Dodge ND Dakota 2009, Dakota 2009 User Manual

2009

OWNER’S MANUAL

DA KOTA

VEHICLES SOLD IN CANADA

With respect to any Vehicles Sold in Canada, the name
Chrysler LLC shall be deemed to be deleted and the
name Chrysler Canada Inc. used in substitution therefor.

DRIVING AND ALCOHOL

Drunken driving is one of the most frequent causes of
accidents.

Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-drinking
driver, call a cab, a friend, or use public transportation.

WARNING!

Driving after drinking can lead to an accident. Your
perceptions are less sharp, your reflexes are slower,
and your judgment is impaired when you have been
drinking. Never drink and then drive.

This manual illustrates and describes the operation of
features and equipment that are either standard or op­tional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.

Chrysler LLC reserves the right to make changes in
design and specifications, and/or make additions to or
improvements to its products without imposing any
obligation upon itself to install them on products previ­ously manufactured.

Copyright © 2008 Chrysler LLC

SECTION PAGE

1

INTRODUCTION

2

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

3

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4

UNDERSTANDING YOUR INSTRUMENT PANEL

5

STARTING AND OPERATING

6

WHAT TO DO IN EMERGENCIES

7

MAINTAINING YOUR VEHICLE

8

MAINTENANCE SCHEDULES

9

IF YOU NEED CONSUMER ASSISTANCE

TABLE OF CONTENTS

.............................................................3

...............................9

...............................75

................................... 163

.................................................235

...............................................331

...............................................349

..................................................399

..........................................417

1
2
3
4
5
6
7
8
9

10

INDEX

....................................................................427

10

CONTENTS

INTRODUCTION

1

m Introduction ...........................4

m How To Use This Manual ..................4

m Warnings And Cautions ...................6

m Vehicle Identification Number ...............6

m Vehicle Modifications/Alterations ............7

4 INTRODUCTION

INTRODUCTION

This Owner’s Manual has been prepared with the assis­tance of service and engineering specialists to acquaint
you with the operation and maintenance of your vehicle.
It is supplemented by a Warranty Information Booklet
and various customer-oriented documents. You are
urged to read these publications carefully. Following the
instructions and recommendations in this manual will
help assure safe and enjoyable operation of your vehicle.

NOTE: After you read the manual, it should be stored
in the vehicle for convenient reference and remain with
the vehicle when sold, so that the new owner will be
aware of all safety warnings.

When it comes to service, remember that your authorized
dealer knows your vehicle best, has the factory-trained
technicians and genuine Mopart parts, and is interested
in your satisfaction.

HOW TO USE THIS MANUAL

Consult the Table of Contents to determine which section
contains the information you desire.

The detailed Index at the back of this Owner’s Manual
contains a complete listing of all subjects.

Consult the following table for a description of the
symbols that may be used on your vehicle or throughout
this Owner’s Manual:

INTRODUCTION 5

1

6 INTRODUCTION

WARNINGS AND CAUTIONS

This Owner’s Manual contains WARNINGS against op­erating procedures that could result in an accident or
bodily injury. It also contains CAUTIONS against proce­dures that could result in damage to your vehicle. If you
do not read this entire manual, you may miss important
information. Observe all Warnings and Cautions.

VEHICLE IDENTIFICATION NUMBER

The Vehicle Identification Number (VIN) is located on
the left front corner of the instrument panel pad, visible
from outside of the vehicle through the windshield. This
number also appears on the Automobile Information
Disclosure Label affixed to a window on your vehicle.
Save this label for a convenient record of your vehicle
identification number and optional equipment.

NOTE: It is illegal to remove the VIN.

VIN Location

VEHICLE MODIFICATIONS/ALTERATIONS

WARNING!

Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and
may lead to an accident resulting in serious injury or
death.

INTRODUCTION 7

1

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

CONTENTS

m A Word About Your Keys ................. 12

▫ Ignition Key Removal .................. 12

▫ Locking Doors With The Key ............. 15

m Steering Wheel Lock — If Equipped ......... 15

▫ If You Wish To Manually Lock The Steering

Wheel.............................. 15

▫ To Release The Steering Wheel Lock ........ 15

▫ Automatic Transmission Ignition Interlock

System ............................. 15

2

m Sentry Keyt Immobilizer System — If

Equipped ............................. 16

▫ Replacement Keys ..................... 17

▫ Customer Key Programming ............. 17

m Vehicle Security Alarm System — If Equipped . . 19

▫ To Set The Alarm...................... 19

▫ To Disarm The System .................. 19

m Illuminated Entry ....................... 20

▫ Vehicles Equipped With Power Door Locks . . . 20

10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

m Remote Keyless Entry .................... 21

▫ To Unlock The Doors ................... 22

▫ To Lock The Doors .................... 22

▫ Using The Panic Alarm ................. 24

▫ General Information .................... 24

▫ Programming Additional Transmitters ....... 25

▫ Battery Replacement ................... 26

m Remote Starting System — If Equipped ....... 27

m Door Locks ........................... 29

▫ Manual Door Locks .................... 29

▫ Power Door Locks ..................... 29

▫ Child Protection Door Lock .............. 32

m Windows ............................. 34

▫ Power Windows ...................... 34

▫ Auto Down (Driver’s Side Only) ........... 35

▫ Window Lockout Switch ................ 35

▫ Wind Buffeting ....................... 35

m Occupant Restraints ..................... 36

▫ Lap/Shoulder Belts .................... 37

▫ Adjustable Upper Shoulder Belt Anchorage . . . 42
▫ Automatic Locking Retractors (ALR) Mode –

If Equipped.......................... 43

▫ Center Lap Belts ...................... 43

▫ Seat Belt Pretensioners .................. 44

▫ Enhanced Driver Seat Belt Reminder System

(BeltAlertt).......................... 44

▫ Seat Belts And Pregnant Women ........... 45

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11

▫ Seat Belt Extender ..................... 45

▫ Driver And Right Front Passenger

Supplemental Restraint System (SRS) –

Airbags............................. 46

▫ Event Data Recorder (EDR) .............. 56

▫ Child Restraint ....................... 58

m Engine Break-In Recommendations .......... 70

m Safety Tips ............................ 71

▫ Exhaust System ....................... 71

▫ Safety Checks You Should Make Inside The

Vehicle ............................. 72

▫ Safety Checks You Should Make Outside The

Vehicle ............................. 73

2

12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

A WORD ABOUT YOUR KEYS

The authorized dealer that sold you your vehicle has the
key code numbers for your vehicle locks. These numbers
can be used to order duplicate keys from your authorized
dealer. Ask your authorized dealer for these numbers
and keep them in a safe place.

Ignition Key

Ignition Key Removal

Automatic Transmission

1. Place the shift lever in PARK.

2. Turn the ignition switch to the LOCK position.

3. Remove the key from the ignition lock cylinder.

Ignition Switch Positions

1 — ACC 4 — ON/RUN
2 — LOCK 5 — START
3 — OFF

NOTE: If you try to remove the key before you place the
shift lever in PARK, the key may become temporarily
trapped in the ignition cylinder. If this occurs, rotate the

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13

key to the right slightly, then remove the key as de­scribed. If a malfunction occurs, the system will trap the
key in the ignition cylinder to warn you that this safety
feature is inoperable. The engine can be started and
stopped, but the key cannot be removed until you obtain
service.

WARNING!

Never leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be seri­ously or fatally injured. Don’t leave the key in the
ignition. A child could operate power windows,
other controls, or move the vehicle.

2

14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

CAUTION!

An unlocked car is an invitation to thieves. Always
remove the key from the ignition and lock all the
doors when leaving the vehicle unattended.

Manual Transmission — If Equipped

When the steering wheel is in the LOCK position, the
steering and ignition systems are locked to provide
antitheft protection for your vehicle. It may be difficult to
turn the key from the LOCK position when starting your
vehicle. Move the steering wheel left and right while
turning the key until it turns easily. To remove the key,
depress and hold the release button located between the
ignition switch and the instrument panel. Turn the igni­tion key to LOCK and remove the key.

Ignition Release Button

1 — ACC 4 — ON/RUN
2 — LOCK 5 — START
3 — OFF

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15

Locking Doors With The Key

You can insert the key into the door lock cylinder with
either side up. To lock the driver’s door, turn the key
rearward. To unlock the driver’s door, turn the key
forward. For external door lock lubrication, refer to
“Body Lubrication” in Section 7.

STEERING WHEEL LOCK — IF EQUIPPED

Your vehicle may be equipped with a passive steering
wheel lock. This lock prevents steering the vehicle with­out the ignition key. If the steering wheel is moved no
more than 1/2 turn in either direction, and the key is not
in the ignition switch, the steering wheel will lock.

If You Wish To Manually Lock The Steering
Wheel:

With the engine running, turn the steering wheel upside
down, turn off the engine and remove the key. Turn the
steering wheel slightly in either direction until the lock
engages.

To Release The Steering Wheel Lock:

Insert the key in the ignition switch and start the engine.
If the key is difficult to turn, move the wheel slightly to
the right or left to disengage the lock.

NOTE: If you turned the wheel to the right to engage
the lock, you must turn the wheel slightly to the right to
disengage it. If you turned the wheel to the left to engage
the lock, turn the wheel slightly to the left to disengage it.

Automatic Transmission Ignition Interlock System

This system prevents the key from being removed unless
the shift lever is in PARK. It also prevents shifting out of
PARK unless the key is in the ACC, or ON position, and
the brake pedal is pressed.

2

16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

SENTRY KEYT IMMOBILIZER SYSTEM — IF
EQUIPPED

The Sentry Keyt prevents unauthorized vehicle opera­tion by disabling the engine. The system does not need to
be armed or activated. Operation is automatic, regardless
of whether the vehicle is locked or unlocked.

The system uses ignition keys that have an embedded
electronic chip (transponder) to prevent unauthorized
vehicle operation. Therefore, only keys that are pro­grammed to the vehicle can be used to start and operate
the vehicle. The system will shut the engine off in two
seconds if someone uses an invalid key to try to start the
engine.

NOTE: A key that has not been programmed is also
considered an invalid key, even if it is cut to fit the
ignition switch lock cylinder for that vehicle.

During normal operation, after turning on the ignition
switch, the Vehicle Security Light will turn on for three

seconds for a bulb check. If the light remains on after the
bulb check, it indicates that there is a problem with the
electronics. In addition, if the light begins to flash after
the bulb check, it indicates that someone used an invalid
key to try to start the engine. Either of these conditions
will result in the engine being shut off after two seconds.

If the Vehicle Security Light turns on during normal
vehicle operation (vehicle running for longer than 10 sec­onds), it indicates that there is a fault in the electronics.
Should this occur, have the vehicle serviced as soon as
possible.

NOTE:

•

The Sentry Keyt Immobilizer System is not compat­ible with some aftermarket remote starting systems.
Use of these systems may result in vehicle starting
problems and loss of security protection.

•

Exxon/Mobil Speedpass™, additional Sentry Keyst,
or any other transponder-equipped components on

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17

the same key chain will not cause a key-related
(transponder) fault unless the additional part is physi-
cally held against the ignition key being used when
starting the vehicle. Cell phones, pagers, or other RF
electronics will not cause interference with this system.

All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.

Replacement Keys

NOTE: Only keys that are programmed to the vehicle
electronics can be used to start and operate the vehicle.
Once a Sentry Keyt is programmed to a vehicle, it cannot
be programmed to any other vehicle.

CAUTION!

Always remove the Sentry Keyst from the vehicle
and lock all doors when leaving the vehicle
unattended.

At the time of purchase, the original owner is provided
with a four-digit Personal Identification Number (PIN).
Keep the PIN in a secure location. This number is
required for authorized dealer replacement of keys. Du­plication of keys may be performed at an authorized
dealer or by following the customer key programming
procedure. This procedure consists of programming a
blank key to the vehicle electronics. A blank key is one
that has never been programmed.

NOTE: When having the Sentry Keyt Immobilizer
System serviced, bring all vehicle keys with you to an
authorized dealer.

Customer Key Programming

If you have two valid Sentry Keyst, you can program
new Sentry Keyst to the system by performing the
following steps:

1. Cut the additional Sentry Keyt Transponder blank(s)
to match the ignition switch lock cylinder key code.

2

18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

2. Insert the first valid key into the ignition switch. Turn
the ignition switch to the ON position for at least three
seconds, but no longer than 15 seconds. Then, turn the
ignition switch to the LOCK position and remove the first
key.

3. Insert the second valid key into the ignition switch.
Turn the ignition switch to the ON position within
15 seconds. After 10 seconds, a chime will sound. In
addition, the Vehicle Security Light will begin to flash.
Turn the ignition switch to the LOCK position and
remove the second key.

4. Insert a blank Sentry Keyt into the ignition switch.
Turn the ignition switch to the ON position within
60 seconds. After 10 seconds, a single chime will sound.
In addition, the Vehicle Security Light will stop flashing.
To indicate that programming is complete, the Vehicle
Security Light will turn on again for three seconds and
then turn off.

The new Sentry Keyt is programmed. The Remote

Keyless Entry (RKE) transmitter will also be pro­grammed during this procedure.

Repeat this procedure to program up to eight keys. If you
do not have a programmed Sentry Keyt, contact your
authorized dealer for details.

NOTE: If a programmed key is lost, see your authorized
dealer to have all remaining keys erased from the sys­tem’s memory. This will prevent the lost key from
starting your vehicle. The remaining keys must then be
reprogrammed. All vehicle keys must be taken to an
authorized dealer at the time of service to be
reprogrammed.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19

VEHICLE SECURITY ALARM SYSTEM — IF
EQUIPPED

The Vehicle Security Alarm system monitors the vehicle
doors and ignition for unauthorized operation. When the
Vehicle Security Alarm system is activated it will provide
both audible and visible signals. The horn will sound
repeatedly for the three minutes and the headlights and
Vehicle Security Light will flash for an additional 15 min­utes. The engine will not run until the Vehicle Security
Alarm system is disarmed

To Set the Alarm

The Vehicle Security Alarm will set when you use the
power door locks, or use the Remote Keyless Entry (RKE)
transmitter to lock the doors. After all the doors are
locked and closed, the Vehicle Security Light in the
instrument cluster will flash rapidly for approximately
15 seconds to signal that the Vehicle Security Alarm

system is arming. After the Vehicle Security Alarm is set,
the Vehicle Security Light will flash at a slower rate to
indicate that the system is armed.

NOTE: If the Vehicle Security Light stays on continu­ously during vehicle operation, have the Vehicle Security
Alarm system checked by an authorized dealer.

To Disarm the System:

Use the RKE transmitter to unlock the door. If something
has triggered the system in your absence, the horn will
sound three times when you unlock the doors. Check the
vehicle for tampering.

The Vehicle Security Alarm system will also disarm if the
vehicle is started with a programmed Sentry Keyt.Ifan
unprogrammed Sentry Keyt isused to start a vehicle, the
engine will run for two seconds and then shut down.
After six unsuccessful attempts at starting the engine, the
system will shut down until the correct key is used. To

2

20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

exit alarming mode, press the RKE transmitter UNLOCK
button or start the vehicle with a programmed Sentry
Keyt.

The Vehicle Security Alarm system is designed to protect
your vehicle; however, you can create conditions where
the system will arm unexpectedly. If you remain in the
vehicle and lock the doors with the RKE transmitter, the
alarm will sound when you pull the door handle to exit.

NOTE: You may accidentally activate the Vehicle Secu­rity Alarm System (horn sounds and lights flash) by
entering the vehicle without using the RKE transmitter to
unlock the door(s). The system can be disarmed with the
RKE transmitter unlock button or by inserting a pro­grammed Sentry Keyt into the ignition and turning the
key to the ON position.

ILLUMINATED ENTRY
Vehicles Equipped With Power Door Locks

All interior lights will illuminate in the vehicle when the
doors are unlocked using the Remote Keyless Entry
(RKE) transmitter.

The interior lights will remain on for 30 seconds after the
last door is closed, or until all doors are closed and either
the ignition is turned to the ON position or a RKE
transmitter LOCK button is pressed.

There is also a battery saver feature that will turn the
interior lights off after eight minutes if the ignition is OFF
and a door is left open or the dimmer control is in the
interior lights ON position.

REMOTE KEYLESS ENTRY

This system allows you to lock or unlock the doors or
activate the Panic Alarm from distances up to a maxi­mum of 66 ft (20 m) using a Remote Keyless Entry (RKE)
transmitter. The RKE transmitter does not need to be
pointed at the vehicle to activate the system.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21

2

Remote Keyless Entry (RKE) Transmitter

1 — Lock
2 — Unlock

NOTE: The line of transmission must not be blocked
with metal objects.

22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Unlock The Doors:

Press and release the UNLOCK button on the RKE
transmitter once to unlock only the driver’s door, or twice
to unlock all the doors. When the unlock button is
pressed, the illuminated entry will initiate, and the
parking lights will flash twice.

The system can be programmed to unlock all the doors
upon the first unlock button press by using the following
procedure:

1. Press and hold the LOCK button on a programmed
RKE transmitter.

2. Continue to hold the LOCK button for at least 4 sec­onds, but not longer than 10 seconds, then press and hold
the UNLOCK button. A single chime will sound to
indicate that this feature has changed.

3. Release both buttons at the same time.

4. Test the feature while outside of the vehicle by press­ing the LOCK/UNLOCK button on the RKE transmitter.

NOTE: Pressing the LOCK button on the RKE transmit­ter while you are inside the vehicle will activate the
Vehicle Security Alarm. Opening a door with the Vehicle
Security Alarm System activated will cause the alarm to
sound. Press the UNLOCK button to deactivate the
Vehicle Security Alarm System.

5. If the desired programming was not achieved, or to
reactivate this feature, repeat the above steps.

To Lock The Doors:

Press and release the LOCK button on the RKE transmit­ter to lock all doors. If the ignition is OFF, when the doors
are locked the parking lights will flash on once and the
horn will chirp once.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23

Horn Chirp Programming

The horn chirp feature is shipped from the assembly
plant activated. If desired, this feature can be disabled by
using the following procedure:

1. Press and hold the LOCK button on the RKE trans­mitter.

2. After holding the LOCK button for four seconds, also
press the PANIC button within six seconds. A single
chime will sound to indicate that this feature has
changed.

3. Release both buttons at the same time.

4. To reactivate this feature, repeat the above steps.

5. Test the horn chirp feature while outside of the vehicle
by pressing the LOCK button on the RKE transmitter
with the ignition in the OFF position and the key
removed.

NOTE: Pressing the LOCK button on the RKE transmit­ter while you are inside the vehicle will activate the
Vehicle Security Alarm. Opening a door with the Vehicle
Security Alarm activated will cause the alarm to sound.
Press the UNLOCK button to deactivate the Vehicle
Security Alarm System.

6. If the desired programming was not achieved, or to
reactivate this feature, repeat the above steps.

Flash Lamps With Lock Programming

1. Press and hold the UNLOCK button on the RKE
transmitter.

2. After holding the UNLOCK button for four seconds,
also press the LOCK button within six seconds. A single
chime will sound to indicate that this feature has
changed.

3. Release both buttons at the same time.

2

24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

4. Test the Flash Lamps With Lock feature while outside
of the vehicle by pressing the LOCK button on the RKE
transmitter with the ignition in the OFF position and the
key removed.

NOTE: Pressing the LOCK button on the RKE transmit­ter while you are in the vehicle will activate the Vehicle
Security Alarm. Opening a door with the Vehicle Security
Alarm activated will cause the alarm to sound. Press the
UNLOCK button to deactivate the Vehicle Security
Alarm System.

5. If the desired programming was not achieved, or to
reactivate this feature, repeat the above steps.

Using The Panic Alarm

To activate the Panic mode while the ignition is OFF,
press and release the PANIC button on the RKE trans­mitter once. When the Panic mode is activated, the
interior lights will illuminate, the headlights and parking
lights will flash, and the horn will sound.

To cancel the Panic mode, press and release the PANIC
button on the RKE transmitter a second time. Panic mode
will automatically cancel after three minutes, or if the
vehicle is started or exceeds 15 mph (24 km/h). During
the Panic Mode, the door locks and RKE systems will
function normally. Panic mode will not disarm the Ve­hicle Security Alarm System, on vehicles so equipped.

General Information

This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference that may be
received including interference that may cause undesired
operation.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25

NOTE: Changes or modifications not expressly ap­proved by the party responsible for compliance could
void the user’s authority to operate the equipment.

If your RKE Transmitter fails to operate from a normal
distance, check for these two conditions.

1. Weak batteries in the RKE transmitter. The expected
life of batteries is five years.

2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, military base, and some mobile
or CB radios.

Programming Additional Transmitters

This vehicle is shipped from the assembly plant with two
RKE transmitters programmed for this vehicle only. A
total of eight RKE transmitters can be programmed for
your vehicle. Additional RKE transmitters can be pro­grammed to your vehicle through the use of currently
programmed RKE transmitters.

NOTE: When entering program mode using that cur­rently programmed RKE transmitter, all other pro­grammed RKE transmitters will be erased and you will
have to reprogram them for your vehicle.

Use the following procedure to program additional RKE
transmitters if the vehicle is not equipped with a Sentry
Keyt:

1. Enter your vehicle and close all the doors.

2. Fasten your seat belt. (Fastening the seat belt will
cancel any chiming that may confuse you during this
programming procedure).

3. Place the key into the ignition.

4. Turn the ignition to the ON position. (Do not start the

engine.)

5. Press and hold the UNLOCK button on the RKE
transmitter.

2

26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

6. After holding the UNLOCK button for four seconds,
also press the PANIC button within six seconds.

7. When a single chime is heard, release both buttons.
The chime is an indication that you have successfully
entered program mode. All RKE transmitters that are to
be programmed must be done so within 60 seconds of
when the chime was heard.

8. Using the RKE transmitter to be programmed, press
and hold both the LOCK and UNLOCK buttons, simul­taneously for two seconds, and then release.

9. Press and release the UNLOCK button. A single chime
will be heard.

10. Repeat steps 8 and 9 to program up to six additional
RKE transmitters.

11. Turn the ignition to the OFF position.

12. Your vehicle will remain in program mode up to
60 seconds from when the original chime was heard.
After 60 seconds, all programmed RKE transmitters
function normally.

NOTE: If you do not have a programmed RKE trans­mitter, contact your authorized dealer for details.

Battery Replacement

The recommended replacement battery is CR2032.
NOTE: Perchlorate Material – special handling may

apply. See www.dtsc.ca.gov/hazardouswaste/
perchlorate

1. If the RKE transmitter is equipped with a screw,
remove the screw. With the RKE transmitter buttons
facing down, use a flat blade to pry the two halves of the
RKE transmitter apart. Make sure not to damage the
elastomer seal during removal.

Battery Access Door

2. Remove and replace the battery. When replacing the
battery, match the + sign on battery to the + sign on the
inside of the battery clip, located on the back cover. Avoid
touching the new battery with your fingers. Skin oils may
cause battery deterioration. If you touch a battery,clean it
with rubbing alcohol.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27

3. To reassemble the RKE transmitter case, snap the two
halves of the case together. Make sure there is an even
“gap” between the two halves. If equipped, install and
tighten the screw until snug. Test the RKE transmitter
operation.

REMOTE STARTING SYSTEM — IF EQUIPPED

Your vehicle may be equipped with a remote starting
system, which will allow the vehicle to be started from
distances up to approximately 300 ft (91 m) away from
the vehicle using the Remote Keyless Entry (RKE) trans­mitter, which is part of your ignition key.

In order to remote start your vehicle, the hood and all the
doors must be closed.

To remote start your vehicle, press the REMOTE START
button on the RKE transmitter twice within five seconds.
To indicate that the vehicle is about to start, the parking
lights will flash and the horn will sound briefly (if
programmed).

2

28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Remote Start Button

Once the vehicle has started, the engine will run for
15 minutes. To cancel remote start, press the REMOTE
START button once.

The parking lights will remain illuminated to indicate
that the vehicle has remote started and the engine is

running. The lights will turn off when the ignition is
turned to RUN or the remote start is cancelled.

To enter the vehicle while the engine is running during a
remote start, you must first unlock the vehicle using the
UNLOCK button on the RKE transmitter. Then, prior to
the end of the 15-minute cycle, insert the key into the
ignition switch and turn the switch to the ON position,
otherwise the engine will cancel remote start and auto­matically turn off.

Remote start will also cancel if any of the following occur:

•

If the engine stalls or the RPM exceeds 2500

•

Any engine warning light come on

•

The hood is opened

•

The Hazard switch is pressed

•

The transmission is moved out of PARK

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29

The vehicle can be started remotely up to a maximum of
two times. The vehicle is also allowed a maximum of one
failed start, where the remote start sequence was initiated
but the engine stopped cranking without starting. After
either of these conditions, or if the VehicleSecurity Alarm
System is activated, or if the PANIC button was pressed,
the vehicle must be reset by inserting a valid key into the
ignition and moving it to the RUN position, then back to
LOCK.

DOOR LOCKS
Manual Door Locks

All the doors can be manually locked from the inside by
pushing down the door lock plunger, located on the door
trim panel. Both front doors may be opened from the
inside with the door lock plunger in the down or locked
position.

WARNING!

•

For personal security and safety in the event of an
accident, lock the vehicle doors as you drive, as
well as when you park and leave the vehicle.

•

Never leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the key in
the ignition. A child could operate power win­dows, other controls, or move the vehicle.

Power Door Locks

A power door lock switch is on each front door trim
panel. Use this switch to lock or unlock the doors.

2

30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

chime will sound if the key is in the ignition switch and
the driver’s door is open, as a reminder to remove the
key.

Automatic Door Locks

If this feature is enabled, your door locks will lock
automatically when the vehicle’s speed exceeds 15 mph
(24 km/h).

This feature is enabled when your vehicle is shipped
from the assembly plant and can be disabled by using the
following procedure:

Power Door Lock Switch

If you press the power door LOCK switch while the key
is in the ignition, and any front door is open, the power
locks will not operate. This prevents you from acciden­tally locking your keys in the vehicle. Removing the key,
or closing the door, will allow the locks to operate. A

1. Enter your vehicle and close all doors.

2. Fasten your seat belt. (Fastening the seat belt will
cancel any chiming that may confuse you during this
programming procedure.)

3. Place the key into the ignition.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31

4. Within 10 seconds, cycle the key from the LOCK
position to the ON position and back to LOCK position,
a minimum of four times; ending in the LOCK position.

(Do not start the engine.)

5. Within 30 seconds, press the driver’s door LOCK
switch in the LOCK direction.

6. A single chime will be heard to indicate the feature has
been disabled.

7. To reactivate this feature, repeat the above Steps.

8. If a chime is not heard, program mode was canceled
before the feature could be disabled. If necessary, repeat
the above procedure.

Auto Unlock On Exit Feature — If Equipped

This feature unlocks all of the doors of the vehicle when
any door is opened. This will occur only after the vehicle

has been shifted into the PARK position after the vehicle
has been driven (shifted out of PARK and the doors
closed).

Auto Unlock Feature Programming

The Customer Programming sequence to disable or en­able Auto Unlock:

1. Enter your vehicle and close all the doors.

2. Fasten your seat belt. (Fastening the seat belt will
cancel any chiming that may be confusing during this
programming procedure.)

3. Insert the key into the ignition.

4. Within 15 seconds, cycle the key from the LOCK
position to the ON position and back to LOCK position,
a minimum of four times; ending in the LOCK position.

(Do not start the engine.)

2

32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

5. Within 30 seconds, press the driver’s door LOCK
switch in the UNLOCK direction.

6. A single chime will sound to indicate the feature has
been changed.

7. To reactivate the feature, repeat the above Steps.

8. If a chime is not heard, program mode was canceled
before the feature could be changed. If necessary, repeat
the above procedure.

Child Protection Door Lock

To provide a safer environment for children riding in the
rear seat, the rear doors of your vehicle have the child­protection door lock system.

Child Lock Lever

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33

To use the system, open each rear door, slide the lever up
to engage the locks, and down to disengage the child­protection locks. When the system on a door is engaged,
that door can only be opened by using the outside door
handle, even if the inside door lock is in the unlocked
position.

WARNING!

Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened
from the outside when the child protection locks are
engaged.

NOTE:

•

After setting the child protection door lock system,
always test the door from the inside to make certain it
is in the desired position.

•

For emergency exit with the system engaged, move
the door lock switch to the UNLOCK position, roll
down the window and open the door with the outside
door handle.

2

34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WINDOWS
Power Windows

The control on the left front door has up-down switches
that give you finger-tip control of all four power win­dows. There is a single opening and closing switch on the
passenger doors for passenger window control. The
windows will operate when the ignition switch is turned
to the ON or ACC position, and for ten minutes after the
ignition is turned OFF or the driver’s door is opened.

Power Window Switch

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35

WARNING!

Never leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be seri­ously or fatally injured. Don’t leave the key in the
ignition. A child could operate power windows,
other controls, or move the vehicle.

Auto Down (Driver’s Side Only)

The driver’s window switch has an Auto Down feature.
Push the window switch past the first detent, release, and
the window will go down automatically. To cancel the
Auto Down movement, operate the switch in either the
up or down direction and release the switch.

Window Lockout Switch

The Window Lockout Switch on the driver’s door allows
you to disable the window control on the other doors. To
disable the window controls on the other doors, press the

Window Lockout button. To enable the window controls,
press the Window Lockout button a second time.

2

Power Window Lockout Switch

Wind Buffeting

Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the
ears. Your vehicle may exhibit wind buffeting with the

36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

windows down or partially open. This is a normal
occurrence and can be minimized. If the buffeting occurs
with the rear windows open, open the front and rear
windows together to minimize the buffeting.

OCCUPANT RESTRAINTS

Some of the most important safety features in your
vehicle are the restraint systems. These include the front
and rear seat belts for the driver and all passengers, knee
bolsters, front airbags for both the driver and front
passenger, and if equipped left and right side curtain
airbags for the driver and passengers seated next to a
window. If you will be carrying children too small for
adult-size seat belts, your seat belts or the LATCHfeature
(refer to the “Child Restraint” in this section), can be used
to hold infant and child restraint systems.

Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly to keep you and your passengers as safe as
possible.

WARNING!

In a collision, you and your passengers can suffer
much greater injuries if you are not properly buckled
up. You can strike the interior of your vehicle or other
passengers, or you can be thrown out of the vehicle.
Always be sure you and others in your vehicle are
buckled up properly.

Buckle up even though you are an excellent driver, even
on short trips. Someone on the road may be a poor driver
and cause a collision that includes you. This can happen
far away from home or on your own street.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37

Research has shown that seat belts save lives, and that
they can reduce the seriousness of injuries in a collision.
Some of the worst injuries happen when people are
thrown from the vehicle. Seat belts reduce the possibility
of ejection and the risk of injury caused by striking the
inside of the vehicle. Everyone in a motor vehicle should
be belted at all times.

Lap/Shoulder Belts

All seating positions, except the front center seating
position (with full bench seat), have combination lap/
shoulder belts. The belt webbing retractor is designed to
lock during very sudden stops or collisions. This feature
allows the shoulder part of the belt to move freely with
you under normal conditions. But in a collision, the belt
will lock and reduce the risk of your striking the inside of
the vehicle or being thrown out.

WARNING!

•

It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seri­ously injured or killed.

•

Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.

•

Be sure everyone in your vehicle is in a seat and
using a seat belt properly.

(Continued)

2

38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

•

Wearing a seat belt incorrectly is dangerous. Seat
belts are designed to go around the large bones of
your body. These are the strongest parts of your
body and can take the forces of a collision the best.
Wearing your belt in the wrong place could make
your injuries in a collision much worse. You might
suffer internal injuries, or you could even slide out
of part of the belt. Follow these instructions to
wear your seat belt safely and to keep your pas­sengers safe, too.

•

Two people should never be belted into a single
seat belt. People belted together can crash into one
another in an accident, hurting one another badly.
Never use a lap/shoulder belt or a lap belt for more
than one person, no matter what their size.

Lap/Shoulder Belt Operating Instructions

1. Enter the vehicle and close the door. Sit back and
adjust the seat.

Pulling Out Belt and Latch Plate

2. The seat belt latch plate is above the back of the front
seat, next to your arm in the rear seat. Grasp the latch

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39

plate and pull out the belt. Slide the latch plate up the
webbing as far as necessary to allow the belt to go around
your lap.

Latch Plate To Buckle

3. When the belt is long enough to fit, insert the latch
plate into the buckle until you hear a “click.”

WARNING!

•

A belt buckled into the wrong buckle will not
protect you properly. The lap portion could ride
too high on your body, possibly causing internal
injuries. Always buckle your belt into the buckle
nearest you.

•

A belt that is too loose will not protect you as well.
In a sudden stop you could move too far forward,
increasing the possibility of injury. Wear your seat
belt snugly.

(Continued)

2

40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

•

A belt that is worn under your arm is very danger­ous. Your body could strike the inside surfaces of
the vehicle in a collision, increasing head and neck
injury and a belt worn under the arm can cause
internal injuries. Ribs aren’t as strong as shoulder
bones. Wear the belt over your shoulder so that
your strongest bones will take the force in a
collision.

•

A shoulder belt placed behind will not protect you
from injury during a collision. You are more likely
to hit your head in a collision if you do not wear
your shoulder belt. The lap and shoulder belt are
meant to be used together.

4. Position the lap belt across your thighs, below your
abdomen. To remove slack in the lap belt portion, pull up
on the shoulder belt. To loosen the lap belt if it is too tight,
tilt the latch plate and pull on the lap belt. A snug belt
reduces the risk of sliding under the belt in a collision.

Removing Slack From Belt

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41

WARNING!

•

A lap belt worn too high can increase the risk of
internal injury in a collision. The belt forces won’t
be at the strong hip and pelvic bones, but across
your abdomen. Always wear the lap belt as low as
possible and keep it snug.

•

A twisted belt can’t do its job as well. In a collision
it could even cut into you. Be sure the belt is
straight. If you can’t straighten a belt in your
vehicle, take it to your authorized dealer and have
it fixed.

5. Position the shoulder belt on your chest so that it is
comfortable and not resting on your neck. The retractor
will withdraw any slack in the belt.

6. To release the belt, push the red button on the buckle.
The belt will automatically retract to its stowed position.
If necessary, slide the latch plate down the webbing to
allow the belt to retract fully.

WARNING!

A frayed or torn belt could rip apart in a collision and
leave you with no protection. Inspect the belt system
periodically, checking for cuts, frays, or loose parts.
Damaged parts must be replaced immediately. Do
not disassemble or modify the system. Seat belt
assemblies must be replaced after a collision if they
have been damaged (bent retractor, torn webbing,
etc.).

2

42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Adjustable Upper Shoulder Belt Anchorage

In the front and second row outboard seats, the shoulder
belt can be adjusted upward or downward to help
position the belt away from your neck. Push in on the
anchorage release button to release the anchorage, and
then move it up or down to the position that fits you best.

Adjustable Upper Shoulder Belt Anchorage

Adjusting Upper Shoulder Belt

As a guide, if you are shorter than average, you will
prefer a lower position, and if you are taller than average,
you’ll prefer a higher position. When you release the
anchorage, try to move it up or down to make sure that
it is locked in the desired position.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43

The adjuster has an easy up (EZ Up) feature, which will
allow it to be moved up without engaging the button.

Automatic Locking Retractors (ALR) Mode – If
Equipped

In this mode, the shoulder belt is automatically pre­locked. The belt will still retract to remove any slack in
the shoulder belt. The automatic locking mode is avail­able on all passenger seating positions with a combina­tion lap/shoulder belt.

When to Use the Automatic Locking Mode

Use the Automatic Locking Mode anytime a child safety
seat is installed in a passenger seating position. Children
12 years old, and younger, should be properly restrained
in the rear seat, whenever possible.

How to Use the Automatic Locking Mode

1. Buckle the combination lap/shoulder belt.

2. Grasp the shoulder portion and pull downward until
the entire belt is fully extended.

3. Allow the belt to retract. As the belt retracts, you will
hear a clicking sound. This indicates the safety belt is
now in the Automatic Locking mode.

How to Disengage the Automatic Locking Mode

To disengage the Automatic Locking Mode, disconnect
the combination lap/shoulder belt and allow it to retract
completely. The vehicle sensitive (emergency) locking
mode is automatically activated.

Center Lap Belts

The center seat position on the front seat bench has a lap
belt only. To fasten the lap belt, slide the latch plate into
the buckle until you hear a “click.” To lengthen the lap
belt, tilt the latch plate and pull. To remove slack, pull the
loose end of the webbing. Wear the lap belt snug against
the hips. Sit back and erect in the seat, then adjust the belt
as tightly as is comfortable.

2

44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Seat Belt Pretensioners

The seat belts for front outboard seating positions are
equipped with pretensioning devices that are designed to
remove any slack from the seat belt system in the event of
a collision. These devices improve the performance of the
seat belt by assuring that the belt is tight about the
occupant early in a collision. Pretensioners work for all
size occupants, including those in child restraints.

NOTE: These devices are not a substitute for proper seat
belt placement by the occupant. The seat belt still must be
worn snugly and positioned properly.

The pretensioners are triggered by the Occupant Re­straint Controller (ORC). Like the airbags, the pretension­ers are single-use items. After a collision that is severe
enough to deploy the airbags and pretensioners, both
must be replaced.

Enhanced Driver Seat Belt Reminder System
(BeltAlertT)

If the driver’s seat belt has not been buckled within
60 seconds of starting the vehicle, and if the vehicle speed
is greater than 5 mph (8 km/h), the Enhanced Warning
System (BeltAlertt) will alert the driver to buckle their
seat belt. The driver should also instruct all other occu­pants to buckle their seat belts. If the driver unbuckles the
seat belt while the vehicle is in motion, an immediate
chime will be heard and, BeltAlertt will continue to
chime and flash the Seat Belt Warning Light for 96 sec­onds or until the driver’s seat belt is buckled. BeltAlertt
will be reactivated if the driver’s seat belt is unbuckled
for more than 10 seconds, and the vehicle speed is greater
than 5 mph (8 km/h).

BeltAlertt can be enabled or disabled by your authorized
dealer, or by following these steps:

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45

NOTE: The following steps must occur within the first
60 seconds of the ignition switch being turned to the ON
or START position. Chrylser LLC does not recommend
deactivating BeltAlertt.

1. Turn the ignition switch to the OFF position and
buckle the driver’s seat belt.

2. Turn the ignition switch to the ON position and wait
for the Seat Belt Warning Light to turn off.

3. Within 60 seconds of starting the vehicle, unbuckle
and then re-buckle the driver’s seat belt at least three
times within 10 seconds, ending with the seat belt
buckled.

4. Turn off the engine. A single chime will sound to
signify that you have successfully completed the
programming.

BeltAlertt canbe reactivated by repeating this procedure.

NOTE: Although the BeltAlertt has been deactivated,
the Seat Belt Warning Light will continue to illuminate
while the driver’s seat belt remains unbuckled.

Seat Belts And Pregnant Women

We recommend that pregnant women use seat belts
throughout their pregnancies. Keeping the mother safe is
the best way to keep the baby safe.

Pregnant women should wear the lap part of the belt
across the thighs and as snug against the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is a collision.

Seat Belt Extender

If a seat belt is too short, even when fully extended, your
authorized dealer can provide you with a seat belt
extender. This extender should be used only if the
existing belt is not long enough. When it is not required,
remove the extender and store it.

2

46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

Using a seat belt extender when not needed can
increase the risk of injury in a collision. Only use the
seat belt extender when the lap belt is not long
enough when it is worn low and snug, and in the
recommended seating positions. Remove and store
the extender when not needed.

Driver And Right Front Passenger Supplemental
Restraint System (SRS) – Airbags

This vehicle has airbags for both the driver and right
front passenger as a supplement to the seat belt restraint
systems. The driver’s front airbag is mounted in the
steering wheel. The passenger’s front airbag is mounted
in the instrument panel, above the glove compartment.
The words SRS/AIRBAG are embossed on the airbag
covers.

1 — Airbags
2 — Knee Bolsters

NOTE: The front airbags are certified to the Federal
regulations that allow less forceful deployment.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47

The front airbags have a multistage inflator design. This
may allow the airbag to have different rates of inflation
that are based on collision severity and occupant size.

This vehicle may also be equipped with window bags to
protect the driver, and front and rear passengers sitting
next to a window. If the vehicle is equipped with window
bags, they are located above the side windows. Their
covers are also labeled SRS AIRBAG.

NOTE: Airbag covers may not be obvious in the interior
trim; but they will open to allow airbag deployment.

WARNING!

•

Do not put anything on or around the front airbag
covers or attempt to manually open them. You may
damage the airbags and you could be injured
because the airbags are no longer functional.
These protective covers for the airbag cushions are
designed to open only when the airbags are inflat­ing.

•

If your vehicle is equipped with window bags, do
not stack luggage or other cargo up high enough to
block the location of the window bag. The area
where the window bag is located should remain
free from any obstructions.

(Continued)

2

48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

•

If your vehicle is equipped with window bags, do
not have any accessory items installed that will
alter the roof, including adding a sunroof to your
vehicle. Do not add roof racks that require perma­nent attachments (bolts or screws) for installation
on the vehicle roof. Do not drill into the roof of the
vehicle for any reason.

NOTE: Do not use a clothing bar mounted to the coat

hooks in this vehicle. A clothing bar will impede the
proper performance of the window bags.

Along with the seat belts, front airbags work with the
instrument panel knee bolsters to provide improved
protection for the driver and front passenger. Window
bags also work with seat belts to improve occupant
protection.

The seat belts are designed to protect you in many types
of collisions. The front airbags deploy in moderate to
severe frontal collisions.

If your vehicle is so equipped, the window bag on the
crash side of the vehicle is triggered in moderate-to­severe side collisions. But even in collisions where the
airbags work, you need the seat belts to keep you in the
right position for the airbags to protect you properly.

Here are some simple steps you can follow to minimize
the risk of harm from a deploying airbag.

1. Children 12 years and younger should always ride
buckled up in a rear seat, in an appropriate child re­straint.

Infants, in rear-facing child restraints, should NEVER
ride in the front seat of a vehicle with a passenger front
airbag. An airbag deployment can cause severe injury or
death to infants in that position.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49

If a child between the ages of 1 and 12 years old, must
ride in the front passenger seat because the vehicle is
crowded, move the seat as far back as possible, and use
the proper child restraint. Refer to 9Child Restraint,9 in
this section.

You should read the instructions provided with your
child restraint to make sure that you are using it properly.

2. All occupants should use their lap and shoulder belts
properly.

3. The driver and front passenger seats should be moved
back as far as practical to allow the airbag room to inflate.

4. If your vehicle has window airbags, do not lean
against the door or window. Airbags will inflate force­fully into the space between you and the door.

5. If the airbag system in this vehicle needs to be
modified to accommodate a disabled person, contact the
Customer Center. Refer to 9If You Need Customer Assis­tance9 in Section 9.

WARNING!

•

Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions the airbags won’t deploy at all.
Always wear your seat belts even though you have
airbags.

•

Being too close to the steering wheel or instrument
panel during airbag deployment could cause seri­ous injury. Airbags need room to inflate. Sit back,
comfortably extending your arms to reach the
steering wheel or instrument panel.

(Continued)

2

50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

•

If the vehicle has window bags, they also need
room to inflate. Do not lean against the door or
window. Sit upright in the center of the seat.

Airbag System Components

The airbag system consists of the following:

•

Occupant Restraint Controller

•

Side Remote Acceleration Sensors – if equipped

•

Airbag Warning Light

•

Driver Airbag

•

Passenger Airbag

•

Window Bags above side windows – if equipped

•

Steering Wheel and Column

•

Instrument Panel

•

Interconnecting Wiring

•

Knee Impact Bolsters

•

Front Acceleration Sensors

•

Driver and Front Passenger Seat Belt Pretensioners

How the Airbag System Works

The Occupant Restraint Controller (ORC) determines

•

if a frontal collision is severe enough to require the
airbags to inflate. The front airbag inflators are de­signed to provide different rates of airbag inflation
from direction provided by the ORC. The ORC will not
detect rollover.

The ORC also monitors the readiness of the electronic
parts of the system whenever the ignition switch is in
the START or RUN position. These include all of the
items listed above, except the steering wheel and
column, and knee bolsters. If the key is in the OFF

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51

position, in the ACC position, or not in the ignition,
the airbags are not on and will not inflate.

During a moderate-to-severe rear impact, the ORC may
only deploy the seat belt pretensioners.

•

Also, the ORC turns on the AIRBAG warn­ing light in the instrument cluster for six to
eight seconds for a self-check when the

ignition is first turned on. After the self­check, the AIRBAG warning light will turn off. If the
ORC detects a malfunction in any part of the system, it
turns on the AIRBAG warning light either momen­tarily or continuously.A single chime will sound if the
light comes on again after initial start up.

WARNING!

Ignoring the AIRBAG warning light in your instru­ment panel could mean you won’t have the airbags to
protect you in a collision. If the light does not come
on, stays on after you start the vehicle, or if it comes
on as you drive, have the airbag system checked right
away.

NOTE: Children 12 years and younger should always

ride buckled up in a rear seat, in an appropriate child
restraint.

•

The Driver and Passenger Airbag/Inflator Units are
located in the center of the steering wheel and the right
side of the instrument panel. When the ORC detects a
collision requiring the airbags, it signals the inflator
units. A large quantity of nontoxic gas is generated to
inflate the front airbags. Different airbag inflation rates

2

52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

may be possible based on collision severity and occu­pant size. The steering wheel hub trim cover and the
upper right side of the instrument panel separate and
fold out of the way as the bags inflate to their full size.
The bags fully inflate in about 50 - 70 milliseconds.
This is about half of the time it takes to blink your eyes.
The bags then quickly deflate while helping to restrain
the driver and front passenger. The driver’s front
airbag gas is vented through vent holes in the sides of
the airbag. The passenger’s front airbag gas is vented
through vent holes in the sides of the airbag. In this
way the airbags do not interfere with your control of
the vehicle.

•

The Side Impact SRS Window Bags are designed to
activate only in certain side collisions. When the ORC
(with side impact option) detects a collision requiring
the window bags to inflate, it signals the inflators on
the crash side of the vehicle. Aquantity of nontoxic gas
is generated to inflate the window bag. The inflating

window bag pushes the outside edge of the headliner
out of the way and covers the window. The airbag
forcefully inflates in about one quarter of the time it
takes to blink your eye. Make sure you are seated and
belted properly and do not position items in the area
where the window bag inflates. This especially applies
to children. The window bag is only about 3-1/2 in
(9 cm) thick when it is inflated.

NOTE: At no time should any supplemental restraint
system (SRS)-component or SRS related component, or
fastener, be modified or replaced with any part except
those which are approved by Chrylser LLC/Mopar.

•

The Knee Impact Bolsters help protect the knees of
the driver and the front passenger, and position every­one for the best interaction with the front airbag.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53

If a Deployment Occurs

The airbag system is designed to deploy the airbags
when the impact sensors detect a moderate-to-severe
frontal collision, to help restrain the driver and front
passenger, and then immediately deflate.

NOTE: A frontal collision that is not severe enough to
need airbag protection will not activate the system. This
does not mean something is wrong with the airbag
system.

If you do have a collision that deploys the airbags, any or
all of the following may occur:

•

The nylon airbag material may sometimes cause abra­sions and/or skin reddening to the driver and front
passenger as the airbags deploy and unfold. The
abrasions are similar to friction rope burns or those
you might get sliding along a carpet or gymnasium
floor. They are not caused by contact with chemicals.
They are not permanent and normally heal quickly.

However, if you haven’t healed significantly within a
few days, or if you have any blistering, see your doctor
immediately. As the airbags deflate, you may see some
smoke-like particles. The particles are a normal by­product of the process that generates the nontoxic gas
used for airbag inflation. These airborne particles may
irritate the skin, eyes, nose, or throat. If you have skin
or eye irritation, rinse the area with cool water. For
nose or throat irritation, move to fresh air. If the
irritation continues, see your doctor. If these particles
settle on your clothing, follow the garment manufac­turer’s instructions for cleaning.

•

It is not advisable to drive your vehicle after the
airbags have deployed. If you are involved in another
collision, the airbags will not be in place to protect you.

2

54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

Deployed airbags and seat belt pretensioners cannot
protect you in another collision. Have the airbags,
and both front seat belt retractor assemblies (w/
pretensioners), replaced by an authorized dealer as
soon as possible.

Maintaining Your Airbag System

WARNING!

•

Modifications to any part of the airbag system
could cause it to fail when you need it. You could
be injured if the airbag system is not there to
protect you. Do not modify the components or
wiring, including adding any kind of badges or
stickers to the steering wheel hub trim cover or the
upper right side of the instrument panel. Do not
modify the front bumper, vehicle body structure,
or add aftermarket side steps or running boards.

•

You need proper knee impact protection in a
collision. Do not mount or locate any aftermarket
equipment on or behind the knee bolsters.

(Continued)

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55

WARNING! (Continued)

•

It is dangerous to try to repair any part of the airbag
system yourself. Be sure to tell anyone who works
on your vehicle that it has an airbag system.

NOTE:

See www.dtsc.ca.gov/hazardouswaste/perchlorate.

Enhanced Accident Response System

If the airbags deploy after an impact and the electrical
system remains functional, vehicles equipped with
power door locks will unlock automatically. In addition,
approximately five seconds after the vehicle has stopped
moving, the interior lights will light until the ignition
switch is turned off.

Perchlorate Material – special handling may apply.

Airbag Warning Light

You will want to have the airbags ready to
inflate for your protection in an impact. While
the airbag system is designed to be mainte­nance free, if any of the following occurs, have

an authorized dealer service the system promptly:

•

The Airbag WarningLight does not come on or flickers
during the six to eight seconds when the ignition
switch is first turned on.

•

The light remains on or flickers after the six to eight
second interval.

•

The light flickers or comes on and remains on while
driving.

NOTE: If the speedometer, tachometer or any engine
related gauges are not working, the Occupant Restraint
Controller (ORC) may also be disabled. The airbags may
not be ready to inflate for your protection. Promptly

2

56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

check the fuse block for blown fuses. Refer to the label
located on the inside of the fuse block cover for the
proper airbag fuses. See your authorized dealer if the
fuse is good.

Event Data Recorder (EDR)

In the event of an accident, your vehicle is designed to
record up to five seconds of specific vehicle data param­eters (see the following list) in an event data recorder,
prior to the moment of airbag deployment, or near
deployment, and up to a quarter-second of high-speed
deceleration data during, and/or after, airbag deploy­ment. EDR data are ONLY recorded if an airbag deploys,
or nearly deploys, and are otherwise unavailable.

NOTE:

1. A near-deployment event occurs when the airbag
sensor detects severe vehicle deceleration usually indica­tive of a crash, but not severe enough to warrant airbag
deployment.

2. Under certain circumstances, EDR data may not be
recorded (e.g., loss of battery power).

In conjunction with other data gathered during a com­plete accident investigation, the electronic data may be
used by Chrylser LLC, and others, to learn more about
the possible causes of crashes and associated injuries, in
order to assess and improve vehicle performance. In
addition to crash investigations initiated by Chrylser
LLC, such investigations may be requested by customers,
insurance carriers, government officials, and professional
crash researchers, such as those associated with univer­sities, and with hospital and insurance organizations.

In the event that an investigation is undertaken by
Chrylser LLC (regardless of initiative), the company, or
its designated representative, will first obtain permission
of the appropriate custodial entity for the vehicle (usually
the vehicle owner or lessee) before accessing the elec­tronic data stored, unless ordered to download data by a

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57

court with legal jurisdiction (i.e., pursuant to a warrant).
Acopy of the data will be provided to the custodial entity
upon request. General data, that does not identify par­ticular vehicles or crashes, may be released for incorpo­ration in aggregate crash databases, such as those main­tained by the U.S. government and various states. Data of
a potentially sensitive nature, such as would identify a
particular driver, vehicle, or crash, will be treated confi­dentially. Confidential data will not be disclosed by
Chrylser LLC to any third party, except when:

1. Used for research purposes, such as to match data
with a particular crash record in an aggregate database,
provided confidentiality of personal data is thereafter
preserved

2. Used in defense of litigation involving a Chrylser LLC
product

3. Requested by police under a legal warrant

4. Otherwise required by law.
Data Parameters that May Be Recorded:

•

Diagnostic trouble code(s) and warning lamp status
for electronically-controlled safety systems, including
the airbag system

•

9Time9 of airbag deployment (in terms of ignition
cycles and vehicle mileage)

•

Airbag deployment level (if applicable)

•

Impact acceleration and angle

•

Seat belt status

•

Brake status (service and parking brakes)

•

Accelerator status (including vehicle speed)

•

Engine control status (including engine speed)

•

Transmission gear selection

2

58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•

Cruise control status

•

Traction/stability control status

•

Tire pressure monitoring system status (if equipped).

Child Restraint

Everyone in your vehicle needs to be buckled up all the
time - babies and children, too. Every state in the United
States, and all Canadian provinces, require that small
children ride in proper restraint systems. This is the law,
and you can be prosecuted for ignoring it. Children
12 years and younger should ride properly buckled up in
a rear seat, if available. According to crash statistics,
children are safer when properly restrained in the rear
seats rather than in the front.

There are different sizes and types of restraints for
children from newborn size to the child almost large
enough for an adult seat belt. Always check the child seat

owner’s manual to ensure you have the right seat for
your child. Use the restraint that is correct for your child.

Infants and Small Children

Safety experts recommend that children ride

•

rearward-facing in the vehicle until they are at least
one year old and weigh at least 20 lbs (9 kg). Two types
of child restraints can be used rearward facing: infant
carriers and 9convertible9 child seats.

•

The infant carrier is only used rearward-facing in the
vehicle. It is recommended for children who weigh up
to about 20 lbs (9 kg). 9Convertible9 child seats can be
used either rearward-facing or forward-facing in the
vehicle. Convertible child seats often have a higher
weight limit in the rearward-facing direction than
infant carriers do, so they can be used rearward-facing
by children who weigh more than 20 lbs (9 kg) but are
less than one year old. Both types of child restraints are
held in the vehicle by the seat belt or the LATCH child

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59

restraint anchorage system. (Refer to “LATCH - Child
Seat Anchorage System” in this section.)

•

Rearward-facing child seats must NEVER be used in
the front seat of a vehicle with a front passenger airbag
that does not have a switch to turn the airbag Off. An
airbag deployment could cause severe injury or death
to infants in this position.

Older Children and Child Restraints

•

Children who weigh more than 20 lbs (9 kg), and who
are older than one year, can ride forward-facing in the
vehicle. Forward-facing child seats and convertible
child seats used in the forward-facing direction are for
children who weigh 20 to 40 lbs (9 to 18 kg), and are
older than one year old. These child seats are also held
in the vehicle by the seat belt or the LATCH child
restraint anchorage system. (Refer to “LATCH - Child
Seat Anchorage System” in this section.)

•

The belt-positioning booster seat is for children weigh­ing more than 40 lbs (18 kg), but who are still too small
to fit the vehicle’s seat belts properly. If the child
cannot sit with knees bent over the seat cushion while
the child’s back is against the seatback, they need a
belt-positioning booster seat. The child and booster
seat are held in the vehicle by the lap/shoulder belt.

Children Too Large for Booster Seats

•

Children who are large enough to wear the shoulder
belt comfortably, and whose legs are long enough to
bend over the front of the seat when their back is
against the seat back should use the lap/shoulder belt
in a rear seat.

•

Make sure that the child is upright in the seat.

•

The lap portion should be low on the hips and as snug
as possible.

2

60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•

Check belt fit periodically. A child’s squirming or
slouching can move the belt out of position.

•

If the shoulder belt contacts the face or neck, move the
child closer to the center of the vehicle. Never allow a
child to put the shoulder belt under an arm.

For additional information, refer to www.seatcheck.org.

WARNING!

•

Improper installation can lead to failure of an
infant or child restraint. It could come loose in a
collision. The child could be badly injured or
killed. Follow the manufacturer’s directions ex­actly when installing an infant or child restraint.

(Continued)

WARNING! (Continued)

•

A rearward-facing infant restraint should only be
used in a rear seat of a vehicle that does not have
an airbag off switch. A rearward-facing infant
restraint in the front seat may be struck by a
deploying passenger airbag, which may cause se­vere or fatal injury to the infant.

Here are some tips for getting the most out of your child
restraint:

•

Before buying any restraint system, make sure that it
has a label certifying that it meets all applicable Safety
Standards. The manufacturer recommends that you
try a child restraint in the vehicle seats where you will
use it before you buy it.

•

The restraint must be appropriate for your child’s
weight and height. Check the label on the restraint for
weight and height limits.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61

•

Carefully follow the instructions that come with the
restraint. If you install the restraint improperly, it may
not work when you need it.

•

The Extended Cab first, and Club/Crew Cab second
row outside seating positions, have cinching latch
plates. These are designed to keep the lap portion tight
around the child restraint so that it is not necessary to
use a locking clip. If the seat belt has a cinching latch
plate, pulling up on the shoulder portion of the
lap/shoulder belt will tighten the belt. The cinching
latch plate will keep the belt tight, however, any seat
belt system will loosen with time, so check the belt
occasionally and pull it tight, if necessary.

•

Buckle the child into the restraint exactly as the
manufacturer’s instructions tell you.

•

When your child restraint is not in use, secure it in the
vehicle with the seat belt or remove it from the vehicle.

Do not leave it loose in the vehicle. In a sudden stop or
collision, it could strike the occupants or seatbacks and
cause serious personal injury.

LATCH - Child Seat Anchorage System (Lower
Anchors and Tether for CHildren) — if equipped

Each vehicle is equipped with the child restraint anchor­age system called LATCH, which stands for Lower
Anchors and Tethers for CHildren. The LATCH system
provides for the installation of the child restraint without
using the vehicle’s seat belts, instead securing the child
restraint using lower anchorages and upper tether straps
from the child restraint to the vehicle structure. LATCH­compatible child restraint systems are now available.
However, because the lower anchorages are to be intro­duced over a period of years, child restraint systems
having attachments for those anchorages will continue to
also have features for installation using the vehicle’s seat
belts. Child restraints having tether straps and hooks for

2

62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

connection to the top tether anchorages have been avail­able for some time. For some older child restraints, many
child restraint manufacturers offer add-on tether strap
kits or retro-fit kits. You are urged to take advantage of all
the available attachments provided with your child re­straint in any vehicle.

Extended Cab

•

The Extended Cab front and right rear (if equipped
with a rear seat) passenger seating positions have
lower anchorages for LATCH-equipped child
restraints.

Crew Cab

•

The Crew Cab second row seat has lower anchorages
that are capable of accommodating LATCH­compatible child seats having flexible, webbing­mounted lower attachments at all three seating posi­tions. Child seats with fixed lower attachments must
be installed in the outboard positions only. Regardless
of the specific type of lower attachment, NEVER install
LATCH compatible child seats such that two seats
share a common lower anchorage. If you are installing
LATCH-compatible child restraints in adjacent rear
seating positions, you can use the LATCH anchors or
the vehicle’s seat belt for the outboard position, but
you must use the vehicle’s seat belt at the center
position.

If your child restraints are not LATCH compatible, you
can only install the child restraints using the vehicle’s
seat belts. Refer to “Installing the LATCH-Compatible
Child Restraint System” in this section.

LATCH Anchors

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63

2

LATCH Anchors

Installing the LATCH-Compatible Child Restraint
System — if equipped

We urge that you carefully follow the directions of the
manufacturer when installing your child restraint. Not all
child restraint systems will be installed as described here.
Again, carefully follow the installation instructions that

64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

were provided with the child restraint system. The rear
seat lower anchorages are round bars, located at the rear
of the seat cushion where it meets the seatback, and are
just visible when you lean into the vehicle to install the
child restraint. You will easily feel them if you run your
finger along the intersection of the seatback and seat
cushion surfaces. In addition, there are tether strap
anchorages at each LATCH seating position (Refer to
“Child Restraint Tether Anchor” in this section.) Many,
but not all, restraint systems will be equipped with
separate straps on each side, with each having a hook or
connector for attachment to the lower anchorage and a
means of adjusting the tension in the strap. Forward­facing toddler restraints, and some rear-facing infant
restraints, will also be equipped with a tether strap, a
hook for attachment to the tether strap anchorage, and a
means of adjusting the tension of the strap. You will first
loosen the adjusters on the lower straps and on the tether
strap so that you can more easily attach the hooks or

connectors to the vehicle anchorages. Next, attach the
lower hooks or connectors over the top of the anchorage
bars, pushing aside the seat cover material. Then, attach
the tether strap to the anchorage located on the back of
the seat, being careful to route the tether strap to provide
the most direct path between the anchor and the child
restraint. If your vehicle is equipped with adjustable rear
head restraints, raise the head restraint and, route the
tether strap under the head restraint and between the two
posts. Finally, tighten all three straps as you push the
child restraint rearward and downward into the seat,
removing slack in the straps according to the child
restraint manufacturer’s instructions.

NOTE: When using the LATCH attaching system to
install a child restraint, please ensure that all seat belts
not being used for occupant restraints are stowed and out
of reach of children. It is recommended that before
installing the child restraint, buckle the seat belt so the
seat belt is tucked behind the child restraint and out of

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65

reach. If the buckled seat belt interferes with the child
restraint installation, instead of tucking the seat belt
behind the child restraint, route the seat belt through the
child restraint belt path and then buckle it. This should
stow the seat belt out of the reach of an inquisitive child.
Remind all children in the vehicle that the seat belts are
not toys and should not be played with, and never leave
your child unattended in the vehicle.

WARNING!

Improper installation of a child restraint to the
LATCH anchorages can lead to failure of an infant or
child restraint. The child could be badly injured or
killed. Follow the manufacturer’s directions exactly
when installing an infant or child restraint.

Installing Child Restraints Using the Vehicle Seat
Belt

The passenger seat belts are equipped with either cinch­ing latch plates or automatic locking retractors, which are
designed to keep the lap portion tight around the child
restraint, so that it should not be necessary to use a
locking clip. If the seat belt has a cinching latch plate,
pulling up on the shoulder portion of the lap/shoulder
belt will tighten the belt. The cinching latch plate will
keep the belt tight; however, any seat belt system will
loosen with time, so check the belt occasionally and pull
it tight if necessary. If the seat belt has an automatic
locking retractor, it will have a distinctive label. Pull the
belt from the retractor until there is enough to allow you
to pass through the child restraint and slide the latch
plate into the buckle. Then, pull the belt until it is fully
extended from the retractor. Allow the belt to return to
the retractor, pulling on the excess webbing to tighten the
lap portion about the child restraint. For automatic

2

66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

locking retractor seat belts, refer to 9Automatic Locking
Mode9 in this section. If you have trouble tightening the
lap/shoulder belt on the child restraint because, the
buckle or latch plate is too close to the belt path opening
on the restraint, follow these steps. If the buckle is
webbing-mounted, disconnect the latch plate from the
buckle and twist the short buckle-end belt to shorten it.
Insert the latch plate into the buckle with the release
button facing out. If the belt still can’t be tightened, the
buckle is not webbing-mounted, or if by pulling and
pushing on the restraint loosens the belt, you may need
to do something more. Disconnect the latch plate from
the buckle, turn the latch plate around, and insert the
latch plate into the buckle again. If you still can’t make
the child restraint secure, try a different seating position
or use the locking clip provided with your child restraint.
To complete the child seat installation, refer to 9Child
Restraint Tether Anchor9 in this section.

Child Restraint Tether Anchor

The Extended Cab model has one routing strap
located behind the passenger side, rear out­board seating position. The tether anchor itself

is located in the center of vehicle, in between
the two seating positions. The front outboard passenger
seating position is also equipped with a child tether
anchorage, located at the base of the front seatback.
When there is a rear seat delete option, the tether
anchorage located on the cab back panel is designed to be
used for the front seat center seating position. The Crew
Cab model has three anchorages located behind each of
the rear seating positions (rear left, rear center, and rear
right).

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67

WARNING!

•

With a child restraint installed in the rear passen­ger side locations, use care when adjusting the
front seat(s) rearward, to avoid the front seatback
coming in contact with the belted child directly
behind the seat. The child could be injured.

•

Improper installation can lead to failure of an
infant or child restraint. It could come loose in a
collision. The child could be seriously injured or
killed. Make sure the child restraint tether strap is
always routed through the proper anchor strap
inner loop.

Tether Strap at the Front Passenger Seat (Extended
Cab)

1. Route the child restraint tether strap up and over the
front passenger seatback, and under the head restraint.

2. Connect the tether strap to the lower anchor.

3. Remove the slack in the tether strap so that it is pulled
tight.

Tether Strap

2

68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Tether Straps at the Rear Passenger Seat (Extended
Cab)

1. Route the child restraint tether strap through the
routing loop, located directly behind the child restraint.
The routing loops are located behind the flip-down door
on the cab back panel (padded bolster).

Tether Strap Routing Loop

2. Route the tether strap across to the center tether
anchorage. The center tether is located behind the slide
door in the center of the vehicle, between the two seating
positions.

Tether Strap Routing

3. Remove the slack in the tether strap so that the anchor
strap is pulled tight.

Tether Straps at the Rear Passenger Seat (Crew Cab)

1. Route the child restraint tether strap under the head
restraint for the outboard seating positions, and then
through the anchor strap outer loop (webbing material
loop), located directly behind the child restraint.

2. Route the tether strap across to the nearest installed
anchor strap, and attach the tether strap hook to the
anchor strap inner metal ring.

3. Remove the slack in the tether strap so that both
anchor straps are pulled tight.

NOTE: Two anchors must be used for any of the three
seating positions.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69

Multiple Child Restraints

1 — Inner Anchor Strap Rings 4 — Passenger Side Rear Child
2 — Snap Hook 5 — Center Rear Child Seat

3 — Tether Strap 6 — Drivers Side Rear Child

Seat

Seat

2

70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

An incorrectly anchored tether strap could lead to
seat failure and injury to the child. In a collision, the
seat could come loose and allow the child to crash
into the inside of the vehicle or other passengers, or
even be thrown from the vehicle. Use only the anchor
positions directly behind the child restraint to secure
a child restraint top tether strap. See your authorized
dealer for help, if necessary.

Transporting Pets

Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision. Pets should be restrained in the rear seat in
pet harnesses or pet carriers that are secured by seat belts.

ENGINE BREAK-IN RECOMMENDATIONS

A long break-in period is not required for the engine in
your vehicle.

Drive moderately during the first 300 miles (500 km).
After the initial 60 miles (100 km), speeds up to 50 or
55 mph (80 or 90 km/h) are desirable.

While cruising, brief full-throttle acceleration within the
limits of local traffic laws, contributes to a good break-in.
Wide-open throttle acceleration in low gear can be detri­mental and should be avoided.

The engine oil installed in the engine at the factory is a
high-quality energy conserving type lubricant. Oil
changes should be consistent with anticipated climate
conditions under which vehicle operations will occur.
The recommended viscosity and quality grades are

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71

shown under “Engine Oil”, under “Maintenance Proce­dures” in section 7 of this manual. NON-DETERGENT
OR STRAIGHT MINERAL OILS MUST NEVER BE
USED.

A new engine may consume some oil during its first few
thousand miles (kilometers) of operation. This should be
considered as a normal part of the break-in and not
interpreted as an indication of difficulty.

SAFETY TIPS
Exhaust System

WARNING!

Exhaust gases contain carbon monoxide, an ex­tremely toxic gas that by itself is colorless and
odorless. Toavoid inhaling these gases, the following
precautions should be observed:

•

Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in
or out of the area.

•

It may be necessary to sit in a parked vehicle with the
engine running for more than a short period. If so,
adjust your climate control system to force outside air
into the vehicle. Set the blower at high speed and the
controls in any position except Off or Recirculation.

•

The best protection against carbon monoxide entry
into the vehicle body is a properly maintained engine
exhaust system.

Be aware of changes in the sound of the exhaust system,
exhaust fumes detected inside the vehicle, or damage to
the underside or rear of the vehicle. Have a competent
mechanic inspect the complete exhaust system and adja­cent body areas for broken, damaged, deteriorated or
mispositioned parts. Open seams or loose connections
could permit exhaust fumes to seep into the passenger

2

72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

compartment. In addition, inspect the exhaust system
each time the vehicle is raised for lubrication or oil
change. Replace or adjust as required.

Safety Checks You Should Make Inside The Vehicle

Heater Defroster Ducts

Inspect the heater defroster ducts for proper operation.
Check for proper airflow through all defroster ducts. If
there is any question regarding the operation of your
heater defroster ducts, have the system checked by an
authorized dealer

Seat Belts

Inspect the seat belt system periodically, checking for
cuts, frays and loose parts. Damaged parts must be
replaced immediately. Do not disassemble or modify the
system.

Seat belt assemblies must be replaced after an accident if
they have been damaged (bent retractor, torn webbing,
etc.) or if the front airbags have deployed. If there is any
question regarding seat belt or retractor condition, re­place the seat belt.

Airbag Warning Light

The airbag warning light should come on, and remain on,
for six to eight seconds as a bulb check when the ignition
switch is first turned ON. If the light is not lit during
starting, see your authorized dealer. If the light stays on,
flickers or comes on while driving, have the system
checked by an authorized dealer. If there is a problem
with the airbag warning light, the seat belt light will
flash.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73

Safety Checks You Should Make Outside The Vehicle

Tires

Examine tires for tread wear or uneven wear patterns.
Check for stones, nails, glass or other objects lodged in
the tread.

Inspect for tread cuts or sidewall cracks. Check wheel
nuts for tightness and tires for proper pressure.

Lights

Check the operation of all exterior lights. Check turn
signal and high beam indicator lights on the instrument
panel.

Door Latches

Check for positive closing, latching and locking.

Fluid Leaks

Check area under vehicle after overnight parking for fuel,
water, oil, or other fluid leaks. Also, if fuel fumes are
detected the cause should be located and corrected.

2

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CONTENTS

m Mirrors .............................. 80

▫ UConnectt System Features .............. 95

3

▫ Inside Day/Night Mirror ................ 80

▫ Outside Mirrors ....................... 80

▫ Outside Mirrors Folding Feature — If

Equipped ........................... 80

▫ Power Mirrors ........................ 81

m Hands-Free Communication (UConnectt)—If

Equipped ............................. 82

▫ Operation ........................... 84

▫ Phone Call Features .................... 92

▫ Advanced Phone Connectivity ........... 100

▫ Things You Should Know About Your

UConnectt System .................... 101

▫ General Information ................... 110

m Voice Recognition System (VR) —

▫ Voice Recognition System (VR) Operation . . . 110

▫ Commands ......................... 112

▫ Voice Training ....................... 115

If Equipped

.. 110

76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

m Seats ............................... 115

▫ Manual Seat Adjustment ............... 115

▫ Front Seats Manual Seat Recliners ......... 116

▫ Manual Lumbar Support Adjustment — If

Equipped .......................... 117

▫ Adjustable Head Restraints — Front Seating

Positions ........................... 118

▫ Six-Way Power Seat Adjuster — Driver’s Side

Only.............................. 119

▫ Extended Cab/Crew Cabt Rear Seat ....... 120

▫ Heated Seats — If Equipped ............. 120

m To Open And Close The Hood ............. 121

m Lights .............................. 123

▫ Interior Lights ....................... 123

▫ Battery Saver ........................ 124

▫ Headlight Delay ..................... 125

Headlights, Parking Lights And Panel Lights

▫

... 125

▫ Daytime Running Lights (Canada – Standard

And U.S. Fleet Vehicles) — If Equipped ..... 126

▫ Lights-On Reminder .................. 126

▫ Fog Lights — If Equipped .............. 126

▫ Cargo Light — If Equipped ............. 126

▫ Multifunction Lever ................... 127

m Windshield Wipers And Washers ........... 129

▫ Windshield Wipers ................... 129

▫ Windshield Washers................... 131

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77

m Tilt Steering Column ................... 131

m Electronic Speed Control — If Equipped ...... 132

▫ To Activate ......................... 133

▫ To Set At A Desired Speed .............. 133

▫ To Deactivate ....................... 133

▫ To Resume Speed .................... 133

▫ To Vary The Speed Setting .............. 134

▫ To Accelerate For Passing ............... 134

m Overhead Console ..................... 135

▫ Courtesy/Reading Lights ............... 136

m Compass/Temperature Mini-Trip Computer . . . 136

▫ US/M Button ....................... 137

▫ Reset Button ........................ 137

▫ Step Button ......................... 138

▫ Average Fuel Economy (AVG ECO) ........ 138

▫ Distance To Empty (DTE) ............... 138

▫ Trip Odometer (ODO) ................. 139

▫ Elapsed Time (ET) .................... 139

▫ C/T Button ......................... 139

▫ Global Reset ........................ 140

▫ Compass/Temperature Display ........... 140

▫ Automatic Compass Calibration .......... 140

▫ Manual Compass Calibration ............ 141

▫ To Put Into a Calibration Mode ........... 141

▫ Outside Temperature .................. 142

3

78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

m Garage Door Opener — If Equipped ........ 142

▫ Programming HomeLinkt .............. 144

▫ Gate Operator/Canadian Programming ..... 146

▫ Using HomeLinkt .................... 147

▫ Reprogramming A Single HomeLinkt

Button ............................ 147

▫ Security ........................... 148

▫ Troubleshooting Tips .................. 148

▫ General Information ................... 148

m Electrical Power Outlets ................. 149

▫ Electrical Outlet Use With Engine Off

(Battery Fed Configuration) ............. 150

m Cupholders .......................... 150

m Rear Storage — If Equipped .............. 151

▫ Rear Convenience Storage Crates ......... 151

▫ Plastic Grocery Bag Retainers ............ 153

m Floor Console — If Equipped ............. 154

▫ Floor Console Features ................. 154

m Rear Cargo Area Utility Rails ............. 155

m Rear Window Features .................. 156

▫ Rear Window Defroster — If Equipped ..... 156

▫ Sliding Rear Window — If Equipped ....... 157

m Slide-In Campers ...................... 157

▫ Camper Applications .................. 157

▫ General Information ................... 158

▫ Carbon Monoxide Warning-Vehicles

Equipped With A Cap Or Slide-In Campers . . 158

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79

m Tailgate ............................. 158

▫ Tailgate Removal ..................... 158

▫ Two–Position Tailgate/Upper Load

Platform ........................... 159

3

80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Inside Day/Night Mirror

A two-point pivot system allows for horizontal and
vertical adjustment of the mirror. The mirror should be
adjusted to center on the view through the rear window.

Headlight glare can be reduced by moving the small
control under the mirror to the night position (toward the
rear of the vehicle). The mirror should be adjusted while
set in the day position (toward the windshield).

Outside Mirrors

To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic with a slight
overlap of the view obtained on the inside mirror.

Outside Mirrors Folding Feature — If Equipped

Folding outside mirrors are hinged, and may be moved
either forward or rearward, to resist damage.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81

Power Mirrors

The power mirror controls are located on the driver’s
door trim panel.

Power Mirror Switch

To adjust a mirror, turn the control wand toward the left
or right mirror positions indicated. Tilt the control wand
in the direction you want the mirror to move. When you
are finished adjusting the mirror, turn the control to the
center position to prevent accidentally moving a mirror.

3

Mirror Directions

82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!

Vehicles and other objects seen in the right-side
convex mirror will look smaller and farther away
than they really are. Relying too much on your right
side mirror could cause you to collide with another
vehicle or other object. Use your inside mirror when
judging the size or distance of a vehicle seen in the
right-side mirror.

HANDS-FREE COMMUNICATION (UConnectT)—
IF EQUIPPED

NOTE: The sales code RER and REU radios contain an
integrated Hands-Free Communication (UConnectt)
system. Refer to your “Navigation User’s Manual” for
UConnectt system operating instructions for these
radios.

UConnectt is a voice-activated, hands-free, in-vehicle
communications system. UConnectt allows you to dial a
phone number with your cellular phone using simple
voice commands (e.g., 9Call” { “Mike” {”Work9 or 9Dial”
{ “248-555-12129). Your cellular phone’s audio is trans­mitted through your vehicle’s audio system; the system
will automatically mute your radio when using the
UConnectt system.

NOTE: The UConnectt system requires a cellular phone
equipped with the Bluetootht9Hands-Free Profile,9 Ver-
sion 0.96 or higher. See the UConnectt website for
supported phones.

NOTE: For UConnectt customer support, visit the
following websites:

•

www.chrysler.com/uconnect

•

www.dodge.com/uconnect

•

www.jeep.com/uconnect

•

or call 1–877–855–8400

UConnectt allows you to transfer calls between the
system and your cellular phone as you enter or exit your
vehicle and enables you to mute the system’s microphone
for private conversation.

The UConnectt system is driven through your
Bluetootht “Hands-Free profile” cellular phone.
UConnectt features Bluetootht technology - the global
standard that enables different electronic devices to con­nect to each other without wires or a docking station, so
UConnectt works no matter where you stow your cellu­lar phone (be it your purse, pocket, or briefcase), as long
as your phone is turned on and has been paired to the
vehicle’s UConnectt system. The UConnectt system
allows up to seven cellular phones to be linked to the
system. Only one linked (or paired) cellular phone can be
used with the system at a time. The system is available in
English, Spanish, or French languages.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83

Phone Button

The rearview mirror contains the microphone
for the system (depending on the type of
mirror and radio equipped), and either the

radio or the mirror has the two control buttons
(PHONE Button and VOICE RECOGNITION button)
that will enable you to access the system.

Voice Recognition Button

Actual button location may vary with radio.

The individual buttons are described in the

“Operation” section.

The UConnectt system can be used with any Hands-Free
Profile certified Bluetootht cellular phone. See the
UConnectt website for supported phones. If your cellu­lar phone supports a different profile (e.g., Headset
Profile) you may not be able to use any UConnectt
features. Refer to your cellular service provider or the
phone manufacturer for details.

3

84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The UConnectt system is fully integrated with the vehi­cle’s audio system. The volume of the UConnectt system
can be adjusted either from the radio volume control
knob or from the steering wheel radio control (right
switch), if so equipped.

The radio display will be used for visual prompts from
the UConnectt system such as 9CELL9 or caller ID on
certain radios.

Operation

Voice commands can be used to operate the UConnectt
system and to navigate through the UConnectt menu
structure. Voice commands are required after most
UConnectt system prompts. You will be prompted for a
specific command and then guided through the available
options.

•

Prior to giving a voice command, one must wait for
the beep, which follows the 9Ready9 prompt or another
prompt.

•

For certain operations, compound commands can be
used. For example, instead of saying 9Setup9 and then
9Phone Pairing,9 the following compound command
can be said: 9Setup Phone Pairing.9

•

For each feature explanation in this section, only the
combined form of the voice command is given. You
can also break the commands into parts and say each
part of the command when you are asked for it. For
example, you can use the combined form voice com­mand 9Phonebook New Entry,9 or you can break the
combined form command into two voice commands:
9Phonebook9 and 9New Entry.9 Please remember, the
UConnectt system works best when you talk in a
normal conversational tone, as if speaking to someone
sitting a few feet/meters away from you.

Voice Command Tree

Refer to “Voice Tree” in this section.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85

Help Command

If you need assistance at any prompt, or if you want to
know your options at any prompt, say 9Help9 following
the beep. The UConnectt system will play all the options
at any prompt if you ask for help.

To activate the UConnectt systemfrom idle, simply press
the PHONE button and follow the audible prompts for
directions. All UConnectt system sessions begin with a
press of the PHONE button on the radio control head.

Cancel Command

At any prompt, after the beep, you can say 9Cancel9 and
you will be returned to the main menu. However, in a
few instances the system will take you back to the
previous menu.

Pair (Link) UConnectt System to a Cellular Phone

To begin using your UConnectt system, you must pair
your compatible Bluetootht enabled cellular phone.

To complete the pairing process, you will need to refer­ence your cellular phone Owner’s Manual. The
UConnectt website may also provide detailed instruc­tions for pairing.

The following are general phone to UConnectt system
pairing instructions:

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
9Setup Phone Pairing.9

•

When prompted, after the beep, say 9Pair a Phone9 and
follow the audible prompts.

•

You will be asked to say a four-digit Personal Identi­fication Number (PIN), which you will later need to
enter into your cellular phone. You can enter any
four-digit PIN. You will not need to remember this PIN
after the initial pairing process.

3

86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•

For identification purposes, you will be prompted to
give the UConnectt system a name for your cellular
phone. Each cellular phone that is paired should be
given a unique phone name.

•

You will then be asked to give your cellular phone a
priority level between 1 and 7, with 1 being the highest
priority. You can pair up to seven cellular phones to
your UConnectt system. However, at any given time,
only one cellular phone can be in use, connected to
your UConnectt system. The priority allows the
UConnectt system to know which cellular phone to
use if multiple cellular phones are in the vehicle at the
same time. For example, if priority 3 and priority 5
phones are present in the vehicle, the UConnectt
system will use the priority 3 cellular phone when you
make a call. You can select to use a lower priority
cellular phone at any time (refer to 9Advanced Phone
Connectivity9 in this section).

Dial by Saying a Number

Press the PHONE button to begin.

•

•

After the 9Ready9 prompt and the following beep, say
9Dial.9

•

The system will prompt you to say the number you
want to call.

•

For example, you can say 9234-567-89019.

•

The UConnectt system will confirm the phone num­ber and then dial. The number will appear in the
display of certain radios.

Call by Saying a Name

Press the PHONE button to begin.

•

•

After the 9Ready9 prompt and the following beep, say
“Call.9

•

The system will prompt you to say the name of the
person you want to call.

•

After the 9Ready9 prompt and the following beep, say
the name of the person you want to call. For example,
you can say 9John Doe,9 where John Doe is a previ­ously stored name entry in the UConnectt phonebook
or downloaded phonebook. To learn how to store a
name in the phonebook, refer to 9Add Names to Your
UConnectt Phonebook,9 in the phonebook.

•

The UConnectt system will confirm the name and
then dial the corresponding phone number, which
may appear in the display of certain radios.

Add Names to Your UConnectt Phonebook
NOTE: Adding names to the UConnectt phonebook is

recommended when the vehicle is not in motion.

•

Press the PHONE button to begin.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87

•

After the 9Ready9 prompt and the following beep, say
9Phonebook New Entry.9

•

When prompted, say the name of the new entry.Use of
long names helps the voice recognition and it is
recommended. For example, say 9Robert Smith9 or
9Robert9 instead of 9Bob.9

•

When prompted, enter the number designation (e.g.,
9Home,99Work,99Mobile,9 or 9Pager9). This will allow
you to store multiple numbers for each phonebook
entry, if desired.

•

When prompted, recite the phone number for the
phonebook entry that you are adding.

After you are finished adding an entry into the phone­book, you will be given the opportunity to add more
phone numbers to the current entry or to return to the
main menu.

3

88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The UConnectt system will allow you to enter up to 32
names in the phonebook with each name having up to
four associated phone numbers and designations. Each
language has a separate 32-name phonebook accessible
only in that language. In addition, if equipped and
supported by your phone, UConnectt automatically
downloads mobile phone’s phonebook.

Phonebook Download – Automatic Phonebook
transfer from Mobile phone

If equipped and specifically supported by your phone,
UConnectt automatically downloads names (text names)
and number entries from the mobile phone’s phonebook.
Specific Bluetootht Phones with Phone Book Access
Profile may support this feature. See UConnectt website
for supported phones.

•

To call a name from downloaded (or UConnectt)
Phonebook, follow the procedure in “Call by Saying a
Name” section.

•

Automatic download and update, if supported, begins
as soon as the phone Bluetootht wireless connection is
made to the UConnectt. For example, after you start
the vehicle.

•

Maximum of 1000 entries per phone will be down­loaded and updated every time a phone is connected
to the UConnectt.

•

Depending on the maximum number of entries down­loaded, there may be a short delay before the latest
downloaded names can be used. Until then, if avail­able, previous downloaded phonebook is available for
use.

•

Only the phonebook of the currently connected mobile
phone is accessible.

•

Only the Mobile phone’s phonebook is downloaded.
SIM card phonebook is not part of the Mobile phone­book.

•

This downloaded phonebook cannot be edited or
deleted on the UConnectt. These can only be edited on
the mobile phone. The changes are transferred and
updated to UConnectt on the next phone connection.

Phonebook Download — Single Entry

If equipped and supported by your phone, UConnectt
allows the user to download entries from their phone via
Bluetootht. To use this feature, press the PHONE button
and say “Phonebook Download.” The system prompts,
“Ready to accept “V” card entry via Bluetootht…” The
system is now ready to accept phonebook entries from
your phone using the Bluetootht Object Exchange Profile
(OBEX). Please see your phone Owner’s Manual for
specific instructions on how to send these entries from
your phone.

NOTE:

•

The phone handset must support Bluetootht OBEX
transfers of phonebook entries to use this feature.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89

•

Some phones cannot send phonebook entries if they
are already connected to any system via Bluetootht,
and you may see a message on the phone display that
the Bluetootht link is busy. In this case, the user must
first disconnect or drop the Bluetootht connection to
the UConnectt system, and then send the address
book entry via Bluetootht. Please see your phone
Owner’s Manual for specific instructions on how to
drop the Bluetootht connection.

•

If the phonebook entry is longer than 24 characters, it
will only use the first 24 characters.

Edit UConnectt Phonebook Entries
NOTE:

•

Editing names in the phonebook is recommended
when the vehicle is not in motion.

•

Automatic downloaded phonebook entries cannot be
deleted or edited.

3

90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
9Phonebook Edit.9

•

You will then be asked for the name of the phonebook
entry that you wish to edit.

•

Next, choose the number designation (home, work,
mobile, or pager) that you wish to edit.

•

When prompted, recite the new phone number for the
phonebook entry that you are editing.

After you are finished editing an entry in the phonebook,
you will be given the opportunity to edit another entry in
the phonebook, call the number you just edited, or return
to the main menu.

9Phonebook Edit9 can be used to add another phone
number to a name entry that already exists in the
phonebook. For example, the entry John Doe may have a

mobile and a home number, but you can add ”John
Doe’s” work number later using the 9Phonebook Edit9
feature.

Delete UConnectt Phonebook Entry
NOTE: Editing phonebook entries is recommended

when the vehicle is not in motion.

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
9Phonebook Delete.9

•

After you enter the Phonebook Delete menu, you will
then be asked for the name of the entry that you wish
to delete. You can either say the name of a phonebook
entry that you wish to delete or you can say 9List
Names9 to hear a list of the entries in the phonebook
from which you choose. To select one of the entries

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91

from the list, press the “Voice Recognition” button
while the UConnectt system is playing the desired
entry and say 9Delete.9

•

After you enter the name, the UConnectt system will
ask you which designation you wish to delete: home,
work, mobile, pager, or all. Say the designation you
wish to delete.

•

Note that only the phonebook entry in the current
language is deleted.

•

Automatic downloaded phonebook entries cannot be
deleted or edited.

Delete/Erase “All” UConnectt Phonebook Entries

Press the PHONE button to begin.

•

•

After the 9Ready9 prompt and the following beep, say
9Phonebook Erase All.9

•

The UConnectt system will ask you to verify that you
wish to delete all the entries from the phonebook.

•

After confirmation, the phonebook entries will be
deleted.

•

Note that only the phonebook in the current language
is deleted.

•

Automatic downloaded phonebook entries cannot be
deleted or edited.

List All Names in the UConnectt Phonebook

Press the PHONE button to begin.

•

•

After the 9Ready9 prompt and the following beep, say
9Phonebook List Names.9

•

The UConnectt system will play the names of all the
phonebook entries, including the downloaded phone­book entries, if available.

3

92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•

To call one of the names in the list, press the “Voice
Recognition” button during the playing of the desired
name, and say 9Call.9

NOTE: The user can also exercise 9Edit9 or 9Delete9
operations at this point.

•

The UConnectt system will then prompt you as to the
number designation you wish to call.

•

The selected number will be dialed.

Phone Call Features

The following features can be accessed through the
UConnectt system if the feature(s) are available on your
cellular service plan. For example, if your cellular service
plan provides three-way calling, this feature can be
accessed through the UConnectt system. Check with
your cellular service provider for the features that you
have.

Answer or Reject an Incoming Call - No Call
Currently in Progress

When you receive a call on your cellular phone, the
UConnectt system will interrupt the vehicle audio sys­tem, if on, and will ask if you would like to answer the
call. Press the PHONE button to accept the call. To reject
the call, press and hold the PHONE button until you hear
a single beep, indicating that the incoming call was
rejected.

Answer or Reject an Incoming Call - Call
Currently in Progress

If a call is currently in progress and you have another
incoming call, you will hear the same network tones for
call waiting that you normally hear when using your cell
phone. Press the PHONE button to place the current call
on hold and answer the incoming call.

NOTE: The UConnectt system compatible phones in
the market today do not support rejecting an incoming

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93

call when another call is in progress. Therefore, the user
can only answer an incoming call or ignore it.

Making a Second Call While Current Call in
Progress

To make a second call while you are currently on a call,
press the “Voice Recognition” button and say 9Dial9 or
9Call9 followedby the phone number or phonebook entry
you wish to call. The first call will be on hold while the
second call is in progress. To go back to the first call, refer
to 9Toggling Between Calls9 in this section. To combine
two calls, refer to 9Conference Call9 in this section.

Place/Retrieve a Call From Hold

To put a call on hold, press the PHONE button until you
hear a single beep. This indicates that the call is on hold.
To bring the call back from hold, press and hold the
PHONE button until you hear a single beep.

Toggling Between Calls

If two calls are in progress (one active and one on hold),
press the PHONE button until you hear a single beep,
indicating that the active and hold status of the two calls
have switched. Only one call can be placed on hold at one
time.

Conference Call

When two calls are in progress (one active and one on
hold), press and hold the PHONE button until you hear
a double beep indicating that the two calls have been
joined into one conference call.

Three-Way Calling

To initiate three-way calling, press the “Voice Recogni­tion” button while a call is in progress, and make a
second phone call, as described under 9Making a Second
Call While Current Call in Progress.9 After the second call

3

94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

has established, press and hold the PHONE button until
you hear a double beep, indicating that the two calls have
been joined into one conference call.

Call Termination

To end a call in progress, momentarily press the PHONE
button. Only the active call(s) will be terminated and if
there is a call on hold, it will become the new active call.
If the active call is terminated by the far end, a call on
hold may not become active automatically. This is cell
phone-dependent. To bring the call back from hold, press
and hold the PHONE button until you hear a single beep.

Redial

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
9Redial.9

•

The UConnectt system will call the last number that
was dialed from your cellular phone.

NOTE: This may not be the last number dialed from the
UConnectt system.

Call Continuation

Call continuation is the progressionof a phone call on the
UConnectt system after the vehicle ignition key has been
switched to OFF. Call continuation functionality avail­able on the vehicle can be any one of three types:

•

After the ignition key is switched to OFF, a call can
continue on the UConnectt system either until the call
ends, or until the vehicle battery condition dictates
cessation of the call on the UConnectt system and
transfer of the call to the mobile phone.

•

After the ignition key is switched to OFF, a call can
continue on the UConnectt system for a certain dura­tion, after which the call is automatically transferred
from the UConnectt system to the mobile phone.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95

•

An active call is automatically transferred to the
mobile phone after the ignition key is switched to OFF.

UConnectT System Features

Language Selection

To change the language that the UConnectt system is
using:

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
the name of the language you wish to switch to
English, Espanol, or Francais.

•

Continue to follow the system prompts to complete
language selection.

After selecting one of the languages, all prompts and
voice commands will be in that language.

NOTE: After every UConnectt language change opera-
tion, only the language-specific 32-name phonebook is
usable. The paired phone name is not language-specific
and usable across all languages.

Emergency Assistance

If you are in an emergency and the mobile phone is
reachable:

•

Pick up the phone and manually dial the emergency
number for your area.

If the phone is not reachable and the UConnectt system
is operational, you may reach the emergency number as
follows:

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
9Emergency9 and the UConnectt system will instruct

3

96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

the paired cellular phone to call the emergency num­ber. This feature is supported in the U.S., Canada, and
Mexico.

NOTE:

•

The emergency number dialed is based on the country
where the vehicle is purchased (911 for the U.S. and
Canada and 060 for Mexico). The number dialed may
not be applicable with the available cellular service
and area.

•

If supported, this number may be programmable on
some systems. To do this, press ‘Phone’ button and say
‘Setup’, followed by ‘Emergency’.

•

The UConnectt system does slightly lower your
chances of successfully making a phone call as to that
for the cell phone directly.

WARNING!

Your phone must be turned on and paired to the
UConnectt systemto allow use of this vehicle feature
in emergency situations, when the cell phone has
network coverage and stays paired to the UConnectt
system.

Towing Assistance

If you need towing assistance:

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
9Towing Assistance.9

UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97

NOTE:

•

The Towing Assistance number dialed is based on the
country where the vehicle is purchased (1-800-528­2069 for the U.S., 1-877-213-4525 for Canada, 55-14­3454 for Mexico City and 1-800-712-3040 for outside
Mexico City in Mexico).

•

If supported, this number may be programmable on
some systems. To do this, press ‘Phone’ button and say
‘Setup’, followed by ‘Towing Assistance’.

Paging

To learn how to page, refer to 9Working with Automated
Systems.9 Paging works properly except for pagers of
certain companies, which time out a little too soon to
work properly with the UConnectt system.

Voice Mail Calling

To learn how to access your voice mail, refer to 9Working
with Automated Systems.9

Working with Automated Systems

This method is used in instances where one generally has
to press numbers on the cellular phone keypad while
navigating through an automated telephone system.

You can use your UConnectt system to access a voice
mail system or an automated service, such as a paging
service or automated customer service line. Some ser­vices require immediate response selection. In some
instances, that may be too quick for use of the UConnectt
system.

When calling a number with your UConnectt system
that normally requires you to enter in a touch-tone
sequence on your cellular phone keypad, you can press
the “Voice Recognition” button and say the sequence you
wish to enter, followed by the word 9Send.9 For example,
if required to enter your PIN followed with a pound, (3 7
4 6 #), you can press the “Voice Recognition” button and
say, 93746#Send.9 Saying a number, or sequence of

3

98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

numbers, followed by 9Send,9 is also to be used for
navigating through an automated customer service cen­ter menu structure, and to leave a number on a pager.

You can also send stored UConnectt phonebook entries
as tones for fast and easy access to voice mail and pager
entries. To use this feature, dial the number you wish to
call and then press the “Voice Recognition” button and
say, “Send.” The system will prompt you to enter the
name or number and say the name of the phonebook
entry you wish to send. The UConnectt system will then
send the corresponding phone number associated with
the phonebook entry, as tones over the phone.

NOTE:

•

You may not hear all of the tones due to cellular phone
network configurations; this is normal.

•

Some paging and voice mail systems have system time
out settings that are too short and may not allow the
use of this feature.

Barge In - Overriding Prompts

The “Voice Recognition” button can be used when you
wish to skip part of a prompt and issue your voice
recognition command immediately. For example, if a
prompt is asking 9Would you like to pair a phone, clear
a{,9 you could press the “Voice Recognition” button and
say, 9Pair a Phone9 to select that option without having to
listen to the rest of the voice prompt.

Turning Confirmation Prompts On/Off

Turning confirmation prompts off will stop the system
from confirming your choices (e.g., the UConnectt sys­tem will not repeat a phone number before you dial it).

•

Press the PHONE button to begin.

•

After the 9Ready9 prompt and the following beep, say
9Setup Confirmations.9 The UConnectt system will

play the current confirmation prompt status and you
will be given the choice to change it.
