
7
77
difference from the normal dump
Tune / CV
wave page num-
ber
The number of the wavetable is determined by the position of the tune control 2 and the voltage applied to CV input ".
Delay mode
55556
67
66
Eff Del Norm
This mode generates a simple delay. The incoming audio signal is delayed and passed to the audio out­put.
H
Principle: The incoming audio signal is sampled and written into a memory position in bank S2. Before this the old value at this position is transferred to the audio output. The number of the memory position is in­creased by 1 and the process is repeated. When reaching the last memory position the process starts at memory position 1. The last memory position depends upon the length (Len, see below).
The memory bank S2 is overwritten in this mode!
Audio / Wave-CV In
7
77
audio signal sampling fre-
Tune / CV
quency
12
doepfer
System A - 100
Sampler
A-112
The length of the delay memory is defined by the parameter Len (see below). The maximum length is the complete sampling memory (64kbyte = 65536 bytes). With a sampling frequency of 32 kHz this corresponds to 2 seconds delay time. The
delay time is decided by a combination of the length of the delay memory (Len) and the sampling fre­quency
Gate = low:
The module is waiting for gate = high; LED 3 is off. The initial sampling frequency is set.
Gate = high:
The delay mode is started; LED 3 turns on. Retrigger is active, i.e. a gate transition to low and back to high starts the delay mode again.
H
.
Moving from delay mode directly to delay with freeze is not possible. To perform this one has to interrupt the delay mode (switch
to S1/S2 or switch 7 to Len) and then
5
select the desired mode.
actual
P By feeding the A-112 output back to its input
one obtains a repeat or echo (see fig 5). Beware: too much feedback leads to an avalanche-like effect. In this case the feed back component has to be reduced.
Audio
In
Feedback
fig. 5: Echo
A-1 12
A-1 12A-138
Audio
Out
Reverse delay mode
55556
67
66
Eff Rev Norm
This mode is the same as the delay mode but the playback of the delayed signal takes place in reverse.
H
Principle: Same as the normal delay mode but writing into the delay memory is performed forward, and reading the delay memory is performed backward. As this is a very simple “bog standard“ algorithm, overlap­ping effects may occur and lead to interference, glit­ches or clicks in the audio output signal.
Memory bank S2 is overwritten in this mode!
Audio / Wave-CV In
7
77
audio signal sampling fre-
Tune / CV
quency
13
A-112
H
Sampler
All functions and controls (sampling fre­quency, length of delay memory ...) are the same as in the normal delay mode (see above).
Pitch shift mode
System A - 100
If read and write frequency differ the audio signal is read out faster or slower and the pitch shift effect occurs.
Because of this very simple “bog standard“ algorithm overlapping effects may occur and lead to interfe­rence, glitches or clicks in the audio output signal.
doepfer
55556
67
66
Eff Pit Norm
In pitch shift mode the audio input signal is sampled and played back at the audio output with shifted pitch/ tuning.
H
Principle: The incoming audio signal is sampled with a fixed sampling frequency (about 16 kHz) and written into memory bank S2. Each sample increases the memory position by 1. Simultaneously the memory is read out with a sampling frequency that is determined by the Tune control 2 and the voltage applied to the CV input ". If the read frequency is nearly the same as the write frequency (i.e. about 16 kHz) no pitch shift occurs ­just a delay depending upon the memory length (Len).
14
Memory bank S2 is overwritten in this mode!
Audio / Wave-CV In
7
77
audio signal sampling fre-
Tune / CV
quency
H
All functions and controls (read sampling frequency, length of delay memory ...) are the same as in the delay mode (see above).
P Very interesting sounds can be obtained if
the original audio signal is mixed with the pitch shifted signal of the A-112 (using a mixer A-138a/b).
doepfer
System A - 100
Sampler
A-112
Freeze option
55556
67
66
Del,
Eff
Rev,
Pit
The effect modes delay, reverse delay and pitch shift may also run with the Freeze option. In this case the audio input is no longer sampled and the memory data no longer overwritten. Instead, the
frozen
memory length (Len) and sampling frequency deter­mine the effect.
Gate control:
The module is waiting for gate = high; LED 3 is off. The initial sampling frequency is determined. If only a short gate pulse appears (i.e. gate turns to high only for a short time and becomes low again) the effect selected functions without freeze. LED 3 is off.
As soon as gate turns high and remains high the freeze option of the effect in question is active. LED 3 is on. The data in the memory are “frozen“ as long as the gate remains high.
memory data are played back. The parameters
7
77
Frz.
Audio / Wave-CV In
audio signal sampling fre-
Tune / CV
quency
When gate turns low the freeze option is cancelled and the module returns to the respective effect without freeze. To re-activate the freeze option, one simply has to turn the gate to high.
H Changing directly to the normal effect without
freeze (permanently) is not possible. To per­form this one has to interrupt the freeze option (switch 5 to S1/S2 or switch 7 to Len) and select the desired mode after this.
Effect parameter "Len"
55556
67
66
Del,
Eff
Rev,
Pit
In this operation mode the parameter Len is adjusted. This value determines the
memory in bank S2 used for the effect modes.
Gate = low:
In this state the parameter. The resolution for the length is one page (256 bytes). The tune knob turned fully to the left (ccw position 0) corresponds to one page, turned fully to the
Audio / Wave-CV In
7
77
Len
Tune control 2222
length of the sampling
Tune / CV
memory length for the effect in que­stion
adjusts the
Len
15
A-112
Sampler
System A - 100
doepfer
right (cw position 10) it corresponds to the whole memory (64 kbyte or 256 pages). During the adjust­ment of Len with the tune control no external voltage should be applied to the CV input ".
Gate = high:
As soon as the gate goes high the current position of the tune control is used to set the Len value.
For the different effect modes the following notes also apply:
Delay, Pitch Shift:
The
factory setting
corresponds to a tune control setting of about 0.5.
Reverse Delay:
The factory setting is 64 kBytes (i.e. 256 pages). This corresponds to tune control setting 10.
The reverse delay effect seems to go very strange with tune control settings of about 1.5 down to 0, i.e. the reverse delay becomes a normal delay, but with ex­treme distortion.
is
4 kBytes
(i.e. 16 pages). This
4. In / Outputs
! Audio In / Wave-CV In
At this socket the audio input signal is patched in (i.e. the signal to be sampled or used for effects). This is a line level input (+/-2.5V or 5Vss). Note that the audio signal must be at line level – microphones won’t give enough output.
H Exception: In
the wavetable control voltage input -
2.5...+2.5V (not an audio signal input)!
wavetable play mode
" CV In
Control voltage input for sampling frequency du-
ring
record, or pitch/tune
follows to the 1V/oct. standard and has 1/4 semitone resolution.
during play. This input
H The control voltage applied to CV in " is
internally added to the voltage generated by the tune control 2.
§ Gate In
this is
16
At the
Gate input §
function depends upon the mode selected.
the
gate signal
is patched in. The
doepfer
System A - 100
Sampler
A-112
The gate signal applied to this socket is inter-
H
nally connected with the signal coming from the button 4. If either of these is high, the module gate is high.
Gate In §§§§ Man. Trig. 7777 result. Gate
high high high high low high low high high low low low
$ Audio Out
Socket $ is the
audio output
of the A-112.
H The audio signal from the DAC passes a
simple low-pass filter to suppress the sampling frequency. It is possible to bypass this internal filter if a more sophisticated low­pass filter (A-120, A-121, A-122) is used or if the sampling frequency should not be sup­pressed for special effects. For this the inter­nal jumper J1 has to be removed.
% MIDI In
Socket % is the data (SysEx dump) via MIDI. For this the dump or wave dump mode has to be selected (see above) and the gate has to be low.
Moreover a sample dump request or a wave dump request message can be received by the A-112 in this mode.
The MIDI SysEx message for a
quest has the following structure:
F0 00 20 20 Doepfer SysEx-ID 7F
< bank> bank number (00 : S1, 01 : S2)
F7
When receiving this message the A-112 transmits at the MIDI output length of the dump is 74.909 bytes altogether. Additio­nally the current sampling frequency is transmitted.
The SysEx message for a wave dump request has the following structure:
MIDI input
a sample dump (LED is on). The
&
used to receive sample
sample dump re-
17
A-112
Sampler
System A - 100
doepfer
F0 00 20 20 Doepfer SysEx-ID 7D
< Wave-Nr., Bit 7 - 1 > < Wave-Nr., Bit 0 >
F7
As the data range in a SysEx message is 0...127 (7 bit) the wave number requires 2 bytes.
Example: Dump of wave no. 201 ("11001001"):
F0 00 20 20 7D
64 "110100" 01 "1"
F7
When it receives this message the A-112 wave dump at the MIDI output & (LED is on). The length of the dump is 305 Bytes altogether. Additio­nally the current sampling frequency is transmitted.
transmits a
& MIDI Out
The MIDI output during sample or wave dumps.
transmits MIDI dump information
&
5. User Examples
The obvious application of the A-112 is the sampling and playback of external sounds or sounds generated with other A-100 modules. On top of this the module opens up a huge number of sound experiment possibi­lities – far too many to be covered in this manual.
The following examples concentrate on applications of the module.
Wavetable Oscillation
The wavetable oscillator feature and the loop feature of the A-112 have already been described in chapter 3. Smooth sequencing of the wavetables with an external control voltage requires a certain amount of subtle intuition - and additional A-100 modules - as it is necessary to control the offset and amplitude of the voltage applied. You do then also have the ability, though, of selecting a specific starting wavetable (offset) and starting the up/down sweep through the waves (amplitude) at this particular point.
For the most effective wavetable control we recom­mend using the A-129/3 (attenuator and offset genera­tor, see below).
wavetable
18
doepfer
System A - 100
Sampler
A-112
The control voltage range 0...+5V corresponds to the 256 tables (0V = table no. 1, +5V = table no. 256). To move from one table to the next one a voltage diffe­rence of about 0.02 V (5V/256) is required.
Example: To sweep with an LFO (Triangle output) through 64 tables starting with table no. 96 (i.e. pas­sing through the tables 64...128) the following conditi­ons are required: An offset voltage of 96*5V/256 =
1.875V and an attenuation of the LFO signal to 64*5V/ 256 = 1.25V (peak-to-peak). Using a A-129/3 the offset voltage is adjusted with the offset control and the LFO level with the attenuator control. If each of the 64 tables are to be used - i.e. none of the tables is to be skipped - there is a maximum frequency that the controlling signal (LFO) must not exceed. If the sampling frequency is 32kHz each wavetable (256 byte) takes 8 milliseconds. All 64 tables take 512 milliseconds. This corresponds to 1.95 Hz LFO fre­quency. Consequently the frequency of the LFO must be about 2 Hz or less to play each table without skipping. This sounds very mathematical and theoreti­cal but it is a good idea to understand these facts as some unforeseen things may happen if one ignores these details. In practice of course the resulting sound is all that counts.
Sequencer-controlled wavetable playback
In the patch in fig. 6 the Analog/Trigger Sequencer A-155 controls the playback of different wavetables (step 1, 4, 5 and 7).
The sawtooth output of the LFO, patched via offset generator A-129/3 generates the control voltage to sweep through the wavetables. This voltage is added to the sequencer voltage (post out 2). Thus different ranges of the wavetable memory are used for each step (displayed by different sound symbols). Regar­ding offset, attenuation and LFO frequency, see the notes on the previous page.
The sequencer control voltage Post Out 1 is used to control the decay of an VC-ADSR, i.e. for different decay times for each step.
Instead of an LFO an ADSR or VC-ADSR may be used. The attack control is used in this case to adjust the speed of sweep (decay, sustain and release con­trol = 0).
19
A-112
Sampler
System A - 100
doepfer
Wavetable playback of a normal sample
Very interesting sounds can be obtained if a normal sample is played back in wavetable mode - especially if human voice is recorded. During normal sample playback the sample length depends upon pitch and the so-called Mickey Mouse effect occurs.
If the wavetable mode is used the sample length depends only upon the slope of the controlling voltage (e.g. sawtooth) but not upon the pitch. This is adjusted independently with the tune control and pitch CV.
Suggestions for sound experiments:
If the slope of the voltage controlling the wavetable is running backwards (e.g. a falling sawtooth) sam­pled words seem to be spoken backwards (sort of).
By selective scanning of a spoken sample one may
obtain voice or vowel loops.
Using a random or S&H voltage for controlling the
wavetables leads to the basics of what is often referred to as granular synthesis.
For the above suggestions it is important that the period of the sampled sound fits almost exactly into the space allotted to each wavetable (256 Bytes). If the result is not satisfactory another record sampling fre­quency should be used until the desired sound is obtained.
20
doepfer
A-155
1 2
3
4 5 6 7 8
Clo c k
Trig. 1
System A - 100
VC-ADSR
Sampler
A-112
Gat e
Po st Out 1
S & H Ctrl. 1
Po st Out 2
S & H Ctrl. 2
0 V 0 V
LFO
Ret r i g . In
A-129 /3
Atten. Off set
fig. 6: sequencer-controlled wavetable playback
A-130
CV D
Wave- CV In
+5 V
A-1 12
0
VCF
0
Clock
VCA
21
A-112
Sampler
System A - 100
doepfer
6. A-112 Sample Dump Loader
The A-112 MIDI interface enables the transfer of sam­ple and wave data from and to the device using MIDI SysEx strings. For that purpose a standard MIDI se­quencer may be used.
In addition we include a 3 1/2“ floppy disk containing a
A-112 sample dump loader
Version 1.2
directional transfer between A-112 and the PC. Sam­ples and waves can be organized and stored on the storage device (e.g. hard disk) of a PC. In the PC each sample or wave can be assigned any name (DOS convention, i.e. max. 8 characters) and stored as a WAV file (8 bit mono). The A-112 format is automati­cally converted into the WAV format.
Conversely, any WAV file can be transferred to the
A-112.
bit mono or stereo formats. Stereo WAV files are converted to mono before transfer to the A-112.
of this software (see fig. 7) enables bi-
The program reads any WAV file in 8, 12 or 16
software for PC.
The WAV file format opens up a wide pool of sounds for use with the A-112. You may try out Windows sy­stem sounds or modifying sounds with a sample editor program and then re-loading back into to the A-112.
For the next version of the sample dump loader pro­gram we are planning to include the ability to generate sample dump MIDI files.
H
The latest version of the sample dump loader can be found on our internet home- page (http://www.doepfer.com) for free download.
22
doepfer
System A - 100
Sampler
A-112
: A-112 sample dump loader
fig. 7
