1. Introduction
Module A-107 is a completely new voltage controlled
filter that has available 36 filter types: different versi-
ons of low pass, high pass, band pass, notch, all pass
and filters with new response curves that have no
name up to now.
Of course the standard VCF controls are available:
manual and voltage control of filter frequency and
resonance. For the filters of the first group (1...18)
self-oscillation is possible, the filters of the second
group (19...36) do not feature self-oscillation. On top of
it a final VCA is available - even with manual and
voltage control. All external control inputs are available
twice: one with attenuator and one without.
The 36 filters are organized in two groups of 18
filters each. The filters can be arranged in 64 different
filter chains. Each chain consists of 32 steps. The
sequence of a filter chain is passed through while the
manual control is operated or the external control
voltage changes from 0...+5V. 64 filter chains can be
programmed by the user and stored in the non-volatile
memory of the module.
The transition between filters can be soft (morphing)
or hard (switching). The morphing time (manual and
voltage controlled) defines the transition time between
succeeding filters from a few milliseconds (switching)
up to about 10 seconds.
Additionally a "clocked" mode is available. This
means that the steps of the currently selected filter
chain are selected one after another. Each positive
transition of the Clock signal calls up the next filter of
the chain. A positive trigger at the Step Reset input
resets to the filter of the chain that corresponds to the
momentary step CV. This allows e.g. to switch between the filters of the currently selected filter chain in
sync with a sequencer.
The filter design is 100% analog (CEM filter chip).
Only the morphing control and memory managing is
carried out by a microcontroller.
Remark: Because of technical reasons the transition
between the two filter groups cannot be carried out soft
as capacitors have to be switched. Soft transition (i.e.
morphing) is possible only between the filters of each
group (i..e. within the filters 1...18 or
between filters causes a "click" if the filters are from
different groups.
19...36). Switching
1
A-107
Multitype Morphing Filter
Permanent Memory
System A - 100
doepfer
Display
Control Unit
Filter
Step
Fig.1: A-107 Overall view
03
S01 S02 S31 S32
CV2 CV2
C02
C01
Chain
12 08
Man
CV 1
Clk Res CV1
Step Morph
Prog
11
C64
Man
Value
Audio Out
Filter
Unit
Audio In
Amp.
Freq.
Res.
CV2
CV 1
Man
CV2
CV 1
Man
CV2
CV 1
Man
2
doepfer
System A - 100
Multitype Morphing Filter
A-107
2. Basic principles
Module A-107 consists of the 100% analog filter unit
with the parameters filter frequency, resonance/emphasis and amplification, and the digital control unit
with display, corresponding controls (buttons, rotary
encoder) and non-volatile memory.
The control unit manages the memory that contains
the 64 filter chains with 32 steps each. The control
unit is responsible for all parameters that refer to
switching and morphing of filters within the selected
chain, the control of the analog filter unit to obtain the
desired filter and the memory management.
The buttons "Step" and "Filter" determine if the display
shows the Step number (S) within the currenty selected filter chain (i.e. the so-called working buffer) or the
filter type (F).
The buttons "Chain" and "Prog" are used to transfer a
filter chain between the non-volatile memory (64 memories) and the working buffer.
The values for Step, Filter and Chain are set by the
endless rotary encoder labelled “Value”.
Provided that a clock signal is applied to the Step
Clock input the clocked mode is activated. In this
mode each positive transition of the clock signal triggers the advance to the next step of the filter chain in
the working buffer. If step 32 is reached the next clock
switches back to step 1 of the chain.
Addressing the filters of the chain in the working
buffer can also be controlled by the manual step
control and/or an external control voltage at one of
the Step CV inputs. According to the manual setting
and the external voltage(s) the corresponding filter
within the chain is addressed.
For both the clocked and CV addressed mode the
transition time between succeeding filters can be controlled manually by the Morphing control and/or an
external control voltage at one of the Morphing CV
inputs.
Attention: CV addressing "overruns" the filter selected
in the clocked mode.
All parameters can be controlled resp. modulated by
different voltages at the same time: filter step, mor-
phing time, filter frequency, resonance and amplifi-
cation.
3
A-107
Multitype Morphing Filter
3. Overview
System A - 100
doepfer
➆
➀
➉
➋
➇
➅
➌
➍
➈
➎
➊
4
doepfer
System A - 100
Multitype Morphing Filter
A-107
Programming Unit Controls:
1 Display: 3 digit LED display
2 Step: button, calls up display mode "Step"
3 Filter: button, calls up display mode "Filter"
4 Chain: button, calls up display mode "Chain"
5 Prog: button, calls up display mode "Prog"
6 Value: rotary encoder to set the value for
Step, Filter and Chain
7 Step: two CV inputs with/without attenuator,
and manual control for Step setting
8 Step Clock: digital signal input for clock/gate-
triggered advance to next step
9 Step Reset: digital signal input to set the step to a
position within the chain defined by the
momentary step CV
0 Morph: two CV inputs with/without attenuator,
and manual control for morphing time
Filter Unit Controls:
! Audio In: audio input of the filter
" Freq.: two CV inputs with/without attenuator,
and manual control for filter frequency
§ Res.: two CV inputs with/without attenuator,
and manual control for filter resonance/emphasis
$ Amp.: two CV inputs with/without attenuator,
and manual control for filter amplification
% Audio Out: audio output of the filter
5
A-107
Multitype Morphing Filter
System A - 100
doepfer
4. Programming Unit Controls
1 Display
This is a 3-digit LED display with three decimal points.
These display modes are available:
S01
current S
buffer), range 01 - 32
Filter type of the currently selected step within
F01
the chain (= working buffer), range 01 - 36
C01
number of the C
memory, range 01 - 64
P01
number of the chain that is used to store
(P
range 01 - 64 (the character "S" is alread used
for Step -> P = Program)
The left and middle decimal point of the display
indicate morphing. The points are flashing alternately
while the morphing is in progress. The blinking frequency is an approximate measure for the morphing
time. As soon as the new filter type is reached both
points turn off.
tep within the filter chain (= working
hain that is called up from the
rogram) the working buffer into the memory,
The right decimal point is a warning indicator for
the functions CHAIN and PRG and is blinking as soon
the button 4 or 5 is operated (see below).
2 Step
Operating this button calls up the display mode that
shows the current step of the chain in the working
buffer.
There are different was to select another step within
the chain:
• Operate the Value control 6
• Operate the manual Step control (see 7)
• Altering one of the the Step CVs (see 7)
• Feeding a Clock signal to socket 8.
The first two items relate to manually controlled steps.
The two last items correspond to voltage resp. clock
controlled step addressing and are suitable for automatic filter addressing and morphing (e.g. controlled
by a LFO, ADSR, random CV, Theremin, ribbon, foot
controller. MIDI-to-CV or a sequencer).
6
doepfer
System A - 100
Multitype Morphing Filter
A-107
3 Filter
Operating this button calls up the display mode that
shows the filter type of the currently selected step of
the chain in the display.
To select another filter type the Value control 6 has to
be operated. A detailed list of all filter types with
frequency response curves is available in chapter 7.
H
How to program a filter chain:
D Make sure that no external control signals are fed
The filters are organized in two filter groups
with 18 filters each. To obtain a continuous
morphing (soft transition) for all filters within
a chain only filters from the same group have
to be used. If two succeeding filters are from
different groups a short "click" will be heard
as capacitors have to be switched between
the filter groups. Of course this characteristic
can be used intentionally for special effects.
into the inputs Step CV 7, Step Clock 8 and Step
Reset 9. These signals would disturb the programming procedure as they change the current
step within the chain !
D Operate the Step button 2 and select the desired
step (e.g. S01) within the current filter chain
(working buffer) by using the value control 6.
D Operate the Filter button 3 and select the desired
filter type (e.g. F13) for the current step by using
the value control 6.
D Select the next step (e.g. S02) by operating the
Step button 2 and assign the filter type for this
step as described above
D Continue until all steps are programmed. It is not
necessary to program all 32 steps of a chain. If
you e.g. want only 5 different filters you may only
program the steps 1...5. But you have to pay
attention that only these programmed steps are
addressed later e.g. by the external CV (use the
attenuated CV input !)
H
If you want to keep the chain in the working
buffer before you modify the settings you have
to store the working buffer into one of the 64
non-volatile memories (see item 5 PROG).
H
The working buffer is erased during power off.
If you want to keep the working buffer you have
to store it into one of the 64 non-volatile memories (see item 5 PROG). After power on chain
#1 is called up from the non-volatile memory.
7
A-107
Multitype Morphing Filter
System A - 100
doepfer
4 Chain
Operating this button calls up a chain from the memory, i.e. the chain is copied from the non-volatile
memory into the working buffer. To avoid wrongly
operation one has to keep the button pressed for about
one second before the function is executed.
The display shows the number of the last chain in use
(e.g. C23) and the right decimal flashes slowly as a
warning that the chain in the working buffer will be
overwritten if the process is continued.
If the chain button was operated wrongly one simply
has to operate the Step button 2 or the Filter button 3
to reach the corresponding display mode.
How to copy a chain from the memory into the working
buffer:
D Select the number of the desired chain by
means of the Value control 6.
D Operate the Chain button again and hold it
pressed for about 2 seconds.
GET
During this time the right decimal points flashes
fast and the display shows GET.
H
If you release the chain button while the display
shows "GET" the copy procedure is interrupted
and the right decimal point flashes slowly again.
After about 2 seconds the chain is copied from the
non-volatile memory into the working buffer.
5 Prog
Operating this button stores a chain into the memory,
i.e. the chain is copied from the working buffer nonvolatile memory. To avoid wrongly operation one has
to keep the button pressed for about one second
before the function is executed.
The display shows the number of the last chain in use
(e.g. P19) and the right decimal flashes slowly as a
warning that the chain in the memory will be overwritten if the process is continued.
If the chain button was operated wrongly one simply
has to operate the Step button 2 or the Filter button 3
to reach the corresponding display mode.
How to store a chain into the non-volatile memory:
D Select the number of the desired chain by
means of the Value control 6.
D Operate the Chain button again and hold it
pressed for about 2 seconds.
PRG
During this time the right decimal points flashes
fast and the display shows GET.
8
doepfer
H
If you release the button while the display shows
"PRG" the store procedure is interrupted and the
right decimal point flashes slowly again.
After about 2 seconds the chain is stored into the
selected chain of the non-volatile memory and the
display shows the latest step.
P
This operation concept makes it possible to
copy chains within the non-volatile memory.
To copy e.g. chain 17 to chain 53 one has to
copy chain 17 by means of the CHAIN function into the work buffer. Then the working
buffer is stored into chain 53 by means of the
function PROG.
System A - 100
6 Value
This endless rotary encoder is used to select steps,
filter types and chains as described in the sections
above.
H
If an external Step CV or Step clock signal is
applied the effects of the external signals and
the value control will interfer. To select a value
with the Value control no step CV or step clock
should be applied.
Multitype Morphing Filter
A-107
7 Step
This group of controls serves to address a step within
the currently selected filter chain. It contains a manual
Step control and two Step CV inputs (one with attenuator, one without attenuator).
A variable control voltage applied to a Step CV input
leads to a step selection and consequently filter selection accordingly to the applied control voltage. The
setting of the Morphing section defines if the transition
time between succeeding steps. resp. filters.
A control voltage of 0V at Step CV input 2 corresponds
to step 01, +5V to step 32.
The effects of the manual step control and the external
step CV inputs are added up. The manual control can
be used to adjust an offset (e.g. step 16). The external
control voltage (e.g. from a LFO) could modulate the
step value around the offset (e.g. 11...21 = 16-5 ....
16+5). For bipolar control voltages (e.g. from an LFO)
an offset is required to take advantage of the full
voltage range. For positive control voltages (e.g. from
an ADSR, sequencer or MIDI-to-CV) the offset control
may be set to zero.
9
A-107
Multitype Morphing Filter
System A - 100
doepfer
8 Step Clock
The positive transition (low to high) of a Clock signal
at this input advances to the next step of the current
chain.
If step 32 is reached the next clock switches back to
step 1 of the chain.
H
If an external Step CV and Step clock signal is
applied the effects of both signals will interfer.
Whenever the step control voltages changes the
step corresponding to this voltage is addressed
immediately !
Therefore we recommend to apply no varying
control voltages to the Step CV inputs in the
clocked mode unless the interfering effects are
intentional.
9 Step Reset
The positive transition (low to high) at this input resets
to the step of the chain that corresponds to the
momentary step CV (manual + external). The manual
step control has to be turned to zero if a reset to step 1
is desired. A slowly varying external control voltage at
the step CV inputs can be used to reset to different
steps.
The step reset input is also helpful to synchronize "filter
sequences" by applying a sequener generated reset
signal to this input (e.g. .
0 Morph
This group of controls serves to define the morphing
time between succeeding filters. It contains a manual
Morphing control and two Morphing CV inputs (one
with attenuator, one without attenuator).
Applying a slowly variable control voltage at one of
the Morphing CV leads to modulations of the morphing
time.
A control voltage of 0V at Morphing CV input 2 corresponds to a few milliseconds (~ switching), +5V to
about 10 seconds morphing time.
The effects of the manual morphing control and the
external morphing CV inputs are added up. The manual control can be used to adjust an morphing off-
set. The external control voltage (e.g. from a LFO or
sequencer) could modulate the morphing time the
offset. For bipolar control voltages (e.g. from an LFO)
an offset is required to take advantage of the full
voltage range. For positive control voltages (e.g. from
an ADSR, sequencer or MIDI-to-CV) the offset control
may be set to zero.
10
doepfer
System A - 100
Multitype Morphing Filter
A-107
5. Filter Unit Controls
! Audio In • Level Control
The socket is the audio input of the filter were the
audio signal has to be fed in. The attenuator controls
the input level of the signal to be filtered. If the filter’s
output signal is distorted, turn this control down, unless
the distortion is wanted as a special effect. Distortion
appears approx. above middle position of the control
(~5) for normal A-100 signals (e.g. VCO A-110).
" Frequency
This group of controls serves to define the filter frequency. It contains a manual frequency control and
two frequency CV inputs (one with attenuator, one
without attenuator).
The filter frequency is manually adjusted with the
manual frequency control. To modulate the cut-off
frequency by an external voltage (e.g. from a LFO or
ADSR) the control voltage has to be patched into one
of the two frequency control inputs. One input is
equipped with an attenuator to control the frequency
modulation amount of the corresponding input.
The effect of filter frequency depends upon the filter
type that is selected with the programming unit. In
case of a lowpass or high pass it is the cut-off frequency, for a bandpass or notch it is the middle
frequency. More details can be found in the manuals of
other A-100 filters (e.g. A-121, A-123, A-124, A-108,
A-105/122).
§ Resonance
This group of controls serves to define the filter resonance/emphasis. It contains a manual resonance
control and two resonance CV inputs (one with attenuator, one without attenuator).
The filter resonance is manually adjusted with the
manual resonance control. To modulate the resonance
by an external voltage the control voltage has to be
patched into one of the two resonance control in-
puts. One input is equipped with an attenuator to
control the resonance modulation amount of the corresponding input.
According to the selected filter type the resonance
effect emphasizes the frequencies around the cut-off
frequency (lowpass, highpass) or alters the bandwidth
(bandpass, notch). For the new filters without names
11
A-107
Multitype Morphing Filter
System A - 100
doepfer
normally one of the frequency peaks shown in the
response curves is lifted up (see chapter 7).
For the filters 01 ... 18 (see chapter 7) the resonance
can be adjusted right up to self-oscillation, in which
case the filter will behave like a sine wave oscillator.
The filters 19...36 do not support self-oscillation.
Even the effect of resonance and self-oscillation is
treated more detailed in the manuals of other A-100
filters (e.g. A-121, A-123, A-124, A-108, A-105/122).
$ Amp.
This group of controls serves to define the filter amplitude or level. It contains a manual amplitude control
and two amplitude CV inputs (one with attenuator,
one without attenuator). This control group is assigned
to the final VCA (nothing but an exponential VCA that
is connected to the filter output).
The filter output level is manually adjusted with the
manual amplitude control. To modulate the amplitude
by an external voltage (e.g. ADSR, LFO, sequencer)
the control voltage has to be patched into one of the
two amplitude control inputs. One input is equipped
with an attenuator to control the resonance modulation
amount of the corresponding input.
% Audio Out
Filter output % sends out the filtered and level control-
led audio signal.
12
doepfer
System A - 100
Multitype Morphing Filter
A-107
6. User examples
H
P
The easiest application is to use only one single filter
from the pool of 38 filters. This makes quite sense as
there are a lot of filters available that cannot be realized with other A-100 modules (e.g. the "fast food filter"
no. 09, look at response curve to understand the name
"fast food"). But the point of the A-107 are of course
the filter chains and the morphing features. In the
following we describe some suggestions:
In the following we use the abbreviations LP
(lowpass), BP (bandpass), HP (highpass), AP
(allpass), NF (notch filter).
Before you continue with more complex applications of the A-107 we recommend to acquaint with the 38 filter types described in
chapter 7. Take the time to hear all the filters
and how they respond to filter frequency, resonance and distortion. Find out how morphing
between 2 filters is influenced by the morphing
time. Differences in loudness can be compensated with the amplitude control.
Clocked mode
The advance to the next filter in the chain can be
triggered by different events. Here some examples:
• Advance triggered by a keyboard by using the gate
signal as step clock
• Advance triggered by manually operated control
devices like foot switches (A-177), Theremin
(gate output of the A-178), light controller (gate
output of the A-179), ribbon controller (gate output of the A-198)
• Random advance with the Random Clock Genera-
tor A-117 or A-149-2 (or via CV with the A-118
random CV output or one of the outputs of A-149-1)
• Periodical advance with the rectangle output of a
LFO, any clock signal or in sync with MIDI clock
(clock out of the A-190 divided by the clock divider
A-160 to obtain a smaller clock frequency)
• Rhythmical advance by means of clock divider
and sequencer A-160/161, combined e.g. with the
logic module A-166 and using the step reset input
of the A-107,
• more complex rhythmical filter sequences by
controlling the step clock by the trigger output of a
analog sequenzer (A-155 or MAQ16/3) or a trig-
ger sequenzer (Schaltwerk)
13
A-107
Multitype Morphing Filter
System A - 100
doepfer
Morphing
But the real fun arises with the morphing features of
the A-107. Even here we recommend first to find out
the sound behaviour between two different filters as it
is a big difference to morph e.g. from 6dB LP => 24 dB
LP, or LP => HP, or BP => NF, or HP => AP and so on.
For this you may use the following system:
D Program a chain with two different filter types at
step 01 and 02.
D Patch the rectangle output of a LFO to the step CV2
input of the A-107 and adjust the frequency of the
LFO to about 1 Hz or less.
D Turn the manual step control, the attenuator of step
CV2 and the manual morph control to zero.
D Select the display mode STEP.
D Look at the display and turn up the attenuator
control of step CV2 slowly until the display shows
alternately 01 and 02.
D Feed the audio input of the A-107 with the desired
audio signal. The sawtooth output of a VCO is a
good start but even a complex audio signal is
suitable for the first tests
D Set the controls of the filter section to suitable
positions: full amplitude, medium filter frequency,
small or medium resonance
D Now you will hear alternatively the two filters that
were programmed to step 01 und 02 of the chain
(see first item above),
D Turn up slowly the morph control to find out how the
switching between the two filters turns more and
more into morphing.
D Alter the setting of the filter section (filter frequency,
resonance, amplitude) to hear the effect of these
controls
D Increase the LFO frequency that controls the step
CV. From a certain LFO frequency (depends upon
the setting of the morphing time) the filters of step
01 and 02 will not be reached as the morphing time
is longer than the LFO period. Instead of this one
obtains an "interim" filter that has a bit of both filters
D Use other control voltage sources (e.g. LFO,
ADSR, Random CV) to control the parameters of
the A-107 by external voltages: morphing time, filter
frequency, filter resonance, amplitude
D Extend the filter chain by adding filters to step 03,
04, 05 ... and try different filter types in the chain
Now you should experiment with a real filter chain (so
far only two filters were used) and try more sophisticated controls:
D Extend the filter chain by adding new filters to step
03, 04, 05 ... and try different filter types in the
chain. You may also use the factory setting of the
chains (step 1 = filter 2, step 2 = filter 2 ...)
14
doepfer
System A - 100
Multitype Morphing Filter
A-107
D Try different waveforms for the LFO that controls
the step CV and increase the effect of the step CV
by turning up the attenuator. This increases the
range of filters that were covered by the LFO CV.
D Adjust LFO frequency and attenuation, manual step
and morphing time to obtain a complete pass
through the complete chain.
D By different settings of the manual step control and
the step CV attenuator one reaches any position
within the chain (e.g. step 16) and varies the range
of filters around this position (e.g. 14...16...18
10...16...22)
D Any control voltage sources of the A-100 can be
used to control the 5 parameters of the A-107.
There are no limits to the user's imagination.
D One may control step CV, morphing time, filter
frequency, resonance and amplitude from the CV
outputs of a sequencer (e.g. A-155 or MAQ16/3),
add a little bit envelop (e.g. from the VC-Decay
A-142) to control the filter frequency, control even
the decay from a sequencer track and you will
discover "filter sequences" you never heard before.
D The voltage controlled polarizer A-133 is a suitable
tool to adjust envelopes dependent on the current
filter type. A LP with a low basic frequency requires
another envelope (normally positive) than a HP
(e.g. a negative envelope). The A-133 is very useful
to change the envelope polarity and level individually for each filter within a sequence.
7. Filter types
The 36 filter types of the A-107 are shown on the next
pages. For each filter the frequency response curve
(X/frequency versus Y/amplitude) is shown and a short
comment is added. For some filters customary names
are available, e.g. xxdB lowpass/highpass, bandpass,
notch or allpass. For the new filters without customary
names we tried to find an explanation that describes
the filter as good as possible.
The filters are divided into two groups. The filters of
the first group (01...18) allow self-oscillation. The
filters of the second group (19...36) do not include this
feature.
15
A-107
Multitype Morphing Filter
System A - 100
doepfer
01
24 dB Lowpass
05 06 07 08
Asymmetric Bandpass 2
(18 dB LP + 6 dB HP)
09 10 11 12
2 Bandpasses separated by a
notch ("fast food filter")
02
12 dB Lowpass
Bandpass
(12 dB LP + 12 dB HP)
Lowpass + shifted Bandpass Lowpass + Notch I "Tooth"
Bandpass
(6 dB LP + 6 dB HP)
Notch + 6 dB Lowpass Allpass + 6 dB Lowpass
03 04
Asymmetric Bandpass 1
(12 dB LP + 6 dB HP)
2 shifted Bandpasses
16
doepfer
System A - 100
Multitype Morphing Filter
A-107
13 14 15 16
Lowpass + 2 shifted Bandpasses with different amplitudes
2 shifted Bandpasses with different amplitudes
17 18
Lowpass + Soft Notch + Bandpass
Lowpass with shifted Bandpass (smaller amplitude)
21 22
6 dB Highpass 12 dB Highpass
Lowpass + Notch + Highpass Lowpass + Notch II
19 20
18 dB Lowpass 6 dB Lowpass
23 24
18 dB Highpass Asymmetric Bandpass 3
(12 dB LP + 6 dB HP)
17
A-107
Multitype Morphing Filter
System A - 100
doepfer
25 26
12 dB Notch Allpass (lower frequencies at-
tenuated)
Notch + Highpass Soft Notch + shifted Bandpass
27
31 32
29 30
Allpass (higher frequencies attenuated)
33 34
Notch + Highpass Lowpass + Notch + Highpass Soft Notch I Soft Notch II
Highpass with "step" "Wave" filter Lowpass + Soft Notch + Band-
pass
35
28
36
18
Loading...
