Dodge 1500, 2500, 3500, 2013 RAM 1500, 2013 RAM 2500 User Manual

...

If you are the rst registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/Media Center Manuals or Warranty Booklet by calling 1-866-726-4636 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer.

Driving anD alcohol

Drunken driving is one of the most frequent causes of collisions. Your driving ability can be seriously impaired with blood alcohol levels far below the legal minimum. If you are drinking, don’t drive. Ride with a designated non-drinking driver, call a cab, a friend, or use public transportation.

Warning

Driving after drinking can lead to a collision. Your perceptions are less sharp, your reﬂexes are slower, and your judgment is impaired when you have been drinking. Never drink and then drive.

RAMTRUCKS.COM

This User Guide is intended to familiarize you with the important features of your vehicle. The DVD enclosed contains your Owner’s Manual, Navigation/

Media Center Manuals, Warranty Booklets, Tire Warranty and Roadside Assistance (new vehicles purchased in the U.S.) or Roadside Assistance (new vehicles purchased in Canada) in electronic format. We hope you

IMPORTANT

This guide has been prepared to help you get quickly acquainted with your new RAM and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual.

For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Media Center Manuals, Multimedia User Manual and other Warning Labels in your vehicle.

Not all features shown in this guide may apply to your vehicle. For additional information on accessories to help personalize your vehicle, visit www.mopar.com or your local RAM dealer.

The driver’s primary responsibility is the safe operation of the vehicle. Driving while distracted can result in loss of vehicle control, resulting in a collision and personal injury. Chrysler Group LLC strongly recommends that the driver use extreme caution when using any device or feature that may take their attention off the road. Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous and could lead to a serious collision. Texting while driving is also dangerous and should never be done while the vehicle is moving. If you ﬁnd yourself unable to devote your full attention to vehicle operation, pull off the road to a safe location and stop your vehicle. Some States or Provinces prohibit the use of cellular telephones or texting while driving. It is always the driver’s responsibility to comply with all local laws.

TABLE OF CONTENTS

INTRODUCTION/WELCOME

WELCOME FROM CHRYSLER

GROUP LLC ..................3

CONTROLS AT A GLANCE

DRIVER COCKPIT ..............6

INSTRUMENT CLUSTER ..........8

GETTING STARTED

KEYFOB ...................10

KEYLESS ENTER-N-GO™ .........11

REMOTE START ..............12

THEFT ALARM ................13

SEATBELT ..................13

SUPPLEMENTAL RESTRAINT

SYSTEM (SRS) — AIR BAGS .......14

CHILD RESTRAINTS ............15

FRONT SEATS ................20

HEATED/VENTILATED SEATS ....... 22

HEATED STEERING WHEEL ........ 23

TILT STEERING COLUMN ......... 24

ADJUSTABLE PEDALS ...........24

OPERATING YOUR VEHICLE

ENGINE BREAK-IN

RECOMMENDATIONS ...........25

TURN SIGNALS/WIPER/WASHER/HIGH

BEAMS LEVER ................ 26

HEADLIGHT SWITCH ............27

SPEED CONTROL ..............28

EIGHT–SPEED AUTOMATIC

TRANSMISSION — IF EQUIPPED .... 29

ELECTRONIC RANGE SELECT (ERS)

OPERATION .................30

ELECTRONIC RANGE SELECT (ERS) OPERATION – 8 SPEED

TRANSMISSION ...............31

MANUAL CLIMATE CONTROLS .....31

AUTOMATIC TEMPERATURE

CONTROL (ATC) ...............32

PARKSENSE PARKVIEW

CAMERA ...................33

TIRE PRESSURE MONITOR SYSTEM

(TPMS) – 2500 MODELS ONLY .....34

POWER SLIDING REAR WINDOW .... 35

POWER SUNROOF .............35

WIND BUFFETING .............37

REAR PARK ASSIST . . . 33

REAR BACK-UP

ELECTRONICS

YOUR VEHICLE'S SOUND SYSTEM . . . 38

IDENTIFYING YOUR RADIO ........40

Uconnect™ ACCESS (Available on Uconnect™

8.4A and Uconnect™ 8.4AN)

Uconnect™ 3.0 ...............46

Uconnect™ 5.0 ...............48

Uconnect™ 8.4A ..............51

Uconnect™ 8.4AN .............65

STEERING WHEEL AUDIO CONTROLS . . . 81 ELECTRONIC VEHICLE INFORMATION

CENTER (EVIC) ............... 81

PROGRAMMABLE FEATURES .......82

UNIVERSAL GARAGE DOOR OPENER (HomeLink

POWER INVERTER .............86

POWER OUTLETS .............87

) .................84

........41

OFF-ROAD CAPABILITIES

FOUR WHEEL DRIVE OPERATION ....88

UTILITY

EASY-OFF TAILGATE ............91

PICKUP BOX ................. 92

RAMBOX

TOWING & PAYLOAD ............98

TOW/HAUL MODE .............99

INTEGRATED TRAILER BRAKE

MODULE ..................100

RECREATIONAL TOWING (BEHIND

MOTORHOME, ETC.) ...........101

..................93

WHAT TO DO IN EMERGENCIES

ROADSIDE ASSISTANCE ......... 103

INSTRUMENT CLUSTER WARNING

LIGHTS ...................103

IF YOUR ENGINE OVERHEATS .....107

JACKING AND TIRE CHANGING .... 108

JUMP-STARTING .............121

EMERGENCY TOW HOOKS .......123

SHIFT LEVER OVERRIDE ........124

TOWING A DISABLED VEHICLE ....127

FREEING A STUCK VEHICLE ......128

EVENT DATA RECORDER (EDR) ....129

MAINTAINING YOUR VEHICLE

OPENING THE HOOD ..........130

ENGINE COMPARTMENT ........131

FLUIDS AND CAPACITIES ........134

MAINTENANCE SCHEDULE ......136

MAINTENANCE RECORD ........ 140

FUSES ....................141

TIRE PRESSURES .............144

WHEEL AND WHEEL TRIM CARE . . . 145

EXTERIOR BULBS ............ 145

TABLE OF CONTENTS

CUSTOMER ASSISTANCE

CHRYSLER GROUP LLC CUSTOMER

CENTER .................. 146

CHRYSLER CANADA INC. CUSTOMER

CENTER .................. 146

ASSISTANCE FOR THE HEARING

IMPAIRED .................146

PUBLICATIONS ORDERING .......146

REPORTING SAFETY DEFECTS IN THE 50 UNITED STATES AND

WASHINGTON, D.C. ...........147

MOPAR ACCESSORIES

AUTHENTIC ACCESSORIES BY MOPAR

INDEX

................148

....................149

FAQ

FREQUENTLY ASKED QUESTIONS . . . 152

INTRODUCTION/WELCOME

WELCOME FROM CHRYSLER GROUP LLC

Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles.

Your new Chrysler Group LLC vehicle has characteristics to enhance the driver's control under some driving conditions. These are to assist the driver and are never a substitute for attentive driving. They can never take the driver's place. Always drive carefully.

Your new vehicle has many features for the comfort and convenience of you and your passengers. Some of these should not be used when driving because they take your eyes from the road or your attention from driving. Never text while driving or take your eyes more than momentarily off the road.

This guide illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This guide may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this guide that are not available on this vehicle. Chrysler Group LLC reserves the right to make changes in design and specifications and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.

This User Guide has been prepared to help you quickly become acquainted with the important features of your vehicle. It contains most things you will need to operate and maintain the vehicle, including emergency information.

The DVD includes a computer application containing detailed owner's information which can be viewed on a personal computer or MAC computer. The multimedia DVD also includes videos which can be played on any standard DVD player (including the Uconnect on the back of the DVD sleeve.

For complete owner information, refer to your Owner's Manual on the DVD in the owner’s kit provided at the time of new vehicle purchase. For your convenience, the information

contained on the DVD may also be printed and saved for future reference.

Chrysler Group LLC is committed to protecting our environment and natural resources. By converting from paper to electronic delivery for the majority of the user information for your vehicle, together we greatly reduce the demand for tree-based products and lessen the stress on our environment.

Vehicles Sold In Canada

With respect to any vehicles sold in Canada, the name Chrysler Group LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefore.

Touch-Screen Radios). Additional DVD operational information is located

INTRODUCTION/WELCOME

WARNING!

• Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.

• Always make sure that objects cannot fall into the driver foot well while the vehicle is moving. Objects can become trapped under the brake pedal and accelerator pedal causing a loss of vehicle control.

• Failure to properly follow floor mat installation or mounting can cause interference with the brake pedal and accelerator pedal operation causing loss of control of the vehicle.

• Never use the ‘PARK’ position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.

• Refer to your Owner's Manual on the DVD for further details.

INTRODUCTION/WELCOME

USE OF AFTERMARKET PRODUCTS (ELECTRONICS)

The use of aftermarket devices including cell phones, MP3 players, GPS systems, or chargers may affect the performance of on-board wireless features including Keyless Enter-N-Go™ and Remote Start range. If you are experiencing difficulties with any of your wireless features, try disconnecting your aftermarket devices to see if the situation improves. If your symptoms persist, please see an authorized dealer.

CHRYSLER, DODGE, JEEP, RAM TRUCK, SRT, ATF+4, MOPAR and Uconnect are registered trademarks of Chrysler Group LLC.

CONTROLS AT A GLANCE

DRIVER COCKPIT

CONTROLS AT A GLANCE

pg. 12

L. Shifter

M. Keyless Engine Starting/Stopping

• Diesel Exhaust Brake

K. Switch Panel

N. Electronic Speed Control pg. 28

• Tow/Haul pg. 99

• Electronic Stability Control pg. 103

at base of instrument panel) pg. 130

O. Hood Release (below steering wheel

Rear Park Assist pg. 33

• Air Suspension System

• ParkSense

P. Parking Brake Release

Q. Power Mirrors

for 2500 system pg. 34

• Tire Pressure Monitoring System

R. Power Windows

S. Power Door Locks

• Front Heated Seats pg. 22

• Front Ventilated Seats pg. 22

• Heated Steering Wheel pg. 23

pg. 100

• Integrated Trailer Brake Module

• Engine Stop Start

Beams Lever pg. 26

A. Headlight Switch pg. 27

B. Turn Signal/Wiper/Washer/High

(EVIC) Controls pg. 81

C. Electronic Vehicle Information Center

(EVIC) Display pg. 9

D. Electronic Vehicle Information Center

E. Instrument Cluster pg. 7

F. Four Wheel Drive Operation pg. 88

G. Identify Your Audio System pg. 40

H. Audio System Hard Controls pg. 38

I. Power Inverter Outlet pg. 86

J. Manual Climate Controls pg. 31

CONTROLS AT A GLANCE

INSTRUMENT CLUSTER

Warning Lights

- Low Fuel Warning Light

- Charging System Light**

- Oil Pressure Warning Light**

- Anti-Lock Brake (ABS) Light**

- Air Bag Warning Light**

- Electronic Throttle Control (ETC) Light

- Engine Temperature Warning Light

(See page 103 or more information.)

BRAKE

- Transmission Temperature Warning Light

- Seat Belt Reminder Light

- Brake Warning Light**

- Malfunction Indicator Light (MIL)**

- SERV (Service) 4WD Indicator Light

CONTROLS AT A GLANCE

Indicators

- Turn Signal Indicators

- High Beam Indicator

- Front Fog Light Indicator

- Vehicle Security Indicator*

- TOW/HAUL Indicator

- Four-Wheel Drive LOW Mode Indicator

- Four-Wheel Drive and 4LOCK Mode Indicator

EVIC Messages

NOTE:

Refer to Electronic Vehicle Information Center (EVIC) in this guide or your owners manual for additional information.

- 4WD Auto Indicator

- Electronic Stability Control (ESC) Off Indicator

- Cargo Lamp On Indicator

- Door Ajar Indicator

- Electronic Speed Control Set Indicator

- Loose Gas Cap Indicator

GETTING STARTED

KEY FOB

Locking And Unlocking The Doors

• Press the LOCK button once to lock all the doors. Press the UNLOCK button once to unlock the driver’s door only and twice within five seconds to unlock all the doors.

• All doors can be programmed to unlock on the first press of the UNLOCK button. Refer to Programmable Features in this guide.

Panic Alarm

• Press the PANIC button once to turn the panic alarm on.

• Wait approximately three seconds and press the button a second time to turn the panic alarm off.

Emergency Key

• Should the battery in the vehicle or the Key Fob transmitter go dead, there is an emergency key located in the Key Fob that can be used for locking and unlocking the doors. To remove the emergency key, slide the button at the top of the Key Fob sideways with your thumb and then pull the key out with your other hand.

WARNING!

• Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be severely injured or killed. Children should be warned not to touch the parking brake, brake pedal, or the shift lever. Do not leave the Key Fob in or near the vehicle, or in a location accessible to children, and do not leave a vehicle equipped with Keyless Enter-N-Go™ in the ACC or ON/RUN mode. A child could start the vehicle, operate power windows, other controls, or move the vehicle.

• Do not leave children or animals inside parked vehicles in hot weather. Interior heat build-up may cause them to be severely injured or killed.

GETTING STARTED

KEYLESS ENTER-N-GO™

• The Keyless Enter-N-Go™ system is an enhancement to the vehicle's Key Fob. This feature allows you to lock and unlock the vehicle's door(s) without having to press the Key Fob lock or unlock buttons, as well as starting and stopping the vehicle with the press of a button.

To Unlock From The Driver or Passenger Side:

• With a valid Keyless Enter-N-Go™ Key Fob located outside the vehicle and within 5 ft (1.5m) of the driver or passenger side door handle, grab either front door handle to unlock the door automatically.

To Lock The Vehicle’s Doors

• With a valid Keyless Enter-N-Go™ Key Fob transmitters within 5 ft (1.5 m) of the driver or passenger front door handles, press the door handle LOCK button to lock all doors.

• DO NOT grab the door handle, when pressing the door handle lock button. This could unlock the door(s).

NOTE:

• After pressing the door handle LOCK button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking.

• The Passive Entry system will not operate if the RKE transmitter battery is dead.

The vehicle doors can also be locked by using the RKE transmitter lock button or the lock button located on the vehicles interior door panel.

GETTING STARTED

Engine Starting/Stopping

Starting

• With a valid Keyless Enter-N-Go™ Key Fob inside the vehicle.

• Place the shift lever in PARK or NEUTRAL.

• While pressing the brake pedal, press the ENGINE START/STOP button once. If the engine fails to start, the starter will disengage automatically after 10 seconds.

• To stop the cranking of the engine prior to the engine starting, press the button again.

NOTE:

In case the ignition switch does not change with the push of a button, the RKE transmitter (Key Fob) may have a low or dead battery. In this situation a back up method can be used to operate the ignition switch. Put the nose side of the Key Fob against the ENGINE START/STOP button and push to operate the ignition switch.

Stopping

• Place the shift lever in PARK.

• Press the ENGINE START/STOP button once. The ignition switch will return to the OFF position.

•

If the shift lever is not in PARK, the ENGINE START/STOP button must be held for two seconds and vehicle speed must be below 5 mph (8 km/h) before the engine will shut off.

REMOTE START

• Press the REMOTE START button Pressing the REMOTE START

• To drive the vehicle, press the UNLOCK button, insert the Key Fob in the ignition and turn to the ON/RUN position.

• With remote start, the engine will only run for 15 minutes (timeout) unless the ignition Key Fob is placed in the ON/RUN position.

• The vehicle must be started with the Key Fob after two consecutive timeouts.

on the Key Fob twice within five seconds.

button a third time shuts the engine off.

GETTING STARTED

WARNING!

• Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause you or others to be severely injured or killed when inhaled.

• Keep Key Fob transmitters away from children. Operation of the Remote Start System, windows, door locks or other controls could cause you and others to be severely injured or killed.

THEFT ALARM

To Arm:

• Press the Key Fob LOCK button or the power door lock switch while the door is open.

To Disarm:

• Press the Key Fob UNLOCK button or turn the ignition to the ON/RUN position.

SEAT BELT

• Be sure everyone in your vehicle is in a seat and using a seat belt properly.

• Position the lap belt across your thighs, below your abdomen. To remove slack in the lap portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.

• Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the belt.

• A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together.

• A belt that is too loose will not protect you properly. In a sudden stop you could move too far forward, increasing the possibility of injury. Wear your seat belt snugly.

• A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after a collision if they have been damaged (bent retractor, torn webbing, etc.).

• The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision.

• A deployed pretensioner or a deployed air bag must be replaced immediately.

GETTING STARTED

WARNING!

In a collision, you and your passengers can suffer much greater injuries if you are not buckled up properly. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly.

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS

• This vehicle has Advanced Front Air Bags for both the driver and right front passenger as a supplement to the seat belt restraint system. The Advanced Front Air Bags will not deploy in every type of collision.

• Advanced Front Air Bags are designed to provide additional protection by supplementing the seat belts in certain frontal collisions depending on several factors, including the severity and type of collision. Advanced Front Air Bags are not expected to reduce the risk of injury in rear, side, or rollover collisions.

• This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains to protect the driver, front and rear passengers sitting next to a window.

• This vehicle is equipped with Supplemental Seat-Mounted Side Air Bags to provide enhanced protection to help protect an occupant during a side impact.

If the Air Bag Warning Light is not on during starting, stays on, or turns on while

• driving, have the vehicle serviced by an authorized service center immediately.

• Refer to the Owner's Manual on the DVD for further details regarding the Supplemental Restraint System (SRS).

GETTING STARTED

WARNING!

• Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly. In some collisions, the air bags won't deploy at all. Always wear your seat belts even though you have air bags.

• Being too close to the steering wheel or instrument panel during Advanced Front Air Bag deployment could cause serious injury, including death. Air bags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instrument panel.

• Supplemental Side Air Bag Inflatable Curtains and Supplemental SeatMounted Side Air Bags need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat.

• Being too close to the Supplemental Side Air Bag Inflatable Curtain and/or Seat-Mounted Side Air Bag during deployment could cause you to be severely injured or killed.

• Do not drive your vehicle after the air bags have deployed. If you are involved in another collision, the air bags will not be in place to protect you.

• After any collision, the vehicle should be taken to an authorized dealer immediately.

CHILD RESTRAINTS

• Children 12 years and under should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front.

• Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it.

Installing The LATCH - Compatible Child Restraint System

• Your vehicle’s second row passenger seats are equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tether for CHildren. LATCH child restraint anchorage systems are installed in the rear seat outboard positions.

• LATCH equipped seating positions have both lower anchor bars, located at the back of the seat cushion, and tether strap anchorages, located behind the seat back.

GETTING STARTED

Installing The Lower Attachments:

• The vehicle lower anchorages are round bars located at the rear of the seat cushion where it meets the seatback. The rear seat lower anchors can be readily identified by the symbol just visible when you lean into the rear seat to install the child restraint.

• Loosen the child seat adjusters on the lower straps and on the tether strap so that you can attach the hooks or connectors to the vehicle anchors more easily.

• Attach the lower hooks or connectors over the top of the seatcover material.

• Then tighten the straps as you push the child restraint rearward and downward into the seat.

located on the seatback directly above the anchorages and are

Tether Anchorage Points At The Right And Center Front Seat (Regular Cab - All Seats):

• Place the child restraint on the seat and adjust the tether strap so that it will reach over the seat back under the head restraint to the tether anchor directly behind the seat.

• Lift the cover (if equipped), and attach the hook to the square opening in the sheet metal.

• Install the child restraint and remove the slack in the tether strap according to the manufacturer's instructions.

Child Restraint Installation Sequence (Mega Cab®- Rear Seats):

•

Place a child restraint on each outboard rear seat and adjust the tether strap so that it will reach under the head restraint to the tether anchor directly behind the seat.

• Lift the cover, and attach the hook to the square opening in the sheet metal.

• Install the child restraint and remove the slack in the tether strap according to the manufacturer's instructions.

GETTING STARTED

Child Restraints Installation Sequence (Quad Cab®/Crew Cab - Rear Seats)

The top tether anchorages in this vehicle are tether strap loops located between the rear glass and the back of the rear seat. There is a tether strap loop located behind each seating position. Follow the steps below to attach the tether strap of the child restraint.

Right or Left Outboard Seats:

1. Raise the head restraint and reach between the rear seat and rear glass to access the tether strap loop.

Head Restraint In Raised Position Tether Strap Loop With Center Head

Restraint In Raised Position

2. Place a child restraint on the seat and adjust the tether strap so that it will reach over the seat back, under the head restraint, through the tether strap loop behind the seat and over to the tether strap loop behind the center seat.

3. Pass the tether strap hook under the head restraint behind the child seat, though the tether strap loop behind the seat and over to the center tether strap loop.

Tether Strap Through Outboard Tether

Strap Loop

GETTING STARTED

4. Attach the hook to the center tether strap loop (see diagram). Tighten the tether strap according to the child seat manufacturer’s instructions.

NOTE:

If there are child seats in both of the outboard (left and right) seating positions, the tether strap hooks of both child seats should be connected to the center tether strap loop. This is the correct way to tether two outboard child seats.

Tether Strap Through Outboard Tether Strap

Loop And Attached To Center Tether Strap Loop

Center Seat:

1. Raise the head restraint and reach between the rear seat and rear glass to access the tether strap loop.

3. Pass the tether strap hook under the head restraint behind the child seat, though the tether strap loop behind the seat and over to the right or left outboard tether strap loop.

Tether Strap Loop With Head Restraint In

Raised Position

Tether Strap Through Center Tether Strap

Loop

GETTING STARTED

4. Attach the hook to the outboard tether strap loop (see diagram). Tighten the tether strap according to the child seat manufacturer’s instructions.

Tether Strap Through Center Tether Strap

Loop And Attached To Outboard Tether Strap

Loop

Installing Three Child Restraints:

1. Place a child restraint on each outboard rear seat. Route the tether straps following the directions for right and left seating positions, above.

2. Attach both hooks to the center tether strap loop, but do not tighten the straps yet.

3. Place a child restraint on the center rear seat. Route the tether strap following the directions for the center seating position, above.

4. Attach the hook to the outboard tether strap loop.

5. Tighten the tether straps according to the child seat manufacturer’s instructions, tightening the right and left tether straps before the center tether strap.

Installing The Child Restraint Using The Vehicle Seat Belts

• To install a child restraint, first, pull enough of the seat belt webbing from the

retractor to route it through the belt path of the child restraint and slide the latch plate into the buckle.

Left Outboard And Center Seating Position

Shown

• Next, extract all the seat belt webbing out of the retractor and then allow the belt

to retract into the retractor. Finally, pull on any excess webbing to tighten the lap portion around the child restraint. Any seat belt system will loosen with time, so check the belt occasionally, and pull it tight if necessary.

GETTING STARTED

• Route the tether strap to provide the most direct path for the strap between the anchor and the child seat, preferably between the head restraint posts underneath the head restraint.

Attach the tether strap hook of the child restraint to the tether anchor and remove slack

• in the tether strap according to the child restraint manufacturer’s instructions.

NOTE:

• Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap.

WARNING!

• In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are. The child and others could be severely injured or killed. Any child riding in your vehicle should be in a proper restraint for the child's size.

• Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be severely injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint.

• An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.

• Rearward-facing child seats must never be used in the front seat of a vehicle with a front passenger air bag. An air bag deployment could cause severe injury or death to infants in this position.

FRONT SEATS

Power Seats

• The seat switch controls forward/ backward and up/down.

• The recline switch controls the angle of the seatback. Push switch forward or rearward and the seatback will move in either direction.

Power Lumbar

• The lumbar controls are located on the outboard side of the seat cushion. The lumbar support can be increased by pressing the front of the switch and decreased by pressing the back of the switch.

GETTING STARTED

Memory Seat

• The memory seat feature allows you to save the driver's seat position (excluding lumbar position), driver's outside mirror position, adjustable brake and accelerator pedals, Automatic Temperature Control (ATC) temperature setting and radio station preset settings. The driver's memory buttons are located on the outboard side of the driver's seat cushion.

• Adjust all memory profile settings, press the SET button, then press 1 or 2 within five seconds.

• To program a Key Fob to the memory position, place the ignition switch in the LOCK position and remove the Key Fob, press and release the LOCK button on the Key Fob to be programmed within 5 seconds of pressing button 1 or 2.

• Press 1 or 2 to recall the saved positions, or press UNLOCK on the programmed Key Fob.

• Refer to the Owner's Manual on the DVD for further details.

Manual Seats

Forward/Rearward

• Lift up on the adjusting bar located at the front of the seat near the floor and release at the desired position. Then, using body pressure, move forward and backward on the seat to be sure that the seat adjusters have latched.

Recliner

• Lift the recliner lever located on the outboard side of the seat, lean back and release at the desired position.

CAUTION!

Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.

GETTING STARTED

WARNING!

• Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted, and you could be severely injured or killed. Only adjust a seat while the vehicle is parked.

• Actuating the recliner handle will allow the seatback to swing (dump) forward on manual recliner seats. Do not stand or lean in front of the seat while actuating the handle. The seatback may swing forward and hit you, causing injury. This dump feature allows access to the storage bin behind the seat. To avoid injury, place your hand on the seatback and actuate the handle, then position the seatback in the desired position.

• Do not ride with the seatback reclined so that the seat belt is no longer resting against your chest. In a collision, you could slide under the seat belt and be severely injured or killed. Use the recliner only when the vehicle is parked.

HEATED/VENTILATED SEATS

Front Heated Seats

• The controls for front heated seats are located on the center instrument panel below the climate controls.

• Press the switch once to select Highlevel heating. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off.

• If the High-level setting is selected, the system will automatically switch to Low-level after approximately 60 minutes. The Low-level setting will turn Off automatically after approximately 45 minutes.

Front Ventilated Seats

• Located in the seat cushion and seatback are small fans that draw the air from the passenger compartment and blow air through fine perforations in the seat cover to help keep the driver and front passenger cooler in higher ambient temperatures.

• The ventilated seat switches are located in the switch bank in the center stack of the instrument panel, just below the climate controls. The fans operate at two speeds, HIGH and LOW. Press the switch once to select High speed. Press the switch a second time to select Low speed. Press the switch a third time to turn the fans Off.

REAR HEATED SEATS

• Second row heated seat switches are located on the rear of the center console.

• Press the switch once to select Highlevel heating. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off.

WARNING!

GETTING STARTED

• Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical conditions must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.

• Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.

HEATED STEERING WHEEL

• The steering wheel contains a heating element that heats the steering wheel to one temperature setting.

• The heated steering wheel switch is located on the center instrument panel below the climate controls.

Press the switch once to turn the heating

• element On. Press the switch a second time to turn the heating element Off.

•

Once the heated steering wheel has been turned on, it will operate for approximately 58 to 70 minutes before automatically shutting off. The heated steering wheel can shut off early or may not turn on when the steering wheel is already warm.

GETTING STARTED

TILT STEERING COLUMN

• The tilt lever is located on the steering column below the turn signal lever.

• Pull forward on the lever and move the steering wheel up or down as desired.

• Release the lever to lock the steering wheel into position.

ADJUSTABLE PEDALS

• Press the switch located on the left side of the steering column forward to move the brake and accelerator pedals away from the driver and press the switch rearward to move the pedals closer to the driver.

NOTE:

• The pedals cannot be adjusted when the vehicle is in REVERSE or when the Electronic Speed Control is set.

CAUTION!

Do not place any article under the adjustable pedals or impede its ability to move, as it may cause damage to the pedal controls. Pedal travel may become limited if movement is stopped by an obstruction in the adjustable pedal's path.

WARNING!

• Tilting the steering column while the vehicle is moving is dangerous. Without a stable steering column, you could lose control of the vehicle and have a collision. Adjust the column only while the vehicle is stopped. Be sure it is locked before driving.

• Do not adjust the pedals while the vehicle is moving. You could lose control and have a collision. Always adjust the pedals while the vehicle is parked.

OPERATING YOUR VEHICLE

ENGINE BREAK-IN RECOMMENDATIONS

• A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle.

• Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.

• While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in. Wide-open throttle acceleration in low gear can be detrimental and should be avoided.

• The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. For the recommended viscosity and quality grades, refer to “Maintaining Your Vehicle”.

NOTE:

A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as an indication of difficulty.

CAUTION!

Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result.

OPERATING YOUR VEHICLE

TURN SIGNALS/WIPER/WASHER/HIGH BEAMS LEVER

Turn Signals/Lane Change Assist

• Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off.

Wipers

Intermittent, Low And High Operation

• Rotate the end of the lever to the first detent position for one of five intermittent settings, the second detent for low wiper operation and the third detent for high wiper operation.

Washer Operation

• Push the end of the lever inward to the second detent and hold for as long as spray is desired.

Mist Feature

• When a single wipe to clear off road mist or spray from a passing vehicle is needed, push the washer knob, located on the end of the multifunction lever, inward to the first detent and release. The wipers will cycle one time and automatically shut off.

High Beams

• Push the lever away from you to activate the high beams.

• A high beam symbol will illuminate in the cluster to indicate the high beams are on.

NOTE:

For safe driving, turn off the high beams when oncoming traffic is present to prevent headlight glare and as a courtesy to other motorists.

OPERATING YOUR VEHICLE

HEADLIGHT SWITCH

Automatic Headlights/Parking Lights/Headlights

• Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent

for parking lights and to the

second detent for headlights

• With the parking lights or low beam headlights on, push the headlight switch once for fog lights.

• Rotate the headlight switch to “AUTO” for AUTO headlights.

• When set to AUTO, the system automatically turns the headlights on or off based on ambient light levels.

SmartBeams™

• This system automatically controls the use of the headlight high beams. Refer to Programmable Features in Electronics for further details.

Instrument Panel Dimmer

• Rotate the dimmer control to the extreme left position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened.

• Rotate the dimmer control right to increase the brightness of the instrument panel when the parking lights or headlights are on.

• Rotate the dimmer control right to the next detent position to fully brighten the odometer and radio when the parking lights or headlights are on. Refer to your Media Center/Radio User Manual on the DVD for display dimming.

• Rotate the dimmer control right to the last detent position to turn on the interior lighting.

Cargo Light

• The cargo light is strategically placed lighting that helps illuminate the bed area of the truck. A cargo light symbol will illuminate in the cluster to indicate the light is on.

• Push the button to turn ON/OFF the cargo lighting.

OPERATING YOUR VEHICLE

SPEED CONTROL

• The speed control switches are located on the steering wheel.

Cruise ON/OFF

• Push the ON/OFF switch to activate the Speed Control.

• The cruise symbol Control is on.

• Push the ON/OFF switch a second time to turn the system off.

Set

• With the Speed Control on, push and release the SET switch to set a desired speed.

Accel/Decel

Push and hold the RESUME/ACCEL switch to accelerate or push and hold the DECEL

• switch to decelerate the vehicle; release the switch to save the new set speed.

• Once a speed is set, pushing the RESUME/ACCEL switch once or the DECEL switch once will increase or decrease the set speed approximately 1 mph (2 km/h).

Resume

• To resume a previously selected set speed in memory, push the RESUME/ACCEL switch and release.

will appear on the instrument cluster to indicate the Speed

+ 134 hidden pages

Dodge 1500, 2500, 3500, 2013 RAM 1500, 2013 RAM 2500 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
